Dahua Technology PFS3102-1T User manual

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
Dahua Single, 4, 8-Port Fiber Transceiver User’s Manual
V1.0.0
Dahua Technology CO., LTD
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
Important Safeguards and Warnings
Please read the following safeguards and warnings carefully before using the product in order to avoid
damages and losses.
Attention:
Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric
shock.
Do not install the device at position exposed to sunlight or in high temperature. Temperature rise
in device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee safety under load and
earthquake. Otherwise, it may cause device to fall off or turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise, temperature in
device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire, explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly. Otherwise, it may cause
fire or electric shock.
Special Announcement:
This manual is for reference only.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
Before Start
Copyrights
© 2014 Dahua Technology. All rights reserved.
Any or full contents of the user’s manual can not be copied, transmitted, distributed without the prior
written notice of Dahua Technology (herein after “Dahua”).
Dahua or the third party may reserve the right of the product described in this user’s manual.
Without the prior written approval of the corresponding party, any person can not (including but not
limited to) copy, distribute, amend, reverse compile, disassemble, engineering, rent, reverse
engineer, reverse compile or disassemble the HDCVI golden test software.
Trademark
, , , , are the trademarks or registered
trademarks of the Dahua technology.
All trademarks and registered trademarks mentioned are the properties of their respective owners.
Update and revision
This user’s manual for reference only. Slight difference may be found in the user interface.
All the designs and software here are subject to change without prior written notice.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website or contact your local retailer for more information.
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
Table of Contents
1Product Overview............................................................................................. - 1 -
1.1 Features............................................................................................................................- 1 -
1.2 Typical Application............................................................................................................- 1 -
2Device Structure............................................................................................... - 3 -
2.1 Single-port 1000M Fiber Transceiver...............................................................................- 3 -
2.1.1 Front panel................................................................................................................- 3 -
2.1.2 Upper Cover..............................................................................................................- 4 -
2.2 4-Port 1000M Fiber Transceiver.......................................................................................- 5 -
2.2.1 Front panel................................................................................................................- 5 -
2.2.2 Upper Cover..............................................................................................................- 6 -
2.3 8-Port 1000M Fiber Transceiver.......................................................................................- 6 -
2.3.1 Front panel................................................................................................................- 6 -
2.3.2 Upper Cover..............................................................................................................- 8 -
3Installation Guide ............................................................................................. - 9 -
Appendix 1 Technical Specifications.................................................................. - 10 -
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 1 -
1 Product Overview
1.1 Features
Common Features:
2-layer industrial level switch.
Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards
MAC automatic learning and aging, MAC address list capacity is up to 8K.
All ports automatic adapt to MDI/MDIX mode.
Industrial level wide temperature design.
Adopt metal structure.
Support DC 12V power supply.
Individual Features:
Single-port fiber switch supports 1 100M/1000M self-adaptive SFP fiber port and 1
10/100M/1000M self-adaptive RJ 45 port.
4-port fiber switch supports 1 100M/1000M self-adaptive SFP fiber port, 1 10/100M/1000M
self-adaptive RJ 45 port and 4 10/100M self-adaptive RJ 45 ports.
8-port fiber switch supports 1 100M/1000M self-adaptive SFP fiber port, 1 10/100M/1000M
self-adaptive RJ 45 port and 8 10/100M self-adaptive RJ 45 ports.
1.2 Typical Application
See Figure 1-1 for the typical networking scene.
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 2 -
Figure 1-1
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 3 -
2 Device Structure
2.1 Single-port 1000M Fiber Transceiver
2.1.1 Front panel
The front panel is shown in Figure 2- 1.
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 4 -
Figure 2- 1
Refer to Sheet 2-1 for more details.
SN
Name
Note
1
10/100/1000 Base-T
10/100/1000M self-adaptive RJ 45 port
2
100/1000 Base-X
100/1000M self-adaptive SFP fiber port
3
Link/Act
Fiber port status indicator light
4
PWR
Power indicator light
Sheet 2-1
2.1.2 Upper Cover
See Figure 2-2 for the device power port, which supports DC 12V power supply.
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 5 -
Figure 2-2
2.2 4-Port 1000M Fiber Transceiver
2.2.1 Front panel
The front panel is shown in Figure 2-3.
Figure 2- 3
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 6 -
Refer to Sheet 2-2 for more details.
SN
Name
Note
1
10/100 Base-T
4 10/100M self-adaptive RJ 45 ports
2
10/100/1000 Base-T
10/100/1000M self-adaptive RJ 45 port
3
100/1000 Base-X
100/1000M self-adaptive SFP fiber port
4
Link/Act
Fiber port status indicator light
5
PWR
Power indicator
Sheet 2-2
2.2.2 Upper Cover
See Figure 2-4 for the device power port, which supports DC 12V power supply.
Figure 2-4
2.3 8-Port 1000M Fiber Transceiver
2.3.1 Front panel
The front panel is shown in Figure 2-5.
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 7 -
Figure 2-5
See Sheet 2-3 for more details.
SN
Name
Note
1
10/100 Base-T
8 10/100M self-adaptive RJ 45 ports
2
10/100/1000 Base-T
10/100/1000M self-adaptive RJ 45 port
3
100/1000 Base-X
100/1000M self-adaptive SFP fiber port
4
Link/Act
Fiber port status indicator light
5
PWR
Power indicator light
Sheet 2-3
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 8 -
2.3.2 Upper Cover
See Figure 2-6 for the device power port, which supports DC 12V power supply.
Figure 2-6
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 9 -
3 Installation Guide
The fiber transceiver supports guide rail installation.
Hang the hook of fiber transceiver on the slider, press the fiber transceiver to make the buckle stuck into
the slider, see Figure 3-1 for more details.
Note:
Both single-port 1000M fiber transceiver and 4-port 1000M fiber transceiver support the slider with
the width of 28mm.
8-port 1000M fiber transceiver supports the slider with the width of 38mm.
Figure 3-1
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 10 -
Appendix 1 Technical Specifications
Technical
parameters
IS2002
IS1106
IS1110
Physical port
Business port
1*100/1000 Base-X、
1*10/100/1000 Base-T
1*100/1000 Base-X、
1*10/100/1000 Base-T、
4*10/100 Base-T
1*100/1000 Base-X、
1*10/100/1000 Base-T、
8*10/100 Base-T
Technical index
Exchange
capacity
2.20Gbps
4.80Gbps
5.60Gbps
Packet
forwarding
rate
1.64Mpps
3.57Mpps
4.17Mpps
Exchange
mode
Store & forward
Store & forward
Store & forward
MAC study
MAC auto study,
address
list capacity 8K
MAC auto study,
address list capacity 8K
MAC auto study,
address list capacity 8K
Common parameters
Indicator light
Power indicator, fiber
port status indicator
Power indicator, fiber
port status indicator
Power indicator, fiber
port status indicator
Power
DC12V
DC12V
DC12V
Power
consumption
≤3W
≤3W
≤3W
Application
humidity
10%～90%
10%～90%
10%～90%
High & low
temperature
﹣40℃～70℃
﹣40℃～70℃
﹣40℃～70℃
Weight
420g
480g
540g
Dimension
150mm×100mm×30mm
150mm×100mm×30mm
150mm×100mm×42mm
Поставщик систем безопасности TELECAMERA.RU

Dahua Single, 4, 8-Port Fiber Transceiver User’s manual
- 11 -
Note
This user’s manual is for reference only.
Slight difference may be found in user interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
