Daewoo electricals COL1066 User manual

1
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating instructions
before using this Tower Fan.
•Before plugging your unit into the mains, visually check that the
unit is intact and has not suffered any transit damage.
•Do not use this product with a programmer, timer, separate
remote-control system or any other device.
•Check that the voltage indicated on the data plate corresponds
with that of the local network before connecting the appliance
to the mains power supply.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
•Close supervision is required when using this appliance near
children.
•Never leave this appliance within reach of children.
•Children of less than 3 years should be kept away unless
continuously supervised.
•Do not immerse the appliance or its cord in water or any other

3
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
liquids.
•Do not leave the appliance unattended during use.
•Do not leave the appliance unattended whilst connected to the
mains supply.
•Always use this appliance on a solid, level, surface.
•Do not use this appliance outdoors.
•It is imperative to unplug the power cord after the appliance has
been used, before it is cleaned and whilst being repaired.
•Repairs to electrical appliances should only be performed by a
qualified electrician. Improper repairs may place user at serious
risk.
•Do not operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
•Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any signs
of damage the appliance should not be used.
•If the power cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in order
to avoid a hazard.
•Do not allow the mains cable to hang over sharp edges or come
in contact with hot surfaces.
•Do not run the mains cable under carpets, rugs, etc.
•This appliance is intended for household use only and should
not be used for industrial purposes.
•Do not use any accessories or attachments with this appliance
other than those supplied or recommended by the supplier.
•Do not use this appliance for anything other than its intended
use.
•Do not push objects (including fingers) into the fan grill or any
openings as this could risk injury, damage to the appliance
and/or electric shock.
•Unplug after each use. Grasp the plug, not the cord.

4
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or Visit www.recycle-more.co.uk, click
on “bank locator” and enter your postcode to find out your nearest
recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating
current mains supply.

5
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1.Timer
2.Speed Control Buttons
3.Oscillate Button
Description of Controls
Assembling Your 30 Inch Tower Fan
Whilst assembling your tower fan, place a cloth or similar underneath it to
prevent damage to the outer casing.
1Place the rear
section of the stand
onto the base of the
tower fan.
3
1
2
Attach the stand
onto the base of the
tower fan by
threading the screws
through the stand
assembly and into
the base of the
tower fan.
Mains Cable
Mains Cord Clamp
Base of Tower Fan
2 Lower the front half of
the stand on top of the rear
half of the stand such that
the two latch together.
Ensure that the mains cable
is fed through the hole in
the centre of the stand.
3

6
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Operating Instructions
Manual Control
•Place the fan into the desired position ensuring that it is on a solid, even surface
and vertical.
•Insert the mains plug into the nearest socket, press the Speed Control Buttons
(2) as follows: Button 1 for low speed, 2 for medium speed and 3 for high speed.
Press the ‘0’ button to switch the fan off.
For normal manual operation, the Timer (1) must be in the ‘ON’ position on
the dial.
Oscillation mode
•Press the Oscillate Button (3) to enable the fan to oscillate from side to side to
disperse air over a larger area. Press the button again to stop the oscillation
mode.
Using the timer
•Rotate the Timer (1) to the desired number of minutes that the fan is required
to be on for. Once the timer control has returned to the ‘OFF’ position on the
dial, the fan will switch off.
For normal manual operation, the Timer (1) must be in the ‘ON’ position on
the dial.
Care and Use of your Fan
•Ensure that the fan is not connected to the mains supply before cleaning.
•Wipe the fan body clean with a clean, soft damp cloth.
•Do not immerse the fan or its cord in water or any other liquid.
Once the base is
attached, thread the
mains cable through the
inner cord guides and
under the cord grip and
tighten the two cord
grip screws.
4
Finally push the
four feet into the
holes in the base of
legs.
5

7
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug fitted to the mains lead and
should the fuse need replacing, you must use an ASTA approved one (conforming
to BS 1362 of the same rating). If in doubt, consult a qualified electrician who will
be pleased to do this for you. If you need to remove the plug –DISCONNECT
FROM THE MAINS –and then cut it off the mains lead and immediately dispose of
it safely. Never attempt to reuse the plug or insert it into a socket outlet as there is
a danger of electric shock.
Technical Data
Model Number
COL1066
Rated Voltage
220 –240V AC ~ 50Hz
Rated Power
50W
Protection Class
II
Disposal of the packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service
Disposal of the product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or Visit www.recycle-more.co.uk, click
on “bank locator” and enter your postcode to find out your nearest
recycling site.

8
30 Inch Tower Fan
Model: COL1066
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must becorrectly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
