PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
CAUTION
To reduce risk of fire and to properly exhaust air, duct air to the outdoors
only (not into walls, attics, crawlspaces, or garages).
WARNING
During duct installation, ensure the damper flaps on top of the hood can
open freely.
• Local building may codes require makeup air systems for use with
ventilation systems that move air at greater than the specified
rate (CFM). In designing the system, consult an HVAC specialist
for local requirements and to ensure best performance.
• All ductwork material (incl. screws and foil tape) shall be bought
by the customer.
• Ductwork must not interfere with floor joists or wall studs.
• On dual-exhaust models, the two 8” exhausts may be merged
into one 10” duct using the optional Dacor transition kit AHT10
(Contact Dacor Customer Assurance for details: 833-353-5483).
• Fasten all joints with sheet-metal screws, and seal with certified
duct/foil tape.
• Usually, the blower vents through the hood top (A) but can be
rotated to vent through the hood rear (B). When planning ducting,
always find the shortest, most direct route to the outside.
Duct-Length Calculation Table
The ducting determines the hood’s maximum straight duct length.
Duct Type Max. Duct Run
8" Round 60 feet
10" Round
50 feet
3 ¼" x 10" Rectangular
For each new elbow and transition, you must subtract “equivalent
lengths” from your total maximum duct run length to compensate
for wind resistance.
To determine your maximum length, start with the duct run’s total
max. length, then subtract all of the ductwork equivalent lengths.
Modernist 30”, 36", 48" Wide
Wall Hood
Page 3 of 3
All tolerances: ±¹/₁₆” (±1.6 mm) unless otherwise stated.
DHDxx
Planning the Ductwork, cont.
A B
Ductwork Equivalent Lengths
Piece Subtract
8” 90° Elbow 7 feet
8” 45° Elbow 3 feet
10” 90° Elbow 5 feet
10” 45° Elbow 2 feet
3” x 10” to Round 90° Transition 25 feet
3 1/4” x 10” to 8”/10” Round Transition 4 feet
Wall Cap w/Damper
*
Roof Cap
*Equivalent lengths of roof and wall caps vary with model and configuration.
Ductwork Tips
• Minimize transitions/turns/sharp angles (ex: two staggered 45°
angles are better than one 90° angle).
• Keep turns as far from the hood exhaust as possible; keep as
much space between bends as possible.
• For best performance, use round ducting, especially for elbows.
• Try to keep at least 24 in. of straight duct between each elbow.
• Avoid using “S” or back-to-back adjacent elbows.
• In extremely cold-weather regions, use thermal breaks (i.e., short
sections of non-metallic duct) to avoid indoor heat loss. Put the
break as close to the outside pass-through point as possible.
• Do not use flexible metal ducting, or ductwork smaller than what
the tables advise.
• The hood exhaust connects to an 8” round duct. You can increase
the duct size over the duct run if desired.
• To prevent backdraft, never decrease the duct size over the run.
If existing ductwork is less than 8 inches in diameter, replace it
with 8” ductwork.
• Join ducting with sheet-metal screws, then seal with certified
duct/foil tape. Never join ducting with tape only.
• Support the weight of the ducting with sheet-metal screws as
needed.
• To avoid backdraft, a damper at the duct outlet may be required.
WARNING
• Have electricity to the range hood installed by a licensed electrician.
• Observe all local codes during site preparation and installation.
Contact your local building department for details.
• Follow wall anchoring directions precisely to ensure the hood does
not fall.
• To avoid electric-shock injury and water damage, know in-wall
utilities locations before breaching the wall.
• Remove temporary holding brackets after anchoring the hood
permanently.
