ACCESS
CONTROL
QUICK INSTALL
GUIDE
Please read this document before installation
V1
Official UK distribution partner

2Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
Dahua access controllers can be used in multiple installations scenarios with options for one door, two door or four door controllers
and one way or two way access.
The example below is based on a one door one way system.
Lock
Reader
Push Exit
Emergency Exit
INOUT
Controller
One Way Access Example
Reader
Lock
WIRING CONFIGURATION - ACS CONTROLLERS

3
The number of connections available varies between controller models but all controllers have the same basic confi guration. Each
controller can support at least one reader per door. Each door can also support push to exit, door sensor, lock output or an additional
reader for two way systems.
When connecting Dahua readers to Dahua controllers, Wiegand connections are not required if RS485 is used.
Reader Connections
Purple Cable RS485+ connection to controller
Power Input
DC/12V
Reset
12v
12v
12v
12v
GND
GND
GND
GND
Case
Case
Case
Case
D1
D1
D1
D1
D0
D0
D0
D0
LED
LED
LED
LED
485-
485-
GND
GND
GND
COM1
COM3
COM2
COM4
GND
GND
GND
485+
Push 2
OUT-
Push 3
Push 4
485-
485-
485+
485+
GND
Push 1
ALM-N
NC1
NC3
NC2
NC4
485-
SR1
OUT+
NO1
NO3
NO2
NO4
ADDRESS
DEFEND
SR2
SR3
SR4
485+
Yellow Cable RS485- connection to controller
Brown Cable Wiegand LED connection to controller
Green Cable Wiegand D0 connection to controller
White Cable Wiegand D1 connection to controller
Blue Cable Wiegand case/tamper connection to controller
Black Cable Reader ground connection to controller
Red Cable Reader 12v positive connection to controller
Connections
485+
LAN
TCP/IP
485 Card
Reader
485
Communication
No.1
Door
Card
Reader
Unlock
+
Door
Sensor
Unlock
+
Door
Sensor
Lock
Control
Output
Lock
Control
Output
No.1
Door
Electric
Lock
No.3
Door
Electric
Lock
No.2
Door
Electric
Lock
No.4
Door
Electric
Lock
Alarm Input
Alarm Output
No.2
Door
Card
Reader
No.3
Door
Card
Reader
No.4
Door
Card
Reader
Platform
Platform
Card
Reader
Power
Wiegand
Card
Reader
As
Above
As
Above
As
Above
No.1 Door Unlock Button
No.1 Door Unlock Button
No.1 Door Unlock Button
No.1 Door Unlock Button
No.1 Door Sensor Input
No.1 Door Sensor Input
No.1 Door Sensor Input
No.1 Door Sensor Input
Power Off Unlock
Lock 12v Input
Power Off Lock
As
Above
As
Above
As
Above

4Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
The ASI1212D is a standalone two way controller with built in keypad, card & fi ngerprint readers. This unit supports a single door with
the option to add an external reader for use as a two way system.
The example below is based on a one way system.
Stand Alone Access Example
Lock
Reader
Push Exit
Emergency Exit
INOUT
Controller
Reader
Lock
WIRING CONFIGURATION - ASI1212D

5
Purple Cable RS485+
Yellow Cable RS485-
Brown Cable Wiegand LED
Green Cable Wiegand D0
White Cable Wiegand D1
Blue Cable Wiegand Tamper
Black Cable 12v - Power Output
Red Cable 12v + Power Output
Connector 2 (for external reader)
When connecting Dahua readers to Dahua controllers, Wiegand connections are not required if RS485 is used.
Purple Cable RS485+
Yellow Cable RS485-
Brown Cable Alarm Input Ground
Green Cable Alarm Input
White Cable Alarm Output
Blue Cable Alarm Output Ground
Black Cable Bell-
Red Cable Bell+
Connector 3
RJ45 Connector Network Connection
Connector 4
Purple Cable Push to Exit
Yellow Cable Ground (Push to Exit / Door Sensor)
Brown Cable Door Sensor
Green Cable Lock Output Normally Open
White Cable Lock Output Normally Closed
Blue Cable Lock Output Common
Black Cable 12v - Power Input
Red Cable 12v + Power Input
Connector 1
Connections

6Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
Confi guring the access control system requires a computer with the ACS tool installed.
To install the ACS tool on a PC follow the steps listed below.
1. Go to www.cop-eu.com
2. Click on the Access Control category
3. Go to Controllers > click on your model of controller
4. Select the Downloads tab from underneath the product picture,
then click on Dahua toolbox and run the installer
Once the Toolbox has been installed an account must be registered before the confi guration tools can be installed.
After installing and registering an account on Dahua toolbox, scroll down the list of applications and fi nd ACSConfi g. Click the
install buttton to install the tool on your computer.
Once the Toolbox has been installed an account must be registered before the confi guration tools can be installed.
After installing and registering an account on Dahua toolbox, scroll down the list of applications and fi nd ACSConfi g. Click the
install buttton to install the tool on your computer, once installed click open to launch the tool.
Note: Make sure the computer running the tool is connected to the same LAN network as the ACS controller.
Any ACS controllers discoverable on the network will now be displayed within the search results, to modify the network confi guration
of the ACS controller, click to enter the new network confi guration. Click OK to save the setting.
Default Settings
Username: admin
Password: 123456
IP Address: 192.168.0.2
of the ACS controller, click to enter the new network confi guration. Click
ACS NETWORK CONFIGURATION

7
The ASI1212D features a screen interface that can be used to confi gure basic settings
including network confi guration.
To adjust the network confi guration of the unit, follow the steps below.
1. Press OK to display the admin login screen.
Enter the admin password followed by OK.
Default Settings
Username: admin
Password: 88888888
IP Address: 192.168.1.108
2. Press the Up/Down arrows to cycle through
the menu options. Highlight Settings and
press OK.
3. Select Network Setup and press OK. 4. Select IP Setup and press OK.
5. Modify the network settings accordingly and
press OK to save the changes.
ASI1212D NETWORK CONFIGURATION

8Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
Both ACS controllers and the ASI1212D can be programmed via the Smart PSS software. If Smart PSS is not currently installed on the
PC then this can be installed using Dahua Toolbox.
When fi rst opening SmartPSS, the software will prompt for a password to be created, this password is used for logging into the
software only and is not the password of the controller.
It is important to keep this password safe as failure to remember the password will result in not being able to run the SmartPSS
software. The second step is to fi ll out the security questions and answers, they are used to reset the password if it is forgotten.
Once a password has been confi gured, login using the chosen password, the default username is admin.
From the home screen select the Devices option.
Smart PSS Initialisation
CONFIGURATION VIA SMART PSS

9
To add a controller, click the Add button.
Enter the connection details for the controller such as IP address, Username & Password, the default port number is 37777,
click Save to store the connection details.
The added controller should now show in the device list with the current status as online.
Adding a Controller
Note: If the device is not found, please refer to page 6.

10 Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
All access control features are located within the Access section of the Smart PSS software. To enter this section, select the Access
icon from the Smart PSS home screen.
Once the access section has been opened the following screen will be shown. The number of doors displayed depends on the
controller type, if a four door controller has been added then four doors will be displayed.
Console
User Menu
Access Control
Menu
Event Menu
Log
Door Selection
Control
All Doors
Realtime
Access Log
Last Logged
Users Details
Toggle
View
Access Menu

11
Users can be added to the system and access levels assigned with the Access section of the SmartPSS software. To add a new
user follow the steps below.
Enter the user menu by clicking on the User Menu icon .
To add a user click the new user button at the top of the SmartPSS interface.
Input the users details including ID, name, department, password and valid date range. The ID fi eld is a unique ID given to each
user, no two users can share the same ID.
When adding a Mifare card or fob to a user, fi rst connect the ASM100 enrolment reader to the computer via USB. Alternatively, any
card readers connected to the controller can be used to scan a user card for enrolment purposes. To choose the type of reader
to be used, select a reader device from the Card Issuer dropdown box.
Once the Card No fi eld shows the message: “Card Reader Ready”, the users card can be scanned which will assign the unique
card ID to the user. Left click the Card No fi eld, an audilble tone can be heard. Place the card over the reader, another audible
tone can be heard which confi rms the reader has scanned the card successfully. The unique card ID is now displayed in the Card
No fi eld.
Users can be organised by department, to add a new department right click the area in the left window pane and select Add
Department. Enter a name for the department and click Save.
Adding Users

12 Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
Select the card type from the dropdown box, there are multiple types available:
If using keypad entry, enter an unlock password for the new user. Passwords must be numerical and a maximum of 6 digits.
General Standard User
VIP VIP User
Guest Temporary User, when used a limit can be set to how many times the
card can be used
Patrol Used for patrol logging without unlocking doors
Blacklist Used to alert when a specifi c user accesses an area
Duress A secondary card given to a user in case of duress. When
scanned an alert can be triggered
Enter how long the new user is required access. A permanent user could be given a number of years, whereas an agency or
temporary contract user could only be given a period of months or weeks.
If required an image of the user can be uploaded to the Smart PSS software. This image will then appear along with the user details
in the access console when the user accesses a given area.
If using biometric fi ngerprint readers, select the Fingerprint Info tab to add a user fi ngerprint.
In the Fingerprint Device dropdown box, select the fi ngerprint reader that will be used to add the users fi ngerprint. This can be the
ASM102-V2 USB reader or a fi ngerprint reader that is part of the system.
Click the Collect button to start recording the users fi ngerprint and follow the onscreen prompts.
1. Place fi nger on fi ngerprint sensor 2. Remove fi nger 3. Place fi nger on fi ngerprint sensor

13
4. Remove fi nger 5. Place fi nger on fi ngerprint sensor
The fi ngerprint should have now been recorded successfully, if the fi ngerprint recording fails, run through the process again making
sure that the user places their fi nger tip over the sensor fl at & central to the sensor.
Select the details tab to enter additional user information such as Gender, Title, DOB & contact information. It is also possible to
enter specifi c times that the user can access areas.
Once all the relevant user information has been entered, select the Finish button to save the user.

14 Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
Before assigning user access, all doors must be added to a door list. The door list groups doors together so users can be granted
access to a single door list or multiple lists.
From the dropdown menu, select Access Level.
Click the add button to create a new door list.
Enter a name for the doorlist, a timezone can also be selected to limit access to specifi c times. Timezones must fi rst be confi gured
by selecting Timezone from the access menu.
Select the access menu icon.
Select the controllers and doors that are to be added to the list, click OK to save the list.
Access Levels

15
Now that the doors have been assigned to a list, it is possible to assign user access.
From the dropdown menu, select User Right.
Select a department from the left window pane to display the users from that department, click on the icon to adjust the
users access rights.
Select the access menu icon.
Select a department from the left window pane to display the users from that department, click on the icon to adjust the
Select which doors the user shall have access to by select the applicable door lists. Click OK to save the setting.

16 Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
There are multiple parameters that can be adjusted when confi guring the operating mode of each door.
From the left window pane, right click the door to confi gure and select Door Confi guration
Select the console icon.
Door Door name.
Reader 1 First readers name and direction. Click direction icon to
toggle between enter or exit.
Reader 2 Second readers name and direction. Click direction
icon to toggle between enter or exit.
Status Change operating mode, options are Normal, Always
Open, Always Closed.
Unlock Hold
Interval
The amount of time in seconds that the relay output will
trigger for.
Close Timeout When a door sensor is installed, this is the amount of time
the door must be left open before an overtime event
occurrs.
Holiday
Timezone
A timezone can be confi gured and selected here to
create a specifi c time period where the door will remain
locked such as weekends.
Keep Open
Timezone
A timezone can be confi gured and selected here to
create a specifi c time period where the door will remain
unlocked.
Keep Closed
Timezone
A timezone can be confi gured and selected here to
create a specifi c time period where the door will remain
locked.
Unlock Mode Select the operating mode of the door readers. It is possible to select a single authentication method
supported by the reader or multiple.
Unlock Mode Examples
• Card/Password/Fingerprint would require only one of these methods be used to unlock the
door.
• Card + Password would require that the user fi rst scans their card, then enters their password
before the door would unlock.
Alarm When a door sensor is installed, events can be confi gured to alert the operator of Smart PSS.
Intrusion Event that occurs if the door is forced open.
Overtime Event that occurs if the door is left open.
Duress Event that occurs if a user is under duress.
Door Sensor Select whether a door sensor is installed.
Door Confi guration

17
Anti-passback can be used to prevent users from passing their card back to a second user or tailgating behing another user when
exiting an area (if tailgating, the user will be unable to regain access through the entrance as they will still be logged as in the area
by the system).
To confi gure anti-passback follow the steps below:
From the dropdown menu, select Anti Passback.
Select the access menu icon.
Click the Add button.
Select a controller from the dropdown list & enter a reference name.
Select the anti-passback confi guration from the available options, click OK to save and apply the setting.
Reader 1 & 2 Antipass Reader 1 enter, Reader 2 exit.
Reader 3 & 4 Antipass Reader 3 enter, Reader 4 exit.
Reader 1,3 & 2,4 Antipass Readers 1 & 3 enter, Readers 2 & 4 exit.
Reader 1,3 & 2,4 Antipass Readers 1 & 3 enter, Readers 2 & 4 exit.
Reader 1 & 2,3 Antipass Reader 1 enter, Readers 2 & 3 exit.
Reader 1 & 2,3,4 Antipass Reader 1 enter, Readers 2, 3 & 4 exit.
Anti-Passback

18 Tel: [phone] | Fax: [phone] | Email: [email protected] | Online: www.cop-eu.com
It is possible to integrate Dahua access control with Dahua CCTV products, enabling the ability to monitor both systems from a
single platform.
Cameras can be monitored by selecting the View button from the access console page and selecting the cameras to view
from the left window pane.
When incorporating Dahua access control and Dahua CCTV within SmartPSS, it is possible to confi gure access control events to
push video alerts to the operator. This can be done by following the steps below.
Push Events with Video
Select the event menu icon.
From the left window pane, select the controller and door that will push events.
INTEGRATION WITH CCTV

19
From the middle window pane select the event group such as Alarm Event, Normal Event or Abnormal Event. In the list that
appears select the event type such as Unlock event, Intrusion event etc.
After selecting the event type, select the enable option at the top of the window and from the notify tab select whether
SmartPSS should play a sound or not when the event occurs.
Select the link video tab and then choose which cameras should be pushed when the event occurs by double clicking on the
cameras within the right window pane.
Select the defence time tab to set specifi c days and times that the push event should run. Once all settings have been
confi gured click the Save button.
When the event occurs a pop up will appear when the event takes place displaying the user information.

COP UK, Delph New Road, Dobcross, OL3 5BG England
