Daewoo COL1573 User manual

1
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Air purifier.
•Before using your unit into the mains, visually check that
the unit is intact and has not suffered any transit damage.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
•Always use this appliance on a solid, level, non-flammable
surface.
•The Air purifier shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
•DO NOT immerse the Air purifier or its power cord in
water or any other liquids.
•DO NOT leave the Air purifier unattended during use.
•DO NOT leave the Air purifier unattended whilst
connected to a mains power supply.
•Avoid touching any moving parts within the appliance.
•Never insert fingers, pencils or any other objects through
the guard.
•DO NOT push objects into any openings as damage to the

3
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
product and/or electric shock may occur.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•Children of less than 3 years should be kept away unless
continuously supervised.
•Close supervision is required when using this Air purifier
near children.
•Never leave this Air purifier within reach of children.
•It is imperative to unplug from mains supply after the Air
purifier has been used, before it is cleaned and whilst
being repaired.
•Unplug after each use.
•DO NOT operate this appliance if the power cord or plug
are damaged. Ensure that the power cord is not stretched
or exposed to sharp objects or edges.
•DO NOT operate this appliance after a malfunction or
after being dropped or damaged in any way.
•DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
•DO NOT run the mains cable under carpets, rugs, etc.
•This product is intended for household use only and
should not be used for industrial purposes.
•Never connect the appliance to an electrical outlet using
an extension lead. If an outlet is not available, one should
be installed by a qualified electrician.
•Never use the mains plug or external timer as a means of
switching the Air purifier on or off. Use the ON/OFF
button located on the control panel.
•Always place the unit on a dry and stable surface.

4
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•The appliance should not be placed in a laundry or wet
room.
•DO NOT position the Air purifier close to sources of heat
and/or ignition such as radiators, heaters, other electronic
equipment, etc.
•No naked flame sources, such as lighted candles, should
be placed on the Air purifier.
•The appliance must be stored in such a way as to prevent
mechanical failure.
•DO NOT use any accessories or attachments with this
product other than those supplied or recommended by
supplier.
•DO NOT use this product for anything other than its
intended use.

5
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This Class 2 symbol indicates that the product is electrically double
insulated and does not require an earth connection.
This symbol provides useful additional information on the use
of this product.
This symbol identifies that the supply uses an alternating current
mains supply.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice or visit www.recycle-more.co.uk enter your postcode to find
out your nearest recycling site.

6
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Description of Parts –Control Panel
4
6. UV Indicator
7. Fan Speed Indicator
8. Fan Speed Button
9. Air Purifier Button
1
2
3
1. Fan
2. Air Purifier Fan
3. Control Panel
4. Adaptor Inlet (base)
5. Base
6
7
8
9
5
5

7
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the First Use of Your Air purifier
•Remove all packing materials and discard responsibly.
•Ensure all parts are present (if applicable) see Description of Parts above.
•Make sure the appliance is unplugged before removing or installing the filter.
•Wipe the dust off the filter regularly, do not wash.
•Use the filter specially designed for this product only.
•Ensure the packaging is removed from the filter before first use –see below:
Installing the Filter
1. Turn the unit upside down and rotate the Base (5) anticlockwise in the
direction of unlock icon ( ) and remove.
2. Remove the Filter from the appliance.
3. Remove the packaging from around the Filter
before use and discard responsibly.
4. Replace the Filter into the unit, make sure
it is all the way in.

8
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Put the Base (5) back on, such that the arrow on the base lines up with the
unlock icon ( ) on the lower edge then rotate clockwise in the direction of
locked icon ( ) to lock the Base (5) back on.
Using your Air purifier
Before use, please ensure that the unit is placed on a firm, level surface in an area
with at least 30cm of free space on all sides to allow for proper air circulation.
1. Insert the Adaptor plug into the nearest socket.
2. Connect the other end to the Adaptor Inlet (4).
3. The appliance will beep once and the Fan Speed
Indicator 1 (7) flashes to confirm power up in
standby mode.
Note: The appliance will beep once for every action.
Adjust the Fan angle up to 90°C as shown below:

9
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Fan Speed Button (8)
1.Press the Fan Speed Button (8) to power up the unit, it will beep once, then the
Fan Speed 1 Indicator (7) will light.
2.Press the Fan Speed Button (8) to adjust the fan speed, select from 1 Low, 2
Medium or 3 High speed.
For Low speed, the Fan Speed Indicator 1 will light.
For Medium speed, the Fan Speed Indicators 1 and 2 will light.
For High speed, all Fan Speed Indicators 1, 2 and 3 will light.
3.To switch the unit off, press the Fan Speed Button (8) to step through the fan
speeds until the unit switches off, or alternatively, hold the button down for 2
seconds.
Air Purifier Button (9)
1.Press the Air Purifier Button (9) to turn on the Air Purifier Fan (2) and the UV
lamp inside and the the UV Indicator (6) will light to sterilise the filter.
2.Press the Air Purifier Button (9) again to turn the Air Purifier mode off.
Replacing the Filter
•It is recommended to replace the HEPA filter every 3 months. It may vary
depends on the air quality and usage time.
•Before replacing the filter, make sure the appliance is turned off and
unplugged. Replace the filter by following Installing Filter section.
Filter Information
Replacement filters are available by telephoning 0161 831 5248 (9.00am-5.00pm
Monday-Thursday, 8.00am –4.00pm Friday) or contacting us via the website:
www.esgltd.com
Cleaning and Maintenance
•Always disconnect the Air Purifier from the mains supply before cleaning.
•Do not immerse the appliance into water or any liquid.
•Do not use abrasive, corrosive, or flammable cleaners such as bleach or
alcohol, to clean any part of the appliance.
•Do not use a vacuum cleaner to clean the filter or wash it.
•The filter can be sterilized by placing in sunlight.
•If you do not intend to use the Air Purifier for a long time, store the appliance
in a cool and dry environment.

10
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Model Number
COL1573
Rated Voltage
100-240V~ 50-60Hz
Power
6W
Protection Class
II
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-
cycling facilities.
Dispose of plastics in the appropriate plastics collection service.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site

11
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

12
2 in 1 Personal Air Purifier
Model No. COL1573
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
