Dahua Technology ASR1200E User manual

ASR1200E ASR1200E-D
www.dahuasecurity.com
Features
· Wiegand34(26 oponal) bits RS-485 protocol
· 13.56MHz(Mifare)
· 125KHz(EM-ID)
· Water-proof design
· Red, blue and green indicator LEDs
· Surface mounted installaon
ASR1200E ASR1200E-D
Water-proof RFID Reader
© 2016 Dahua . All rights reserved. Design and specifications are subject to change without notice
Rev 001.001
Wiegand/RS485
IP67
·Connect to third party controller
by wiegand protocol;
·RS485 support longer distance;
Wiegand/RS485
IP67
·Outdoor use;
Overview
The reader support wiegand, it means you can integrate it with the third party controllers.
Certainly, any Dahua access controller can connect to the reader by using wiegand or RS485.
For RS485, it support 100m distance when power supply from controller. If power supply
separate, it can extend to 1000m. The slim and water-proof design can make it used in any
environment.

Technical Specificaon
Mode ASR1200E ASR1200E-D
System
Main Processor 8 Bit
Read
Read Format 13.56MHz 125KHz
Read Range 3-6cm (max.)
Reading time <0.1s
Funcon
Water-proof IP67
Interface
To Controller RS485,Wiegand 34(26 optional)
General
Beep Tone Buzzer
Ingress protecon IP67, water resistant
Power Supply 9-15VDC/100mA
Working Environment -30°C~60°C
Working Humidity ≤95%
Dimension(W×D×H) 96mm*43mm*17mm
Weight 0.1Kg
Dimensions
© 2016 Dahua . All rights reserved. Design and specifications are subject to change without notice
Rev 001.001
www.dahuasecurity.com
Connecon
RS485 wiring
AWG 24, twisted-pair cable;
RS485: 1000m;
Power: 100m;
Wiegand wiring
AWG 24, twisted-pair cable;
Wiegand: 40m;
Power: 100m;
LED cable control the reader
buzzer and LED light;
