IP DES - Video entrance panel
with 10” touch display
with face recognition and finger print
Legend
1. Microphone
2. LED for the shooting field lighting
3. Camera
4. Light sensor
5. Display 10”(touch screen)
6. Home Page
7. Badge reader for door lock opening
8. Loudspeaker
9. Finger print reader
10. Locking screws
Front view
Video entrance panel with 10”touch display, double face recognition camera, fingerprint
reader and badge reader for access control functions.
Fromthe touchdisplay,itis possibletomakecallstotheapartmentsandthe guardstation
and enter the access code to release the lock. Configuration of different calling modes:
- Apartment code (Area - Building - Riser - Floor - Apartment)
- Numeric or alphanumeric codes for residents
- Address book with contact list
Enter the settings menu with a specific code for maintenance and for managing
the settings (e.g. backlight brightness, ring volume, speaker volume, touch volume,
screensaver time). Possibility to upload customized screensavers and advertisements
using the configuration software. The entrance panel can be PoE (power over Ethernet)
powered, or directly powered using power supply 375005. Flush mounted installation
using the dedicated box 375007.
Description
Dimensional data
A B C D
195 mm 430 mm 58 mm 12 mm
Voltage: 24Vdc
Maximum consumption: 0.65 A
C NC NO contact output: 125Vac/0.5A, 30Vdc/2A
Max. cable section for clamps: 0.8 mm²
Operating temperature: (- 40) – (+ 70) °C
Working temperature finger print: (- 10) – (+ 55) °C (± 2)
IP degree of protection: 54
IK degree of protection: 07
Camera resolution: 1080 p
Camera viewing field angle: H= 80°;V= 53°
Face recognition distance during daytime: 30 – 80 cm
Face Recognition Distance at Night: 30 – 50 cm
Badge reader Frequency: 13.56 MHz
Badge reader transmission power: < 42 dBuA/m @ 10m
Technical data
375007 Metal box for flush-mounting installation
Related items
1 42 23
5
6
7
9
10
88
2
ST-00001215-
374000
1
2
6
3
3
57
9
84
27/09/2023EN
IP DES - Video entrance panel
with 10” touch display
with face recognition and finger print
Rear view
Legend
1. Tamper switch
2. SD card
3. Connection clamp
4. Not used
5. Not used
6. Mounting bracket
7. USB Connector (not used)
8. RJ45 Connector (*)
9. Reset setting password and local access code
(*) This device does not support standard POE power supplies, but only POE
power supplies identified with item no. 375002. Connect the cat5/5e/6 FTP or
cat5/5e/6 UTP cable with ferrite supplied to the connector. The wrong wiring
of the Ethernet cable connecting the device to the Poe Switch 375002 could
damage the device itself. The RJ45 cable must be at least 200 mm long.
Connection clamps
LOCK+ electric door lock connection and control
(12V - 4A impulsive on 30 Ohm maximum)
LOCK-
SENSE door status signal input (dry contact)
GND system common ground terminal for third party connection
OPEN third party access control signal input for door lock opening
(+12Vdc pulse)
GND access control devices power supply
+12V
Door OPEN – GND local door lock release pushbutton connection
FIRE Linkage –
GND
local door lock release pushbutton connection for firealarm
system
NO
interlocked contactC
NC
DC24V additional power supply clamps (not polarized)
RS485A
Lift Control
terminal A
RS485B terminal B
GND system common ground terminal for
RS485 connection
Configuration
To use the device, it is necessary to configure it and create the Community structure
using the IP DES System software, following the steps below:
For further information, please refer to the IP DES System Software Manual and Small
video entrance panel manual, available for download from
www.homesystems-legrandgroup.com website
Step
Step
Step
Step
Step Community customisation
Step
Step
Step
Step
Step
Step
Registration of the Community on the installer’s Cloud
Saving of passwords
CommunityVLAN network creation
Community structure definition
Community structure creation
Device MAC address registration
Forwarding of the address book to the DES Server
Installation of the devices
Activation of the devices
System test
01
02
03
04
05
06
07
08
09
10
11
3
