Daewoo ACP-5280 RDS User manual

DAEWOO CAR STEREO SERVICE GUIDE
SCAN
TA/RDS
MUTE
SD
CARD
Service Guide
Service Guide
CAR AUDIO
AGC 5280 RDS : USB / SD / MP3 / CD Player with Radio
AGC 5200 RDS : MP3 CD Player with Radio
AGC-5200 / ACP-5200 RDS
AGC-5220 / ACP-5220 RDS
AGC-5240 / ACP-5240 RDS
AGC-5260 / ACP-5260 RDS
AGC-5280 / ACP-5280 RDS

1. PRODUCT SPECIFICATION 1
2. APPEARANCE & CONNECTION 2
3. FRONT PANNEL INFOMATION 8
4. STANDARD TEST REPORT 13
5. ELECTRICAL SPECIFICATION 15
6 TROUBLE SHOOTING GUIDE 19
7. FUNCTION OF MICOM IC 20
8. IC BLOCK DIAGRAM 23
9. PARTS LOCATION ON P.C.BOARD 26
10. BLOCK & SCHEMATIC DIAGRAM 37
11. ELECTRICAL PARTS LIST 41
12. OVERALL EXPLODED VIEW 57
Contents

1
1. PRODUCT SPECIFICATION
SPECIFICATION
GENERAL
POWER : NEGATIVE GROUND
: 14.4V DC
SPEAKER IMPEADANCE : 4-8 OHM(4 SPEAKER)
OUTPUT POWER (4 ohm/CH) : 40W 4 ch Maximum
Size : 7” (W) x 2” (H) x 6-1/2” (D)
: 178 mm x 50 mm x 160 mm
Fuse Ratings : Constant (Yellow wire) : 10AMP.
Switched (Red wire) : 1.0 AMP.
Output Wiring : Floating - ground type designed for 4 speaker use.
: RCA low-level outputs.
Low - Level Output : 500mV
RADIO SECTION
TUNING RANGE -FM : 87.5-108.0 MHz (50 kHz step)
-MW : 522-1620kHz (9 kHz step)
-LW : 144 - 288 MHz
SENSITIVITY -FM : 5dBu S/N : 30dB
-MW : 20dBu S/N : 20dB
S/N RATIO -FM : 80dB
-MW : 50dB
STEREO SEPERATION -FM : 30dB
CD / MP3 CD / USB / SD CARD SECTION
DISC : COMPACT DISC(12cm Std. DISC)
ROTATION RPM : 1.2m/S~1.4m/S(500rpm~200rpm)
FREQUENCY RESPONSE : 20Hz~20kHz
TOTAL HARMONIC DISTORTION : 0.1%
DYNAMIC RANGE : 60dB
S/N RATIO : 60dB
CHANNEL SEPERATION : 50dB

2. APPEARANCE & CONNECTION
2
AGC-5200 / ACP 5200 + RDS (option)
FRONT PANNEL
ESC.
CD / CD-R / RW Playble
DSP (Pop / Classic / Rock)
ESP (Electric Shock Protection)
Face Flip Down and Full Detachable for Anti-Theft
4-Channel High Power Output (40W 4Ch)
Encoding Volume Control
Electronic Bass / Treble / Balance / Fader Control
42 Station Memory Capability (18FM+12MW+12LW)
Seek / Auto Memory
Mute / Tel. Mute
Aux-In
9
Disc Eject
Theft Deterrent LEDBall Mechanism
(Left Side)
Disc Slot
Ball Mechanism
(Right Side)

3
AGC-5220 / ACP 5220 + RDS (option)
FRONT PANNEL
ESC.
APPEARANCE & CONNECTION
CD / CD-R / RW Playble
DSP (Pop / Classic / Rock)
ESP (Electric Shock Protection)
Face Full Detachable for Anti-Theft
4-Channel High Power Output (40W 4Ch)
Theft Deterrent LEDBall Mechanism
(Left Side)
Disc Slot
Ball Mechanism
(Right Side)
Encoding Volume Control
Electronic Bass / Treble / Balance / Fader Control
42 Station Memory Capability (18FM+12MW+12LW)
Seek / Auto Memory
Mute / Tel. Mute
Aux-In

AGC-5240 / ACP 5240 + RDS (option)
SCAN
TA/RDS
PWR
SRC
MU
TE
1 TOP 2 INT 3 RPT 4 RDM 5 D-6 D+ AUTSEL
LOC
IN
FO
BAND
FRONT PANNEL
ESC.
APPEARANCE & CONNECTION
4
MP3 Playback(ID3 Tag)
CD / CD-R / RW Playable
Black Masked Multi-Color Graphic Display
DSP (Pop/Classic/Rock)
ESP (Electric Shock Protection)
Face Flip-Down and Full Detachable for Anti-Theft
9
Disc Eject
Theft Deterrent LEDBall Mechanism
(Left Side)
Disc Slot
Ball Mechanism
(Right Side)
4-Channel High Power Output(40W 4CH)
Encoding Volume Control
Electronic Bass/Treble/Balance/ Fader Control
42 Station Memory Capability (18FM +12MW +12LW)
Mute / Tel. Mute
Aux-In

AGC-5260 / ACP 5260 + RDS (option)
1 TOP 2 INT 3 RPT 4 RDM 5 D- 6 D+
TA/RDS
LOC
IN
FO
SRC
MU
TE
PWR
AUTSEL
Vol.
BAND
FRONT PANNEL
ESC.
APPEARANCE & CONNECTION
5
Theft Deterrent LEDBall Mechanism
(Left Side)
Disc Slot
Ball Mechanism
(Right Side)
MP3 Playback(ID3 Tag)
CD / CD-R / RW Playable
Black Masked Multi-Color Graphic Display
DSP (Pop/Classic/Rock)
ESP (Electric Shock Protection)
Face Flip-Down and Full Detachable for Anti-Theft
4-Channel High Power Output(40W 4CH)
Encoding Volume Control
Electronic Bass/Treble/Balance/ Fader Control
42 Station Memory Capability (18FM+12MW+12LW)
Mute / Tel. Mute
Aux-In

6
ESC.
AGC-5280 / ACP 5280 + RDS (option)
SCAN
TA/RDS
MUTE
SD
CARD
FRONT PANNEL
APPEARANCE & CONNECTION
SD Card / USB Memory
MP3 Playback(ID3 Tag)
CD / CD-R / RW Playable
Black Masked Multi-Color Graphic Display
DSP (Pop/Classic/Rock)
ESP (Electric Shock Protection)
Face Flip-Down and Full Detachable for Anti-Theft
4-Channel High Power Output(40W 4CH)
Encoding Volume Control
Electronic Bass/Treble/Balance/ Fader Control
42 Station Memory Capability (18FM+12MW+12LW)
Mute / Tel. Mute
Aux-In
Theft Deterrent LEDBall Mechanism
(Left Side)
Disc Slot
Ball Mechanism
(Right Side)
Disc Eject

7
CONNECTION
Connection
AGC-5200,5220,5240,5260,5280 ACP-5200,5220,5240,5260,5280
A. ELECTRIC CONNECTIONS
1. T.MUTE : BROWN
4. Back-up +12V : YELLOW
5. +12V (Automatic antenna) : BLUE
6. Dimmer : PINK
7. +12V supply (from ignition Lock) : RED
8. Ground : BLACK
Aux-In
16 Pin ISO Connector
B. SPEAKER CONNECTIONS
1. Right Rear (+) : VIOLET
2. Right Rear (
- ): VIOLET/BLACK
3. Right Front (+) : GRAY
4. Right Front (
- ):GRAY/BLACK
5. Left Front (+) : WHITE
6. Left Front (
- ):WHITE/BLACK
7. Left Rear (+) : GREEN
8. Left Rear (
- ): GREEN/BLACK
C. FUSE : 10A
D. Aux-In (RCA Cord)
AUX IN / RCA JACK
NOTE! The red cable must be connected via the car’s ignition lock to prevent
unwanted discharge of the battery if it is not used for longer periods of time.

3. FRONT PANNEL INFOMATION
8
FRONT PANNEL
AGC-5200 / ACP 5200 + RDS (option)
Source Selector(Radio, AUX, CD)
Tune/Seek Button
(Disc Track Up/Down Button,
(Cue/Review Function Button)
Audio (Volume) Control
Push Select Control Button
(Bass, Treble ,( Loudness),
DSP, Balance, Fader)
Folder Down Button (#5)
Folder Up Button (#6)
Auto Store Tuning
Audio Mute Selector
Information Display
(Time, Freguency, PTY)
Power ON/OFF Button
Station Preset Memory Buttons
Track One Position (TOP)
Track Introduction Scan (INT)
Repeat Play (RPT)
Random Play (RDM)
LOCAL Button
Front Panel Release Button
AM/FM Band Selector
TA / RDS Control Button
Scan Button
FM Stereo
Audio Mode
Radio Frequency & Number of Preset Station
Disc Number & Track Number
MP3 File Name & Folder Name
Volume Level
Disc Play
LOCAL Tuning
Loudness
AUT Band
Repeat Play
Random Play
Intro Scan
CDC

9
FRONT PANNEL
AGC-5220 / ACP 5220 + RDS (option)
FRONT PANNEL INFOMATION
Source Selector(Radio, AUX, CD)
Tune/Seek Button
(Disc Track Up/Down Button,
(Cue/Review Function Button)
Audio (Volume) Control
Push Select Control Button
(Bass, Treble ,( Loudness),
DSP, Balance, Fader)
Folder Down Button (#5)
Folder Up Button (#6)
Auto Store Tuning
Information Display
(Time, Freguency, PTY)
Front Panel Release Button
Power ON/OFF Button
Station Preset Memory Buttons
Track One Position (TOP)
Track Introduction Scan (INT)
Repeat Play (RPT)
Random Play (RDM)
Local Button
CD Eject Button
TA / RDS Control Button
AM/FM Band Selector
Audio Mute Selector
FM Stereo
Audio Mode
Radio Frequency & Number of Preset Station
Disc Number & Track Number
MP3 File Name & Folder Name
Volume Level
Disc Play
LOCAL Tuning
Loudness
AUT Band
Repeat Play
Random Play
Intro Scan
CDC

10
FRONT PANNEL
AGC-5240 / ACP 5240 + RDS (option)
L.C.Display
FRONT PANNEL INFOMATION
TA / RDS Control Button
Source Selector (Radio, Aux, CD)
Audio Mute Selector
Audio (Volume) Control
Power ON/OFF Button
Push Select Control Button
Bass,Treble, (Loudness),
DSP, Balance, Fader
SCAN
TA/RDS
PWR
SRC
MU
TE
1 TOP 2 INT 3 RPT 4 RDM 5 D-6 D+ AUTSEL
LOC
IN
FO
BAND
Station Preset Memory Buttons
Track One Position (TOP)
Track Introduction Scan (INT)
Repeat Play (RPT)
Random Play (RDM)
Folder Down Button
Folder Up Button
Auto Store Tuning
AM/FM Band Selector
Information Display
(Time, Frequency, PTY)
LOCAL Button
Front Panel Release Button
Station Scan Button
Tune/Seek Button
(Disc Track Up/Down Button)
(MP3 File Up/Down Button)
(Cue/Review Function Button)
FM Mono/ST Operation
Volume/Audio Level Meter
FM Stereo
Audio Mode
Radio Frequency & Number of Preset Station
Disc Number & Track Number
MP3 File Name & Folder Name
Volume Level
Disc Play
LOCAL Tuning
Loudness
AUT Band
Repeat Play
Random Play
Intro Scan
CDC

11
FRONT PANNEL
AGC-5260 / ACP 5260 + RDS (option)
L.C.Display
FRONT PANNEL INFOMATION
TA / RDS Control Button
Source Selector (Radio, Aux, CD)
Audio Mute Selector
Audio (Volume) Control
Power ON/OFF Button
Push Select Control Button
Bass,Treble, (Loudness),
DSP, Balance, Fader
1 TOP 2 INT 3 RPT 4 RDM 5 D- 6 D+
TA/RDS
LOC
IN
FO
SRC
MU
TE
PWR
AUTSEL
Vol.
BAND
Station Preset Memory Buttons
Track One Position (TOP)
Track Introduction Scan (INT)
Repeat Play (RPT)
Random Play (RDM)
Folder Down Button
Folder Up Button
Auto Store Tuning
Station Scan Button
Information Display
(Time, Frequency, PTY)
Front Panel Release Button
LOCAL Button
CD Eject Button
Tune/Seek Button
(Disc Track Up/Down Button)
(MP3 File Up/Down Button)
(Cue/Review Function Button)
FM Stereo
Audio Mode
Radio Frequency & Number of Preset Station
Disc Number & Track Number
MP3 File Name & Folder Name
Volume Level
Disc Play
LOCAL Tuning
Loudness
AUT Band
Repeat Play
Random Play
Intro Scan
CDC

12
FRONT PANNEL
AGC-5280 / ACP 5280 + RDS (option)
L.C.Display
CD, MP3 CD Intro ScanFM Stereo
Single CD or CD, MP3 CD Play
CD, MP3 CD Random Play
MP3 CD Repeat Play
(1~6)
(AXR-519R)
SD
USB
Volume Level
SD Card
Audio Mode
Radio Frequency & Number of Preset Station
Disc Number & Track Number
MP3 File Name & Folder Name
LOCAL Tuning
Loudness
AUT Band
USB
CD Track
FRONT PANNEL INFOMATION
Front Panel Release Button
Tune/Seek Button
(Disc Track Up/Down Button)
(MP3 File Up/Down Button)
(Cue/Review Function Button)
Audio (Volume) Control
Power ON/OFF Button
Push Select Control Button
Bass,Treble, (Loudness),
DSP, Balance, Fader
Station Preset Memory Buttons
Track One Position (TOP)
Track Introduction Scan (INT)
Repeat Play (RPT)
SCAN
TA/RDS
MUTE
SD
CARD
Random Play (RDM)
Folder Down Button
Folder Up Button
Auto Store Tuning
Information Display
(Time, Frequency, PTY)
AM/FM Band Selector
LOCAL Button
Source Selector
(Radio, SD Card, USB, Aux, CD)
Station Scan Button
TA / RDS Control Button
Audio Mute Selector

The Condition of Standard Measurement
1-1. SCOPE
This standard specification is applied to radio receiver with MP3 Player receiver named AGC-5200/20/40/60/80 that is
designed an produced by DAEWOO ELECTRONICS CO., LTD.
1-2. PURPOSE
The purpose of this specification standardizes of specification for car audio units and increase the efficiency of business
and improves the quality of design and production.
1-3. DETAILS
1-3-1. FEATURES
A. This unit is single din MP3 PLAYER
B. Mechanical and eletronic part is newly designed and major key parts are as follows.
1) OUTPUT : 4X40W (EIAJ)
2) BAND : 3-BAND (FM 18MEMORY, MW 12MEMORY, LW 6MEMORY)
3) AUDIO CONTROL : ELECTRONIC VOLUME CONTROL (VOLUME, BASS, TREBLE, BALANCE,FADER)
4) DECK MECHANISM : KOMEC DECK
5) TUNER : KWANG SUNG
6) AUX (option)
7) OPTION :RDS
1-3-2. UNIT SPECIFICATION
1) NAME: AGC-5200/20/40/60/80
2) CHARACTERISTIC
- BLACK MASK LCD - AMBER COLOR ILLUMINATION
- KOMEC DECK MECHANISM - CD-DA(CD-TEXT), MP3 readable
- PRESET(FM:18, MW:12, LW:6) - PRESET SCAN/AUTO MEMORY
- BAND DIMMER ON/OFF CONTROL
- 4X40W (MAX.) - FRONT PANEL DETACHABLE/FLIPDOWN
- ALL FUNCTION REMOCON
3) DIMESIONS(mm)
- BODY : 188(W) X 58(H) X 166.5(D) - ESCUTCHEON : 188(W) X 58(H) X 10(D)
- WEIGHT : 1.448Kg
4) GENERAL
- OPERATING VOLTAGE : DC 10.5 - 16V - MAX OUTPUT (FM 45KHz DEVIATION) : 40W/CH
- MW : 522kHz - 1620kHz 9kHz STEP - FM : 87.5 MHz - 108 MHz 50kHz STEP
- LW : 144KHz - 288KHz
5) AUDIO SECTION
- RADIO OUT POWER : 18W X4 CHANNEL INTO 4 ohm (1kHz 10% THD)
- LOAD IMPEDANCE : 4ohm PER EACH CHANNEL (4 ohm X 4 )
6) FM SECTION
- TUNING RANGE : 87.5 MHz - 108 MHz - IF FREQUENCY : 10.7 MHz - S/N : 50dB
7) MW SECTION
- TUNING RANGE : MW :522 kHz - 1620 kHz - IF FREQUENCY : 10.7MHz - S/N : 40dB
8) LW SECTION
- TUNING RANGE : 144KHz - 288KHz - IF FREQUENCY : 10.7MHz - S/N : 40dB
9) ISO 16P CONNECTION (A,B PART)
"A" PART : POWER SUPPLY PART , TELEPHOLE IN (A1), DIMMER
"B" PART : SPEAKER CONNECTION
4. Standard Test Report
13

1-3-3. MEASUREMENT CONDITIONS & GENERAL SPECIFICATION
1-3-3-1. MEASUREMENT CONDITIONS
The measurement condition of FM radio part
1) State of control part of receiver (When available)
-LOUD ------------------------ OFF
-LOCAL/DX SWITCH ----- DX
-MUTE SWITCH ------------ OFF
-MONO / STEREO ----------- MONO except stereo mode.
2) Standard measurement input signal
Carrier wave frequency
- Makes 90.1MHz, 98.1MHz, 106.1MHz as a standard and considers the channel space for the digital tuning radio
and selects the nearest frequency from the specified frequency.
- If there is an outside interference, it's possible to move it to the nearest frequency.
- Reference carrier wave strenth : 1mV(60dBuV)
Modulation
- MONO : 1KHz 30% (22.5KHz DEV.)
- STEREO : 1KHz 60% (45KHz DEV.) / L+R=45%, L-R=45%, PILOT =10%
- RDS(OPTION) : MPX=40%(L+R=15%,L-R=15%, PILOT=10%) RDS(57KHz)= 2.66% ( 1.2KHz) DK (125Hz) :
30% AM / BK : 60% AM
- Pre-emphasis : Set as 50uS when needed to measure FM audio response.
3) SSG matching pad
4) Receiver tuning : Indicated frequency of receiver and carrier wave frequency should be matched.
Measurement condition of AM radio part
1) Standard measurement input signal
Carrier wave frequency
- Makes 603KHz, 999KHz, 1404KHz as a standard and considers the channel space for the digital tuning radio and
selects the nearest frequency from the specified frequency.
- If there is an outside interference, it's possible to move it to the nearest frequency.
- Standard LW band test frequencies are 160KHz, 220KHz, 280KHz and considers the channel space for the digital
tuning radio and selects the nearest frequency from the specified frequency.
- If there is an outside interference, it's possible to move it to the nearest frequency.
- Reference carrier wave strenth : 5mV(74dBuV)
Modulation : Standard modulation : 400Hz, 30%
2) SSG matching pad
1-4. REFERENCE CONDITION
1-4-1. STANDARD POWER SOURCE : 14.4 V
1-4-2. OPERATING VOLTAGE : 10.5 ~ 16 V
1-4-3. LOAD IMPEDANCE : 4 OHM PER EACH CHANNEL ( 4 OHM *4 )
1-4-4. STANDARD OUTPUT : 1 W
1-5. SUB RULE
This specification is applied from 03.04.2005
14
Standard Test Report

5. ELECTRICAL SPECIFICATION
15
NO PERFORMANCE POSITION UNIT NOMINAL LIMIT
RADIO - FM SECTION
1 TUNING RANGE MIN MHz 87.5 87.5
MAX MHz 108.0 108.0
2CHANNEL SPACE ALL KHz 50 50
3 INTERMEDIATE FREQUENCY ALL MHz 10.7 10.7 0.3
4 USABLE SENSITIVITY 90.1 MHz dB 10 18
(S/N = 30dB) 98.1 MHz dB 10 18
106.1 MHz dB 10 18
5 IMAGE REJECTION RATIO 98.1 MHz dB 70 40
6 IF REJECTION RATIO 98.1 MHz dB 90 50
7 LIMITING SENSITIVITY (-3dB) 98.1 MHz dB 11 12 8
8 AM SUPPRESSION (AM 30%) 98.1MHz dB 45 30
9S/N RATIO 90.1 MHz dB 52 45
( 60 ) dB INPUT 98.1 MHz dB 52 45
106.1MHz dB 52 45
10 T.H.D 22.5KHz 98.1MHz % 0.3 3
(60) dB INPUT 75KHz 98.1MHz % 0.4 3.5
11 AUDIO LOW 100 Hz dB 0 0 5
FIDELITY HIGH 10 KHz dB -3 -3 5
12 STEREO ON SENSITIVITY 98.1MHz dB 15 20
13 CHANNEL 1KHz/60dBu L-->R dB 30 20
SEPARATION R-->L dB 30 20
1KHz/40dBu L-->R dB 10 20
R-->L dB 10 20
14 SEARCH STOP LEVEL 98.1 MHz dB 20 20 10
15 LOCAL SEARCH STOP LEVEL 98.1 MHz dB 25 20 10
16 MHz dB
17 MHz mV
18 PI SEEK LEVEL 98.5MHz dB 35
19 AF SEARCH LEVEL 98.1MHz dB 35
20 TA POWER(98.1M,45K,60dBu) 98.1MHz mV 200mVrms
21 TP INDICATOR ON LEVEL 98.1MHz dB 35

1TUNING RANGE MIN KHz 522 522
MAX KHz 1620 1620
2 CHANNEL SPACE KHz KHz 9 9
3MANUAL - KHz 9 9
4INTERMEDIATE FREQUENCY ALL KHz 450 450
5 USABLE SENSITIVITY 603 KHz dB 23 35
(S/N = 20dB) 999 KHz dB 23 35
1404 KHz dB 23 35
6 IMAGE REJECTION RATIO 1404 KHz dB 100 40
7IF REJECTION RATIO 603 KHz dB 80 50
8 SELECTIVITY ( 9 KHz) 999 KHz dB 50 50
9 BAND WIDTH (-6dB) 999 KHz KHz 4~8 5 4
10 S/N RATIO 603 KHz dB 50 40
999 KHz dB 50 40
1404 KHz dB 50 40
11 T.H.D (74dBu) 30% 400Hz 999 KHz % 0.5 3
12 AUDIO FIDELITY(-6dB) 999 KHz Hz 110 120
1KHz 0dBu Ref.(74dBu) KHz 2.2 1.4 K
13 SEARCH STOP LEVEL 603 KHz dB 30 30 10
999 KHz dB 30 30 10
1404 KHz dB 30 30 10
14 LOCAL SEARCH STOP LEVEL 999 KHz dB 20 20 10
15 TWEET MODULATION (2*IF) 900 KHz % 1 1
ELECTRICAL SPECIFICATION
RADIO - AM SECTION
16
NO PERFORMANCE POSITION UNIT NOMINAL LIMIT

1FREQUENCY 100Hz dB 0 0 5
RESPONSE 10KHz dB 0 0 3
2S/N RATIO 1KHz dB 60 50dB
3T.H.D 127Hz % 0.5 1
1KHz % 0.2 1
10KHz % 0.5 1
4 CHANNEL SEPERATION 1KHz dB 40dB
10KHz dB 35dB
5 DE-EMPHASIS 4KHz dB 0 3
-20dB/1KHz ref. 16KHz dB 0 3
6 CHANNEL BAL 0dB 1KHz dB 0 0 3
NOMINAL LIMIT
17
CD SECTION
NO PERFORMANCE POSITION UNIT
ELECTRICAL SPECIFICATION
1FREQUENCY 100Hz dB 0 0 5
RESPONSE 10KHz dB 0 0 3
2S/N RATIO 1KHz dB 50dB
3T.H.D 127Hz % 1
1KHz % 1
10KHz % 1
4 CHANNEL SEPERATION 1KHz dB 40
10KHz dB 35
5CHANNEL BAL 1KHz dB 0 3
NOMINAL LIMIT
MP3 CD / USB SD SECTION
NO PERFORMANCE POSITION UNIT
