Daewoo DWD-CV701PC User manual

• As this product undergoes a functional test, a small amount of water may remain in the product.
• Store the user manual in an easily reachable place for later use.
• Please read 'Safety Instructions' carefully before use.
※mini is the world's first wall-mounted front-load washer developed by Daewoo Electronics.
Wall-Mounted Front Load Washer
Wall-Mounted Front Load Washer
DWD-CV701PC
DWD-CV701PC_Cotton_ZORA.indd 1 2014-11-18 오전 11:41:26

mini is the world's first ever wall-mounted front-load
washer, which is installable in bathroom,
pantry, kitchen and various locations.
mini is a unique home appliance
featuring an innovative design and
practical functions.
World's First Ever Design
Wall-Mounted Front-Load Washer
mini features a cute and adorable design in a stable
cubic frame and harmonious colors to help decorate
house interiors.
Ultrasmall Design
Daewoo Electronics' cutting-edge technologies
apply to mini, featuring a variety of essential
functions for better everyday lives.
Mini's Practical Function
Wall-Mounted Front Load Washer
Wall-Mounted Front Load Washer
DWD-CV701PC_Cotton_ZORA.indd 2 2014-11-18 오전 11:41:26

| 2 |
Product Features ..................................................................... 3
Safety Instructions .................................................................... 4
Preparation ............................................................................... 9
Parts and Components ............................................................. 10
Washable Items ........................................................................ 11
Non-Washable Items ................................................................ 11
Preparing Clothes for washing ................................................. 12
Directions on Detergent and Softener Containers .................... 13
Washing Course ....................................................................... 15
Preparation
Use
Installation
Buttons and Functions .............................................................. 16
Cotton 40°C .............................................................................. 17
Cotton 60°C .............................................................................. 18
Synthetic 20°C .......................................................................... 19
Baby Care................................................................................. 20
Spin ......................................................................................... 21
Cotton Eco ................................................................................ 22
Rinse+Spin ............................................................................... 24
Q&A on Laundry ....................................................................... 25
Cleaning ................................................................................... 26
When malfunctions are suspected ........................................... 27
Before calling for service .......................................................... 28
Specifications and Wiring Diagram........................................... 29
CONTENTS
DWD-CV701PC_Cotton_ZORA.indd 2 2014-11-18 오전 11:41:26

| 3 |
Product Features
mini enables daily washes of towels, shirts,
underwear and socks for a cleaner home
environment.
Powerful Daily Cleaning
mini's unique functions for faster and
powerful cleaning of various fabrics
As synthetic 20℃ cycle takes only 29 minutes,
it speeds the laundry process and reduces
water and power consumption by 14%
compared to regular front-load washers.
29 minute wash
mini's 'Baby Care' cycle leaves no detergent
residue after washing to protect sensitive
baby skin from irritation.
Baby Care (DWD-M301WP, DWD-M301WA)
mini enables safe washing of blouses,
knitwear, and wool clothing that are
vulnerable to deformation without fabric
damage and discoloration.
Delicate Cleaning for High Quality Clothes
DWD-CV701PC_Cotton_ZORA.indd 3 2014-11-18 오전 11:41:27

Ensure that the power
voltage, frequency, and
current match the product's
specification.
Violations may cause fire and
electric shock.
| 4 |
This appliance is not intended for use by persons (including children) with reduced physical, sensory or metal
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Cautionary information on cases that
may cause death or severe personal
injuries
Cautionary information on cases that
may cause minor personal injuries or
damage to products
Warning
Do not scratch, damage,
deform, bend, pull, twist, or
tie the power cord. Do not
place or insert a heavy item
on the cord.
Violations may damage the
power cord, raising the risk of fire
and electric shock.
Do not unplug or plug the
cord with wet hands.
Violations may cause electric
shock.
Safety Instructions
Do not use the washer when
the power cord is damaged
or loosely plugged in.
Violations may cause electric
shock, short circuit, or fire.
Contact a sales store to request
the maintenance service.
If the washer doesn't run or
smokes or unusal smells
occur, unplug the washer
and contact the service
center promptly to prevent
accidents.
Violations may cause electric
shock, short circuit, or fire.
Do not disassemble, repair,
or rebuild the washer
without the assistance of
service engineer.
Violations may cause fire, electric
shock, and personal injuries.
Contact a sales store or read the
back page of user manual to
request the maintenance service.
DWD-CV701PC_Cotton_ZORA.indd 4 2014-11-18 오전 11:41:27

| 5 |
Safety Instructions
Warning
If the power cord pin is
contaminated with dust or
water, wipe the pin clean
with a dry cloth before use.
Violations may cause fire.
Do not expose the washer to
rain or wind.
Violations may cause electric
shock, fire, technical problems,
or deformation.
Unplug the cord and open
the window for ventilation
without touching any
buttons if a gas leak occurs.
Violations may cause a spark
and, accordingly, explosion, fire,
or burns.
Electrical grounding is
required for safety.
Technical problems or short
circuits may cause electric
shocks.
Read user manual or contact the
service center with further
inquiries on grounding method.
Do not place gasoline,
petroleum, benzol, thinner, or
alcohol inside or beside the
washer. Do not place laundry
containing such materials
inside or beside the washer.
Violations may cause explosion
or fire.
Unplug the power cord before
cleaning or maintenance work.
Violations may cause electric
shock or injury.
Do not sprinkle water on the
washer. Violations may cause
short circuit or electric shock.
Do not enter the laundry
room and contact the
service center, if the washer
is submerged in water as the
water supply hose was
dislocated.
Violations may cause electric
shock.
Do not install the washer
near a heater and do not
place candles or cigarettes
on the washer.
Violations may cause fire or
deformation.
Insert the plug with 10A or
higher in the outlet directly.
Multiple connections to a single
outlet may cause fire due to heat.
DWD-CV701PC_Cotton_ZORA.indd 5 2014-11-18 오전 11:41:27

| 6 |
Safety Instructions
Warning
Do not place your hands or
metal objects below the
washer while the washer is
running.
Violations may cause personal
injuries.
Prohibit children from
operate the washer. Do not
let children stand on the
washer or insert their head
into the tub at any time.
Violations may cause personal
injury, burn, or electric shock.
Do not insert hands, sticks
or metal objects into the tub
or touch laundry during
operation.
Violations may cause personal
injuries.
With 'Door Locked', do not
open the door by force.
Violations may destroy the door
or lock, causing technical
problems.
Prevent children from having
their hands jammed in the
door and approaching the
washer.
Violations may cause personal
injuries.
Children or people who are
not well-informed of use
method must not use the
washer.
Violations may cause burn,
electric shock, or injury.
Do not press the button with
sharp object.
Violations may cause electric
shock.
Install the washer where the
electric outlet is easily
accessible. Unplug the
power cord if the washer is
not to be used for a long
time.
Violations may cause electric
shock, short circuit, or fire. Hold
the plug firmly when unplugging
the power cord.
DWD-CV701PC_Cotton_ZORA.indd 6 2014-11-18 오전 11:41:28

| 7 |
Caution
Turn on the tap to check for
leaks before use.
Improper connection may cause
leaks.
Do not operate the washer
with the detergent or
softener container detached.
Detachment of the detergent or
softener container causes water
leaks during operation. Please
close the detergent and softener
containers tight.
Leaks may cause personal
injuries.
Install the washer on a solid
wall and even.
Violations may cause abnormal
vibrations or noise.
Do not stand on the washer
or place a heavy item on it.
Violations may destroy the
washer or cause personal
injuries.
Prevent children from hanging on
the washer. Violations may
cause injuries.
Prevent pets and animals
from entering the washer
tub.
Violations may cause injuries.
Do not place magnets beside
the cap or the washer during
operation.
Violations may cause
malfunctioning of 'Door Lock
Sensor' and personal injuries
accordingly.
Do not use laundry net for
wash.
Violations may cause abnormal
vibrations, which can lead to
damage wall or cause personal
injuries.
Contact the service center
and do not operate the
washer when it is slanted or
out of horizontal.
Violations may cause injuries.
Safety Instructions
DWD-CV701PC_Cotton_ZORA.indd 7 2014-11-18 오전 11:41:28

| 8 |
Safety Instructions
Caution
Remove any detergent
residue or contaminants on
the washer with a wet soft
cloth.
Remaining contaminants may
deform plastic parts.
Turn off the tap after use.
It aims to prevent leaks caused
by poor inlet hose connections.
Do not use the washer to
wash non-clothing items.
(Footwear, potato, cabbage,
kelp, etc.)
Violations may cause abnormal
vibrations, damage the washer or
cause personal injuries.
Do not wash waterproof
clothes and items such as
raincoat, car cover, and
sleeping bags.
Violations may cause abnormal
vibrations during spin, which may
lead to personal injuries.
Violations may cause abnormal
vibrations during wash, which may
lead to damage the wall, floor, or
clothing and cause part abrasion.
Close the door carefully to
prevent laundry from getting
jammed in the door.
It may cause damage to clothes
or malfunction.
Press the Start button after turning
off the tap and then slowly turn it
on when the water supply
resumes or the inlet hose is
reconnected (or when resuming
the use of washer after a long-term
suspension)
The high air pressures built in inlet hose
or water pipes may damage the washer,
causing leaks or personal injuries.
Put detergent and softener
in detergent and softener
containers separately.
Confusion or mixture may
prevent laundry from being
washed properly.
Remove all liquid detergent
and fabric softener in the
washer when relocating it.
Violations may cause liquid leaks
and malfunctions.
DWD-CV701PC_Cotton_ZORA.indd 8 2014-11-18 오전 11:41:28

| 9 |
- This washer is available for use with cold water only.
Do not connect the inlet hose to the hot water tap.
Connect the drain hose to the drain.
- Check that the drain hose is tightly connected.
- A minor water leak may occur during installation or the initial cycle. The leak is
caused not by a malfunction or a mechanical problem but by the remnant for
functional test performed at the manufacturing plant.
1
Connect the inlet hose and turn on the tap.
- Check whether any leaks occur around the hose guide or inlet hose connection.
Plug in the power cord.
- Check the grounding procedure to prevent electric shocks.
Preparation
Caution
2
3
DWD-CV701PC_Cotton_ZORA.indd 9 2014-11-18 오전 11:41:29
