1 General information
Receiving goods
Remove the packaging and verify the corrispon-
dence to the order and the integrity of the content.
In case of damaged package, immediately note it on
the delivery paper the courier will ask you to sign as
receipt, without the note, no refund from insurance
or replacement will be accepted. In case of evident
damage, you can also refuse the delivery, always with
written notication on the courier documents.
Damages occured after unpacking the goods, must
be notied within 8 days (D.D.T) with written
comunication to the courier and considering them
responsible for any possible consequence.
Test
Test and calibration are done at Dado Lab’s facility,
at the end of it, a report is produced and includ-
ing results and acceptability verication for all the
executed tests.
To request a test at your place, please contact your
local dealer.
Warranty Conditions
Warranty cover the instrument for 12 months from
the delivery/test of the goods.
Disposable/rechargeable batteries have a warranty
of 6 months.
Consumable materials, like components which have
to be replaced periodically during the lifetime of the
instrument (protection lters, fuses or lamps) are
not covered by the warranty.
Warranty Exclusions / Limitation
Dado Lab cannot be considered responsible for any
damage or aws caused by external factors, acci-
dental damages, unproper uses, modication on any
part, transformation, use of non original parts, negli-
gency or lost of the instrument during the delivery
of the instrument.
e warranty will not cover any repair or job which
is not done by Dado Lab or authorized dealer. e
responsability is, in any case, limited to the value of
the purchased instrument.
In case of malfunctioning, please contact:
[e-mail]

2| QB1 User Manual
Conformity
Safety and CE mark
Dado Lab declares the instrument is in compliance
with the following standard:
Low voltage instruments directive BT 2014/35/UE
Directive 2011/65/UE ROHS - Restriction of
Hazardous Substances Directive
Directive EMC 2014/30/UE for the electro-mag-
netic compatibility (EMC)
Machinery Directive 2006/42/EC
Sampling Methods
Dado Lab declares that the instrument is compli-
ant to the following standards and methods for the
sampling.
Workplace atmospheres
UNI EN ISO 13137:2015
Pumps for the sampling of chemical agents with a
volume ow rate of over 5 l/min. Requirements and
test methods
Stack Emission
UNI EN 13284-1:2017
Stationary source emissions – Determination of low
range mass concentration of dust – Part 1: Manual
gravimetric method.
UNI EN 1911
Stationary source emissions - Determination of
mass concentration of gaseous chlorides expressed
as HCl - Standard reference method
UNI EN 14385
Stationary source emissions – Determination of the
total emission of As, Cd, Cr, Co, Cu, Mn, Ni, Pb,
Sb, Tl and V
UNI EN 13211
Stationary source emissions. Manual method of
determination of the concentration of total mercury
CEN/TS 13649:2014
Stationary source emissions. Determination of the
mass concentration of individual gaseous organic
compounds. Activated carbon and solvent desorp-
tion method.
Environment
UNI EN ISO 16000-7
Indoor air - Part 7: Sampling strategy for determi-
nation of airborne asbestos bre concentrations.

ENGLISH | 3
Safety rules
To safely operates the instrument, carefully follow
those indications.
1. Do not remove, for any reasons the enclosure
panels, without having turned o the instru-
ment and disconnected the power supply cable.
2. Always connect the instrument to a power
socket equipped with operational and ecient
grounding.
3. Do not operate the QB1 outdoor without hav-
ing provided protection from weather events
(rain, humidity etc).
4. Before starting any operation, nd a at and
stable accomodation for the QB1 with an ad-
equate sorrounding space for ventilation.
5. Operating temperature -10÷40°C
6. Max sampled gas temperature 45°C
7. Avoid contact and sampling of corrosive and
ammable compounds.
Precautions for humidity
Condense formation inside the sampler, reduces
the lifetime of some components, such as the pump
itself and dry gas meter as well.
Be sure the gases entering the QB1 are dry.
In case of presence of very wet/condensing gases
during the sampling, at the end of the operation,
allow the sampler to work with open air for at least
10 minutes.
The supply includes
QB1 is supplied with the following items:
♦QB1 sampler
♦Power cable
♦Sampling line quick connector
♦Hose barb for leak check
♦Operation quick guide

4| QB1 User Manual
6. Low ow regulation knob, range 0.2 ÷ 3.0 Nl/
min
7. High ow regulation knob, range 2 ÷ 32 Nl/min
8. Sampled gas exhaust, equipped with 1/8” gas
threaded connector
9. Protection fuse box, type 5x20 T1.6A
10. Power switch
2 Parts identication
Connections panel QB1 V1.5 -
V3.0
1. Vacuum meter indicating the line pressure drop
with range 0 ÷ 1 Bar
2. Ball owmeter, with indication scale in Nl/min
(@ 20°C e 101.3 kPa)
3. Water trap inspection window
4. Dust protection lter cap
5. Sampling line quick connector

ENGLISH | 5
Connections panel QB1 V5.0
1. Vacuum meter indicating the line pressure drop
with range 0 ÷ 1 Bar
2. Ball owmeter, with indication scale in Nl/min
(@ 20°C e 101.3 kPa)
3. Water trap inspection window
4. Sampling line quick connector
5. Flow regulation knob, range 2 ÷ 32 Nl/min
6. Flow regulation knob, range 2 ÷ 32 Nl/min
7. Sampled gas exhaust, equipped with 1/8” gas
threaded connector
8. Bypass valve (see chapter “6 Leak test - QB1
V5.0” on page 14)
9. Protection fuse box, type 5x20 T3.15A
10. Power switch

6| QB1 User Manual
Connections panel QB1 V1.5DC
1. Vacuum meter indicating the line pressure drop
with range 0 ÷ 1 Bar
2. Ball owmeter, with indication scale in Nl/min
(@ 20°C e 101.3 kPa)
3. Water trap inspection window
4. Sampling line quick connector
5. Flow regulation knob, range 0.2 ÷ 3 Nl/min
6. Flow regulation knob, range 2 ÷ 32 Nl/min
7. Sampled gas exhaust, equipped with 1/8” gas
threaded connector
8. External battery connector
9. Protection fuse box, type 5x20 T1.6A
10. Power switch

ENGLISH | 7
Connections panel QB1
V2x5DC
1. Protection fuse box, type 5x20 T1.6A
2. Power switch
3. Vacuum meter indicating the LINE 1 pressure
drop with range 0 ÷ 1 Bar
4. Vacuum meter indicating the LINE 2 pressure
drop with range 0 ÷ 1 Bar
5. Sampling LINE 1 quick connector
6. Sampling LINE 2 quick connector
7. Sampled gas exhaust, equipped with 1/8” gas
threaded connector LINE 1
8. Sampled gas exhaust, equipped with 1/8” gas
threaded connector LINE 2
9. LINE 1 Flow regulation knob, range 0.2 ÷ 5.0
Nl/min
10. LINE 2 Flow regulation knob, range 0.2 ÷ 5.0
Nl/min
11. LINE 1 Ball owmeter, with indication scale in
Nl/min (@ 20°C e 101.3 kPa)
12. LINE 2 Ball owmeter, with indication scale in
Nl/min (@ 20°C e 101.3 kPa)

8| QB1 User Manual
Controls panel QB1 V1.5 - V3.0
- V5.0
1. Polycarbonate protection cover
2. Turn-on timer programmer
3. Temperature of the sampled gas
4. Dry Gas Meter, with 0.1 liters resolution

ENGLISH | 9
Controls panel QB1 V1.5DC
1. Polycarbonate protection cover
2. Turn-on timer programmer
3. Battery power switch
4. Dry Gas Meter, with 0.1 liters resolution
5. Reset button after battery recharge
When the battery is low, the electronic discon-
nect it to avoid damages. Once disconnected, in
order to restore the battery operation, perform a
complete charge cycle and press the reset button
6. Battery status led:
Green = charged battery
Yellow = battery about to die
Red = low battery
7. Temperature of the sampled gas

10 | QB1 User Manual
Controls panel QB1 V2x5DC
QB1-D
1. Polycarbonate protection cover
2. LINE 1 Dry Gas Meter, with 0.1 liters resolu-
tion
3. Temperature of the sampled gas on LINE 1
4. LINE 1 Turn-on timer programmer
5. Battery power switch
6. LINE 2 Dry Gas Meter, with 0.1 liters resolu-
tion
7. Reset button after battery recharge
When the battery is low, the electronic discon-
nect it to avoid damages. Once disconnected, in
order to restore the battery operation, perform a
complete charge cycle and press the reset button
8. Battery status led:
Green = charged battery
Yellow = battery about to die
Red = low battery
9. LINE 2 Turn-on timer programmer
10. Temperature of the sampled gas on LINE 2

AUTO
MO

MANUA L
M+
D+
H+
P
C
ENGLISH | 11
Pump manual ON / OFF
Pressing the MANUAL Pressing the MANUAL key
you can force the start of the pump.
is key is active also during a time based program.
At every press, the display will shows (in sequence):
AUTO Automatic execution of the set program
OFF Pump OFF
ON Pump ON
How to program timed sam-
pling
You can program up to six turn on and o within
the same day. To set up a time turn on proceed as
follow:
Press the display will show
Press D+ to select the day of the week (15 dierent
combinations available)
e press H+ for the hour and M+ for the minutes
of the rst turn on.
Press the display will show
As for the turn on, select the day with D+, hour
with H+ and minutes M+. Press <P> to conrm
If you want to add new timed turn on, proceed with
the second ON
Press to activate the program..
Date and Time
Press the“C”key to reset the actual program before
starting
Hold and press:
D+ to set day of the week
H+ to set hour
M+ to set minutes
e instrument is equipped with a Lithium battery
to backup date and time information, this also allow
the automatic restart after power failure.
e Lithium battery recharges when the instrument
is connected to power supply and switched on [ I ].
3 Timer setup

12 | QB1 User Manual
e thermometer shows the sampled gas condition
measured inside the dry gas meter.
e temperature is expressed in °C and it’s used to
normalize the volume considering the mean value
between the sampling starting and nal temperature
value.
4 Thermometer

ENGLISH | 13
Readings and normalization
of the volumes
e totalizer of the installed dry gas meter has a
resolution of 0.1 liters.
Before starting the sampling, take note of the vol-
ume and temperature values.
At the end of the operation, read again the volume
indicated and note it, with temperature value as
well.
Normalization of the volume can be done using the
following formula:
Vs = Vm . Pa . Tn
101.3 273 + Tgm
Where:
Vs [lt] = Normalized volume
Vm [lt] = Dry gas meter total volume
Pa [kPa] = Ambient pressure
Tn [K] = Normalization temperature
Tgm [°C]= Dry gas meter temperature
5 Dry Gas Meter

14 | QB1 User Manual
Check the leak
Slowly let air enter the samplping line
Turn o the pump
Close the bypass valve
Sampling line leak check
QB1 V5.0 is equipped with a bypass valve that al-
lows to perform the leak check of the sampling line
as per regulations.
Leak check
Connect the sampling line
Turn on the pump
Close the sampling line
Open the bypass valve and adjust the vacuum to
about 0.5bar
6 Leak check - QB1 V5.0
bypass valve

ENGLISH | 15
Flowrates denition
e sampling owrates depends on tubes used:
0.4 l/min - large tubes (600 mg)
1.0 l/min - jumbo tubes (1000 mg)
Set the owrate on LINE1 owmeter
Calculate dilution owrate
e owrate depends from humidity of duct fumes,
the ambient temperature and must avoid reaching
the condensation point in the sampled gas.
e graph on page 17 shows the dilution owrate
to set on QB1-D sampler.
1. FindtheRDvalue(dilutionratio)ndingonXaxis
the rw of duct gas (ratio by volume of the vapor
content e.g. 10% of vapor equals 0.1 of rw).
2. Findthecorrespondingcurveonambienttempera-
ture and read on Y axis the RD value.
3. Multipling RD value with sampling owrate
chosen, you nd the dilution owrate to use
Dilution sampler
QB1-D is a special version of the QB1 V2x5DC in
which the owrate of the secondary pump delivers
the dilution air instead of sampling.
is particular version is dedicated to VOCs
sampling in accordance with the EN13649 which
requires the dilution of the sample with, previously
cleaned and dehydrated, ambient air introduced in
the dilution chamber of the probe (HP1).
e dilution sampling oers the advantage of im-
proving the adsorbing eect on the sampling tube
thanks to the lower temperature and dehydrated gas
stream conditions.is allows also to use only one
charcoal tube and to greatly reduce the stripping
eect, usually due to high temperatures and water
presence.
To set the dilution rate, e.g. 1:4, regulate the total
sampling owrate, 1 lt/min for instance, and the
dilution owrate, 0.8 lt/min, the dierence of the
two values, 0.2 lt/min will be the resulting sampling
owrate.
e sampled volume will be given by the dierence
between the total sampled and the dilution volumes.
7 QB1-D
