TimeTec FingerTec Face ID 6 User manual

4 feet / 1.5 meter
(recommended)
Step 1
Determine the Installation Location
• Avoid installing the terminals in locations that have contact with
strong light source (e.g direct sunlight, spotlight, fluorescent
light, etc)
• Avoid installing the terminals in locations with high moisture or
condensation levels in the air
• The recommended installation height of the terminal from the
ground to the camera is 1.5 meter.
Step 2
Mount Terminal on a Wall
1. Avoid strong sunlight
2. Install the terminal 1.5m from the ground level (measure the
height from the ground to the face camera)”
After measuring the height accordingly and make relevant markings on
the wall, drill the screws into the wall to secure the back plate.
Attach the terminal to the back plate and tighten the screws.
Refer to Appendix II for dimensions and measurements of installation.
Installation Guide
Hybrid Face Recognition Access Device
Step 3
Wiring for Power Supply
Use power cables (black and red) to connect to a linear power sup-
ply with specifications of 12VDC 3A to Power Port.
TimeTec © 2022, All Rights Reserved • 122022
Indoor Use Avoid Glass Avoid Direct Far Away Keep Effective
Refraction Sunlight Heat Source Distance
And Exposure 0.3-2.5m
Step 4
Setting Up Data Communications
(Skip this step if you are using USB ash disk to transfer data)
The data communication ports are positioned at the rear of the ter-
minal, please refer to the diagram shown on Step 3 to determine the
wiring. Plug the communication jacks (TCP/IP) to the corresponding
ports.
TCP/IP – LAN Connection
For TCP/IP connection, plug the special RJ45 jack into the TCP/IP
(LAN) Port of the terminal. Connect the other end (normal RJ45 jack)
to the local area network hub or a PC. Configure the device ID, IP ad-
dress, subnet mask and Gateway in the terminal (refer to the hard-
ware user manual for details).

Diagram1 • Normally Close (NC)
Diagram 2 • Normally Open (NO)
Diagram 3 • Other Accessories
Use either Type NO or Type NC alarm device.
Door Lock Connectors
The terminal will trigger the alarm output in the following situations:
• Door forced open (A door sensor must be installed)
• Door open time out (A door sensor must be installed)
• Terminal has been illegally dismantled
Door Sensor (SEN-GND)
Release Button (BUT-GND)
Dry Contact
(Independent power supply for door lock)
• NO type door lock (NO1-COM)
• NC type door lock (NC1-COM)
Power Contact
(Using power from terminal to power on door lock)
• NO type door lock (NO1-GND)
• NC type door lock (NC1-GND)
Dry Contact (independent power supply for door lock)
• NO type door lock (NO1-COM)
• NC type door lock (NC1-COM)
Power Contact (using power from terminal to power on door lock)
• COM1 - +12V
Alarm System
WIRING PORT USAGE
SEN
GND
BUT
NO1
NC1
COM
AL+
AL-
AUX
GND
SEN
GND
BUT
NO1
COM
NC1
AL+
AL-
Release Button
EM Lock
Emergency
Break Glass
Overwrite Key
Switch
+
_
1
3
B
D
DC12V 3A +
_
+12V
GND
AUX
GND
SEN
GND
BUT
NO1
COM
NC1
AL+
AL-
Release Button
EM Lock
Emergency
Break Glass
Overwrite Key
Switch
+
_
2
3
A
C
DC12V 3A +
_
+12V
GND
AUX
GND
SEN
GND
BUT
NO1
COM
NC1
AL+
AL-
DC12V 3A +
_
+12V
GND
Door Sensor
Alarm Device
Step 5
Finalizing the installation
1. Check that all cable connections are done correctly.
2. Attach the terminal to the corresponding back plate, tight-
en the screws to fix the terminal on a wall.
3. Switch on the power to the terminal.
4. Start using it.
Other Accessories
Note: All Accessories are offered at http://accessory.fingertec.com
AdapTec Plus
The AdapTec Plus is a 12VDC power supply inclusive of a 110~240VAC
switching linear power. The AdapTec Plus supplies 12VDC power to
the FingerTec terminal and door lock system as well as charges a
12VDC 7.0Ah backup battery simultaneously. During an event of a
power failure, the back up battery automatically provides power to
the terminal and maintains the door lock system. The AdapTec Plus
also prevents a secured door from being opened if it has been tam-
pered with.
Door Lock Accessories
FingerTec offers various door locks accessories to complement the
door access product range.
Appendix I
Power Supply & Door Lock System Wiring
Diagrams
Appendix II
Terminal Dimensions and Measurements
72mm 23mm
158mm
