Daewoo DTC-14D9T User manual

Caution
: In this Manual, some parts can be changed for improving. their
performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List)in
Service Information Center.
Service Manual
COLOR Television
CHASSIS :
Model:
Specification
S/M No. : TCP195LFEF0
Version Pal multi system
TV Standard PAL-SECAM B/G, D/K, H, I/I (NTSC : AV Only)
Sound system Mono
Power consumption * 2Speaker
14":57W / 20":66W / 21":73W
Speaker 7W 8 Ohm
Teletext system Option
Aerial Input 75 Ohm unbalanced
Channel coverage off-air channels, S-cable channels and hyperband
Tuning system Ferquency synthesiser tuning system
14":34cm
Visual screen size 20’:48cm
21":51cm
Channel indication On screen display
Program selection 200 Programmes
RCA jack : Audio input and Vidio input
ERUO SCART Jack : Audio/Video and R/G/B input.
Auxiliary Outpup Terminal Sloe and fast swtching, SVHsin
Audio - Video jack on front of cabinet in common
connection with EURO-SCART
Headphone jack on front of cabinet
R-48A02 (None teletext) AAA Battery type
Remote control R-48A01(With teletext) AAA Battery type
R-44C05(With teletext) AA Battery type
May. 2006
CP-195L
DTC-14D9T
DTC-20D9T
DTC-21D9T
DTC-2131TF

SAFETY INSTRUCTION 2
SPECIFICATIONS 3
21 Pin EURO-SCART 3
CIRCUIT BLOCK DIAGRAM 4
ALIGNMENT INSTRUCTIONS 5
1. Service mode 5
2. Microcontroller configuration 5
3. TV SET Alignment 5~6
SCHEMATIC DIAGRAM 7
PRINTED CIRCUIT BOARD 8
EXPLODED VIEW 9~12
SERVICE PARTS LIST 13~25
FUNCTIONAL DESCRIPTION 1~6
IC DESCRIPTION 7~44
1
TABLE OF CONTENTS
APPENDIX (Appendix is provide only by internet [http://svc.dwe.co.kr])

2
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high
voltage must not exceed the specified limit. The nominal value of the high voltage of this receiver is 22-23 kV (14")or
24-26 kV (20"-21")at max beam current. The high voltage must not, under any circumstances, exceed 27.5 kV (14",
20"), 29KV (21"). Each time a receiver requires servicing, the high voltage should be checked. It is important to use an
accurate and reliable high voltage meter.).
2. The only source of X-RAY Radiation in this TV receiver is the picture tube. For continued X-RAY RADIATION
protection, the replacement tube must be exactly the same type tube as specified in the parts list.
SAFETY PRECAUTION
1. Potentials of high voltage are present when this receiver is operating. Operation of the receiver outside the cabinet or
with the back cover removed involves a shock hazard from the receiver.
1) Servicing should not be attempted by anyone who is not thoroughly familiar with the precautions necessary when
working on high voltage equipment.
2) Discharge the high potential of the picture tube before handling the tube. The picture tube is highly evacuated and if
broken, glass fragments will be violently expelled.
2. If any Fuse in this TV receiver is blown, replace it with the FUSE specified in the Replacement Parts List.
3. When replacing a high wattage resistor (oxide metal film resistor) in circuit board, keep the resistor body 10 mm away
from the circuit board.
4. Keep wires away from high voltage or high temperature components.
5. This receiver must operate under AC 230 volts, 5O Hz. NEVER connect to a DC supply of any other voltage or
frequency.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this equipment have special safety-related characteristics. These characteristics
are often passed unnoticed by a visual inspection and the X-RAY RADIATION protection afforded by them cannot
necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts
which have these spe- cial safety characteristics are identified in this manual and its supplements, electrical components
having such features are identified by designated symbol on the parts list. Before replacing any of these components,
read the parts list in this manual carefully. The use of substitutes replacement parts which do not have the same safety
characteristics as specified in the parts list may create X-RAY Radiation.
SAFETY INSTRUCTION
WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment

3
PIN SIGNAL DESCRIPTION MATCHING VALUE
1 Audio Output Right 0.5 Vrms, Impedance < 1k‰, (RF 54% Mod)
2 Audio Input Right 0.5Vrms, Impedance > 10k‰
3 Audio Output Left 0.5 Vrms, Impedance < 1k‰, (RF 54% Mod)
4 Audio Earth
5 Blue Earth
6 Audio Input Left 0.5Vrms, Impedance > 10k‰
7 Blue Input 0.7Vpp + 0.1V, Inpedance 75‰
8 Slow Switching TV : 0 to 2V, AV : 4.5 to 12V, Impedance > 10k‰
9 Green Earth
10 N.C
11 Green Input 0.7Vpp + 0.1V, Impedance 75‰
12 N.C
13 Red Earth
14 Blanking Earth
15 Red Input 0.7Vpp 0.1V, Impedance 75‰
Chroma Input 3dB for a luminance signal of 1 Vpp
16 Fast Switching 0 to 0.4V : Logic :"0", 1 to 3V : Logic "1", Impedance 75‰
17 Video Out Earth
18 Video In Earth
19 Video Output 1 Vpp 3dB, Impedance 75‰
20 Video Input 1 Vpp 3dB, Impedance 75‰
21 Common Earth
21Pin EURO-SCART
SPECIFICATIONS

4
CIRCUIT BLOCK DIAGRAM

5
Microcontroller configuration : Service mode
To switch the TV set into service mode please see instruction below.
1 - Select pr. number 91
2 - Adjust sharpness to minimum and exit all menu.
3 - Quickly press the key sequence : RED - GREEN - menu
4 - List of service manual item
To exit SERVICE menu press menu key or Std By key.
In Service Mode press "OK" to the microcontroller i.e. the I2C bus is free and the set can be controlled by external
equipment.
Press "OK" again to allow the microcontroller to control the set again
TV set Alignment
1 - G2 alignment
- Set TV in NORMAL I mode.
- Receive the RETMA PATTERN (or color bar).
- Press the SVC button in Service Remocon.
- Press the Screen button in Service Remocon.
- Turn round the screen volume of FBT until the horizontal line of screen disappear.
- Press the Screen button to exit Screen mode.
2 - White balance
- Select a dark picture and adjust Black G and Black R to the desired colour temperature.
- Select a bright picture and adjust WP Red, WP Green, WP Blue to the desired colour temperature.
ALIGNMENT INSTRUCTIONS
No Item
1 AGC
2 Black R
3 Black G
4 WR Red
5 WP Green
6 WP Blue
7 H Shift
8 V Slope
9 V Amp
10 S Correct
11 V Shift
12 Sub Bright
13 BRM
14 CH Lock
15 MAX Vol
16 AV Start
17 Key Lock
18 PSNS Mode

6
3 - Focus
- Adjust the Focus volume ( on FBT ) to have the best resolution on screen.
4 - Vertical geometry
- Adjust the Vertical Amplitude, Shift, S-Correction and Slope
to compensate for vertical distortion
5 - Horizontal picture centering
- Adjust H Shift to have the picture in the center of the screen.
7 - AGC
- Adjust the antenna signal level to 64dB V 2
- Set RF AGC to 0.
- Increase RF AGC level and stop when the level on pin 6 of I501 goes below 2.5 Vdc
ALIGNMENT INSTRUCTIONS

-7-

-8-

-9-

-10-

-11-

-12-
SCREW CRT FIX
SCREW TAPPTITE
SCREW TAPPTITE
SCREW TAPPTITE
4856013300
4855936900
7128301011
7122401412
7122401212
30X80 BK
ABS BLUE
TT2 WAS 3X12 MFZNBK
TT2 TRS AX14 MFZNBK
TT2 TRS 4X12 MFZNBK
EPS-2131
150ART P/E FILM
BOX CARTON
PAD
SPEC PLATE
4858100Q00
7128301212
4858061600
DW-3
4852080301
4856215402
4852162211
4854853501
4856013302
SCREW CRT FIX
BUTTON CH
COVER BACK
MASK FRONT
SASHER RUBBER
BUTTON POWER
HIPS GY
HIPS GY
HIPS GY
CR T2.0
HIPS GY
30X190 BK
21
11
10
9
8
7
5
6
4
3
20
18
19
17
15
16
14
13
12
4855617500
MARK BRAND
CU AU+ABS BK
21D8
CM-907S CORE
4854803201
4855548000
DECO SENSOR
PC SMOG
4856013610
SCREW SPKR FIX
L=16 A=17
4858311110
SPEAKER
12W8OHM SP-58126F
4856716000
SPRING
SWPA PIE 0.5
4855415800
MIAN-CHASSIS
CM-907SF
SCREW TAPPTITE
TT2 WAS 3X10 MRZN
DECO EYE
J.KY.W.KANG S.D.PARKKIM
2
7
1
8
1
1
1
1
11
1
2
1
PART NAME
MODEL
REFERENCE
PART CODE
N.S
SCALE
No
UNITS
1
2
mm
MATERIAL
ASSY NAME
D
N
DAEWOO Electronics Corp.
Mechanical Design Team, TV Research Center
Q’ty
REMARKS
Designed by Checked by Inspected by Approved by
1
1
1
4
2
1
1
3
1
DEVELOPMENT DWG(1/1)
CM-907S
DTC/DTD-2131 485009JY

13
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ100 48B5748A01 TRANSMITTER REMOCON R-48A01 (AAA)
ZZ110 PTACPWD434 ACCESSORY AS DTA-20V1MZ
00100 4850Q00910 BATTERY R03/NN
00200 48586002E2 MANUAL INSTRUCTION ENGLISH,ARABIC
M821 4858213803 BAG INSTRUCTION L.D.P.E TO.05X250X400(+20)
ZZ120 PTBCSHD678 COVER BACK AS DTB-21D7MT
M211 4852160312 COVER BACK HIPS BK 21D7
M781 4857817610 CLOTH BLACK FELT 300X20X0.7
10 6520010100 STAPLE PIN AUTO W65
M801 4858057500 BOX CARTON DW-3
M811 4858197700 PAD EPS 21D7
M821 4858211801 BAG P.E L.D.P.E T0.03X1300X1100
ZZ131 48519A7610 CRT GROUND NET 2103S-1015-1P
ZZ132 58G0000177 COIL DEGAUSSING DC-21SF AL
ZZ140 PTCACAE248 CABINET AS DTC-21D7T
40 2TF01612CL TAPE FILAMENT 0.15X12mmX55mm
M201A 4856017703 SCREW CRT FIX 5X30 L80 BK 3CR
M201B 4856215402 WASHER RUBBER CR T2.0
M201C 4856017710 SCREW CRT FIX 5X30 L190 BK 3CR
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFAN BK 3CR
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M681 4856812001 TIE CABLE NYLON66 DA100
SP01A 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
SP01B 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
V901 4859640860 CRT A51AEZ90X27 P38
ZZ200 PTFMSJD678 MASK FRONT AS DTB-21D7MT
M191 4854950201 BUTTON CH ABS GY
M191A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M201 4852078611 MASK FRONT HIPS GY
M201A 4857818703 CLOTH BLACK FELT 300X15XT1.0
M481 4854860701 BUTTON POWER ABS GY
M551 4855544701 DECO SENSOR PC SMOG
M561 4855617500 MARK BRAND CU AU+ABS BK
M591 4855936101 DECO EYE ABS BLUE
M591A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M671 4856716000 SPRING SWPA PIE0.5
ZZ210 PTSPPWD536 SPEAKER AS DTB-21D3MZ
P602A 4850704S31 CONNECTOR YH025-04+YRT205+ULW800400
SP01 4858317510 SPEAKER SP-58126F01C
SP02 4858317510 SPEAKER SP-58126F01C
ELECTRICAL PARTS LIST
is a recommendable part for stock.
is safety component, so it must be used the same component.
In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Prats Price List) in Service information Center (http://svc.dwe.co.kr)
Caution
Caution

14
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ290 PTMPMSE248 PCB MAIN MANUAL AS DTC-21D7T
C403 CMYH3C822J C MYLAR 1.6KV BUP 8200PF J
C407 CMYF2D514J C MYLAR 200V MPP 0.51MF J
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C804 CEYD2W151D C ELECTRO 450V FHS 150MF (25X40)
C811 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
D707 4858900002 HOLDER LED ASSY LH-3P
I301 PTE2SW7100 HEAT SINK ASS Y 1LA78040 + 7174300851
00001 1LA78040 IC VERTICAL LA78040
0000A 4857027100 HEAT SINK SPCC T1.0+SN
0000B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I501 19346PSN3P IC SIGNAL PROCESSOR TDA9346 PS-N3
I601 PTG2SW4401 HEAT SINK ASS‘Y 1LA42052 + 7174300851
00001 1LA42052 IC AUDIO AMP LA42052-E
0000A 4857024401 HEAT SINK AL EX
0000B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I702 124LC16B1B IC MEMORY 24LC16B1B
I801 PTM2SW4600 HEAT SINK ASS‘Y 1STRW6753- + 7174300851
00001 1STRW6753- IC POWER STR-W6753
0000A 4857024600 HEAT SINK AL EX B/K
0000B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I802 1LTV817C IC PHOTO COUPLER LTV-817C
I804 1LE33CZ - IC REGULATOR LE33CZ
IF01 1441VF6 - IC PREAMP 441VF6
JPA01 4859200401 SOCKET RGB YRS21-R1
JPA02 4859109950 JACK PIN BOARD PH-JB-9710A
L401 58H0000020 COIL H-LINEARITY L-76(76.5UH)
LF801 5PLF24A3 FILTER LINE LF-24A3
M682 4856812001 TIE CABLE NYLON66 DA100
P401 4859240020 CONN WAFER YFW500-05
P901 4850708N08 CONNECTOR BIC-08T-25T+C-20T+ULW=400
PW801 4859908110 CORD POWER AS 1-L0+H03VVH2-F+HOU=2200
Q402 PTJ2SW7200 HEAT SINK ASSY TST1803DH- + 7174301051
00001 TST1803DH- TR HORI ST1803DHI
0000A 4857027200 HEAT SINK AL T1.0
0000B 7174301051 SCREW TAPPTITE TT2 RND 3X10 MFZN 3CR
R800 RX07B229JP R CEMENT 7W 2.2 OHM J BEN 15MM 4P
R801 DTC7R0M270 POSISTOR PDC7R0MP6B7Z81C
SCT1 4859303530 SOCKET CRT PCS629-03C
SF01 5PD2917N FILTER SAW D2917N
SW801 5S40101143 SW POWER PUSH PS3-22SP (P.C.B)
T401 50D10A3 - TRANS DRIVE TD-10A3
T402 50H0000295 FBT LTC-535
T801 50M3541C3- TRANS SMPS TSM-3541C3
U100 4859729030 TUNER VARACTOR TAEM-G008D

15
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ200 PTMPJ0E248 PCB MAIN (RHU) AS DTC-21D7T
C306 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C408 CEXF2E330V C ELECTRO 250V RSS 33MF (13X25) TP
C409 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C607 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C609 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C610 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C805 CBXB3D471K C CERA SEMI 2KV BL(N) 470PF K (T)
C813 CEXF2C101C C ELECTRO 160V RUS 100MF (16X25) TP
C814 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C816 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25) TP
C817 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C821 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C830 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C833 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C904 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
ZZ200 PTMPJBE248 PCB MAIN M-10 AS DTC-21D7T
E001 4856310300 EYE LET BSR T0.2 (R1.6)
E002 4856310300 EYE LET BSR T0.2 (R1.6)
E003 4856310300 EYE LET BSR T0.2 (R1.6)
E004 4856310300 EYE LET BSR T0.2 (R1.6)
E005 4856310300 EYE LET BSR T0.2 (R1.6)
E006 4856310300 EYE LET BSR T0.2 (R1.6)
E007 4856310300 EYE LET BSR T0.2 (R1.6)
E008 4856310300 EYE LET BSR T0.2 (R1.6)
E009 4856310300 EYE LET BSR T0.2 (R1.6)
E010 4856310300 EYE LET BSR T0.2 (R1.6)
E011 4856310300 EYE LET BSR T0.2 (R1.6)
E012 4856310300 EYE LET BSR T0.2 (R1.6)
E101 4856310600 EYE LET BSR T0.2 (R2.3)
E102 4856310600 EYE LET BSR T0.2 (R2.3)
E103 4856310600 EYE LET BSR T0.2 (R2.3)
E104 4856310600 EYE LET BSR T0.2 (R2.3)
E105 4856310600 EYE LET BSR T0.2 (R2.3)
E106 4856310600 EYE LET BSR T0.2 (R2.3)
E109 4856310600 EYE LET BSR T0.2 (R2.3)
E110 4856310600 EYE LET BSR T0.2 (R2.3)
N801 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N802 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N803 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N804 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P601 485923172S CONN WAFER YW025-04 (STICK)
R403 RS02Z751JS R M-OXIDE FILM 2W 750 OHM J SMALL
R406 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
R407 RS02Z102JS R M-OXIDE FILM 2W 1K OHM J SMALL
ELECTRICAL PARTS LIST

16
LOC PART CODE PART NAME DESCRIPTION REMARK
R408 RS02Z300JS R M-OXIDE FILM 2W 30 OHM J SMALL
R410 RS01Z828J- R M-OXIDE FILM 1W 0.82 OHM J (TAPPING)
R805 RS02Z278JS R M-OXIDE FILM 2W 0.27 OHM J SMALL
R826 RS02Z470JS R M-OXIDE FILM 2W 47 OHM J SMALL
R842 RS02Z560JS R M-OXIDE FILM 2W 56 OHM J SMALL
R847 RS02Z560JS R M-OXIDE FILM 2W 56 OHM J SMALL
R904 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
R905 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
R906 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
R910 RS01Z680J- R M-OXIDE FILM 1W 68 OHM J (TAPPING)
ZZ200 PTMPJRE248 PCB MAIN RADIAL AS DTC-21D7T
C101 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C102 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C104 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C302 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C307 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C401 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C402 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C404 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C405 CCXB2H561K C CERA 500V B 560PF K (TAPPING)
C406 CEXF2C229V C ELECTRO 160V RSS 2.2MF (8X11.5)TP
C412 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C414 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C415 CXSL2H470J C CERA 500V SL 47PF J (TAPPING)
C505 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C507 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C508 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C509 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C511 CMXM2A332J C MYLAR 100V 3300PF J (TP)
C512 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C513 CCXB1H222K C CERA 50V B 2200PF K (TAPPING)
C515 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C516 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C517 CCXF1H104Z C CERA 50V F 0.1MF Z
C518 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C519 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
C521 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C525 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C526 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C528 CEXF1C100V C ELECTRO 16V RSS 10MF 4X7
C529 CEXF1C100V C ELECTRO 16V RSS 10MF 4X7
C531 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C601 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C602 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C603 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
ELECTRICAL PARTS LIST

17
LOC PART CODE PART NAME DESCRIPTION REMARK
C604 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C702 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C704 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C706 CXCH1H270J C CERA 50V CH 27PF J (TAPPING)
C707 CXCH1H270J C CERA 50V CH 27PF J (TAPPING)
C708 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C802 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C806 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C807 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C812 CCXB3A271K C CERA 1KV B 270PF K (TAPPING)
C815 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C819 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C820 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C831 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C832 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CA04 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
F801 5FWPS4022L FUSE WIDE TL 250V 4A CASE
I803 1K1A431B IC REGULATOR(SHUNT) KIA431B 2.495V 0.5% TO-92
L402 58C0000116 COIL BEAD HC-3550R
L602 58CX430599 COIL CHOKE AZ-9004Y 940K TP
L802 58CX430599 COIL CHOKE AZ-9004Y 940K TP
Q104 TKTC3198Y- TR KTC3198Y
Q401 TKTC3207 TR KTC3207 (TP)
Q403 TKTC3198Y- TR KTC3198Y
Q501 TKTC3198Y- TR KTC3198Y
Q502 TKTA1266Y- TR KTA1266Y (TP)
Q503 TKTC3198Y- TR KTC3198Y
Q504 TKTC3198Y- TR KTC3198Y
Q505 TKTA1266Y- TR KTA1266Y (TP)
Q601 TKTC3198Y- TR KTC3198Y
Q602 TKTC3198Y- TR KTC3198Y
Q802 TKTC3198Y- TR KTC3198Y
Q803 TKTC3198Y- TR KTC3198Y
Q809 TKTA1270Y- TR KTA1270Y (TP)
Q810 TKTC3205Y- TR KTC3205Y (TP)
Q811 TKTC3198Y- TR KTC3198Y
Q901 TKTC3207 TR KTC3207 (TP)
Q902 TKTC3207 TR KTC3207 (TP)
Q903 TKTC3207 TR KTC3207 (TP)
Q904 TBF420 TR BF420
Q905 TBF420 TR BF420
Q906 TBF420 TR BF420
Q907 TBF421 TR BF421
Q908 TBF421 TR BF421
ELECTRICAL PARTS LIST

18
LOC PART CODE PART NAME DESCRIPTION REMARK
Q909 TBF421 TR BF421
R301 RN02B229JS R METAL FILM 2W 2.2 OHM J SMALL
R409 RN02B229JS R METAL FILM 2W 2.2 OHM J SMALL
R827 RN01B300JS R METAL FILM 1W 30 OHM J SMALL
SW01 5S50101090 SW TACT THVH472GCA
SW02 5S50101090 SW TACT THVH472GCA
SW03 5S50101090 SW TACT THVH472GCA
SW04 5S50101090 SW TACT THVH472GCA
SW05 5S50101090 SW TACT THVH472GCA
SW06 5S50101090 SW TACT THVH472GCA
X701 5XEX12R00E CRYSTAL QUARTZ HC-49/U 12.000MHZ 30PPM TP
Z501 5PXXT5R5MB FILTER CERA XT 5.5MB-TP
Z502 5PXXT6R0MB FILTER CERA XT 6.0MB-TP
Z503 5PXXT6R5MB FILTER CERA XT 6.5MB-TP
ZZ200 PTMPJAE248 PCB MAIN AXIAL AS DTC-21D7T
A001 4859814093 PCB MAIN 330X246 G1B
C105 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C106 CCZF1H103Z C CERA 50V F 0.01MF Z
C301 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C309 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
C410 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C501 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C502 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C503 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C504 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C506 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C510 CCZF1H103Z C CERA 50V F 0.01MF Z
C514 CCZB1H331K C CERA 50V B 330PF K (AXIAL)
C520 CCZF1H473Z C CERA 50V F 0.047MF Z
C522 CCZF1H223Z C CERA 50V F 0.022MF Z
C523 CCZF1H223Z C CERA 50V F 0.022MF Z
C524 CCZF1H223Z C CERA 50V F 0.022MF Z
C527 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C530 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C606 CCZB1H472K C CERA HIKB 50V 4700PF K AXIAL
C612 CCZB1H472K C CERA HIKB 50V 4700PF K AXIAL
C616 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C701 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C703 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C705 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C710 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C808 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
C809 CCZF1H473Z C CERA 50V F 0.047MF Z
C810 CCZB1H821K C CERA 50V B 820PF K AXIAL
C901 CCZB1H391K C CERA 50V B 390PF K (AXIAL)
ELECTRICAL PARTS LIST

19
LOC PART CODE PART NAME DESCRIPTION REMARK
C902 CCZB1H391K C CERA 50V B 390PF K (AXIAL)
C903 CCZB1H391K C CERA 50V B 390PF K (AXIAL)
C905 CCZB1H561K C CERA 50V B 560PF K
CA01 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA02 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA03 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CV04 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CV05 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CV06 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CV07 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
D101 DUZ33B DIODE ZENER UZ-33B
D103 D1N4148 - DIODE 1N4148 (TAPPING)
D104 DUZ5R1BM DIODE ZENER UZ-5.1BM
D301 D1N4004S DIODE 1N4004S
D302 D1N4937G DIODE 1N4937G (TAPPING)
D401 D1N4937G DIODE 1N4937G (TAPPING)
D402 D1N4937G DIODE 1N4937G (TAPPING)
D403 D1N4937G DIODE 1N4937G (TAPPING)
D501 D1N4148 - DIODE 1N4148 (TAPPING)
D502 D1N4148 - DIODE 1N4148 (TAPPING)
D505 DUZ7R5BM DIODE ZENER UZ-7.5BM
D506 DUZ7R5BM DIODE ZENER UZ-7.5BM
D507 DUZ7R5BM DIODE ZENER UZ-7.5BM
D508 D1N4148 - DIODE 1N4148 (TAPPING)
D509 D1N4148 - DIODE 1N4148 (TAPPING)
D510 D1N4148 - DIODE 1N4148 (TAPPING)
D511 D1N4148 - DIODE 1N4148 (TAPPING)
D701 DUZ5R6BM DIODE ZENER UZ-5.6BM
D801 DLT2A05G DIODE LT2A05G (TP)
D802 DLT2A05G DIODE LT2A05G (TP)
D803 DLT2A05G DIODE LT2A05G (TP)
D804 DLT2A05G DIODE LT2A05G (TP)
D805 D1N4937G DIODE 1N4937G (TAPPING)
D806 D1N4937G DIODE 1N4937G (TAPPING)
D807 D1N4148 - DIODE 1N4148 (TAPPING)
D808 DUZ6R2BM DIODE ZENER UZ-6.2BM
D809 DRGP15J - DIODE RGP15J DO-204AC 600V 1.5A
D810 D1N4937G DIODE 1N4937G (TAPPING)
D811 D1N4937G DIODE 1N4937G (TAPPING)
D812 DRGP15J - DIODE RGP15J DO-204AC 600V 1.5A
D817 DUZ9R1BM DIODE ZENER UZ-9.1BM
D818 DUZ6R2BM DIODE ZENER UZ-6.2BM
D902 D1N4148 - DIODE 1N4148 (TAPPING)
D903 D1N4148 - DIODE 1N4148 (TAPPING)
D904 D1N4148 - DIODE 1N4148 (TAPPING)
ELECTRICAL PARTS LIST
