Daewoo DVT-14/20H1(T)D User manual

TV /VCR Combination
CHASSIS :CP-062
MODEL :
DAEWOO ELECTRONICS CO.,LTD
Service Manual
S/M No:TCP062PEF0
http ://svc.dwe.co.kr
Aug.2000
SPECIFICATIONS
DVT-14/20H1(T)F DVT-14/20H2(T)F
DVT-14/20H1(T)P DVT-14/20H2(T)P
DVT-14/20H1(T)D DVT-14/20H2(T)D
DVT-14H2(T)FG/(T)PG DVT-14H2(T)FB/(T)PB
ITEMS MODEL DVT-14/20H1(T)F,DVT-14/20H2(T)F,DVT-14/20H1(T)P,DVT-14/20H2(T)P,
 DVT-14/20H1(T)D,DVT-14/20H2(T)D,DVT-14H2(T)FG/(T)PG,DVT-14H2(T)FB/(T)PB
TVSECTION STANDARD PAL-B/G(FMODEL),PAL-I/II(PMODEL),PAL/SECAM-B/G,D/K(DMODEL)
SCREENSIZE 14":A34JLL90X01,A34AGT13X,A33LPE02X01,A34EAC01X06,
 20":A48JLL90X01,A48LPE01X01,A48EAX33X01
MAINVOLTAGE 220V~240VAC,50Hz
POWER STANDBYMODE:BELOW5Watts
CONSUMPTION OPERATIONMODE:14"=59Watts,20"=65Watts
SOUNDOUTPUT 1Wmin(14"),1.2Wmin(20")(at60%mod.,10%THD)
SPEAKER 3Watts8Ohm
ANTENNA
IMPEDANCE 75Ohmunbalancedinput
TUNINGSYSTEM FVS(FREQUENCYSYNTHESIS)TUNING
TUNER VHF-L:E2-S7,VHF-H:S8-S36,UHF:S37-E69(PAL-I=UHFONLY)
NUMBEROFPROGRAM70PROGRAM
AUX.TERMINAL SCARTJACK(REAR)
REMOTECONTROLLERR-46Cwith2"AAA"typebatteries
OTHERFEATURE ONSCREENDISPLAY,SLEEPTIMER,WAKEUPTIMER
 FULLAUTOSEARCH,MANUAL/FINETUNING
 CHILDLOCK,AUTOREPEAT
 PICTURETYPESELECTION(NORMAL1/2,FAVOURITE)
 INDEXSEARCH,TV/AV
VIDEOSECTIONSINGLESYSTEM PAL/SECAMcolourandCCIRmonochromesignals,625lines/50fields.
RECORDINGSYSTEMRotary2-HeadhericalScanwithaslantdoubleazimuthcombinationvideohead
INPUT 1Vp-p,75ohms,unbalanced
OUTPUT 1Vp-p,75ohms,unbalanced
SIGNALTONOISERATIO45dBwithNETTETEIMAGEcontrolatcenterposition.
HORIZONTALRESOLUTION240lineswithNETTETEIMAGEcontrolatcenterposion
AUDIO RECORDINGSYSTEMLONGITUDINALTRACK
INPUT -3.8dBm(500mVrms),morethan47Kohms,unbalanced
OUTPUT -3.8dBm(500mVrms),lessthan1Kohm,unbalanced
FREQUENCYRANGE100Hzto8KHZ
SIGNALTONOISERADIO40dB(morethan)
GENERAL TEMPERATRE 5Cto35C(operating),-20Cto60C(storagetemperature)
FORMAT standard
TAPEWIDTH12.65mm
TAPESPEED SP:23.39mm/sec,LP:11.70mm/sec
MAX.RECORDINGTIME SP:240min.winE-240videocassette
WITHFULLSIZECASSETTELP:480min.withE-240videocassette







REMARK

1
TABLE OF CONTENTS
SAFETY INSTRUCTION .................................................................................................... 2
SPECIFICATION ............................................................................................................ 3
CIRCUIT BLOCK DIAGRAM ............................................................................................ 4
ALIGNMENT INSTRUCTIONS............................................................................................ 5
SERVICE REMOCON DIAGRAM..................................................................................... 8
SCHEMATIC DIAGRAM.................................................................................................. 11
EXPLODED VIEW .......................................................................................................... 13
PRINTED CIRCUIT BOARD............................................................................................... 15
SERVICE PARTS LIST ....................................................................................................... 16
Different parts list for size ..................................................................................................................27
The different parts list for system.......................................................................................................29
APPENDIX ( Appendix is provided only by internet [http://svc.dwe.co.kr] )
CIRCUIT DESCRIPTION................................................................................................... 1

2
SAFETY INSTRUCTION
WARNING : BEFORESERVICINGTHISCHASSIS,READ
THE "X-RAY RADIATION PRECAUTION", "SAFETY
PRECAUTION" AND "PRODUCTION SAFETY NOTICE"
BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazard
ous X-RAY RADIATION. To avoid such hazards,
the high voltage must not exceed the specified limit
The nominal value of the highvoltage of this receiver is
23-25KV(14"),25-28KV(20") at max. beam current. The
high voltage must not,under any circumstances,
exceed 26KV (14"),30KV (20"). Each time a receiver
requires servicing,the high voltage should be checked.
It is recommended the reading of the high voltage be
recorded as a part of the service records, It is important
to use an accurate and reliable high voltage meter.
2. The only source of X-RAY radiation in this TV receiver
is the picture tube. For continuous X-RAY RADIATION
protection, the replacement tube must be exactly the
same type tube as specified in the parts list.
SAFETY PRECAUTION
1. Potentials of high voltage are present when this
receiver is operating. Operation of the receiver outside
the cabinet or with the back board removed involves a
shock hazard from the receiver.
1) Servicing should not be attempted by anyone who is
not thoroughly familiar with the precautions necesary
whenworkingonhighvoltageequipment.
2) Always discharge the picture tube before handling the
tube. The picture tube is highly evacuated and if
briken, glass fragments will be violently expelled.
2. If any fuse in this TV receiveris blown, replace it with
the FUSE specified in the Replacement Parts list.
3. When replacing a high wattage resistor ( metal oxide
film resistor ) in circuit board, keep the resistor 10mm
away from circuit board.
4. Keep wires away from high voltage orhightemperature
components.
5. This receiver must operate under AC260 volts, 50Hz.
NEVER connect to DC supply or any other power or
frequency.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this have special
safety-related characteristics.
These characteristics are often passed unnoticed by a
visual inspection and the X-RAY RADIATION protection
afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, watt-
age,etc. Replacement parts which have these special
safety characteristics are identified in this manual and its
supplements, electrical components having such features
are identified by designated symbol on the parts list.
Before replacing any of these components,read the parts
list in this manual carefully.
Theuseofsubstitutereplacementparts which donothave
the same safety characteristics as specified in the parts
list may create X-RAY Radiation.

3
SPECIFICATION
ITEMS MODEL DVT-14/20H1(T)F, DVT-14/20H2(T)F, DVT-14/20H1(T)P, DVT-14/20H2(T)P,
DVT-14/20H1(T)D, DVT-14/20H2(T)D, DVT-14H2(T)FG/(T)PG , DVT-14H2(T)FB/(T)PB REMARK
TV
SECTION STANDARD PAL-B/G(F MODEL) PAL-I/II(P MODEL)
PAL/SECAM-B/G, D/K (D MODEL)
SCREEN SIZE 14”: A34JLL90X01, A34AGT13X, A33LPE02X01, A34EAC01X06
20”: A48JLL90X01, A48LPE01X01, A48EAX33X01
MAIN VOLTAGE 220V~240V AC, 50Hz
POWER
CONSUMPTION STAND BY MODE : BELOW 5 Watts OPERATION MODE : 14”= 59Watts, 20” = 65Watts
SOUND OUTPUT 1Wmin(14”), 1.2 Wmin(20”)(at 60% mod., 10% THD)
SPEAKER 3Watts 8 Ohm
ANTENNA
IMPEDANCE 75 Ohm unbalanced input
TUNING SYSTEM FVS(FREQUENCY SYNTHESIS) TUNING
TUNER VHF-L: E2-S7
VHF-H:S8-S36
UHF:S37-E69(PAL-I = UHF ONLY)
NUMBER OF PROGRAM 70 PROGRAM
AUX. TERMINAL SCART JACK (REAR)
REMOTE CONTROLLER R-46C with 2 “AAA” type batteries
OTHER FEATURE ON SCREEN DISPLAY, SLEEP TIMER, WAKE UP TIMER
FULL AUTO SEARCH, MANUAL/FINE TUNING
CHILD LOCK
AUTO REPEAT
PICTURE TYPE SELECTION(NORMAL 1/2, FAVOURITE)
INDEX SEARCH, TV/AV
VIDEO
SECTION SINGLE SYSTEM PAL/SECAM colour and CCIR mono chrome signals, 625lines/50fields.
RECORDING SYSTEM Rotary 2-Head herical Scan with a slant double azimuth combination video head
INPUT 1Vp-p, 75 ohms, unbalanced
OUTPUT 1Vp-p, 75 ohms, unbalanced
SIGNAL TO NOISE RATIO 45dB with NETTETE IMAGE control at center position.
HORIZONTAL RESOLUTION 240lines with NETTETE IMAGE control at center posion
AUDIO
RECORDING SYSTEM LONGITUDINAL TRACK
INPUT -3.8dBm(500m Vrms), more than 47 Kohms, unbalanced
OUTPUT -3.8dBm(500mVrms), less than 1Kohm, unbalanced
FREQUENCY RANGE 100Hz to 8KHZ
SIGNAL TO NOISE RADIO 40dB(more than)
GENERAL TEMPERATRE 5 ° C to 35 °C(operating)
-20 ° C to 60 ° C(storage temperature)
FORMAT standard
TAPE WIDTH 12.65mm
TAPE SPEED SP : 23.39mm/sec
LP : 11.70mm/sec
MAX. RECORDING TIME
WITH FULLSIZE CASSETTE SP :240min. win E-240 video cassette LP :480min. with E-240 video cassette
NOTE
Design and specifications can be subjected to change without notice.

4
CIRCUIT BLOCK DIAGRAM

5
ALIGNMENT INSTRUCTIONS
1. MAIN TUNER AGC
1) Set a Pattern Generator with RF level 62 6 2 dBuV, 210.25 MHz.
2) Connect a OSCILLOSCOPE PROBE to P101 ( TUNER AGC INPUT ).
3) Adjust AGC UP/DOWN KEY the voltage drop about 1V DC over below it's maximum voltage.
2. SCREEN
1) Apply a COLOR BAR PATTERN SIGNAL.
2) Press the "SCREEN" KEY .
3) Connect a OSCILLOSCOPE PROBE to P901 ( CRT CATHODE R,G,B )
4) Adjust the screen volume on FBT such that the highest black level voltage 120V
6 5Vdc .
∗ Another methode
1) Press "AV Key" in condition of AV no signal.
2) Press the "SCREEN" KEY .
3) Connect a OSCILLOSCOPE PROBE to P901 ( CRT CATHODE R,G,B )
4) Adjust the screen volume on FBT such that the highest black level voltage 140 V
6 5Vdc .
3. WHITE BALANCE
1) Apply a COLOR BAR PATTERN SIGNAL.
2) Adjust the R,G,B UP/DOWN KEY of the other color which did not appear on the screen to obtain WHITE.
4. FOCUS
1) Apply a RETMA PATTERN SIGNAL.
2) Adjust the FOCUS VOLUME on FBT to obtain optimal resolution.
5. GEOMETRY
5.1 S-CORRECTION
1) Apply a CROSSHATCH PATTERN SIGNAL.
2) Adjust the S-CORR UP/DOWN KEY obtain the same distance between horizontal lines.
5.2 VERTICAL SLOPE
1) Apply a RETMA PATTERN SIGNAL.
2) Pressing the V-SLOPE +/- KEY,the lower half of the screen is blanked.
3) Adjust the border line of blanked picture coincident with the center marks of the pattern
using the V-SLOPE +/- KEY.
5.3 VERTICAL CENTER
1) Apply a RETMA PATTERN SIGNAL.
2) Adjust the center line of pattern coincident with the mechanical center marks of the
CRT using the V-CENTER +/- KEY.
5.4 VERTICAL SIZE
∗ The V-CENTER adjustment has to be done in advance.
1) Apply a RETMA PATTERN SIGNAL.
2) Adjust the upperside of the pattern coincident with the mechanical center marks of
the CRT using the V-SIZE +/- KEY.

6
ALIGNMENT INSTRUCTIONS
5.5 HORIZONTAL CENTER
1) Apply a RETMA PATTERN SIGNAL.
2) Adjust picture centering with H-CENTER +/- KEY.
6. DECK ADJUSTMENT
6-1. X-POSITION AND P2,P3 ADJUSTMENT
1) Adjust point : X-POSITION
Checking point : oscilloscope ch1 = H/SW (PY03 #2)
oscilloscope ch2 = PB ENVE (PY03 #4)
Triggering : CH1
Measuring Equipment : oscilloscope, path jig
Mode : PLAYBACK,ATK OFF
Test tape : DP-2 (6KHz)
* Adjustment Procedure
1) Connect the PATH JIG to PY03 after Test tape PLAYBACK
2) Insert the DP-2 TAPE. ( Auto playback)
3) Pressing the "ATK OFF" KEY.
4) Adjust the waveform of PB ENVE to maximum(figure1) using X-position VR.
5) Adjust IN/OUTPUT GUIDE until the exact waveform appear as bellow figure2.
OSCILLOSCOPE1
OSCILLOSCOPE2
CH2
CH1
ADJUST JIG
CONNECTION METHODE
PY03
P601
1
2
2
4
3
CH1
max.
(figure 1) (figure 2)

7
ALIGNMENT INSTRUCTIONS
6-2. AUTO PG ADJUSTMENT
1) After adjustment of 6-1. Press the " REC." button.
2) Eject the Test tape.
6-3. AZIMUTH ADJUSTMENT
1) Adjust point : AZIMUTH SCREW
Checking point : SOUND OUTPUT (P601)
Measuring Equipment : oscilloscope or audio level meter.
Mode : PLAYBACK
Test tape : DP-2 (6KHz)
* Adjustment Procedure
1) Connect the measuring equipment to the AUDIO OUTPUT (P601) terminal.
2) After test tape playback, adjust the output level maximally by varing the azimuth screw.
3) Fix the azimuth screw with locking paint.
∗ If EEPROM ( I702 ) has been changed :
- Option data has to be changed and
- all alignment function has to be readjusted.

8
SERVICE REMOCON
1. DIAGRAM
1'st
2'nd
3'rd
4'th
5'th
LANGUAGE
V-SLOPE
V-CENT V-SIZE H-CENT
S-CORR
B
GR
ATK OFF
OSD
SUB AGC
OSD
SHIPPING
AGC-
REC
AGC+
SCREEN
R-46C04
To enter the " SERVICE MODE"
Press NORMAL-> AV->SLEEP->CLEAR->POWER buttons in regular sequency
within 10seconds using USER REMOCON after setting ST-BY.

9
SERVICE REMOCON
2. HOW TO CHECK TV SECTION WITHOUT VCR DECK
If you want to check TV section without DECK mechanism, then please perform in this order.
1. Pull out the power cord.
2. Remove the VCR DECK mechanism.
3. Supply the main power. ( Main sw on )
4. Wait for about 10 seconds. ( You can see the light of power LED if the TV is normal.
5. Turn on the TV using the remocon. ( You can see the OSD "EMERGENCY" )
6. Check the TV section.
3. Refer to general adjustment
1. S-CORR +/- ( S-CORRECTION )
Press this button to adjust the same distance between horizontal lines on screen of crosshatch pattern.
2. V-SLOPE +/- ( VERTICAL SLOPE )
Press this button to adjust the border line of blanked picture coincident with the center marks of the pattern.
3. V-CENT +/- ( VERTICAL CENTER )
Press this button to adjust the center line of the pattern coincident with the mechanical center marks of the CRT on
screen of RETMA pattern.
4. V-SIZE +/- ( VERTICAL SIZE )
Press this button to adjust the upperside of the pattern coincident with the mechanical center marks the CRT on
screen of RETMA pattern.
5. H-CENT +/- ( HORIZONTAL CENTER )
Press this button to adjust picture centering with H-center on screen of RETMA pattern.
6. R,G,B +/- ( WHITE BALANCE )
The screen is become WHITE adjust R,G,B level by this button.
7. ATK OFF ( Auto tracking off )
Press this button to adjust X-Position adjustment.
Front panel's LED's are lighted up if you press this button.
Press the PB button.
ATK OFF: (RED, RED)
ATK MAX : (BLINK, OFF)
ATK MIN : (OFF, BLINK)
ATK ON : (BLINK,BLINK) ; LEFT LED = ST-BY, RIGHT LED = REC/T.REC"
8. REC
Press this button to adjust AUTO PG.
9. SCREEN
Press this button to adjust the screen volume on FBT.
10. SHIP ( SHIPPING CONDITIONS )
Press this button to set the SHIPPING CONDITIONS.
11. SUB AGC ( Only 2-TUNER Model )
Press this button to adjust SUB TUNER AGC.
Press once : picture is displayed colour pattern.
Press once more : picture is displayed black/white pattern.
12. AGC +/-
Press this button to adjust MAIN TUNER AGC.

10
SERVICE REMOCON
13. STILL
Press this button to enter the PAUSE/STILL mode.
14. STOP
Press this button to enter the STOP mode.
15. REW/REV
Press this button to enter the REW/REV mode.
16. PLAYBACK
Press this button to enter the PLAYBACK mode.
17. FF/CUE
Press this button to enter the FF/CUE mode.
18. LANGUAGE
Press this button to enter the LANGUAGE SELECTION mode.
You can select the language by AGC+(moving up) and AGC-(moving down)
buttons.
19. OSD
Press this button to adjust the OSD H-Position.
∗ If you forget your " child lock secret No. "
-> 1. Enter the SERVICE MODE.
2. POWER OFF/ON

11
SCHEMATIC DIAGRAM

12
SCHEMATIC DIAGRAM

13
EXPLODED VIEW
1. DVT-14H1F

14
EXPLODED VIEW
2. DVT-20H1F

15
PRINTED CIRCUIT BOARD

16
SERVICE PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ100 48B4446C04 TRANSMITTER REMOCON R-46C04 (AAA) 2
ZZ110 PTACPWA643 ACCESSORY AS DVT-14H1F
10 4850Q00910 BATTERY R03/NN
20 4850A03310 ANT ROD PH-RM-008A
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHA643 COVER BACK AS DVT-14H1F 2
M211 4852153021 COVER BACK HIPS BK
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M781 4857817610 CLOTH BLACK FELT 300X20X0.7
M782 4857817640 CLOTH BLACK FELT 100X20X0.7
M783 4857817621 CLOTH BLACK CLOTH T0.7 L=60
ZZ130 PTPKCPA643 PACKING AS DVT-14H1F
M801 4858042700 BOX CARTON SW-3
M801A 6520010100 STAPLE PIN 18M/M J D O
M811 4858189400 PAD EPS 14H1
M822 4858215700 BAG PE PE FOAM t0.5x1000X950
ZZ131 48519A4710 CRT GROUND NET 1401S-1015-1P
ZZ132 58G0000084 COIL DEGAUSSING DC-1450 I
ZZ140 PTCACAA643 CABINET AS DVT-14H1F
CRT1 PTRTPWA643 CRT AS DVT-14H1F 2
V01 58D1000046 COIL DY ODY-M1401
V02 48A96R004- RUBBER WEDGE HMR 28 SR (|0X54)
V03 4850PM001- MAGNET CP NY-225 (MINI NECK)
V04 2TC26019BE TAPE CLOTH 19X30 BEIGE
V05 2224050033 BOND SILICON RTV 252
V901 48A96414P1 CRT BARE A34JLL90X I
M191 4851936700 BUTTON CTRL 4941901+5536500 2
M191A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M201A 4856013300 SCREW CRT FIXING 30X80 BK
M201B 4856013301 SCREW CRT FIXING 30X140 YL
M201C 4856214902 WASHER RUBBER CR T2.0
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M281 4852817720 DOOR F/L ABS BK SILK
M281A 4856723400 SPRING SWPB 0.4
M351 4853535600 HOLDER CORD NYROLN 66
M382A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M481 4854854601 BUTTON POWER ABS BK 2
M481A 4856715600 SPRING SWPA PIE 0.4
M482 4854858401 BUTTON POWER A ABS BK
M482A 4856715600 SPRING SWPA PIE 0.4
M561 4855613600 MARK BRAND COPPER T0.4
ZZ200 PTFMSJA643 MASK FRONT AS DVT-14H1F 2
M201 4852070021 MASK FRONT HIPS BK
M331 4853311601 RETAINER BACK HIPS NC
ZZ210 PTSPPWA643 SPEAKER AS DVT-14H1F 2
PA601 4850703S51 CONNECTOR YH025-03+35098+ULW=300
SP01 4858314310 SPEAKER SP-5070A01 3W 8 OHM 2
ZZ290 PTMPMSA643 PCB MAIN MANUAL AS DVT-14H1F 2
C801 CL1JB3474K C LINE ACROSS AC250V0.47MF U/C/SNDF/S
C804 CEYN2G101P C ELECTRO 400V LHS 100MF (22X30) I
C806 CCYR3D471K C CERA 2KV R 470PF K 125 DE0907
C810 CH1AFE472M C CERA AC 4KV 4700PF M KX DE1610 I
D821 DRGP30J--- DIODE RGP30J I
DN03 DS15312H-- LED IR SI5312-H
DN03A 97P2339600 HOLDER IR ABS
DQ01 DLH2PR---- LED BLOCK LH-2P-R
DQ02 DLH2PR---- LED BLOCK LH-2P-R
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51 I
I501 1TDA8841-- IC VIDEO TDA8841 2
I502 1TC4066BP- IC TC 4066BP 2
I601 PTM2SW5400 HEAT SINK ASS`Y 1TDA8943SF + 7174300811
11TDA8943SF IC AUDIO AMP TDA8943SF
0000A 4857025400 HEAT SINK A1050P-H24 T2.0
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I701 1SDA555XFL IC MICOM OTP SDA555XFL 2
I702 1AT24C08PC IC AT24C08-10PC 2
I801 PTG2SW7701 HEAT SINK ASS`Y 1STRF6653- + 7174300811
11STRF6653- IC SMPS STR-F6653
0000A 4857027701 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I802 1LTV817C-- IC PHOTO COUPLER LTV-817C 2
I821 1SE125N--- IC SE125N 2
I822 TX0202DA-- THYRISTOR X0202DA1BA2
I823 PTB3SW1201 HEAT SINK ASS`Y 1K1A7808/06/P1+7174300811 2
I823 1K1A7808P1 IC REGULATOR KIA7808API
I823A 4857031201 HEAT SINK AL 6063S
I823B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I824 1K1A7806P1 IC REGULATOR KIA7806API 2
I827 1K1A7812P1 IC REGULATOR KIA7812API 2
I825 1K1A7806P1 IC REGULATOR KIA7806API 2
LOC PART CODE PART NAME DESCRIPTION REMARK
“ I “ is safety component, so it must be used the same component.
" 2 " is recomendable part for stock.
CAUTION

17
I826 1LE33CZ--- IC REGULATOR LE33CZ 2
I901 PTB3SW1300 HEAT SINK ASS`Y 1TDA6107Q- + 7174301011
11TDA6107Q- IC VIDEO TDA6107Q 2
0000A 4857031300 HEAT SINK A1050P-H24 T1.6
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
IN02 1K1A6801K- IC MOTOR DRIVER KIA6801K
IQ01 1KRT30---- IC PREAMP KRT30 2
JS01 4859200401 SOCKET RGB YRS21-R1
L801 5PLF24A1-- FILTER LINE LF-24A1 I
M193 4851942300 DECK AS DRP-9200N
M351 97P0475800 CASE SHI PREAMP ET T0.4
M353 4853535500 HOLDER CORD NYROLN 66
M381 4853817200 FRAME MAIN PCB FR HIPS BK
M381A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M391 4853948400 BRKT EARTH C5212P-1/2M T0.15
M721 4857246201 SHIELD TOP SPTH-C T0.5
M721A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M721B 7171301212 SCREW TAPTITE TT2 PAN 3X12 MFZN BK
P801 4859287320 CONN WAFER MKS2822-6-10-202
P901 4859289920 CONN WAFER YFW254-05S
PA501 4850705S04 CONNECTOR YH025-05+YST025+ULW=400
PA807 4850710V03 CONNECTOR YH025-10+YST025+ULW=400
PAN01 4850707V04 CONNECTOR 60-8283-3078-45+ULW=200
PAY01 4850706N07 CONNECTOR 60-8283-3068-45+USW=250
PN02 4859292320 CONN WAFER GF120-07S-TS
PN02A 4859200170 CONN FFC K-7X100-0.25
PN03 4859278220 CONN WAFER TKC-G10P-A1
PWC1 PTWBSW7410 CORD POWER ASS`Y 906111+HOUSING+TUBE+177 I
PW000 4859906111 CORD POWER M5206+H03VVH2-F=2250
PW001 4857417700 TERM CLAMP PT-01-T3
PY02 4859292220 CONN WAFER GF120-04S-TS-R
R801 DEC140M290 POSISTOR ECPCC140M290 I
R802 RX10T339J- R CEMENT 10W 3.3 OHM J TRIPOD
RLY1 5SC0101338 SW RELAY DQ5D1-O(M)/GJ-SS-105LM 2
SCT01 4859303430 SOCKET CRT PCS633A I 2
SF501 5PG1966M-- FILTER SAW G1966M
SG01 4SG0D00103 SPARK GAP S-23 900V-1.5KV
SN01 TST5811--- TR PHOTO ST-5811
SN01A 97P2343500 HOLDER TR ABS FR
SN02 TST5811--- TR PHOTO ST-5811
SN02A 97P2343500 HOLDER TR ABS FR
SN03 4850S00001 SENSOR REEL SG-258S
SN04 4850S00001 SENSOR REEL SG-258S
SW10 5S50202002 SW TACT KPT-2105A 2C-2P
SW12 5S50202002 SW TACT KPT-2105A 2C-2P
SW801 5S40101146 SW POWER PUSH SS-160-7-B
SWN01 5SN0101Z20 SW DETECT JDS1105-6X
LOC PART CODE PART NAME DESCRIPTION REMARK
TU01 5800000032 COIL OSC DE0-006
U101 4859719930 TUNER VARACTOR DT5-BF18D 2
X701 5XE6R0000C CRYSTAL QUARTZ HC-49/U6.0000 MHZ 20PPM
XN01 5XJ16R000E CRYSTAL QUARTZ HC-49S 16.000000MHZ 30PPM
XN02 5XYR03276C CRYSTAL QUARTZ C-001R 32.768000KHZ 20PPM
Z503 5PYXT5R5MB FILTER CERA XT 5.5MB
ZZ200 PTMPJ2A643 PCB CHIP MOUNT B A DVT-14H1F
CC501 HCQK221JCA C CHIP CERA 50V CH 220PF J 2012
CC512 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC517 HCQK181JCA C CHIP CERA 50V CH 180PF J 2012
CC520 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC521 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC522 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC524 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC525 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC530 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC533 HCQK181JCA C CHIP CERA 50V CH 180PF J 2012
CC535 HCBK332KCA C CHIP CERA 50V X7R 3300PF K 2012
CC536 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC538 HCQK181JCA C CHIP CERA 50V CH 180PF J 2012
CC539 HCQK181JCA C CHIP CERA 50V CH 180PF J 2012
CC703 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC712 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC713 HCQK221JCA C CHIP CERA 50V CH 220PF J 2012
CC722 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC724 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC726 HCQK330JCA C CHIP CERA 50V CH 33PF J 2012
CC727 HCQK330JCA C CHIP CERA 50V CH 33PF J 2012
CC728 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC730 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC732 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC862 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC863 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC864 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC865 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCA03 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCA05 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCA06 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCA07 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCA20 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCY15 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY34 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY50 HCQK510JCA C CHIP CERA 50V CH 51PF J 2012
CCY51 HCQK300JCA C CHIP CERA 50V CH 30PF J 2012
CCY52 HCQK300JCA C CHIP CERA 50V CH 30PF J 2012
ICN01 1M37777EFQ IC CHIP MICOM M37777EFAGP
ICY01 1LA71598MQ IC CHIP Y/C LA71598SM
LOC PART CODE PART NAME DESCRIPTION REMARK
SERVICE PARTS LIST

18
QC501 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC502 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC503 T2SA812T2B TR CHIP 2SA812-T2B
QC504 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC505 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC506 T2SA812T2B TR CHIP 2SA812-T2B
QC508 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC605 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC702 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC703 T2SA812T2B TR CHIP 2SA812-T2B
QC704 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC707 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC708 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QC710 T2SA812T2B TR CHIP 2SA812-T2B
QC711 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCN01 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCU05 T2SA812T2B TR CHIP 2SA812-T2B
QCU06 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCU07 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCY01 TKTC3121-B TR CHIP KTC3121-B
QCY02 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCY03 T2SA812T2B TR CHIP 2SA812-T2B
QCY04 T2SA812T2B TR CHIP 2SA812-T2B
QCY05 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCY06 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
QCY50 T2SC1623T2 TR CHIP 2SC1623-L6/T2B
RC510 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RC511 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RC514 HRFT241JCA R CHIP 1/10 240 OHM J 2012
RC519 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC520 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC521 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC522 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC523 HRFT753JCA R CHIP 1/10 75K OHM J 2012
RC524 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RC526 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC529 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC701 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC702 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC703 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC704 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC714 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC715 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC732 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC780 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC781 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCA03 HRFT153JCA R CHIP 1/10 15K OHM J 2012
LOC PART CODE PART NAME DESCRIPTION REMARK
RCA04 HRFT154JCA R CHIP 1/10 150K OHM J 2012
RCA05 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RCN22 HRFT105JCA R CHIP 1/10 1M OHM J 2012
RCN23 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RCN25 HRFT106JCA R CHIP 1/10 10M OHM J 2012
RCN26 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RCY18 HRFT563JCA R CHIP 1/10 56K OHM J 2012
RCY50 HRFT511JCA R CHIP 1/10 510 OHM J 2012
ZZ200 PTMPJ0A643 PCB MAIN (RHU) AS DVT-14H1F
C620 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
C805 CEXF2W100V C ELECTRO 450V RSS 10MF (13X20) TP
C821 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C822 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C823 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C824 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C825 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C837 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
C850 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C906 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
CN28 CEXF1A471V C ELECTRO 10V RSS 470MF (8X11.5) TP
ZZ200 PTMPJBA643 PCB MAIN M-10 AS DVT-14H1F
10 2TM18006BE TAPE MASKING 6.2X500
E001 4856310300 EYE LET BSR T0.2 (R1.6)
E002 4856310300 EYE LET BSR T0.2 (R1.6)
E003 4856310300 EYE LET BSR T0.2 (R1.6)
E004 4856310300 EYE LET BSR T0.2 (R1.6)
E005 4856310300 EYE LET BSR T0.2 (R1.6)
E006 4856310300 EYE LET BSR T0.2 (R1.6)
E007 4856310300 EYE LET BSR T0.2 (R1.6)
E008 4856310300 EYE LET BSR T0.2 (R1.6)
E009 4856310300 EYE LET BSR T0.2 (R1.6)
E010 4856310600 EYE LET BSR T0.2 (R2.3)
E011 4856310600 EYE LET BSR T0.2 (R2.3)
E012 4856310600 EYE LET BSR T0.2 (R2.3)
E015 4856310600 EYE LET BSR T0.2 (R2.3)
E016 4856310600 EYE LET BSR T0.2 (R2.3)
E017 4856310600 EYE LET BSR T0.2 (R2.3)
E018 4856310300 EYE LET BSR T0.2 (R1.6)
E019 4856310300 EYE LET BSR T0.2 (R1.6)
E020 4856310300 EYE LET BSR T0.2 (R1.6)
E021 4856310600 EYE LET BSR T0.2 (R2.3)
E022 4856310600 EYE LET BSR T0.2 (R2.3)
E023 4856310600 EYE LET BSR T0.2 (R2.3)
P101 485923162S CONN WAFER YW025-03 (STICK)
P501 485923182S CONN WAFER YW025-05 (STICK)
P601 485923162S CONN WAFER YW025-03 (STICK)
P802A 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
LOC PART CODE PART NAME DESCRIPTION REMARK
SERVICE PARTS LIST

19
P802B 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P904 485923162S CONN WAFER YW025-03 (STICK)
PY03 485923202S CONN WAFER YW025-07 (STICK)
R809 RS02Z228JS R M-OXIDE FILM 2W 0.22 OHM J SMALL !
R832 RS02Z828JS R M-OXIDE FILM 2W 0.82 OHM J SMALL
ZZ200 PTMPJRA643 PCB MAIN RADIAL AS DVT-14H1F
C102 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C105 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C121 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C507 CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP
C509 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C511 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C515 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C516 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C518 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C519 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C523 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C527 CXCH1H150J C CERA 50V CH 15PF J (TAPPING)
C528 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C531 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C532 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C534 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C537 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C541 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C542 CEXD1H109F C ELECTRO 50V RND 1MF (5X11) TP
C544 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C545 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C547 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C549 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C551 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C609 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C613 CMXM2A224J C MYLAR 100V 0.22MF J
C614 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C615 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C617 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C619 CMXM2A224J C MYLAR 100V 0.22MF J
C702 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C704 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C706 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C723 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C729 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C731 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C733 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C802 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C807 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C809 CCXB1H152K C CERA 50V B 1500PF K (TAPPING)
LOC PART CODE PART NAME DESCRIPTION REMARK
C811 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C838 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C842 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C843 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C844 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C845 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C846 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C849 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C851 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C857 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C858 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C905 CMXL2E104K C MYLAR 250V MEU 0.1MF K
CA01 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CA24 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CN05 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
CN08 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CN09 CXCH1H220J C CERA 50V CH 22PF J (TAPPING)
CN10 CXCH1H220J C CERA 50V CH 22PF J (TAPPING)
CN11 CDXF0H104K C SUPER 5.5V 0.1F F (TAPPING)
CN12 CXCH1H180J C CERA 50V CH 18PF J (TAPPING)
CN13 CXCH1H180J C CERA 50V CH 18PF J (TAPPING)
CN15 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CN18 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
CN26 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CN27 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CN29 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CN31 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CN33 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CU02 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
CU03 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
CU04 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
CU05 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
CU07 CMXM2A822J C MYLAR 100V 8200PF J (TP)
CU10 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CU12 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CU13 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
CU14 CMXM2A272J C MYLAR 100V 2700PF J (TP)
CU15 CMXM2A122J C MYLAR 100V 1200PF J (TP)
CU16 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
CU17 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
CU18 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CU19 CMXM2A223J C MYLAR 100V 0.022MF J TP
CU21 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
CU23 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CU24 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CY01 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY02 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
LOC PART CODE PART NAME DESCRIPTION REMARK
SERVICE PARTS LIST
