Dahua DH-SP-PIXX User manual

DH-SP-PIXX
User’s Manual
V1.0.0
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

User’s Manual
I
Foreword
General
This manual introduces the installation, functions and operations of the device (hereinafter referred to
as "the Device"). Read carefully before using the device, and keep the manual safe for future reference.
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, reductions in performance, or
unpredictable results.
TIPS Provides methods to help you solve a problem or save time.
NOTE Provides additional information as a supplement to the text.
Revision History
Version Revision Content Release Time
V1.0.0 First release. May 2023
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number.You need to be in compliance with your local privacy protection
laws and regulations to protect the legitimate rights and interests of other people by implementing
measures which include but are not limited: Providing clear and visible identification to inform people
of the existence of the surveillance area and provide required contact information.
About the Manual
The manual is for reference only. Slight differences might be found between the manual and the
product.

User’s Manual
II
We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
There might be errors in the print or deviations in the description of the functions, operations and
technical data. If there is any doubt or dispute, we reserve the right of final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
If there is any uncertainty or controversy, we reserve the right of final explanation.

User’s Manual
III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the device, hazard prevention, and
prevention of property damage. Read carefully before using the device, and comply with the
guidelines when using it.
Transportation requirements
Please transport the equipment within the allowed humidity (≤ 95% RH) and temperature range (-10 ℃
to +50 ℃).
Storage requirements
Please store the equipment within the allowed humidity (≤ 95% RH) and temperature range (-10 ℃to
+50 ℃).
Installation requirements
WARNING
To avoid electric shock to the human body or damage to the product, please turn off the AC
power supply before connecting (non plug and play) devices each time.
Avoid using this product in environments with high or low temperatures (operating temperature:
-10 to 50 degrees Celsius; humidity: 10% to 95%; storage temperature: -20 to 70 degrees Celsius).
Do not subject the product to strong impact or vibration, as it may cause equipment malfunction
or damage.
When moving the product, be sure to unplug the AC power supply.
NOTE
Do not install the device in a damp place.

User’s Manual
IV
Maintenance Requirements
WARNING
Do not use a damp cloth to clean your computer to prevent liquid from dripping into the
computer and causing it to burn.
To avoid unnecessary damage to the product caused by frequent switching on and off, wait at
least 30 seconds before turning on the machine.
NOTE
Please do not disassemble the equipment randomly. Professional personnel must be present for
maintenance and installation.

User’s Manual
V
Table of Contents
Foreword............................................................................................................................................................ I
Important Safeguards and Warnings............................................................................................................. III
1 Summarize ..................................................................................................................................................... 1
2 Product Introduction .................................................................................................................................... 1
Product Configuration ............................................................................................................................................................. 1
IO interface ................................................................................................................................................................................... 2
Cybersecurity Recommendations............................................................................................... 4
Product Warranty Card..................................................................................................................................... 7

User’s Manual
1
1Summarize
Thank you for choosing our products.
Before using your product, please make sure your packaging is complete, if there have been damaged or you
find any shortage, please contact your agency as soon as possible.
OPS X 1
Product manual X 1
ATN Screw X 2
WiFi antenna X 2

User’s Manual
1
2Product Introduction
Product Configuration
Processor - DH-SP-PIXX
CPU - Intel® Tiger Lake Mobile Processor
Graphics - Intel® Iris® Xe Graphics
Storage
- 1 x M.2 2280 size for NVMe/SATA SSD
- 1 x 2.5’’ SATA Interface
Memory - 2 x SO-DIMM DDR4 3200 MHz，Max 32GB
Audio - Realtek ALC897 HD Audio IC
Front IO interface
- 1 x HDMI1.4
- 2 x USB3.1, 1 x USB2.0, 1 x Type-C (USB3.1)
- 1 x RJ45
- 1 x Line-out & MIC-In Two In One Connector
- 2 x Wi-Fi/BT ANT
- 1 x Power button
- 1 x Reset button
Rear IO interface
- 1 x 80pin：1 x HDMI 2.0 out，1 x USB3.0，2 x USB2.0
，
TTL
- 1 x 2.5/5.5 DC IN JACK
Wireless - 1 x M.2 2230 WIFI/BT Module
Network - Realtek Gigabit Ethernet

User’s Manual
2
Watchdog - Support
Power input - 12-19V DC IN
Environmental
requirement
- Working temperature / storage temperature: -
5 ~
45 ℃/ - 20 ~ 70 ℃
- Working / non working humidity:
10% ~ 90% non
condensing / 5% ~ 95% non condensing
OS - Support Windows10 / Windows11 / Linux
Dimensions - 119 x 180 x 30 mm
IO interface
Front IO interface
Rear IO interface
• WIFI-1/2：WIFI/BT antenna
• POWER BUTTON: Power Switch Button
• LINE_OUT&MIC-IN Two in One Connector: Audio output interface with mic
• LED: (top) hard disk indicator, (bottom) power indicator
• TYPE_C: TYPE_ C port
• RESET: Reset button
• Lock: Anti-theft hole

User’s Manual
3
• HDMI: High definition multimedia display interface
• USB3.1: USB3.1 port
• LAN: RJ-45 network interface
• USB2.0: USB2.0 port
• JAE 80PIN: 80 pin extension port
• DC IN: DC power interface

User’s Manual
4
Cybersecurity Recommendations
Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is
connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps
toward protecting and strengthening networks and networked appliances will make them less
susceptible to attacks. Below are some tips and recommendations from Dahua on how to create a
more secured security system.
Mandatory actions to be taken for basic device network security:
1. Use Strong Passwords
Please refer to the following suggestions to set passwords.
The length should not be less than 8 characters.
Include at least two types of characters; character types include upper and lower case
letters, numbers and symbols.
Do not contain the account name or the account name in reverse order.
Do not use continuous characters, such as 123, abc, etc.
Do not use overlapped characters, such as 111, aaa, etc.
2. Update Firmware and Client Software in Time
According to the standard procedure in Tech-industry, we recommend to keep your device
(such as NVR, DVR, IP camera, etc.) firmware up-to-date to ensure the system is equipped
with the latest security patches and fixes. When the device is connected to the public
network, it is recommended to enable the “auto-check for updates” function to obtain
timely information of firmware updates released by the manufacturer.
We suggest that you download and use the latest version of client software.
"Nice to have" recommendations to improve your device network security:
1. Physical Protection
We suggest that you perform physical protection to device, especially storage devices. For
example, place the device in a special computer room and cabinet, and implement well-done
access control permission and key management to prevent unauthorized personnel from
carrying out physical contacts such as damaging hardware, unauthorized connection of
removable device (such as USB flash disk, serial port), etc.
2. Change Passwords Regularly
We suggest that you change passwords regularly to reduce the risk of being guessed or cracked.
3. Set and Update Passwords Reset Information Timely
The device supports password reset function. Please set up related information for password
reset in time, including the end user’s mailbox and password protection questions. If the
information changes, please modify it in time. When setting password protection questions, it is
suggested not to use those that can be easily guessed.
4. Enable Account Lock
The account lock feature is enabled by default, and we recommend you to keep it on to guarantee
the account security. If an attacker attempts to log in with the wrong password several times, the
corresponding account and the source IP address will be locked.

User’s Manual
5
5. Change Default HTTP and Other Service Ports
We suggest you to change default HTTP and other service ports into any set of numbers between
1024–65535, reducing the risk of outsiders being able to guess which ports you are using.
6. Enable HTTPS
We suggest you to enable HTTPS, so that you visit Web service through a secure communication
channel.
7. MAC Address Binding
We recommend you to bind the IP and MAC address of the gateway to the device, thus reducing
the risk of ARP spoofing.
8. Assign Accounts and Privileges Reasonably
According to business and management requirements, reasonably add users and assign a
minimum set of permissions to them.
9. Disable Unnecessary Services and Choose Secure Modes
If not needed, it is recommended to turn off some services such as SNMP, SMTP, UPnP, etc., to
reduce risks.
If necessary, it is highly recommended that you use safe modes, including but not limited to the
following services:
SNMP: Choose SNMP v3, and set up strong encryption passwords and authentication
passwords.
SMTP: Choose TLS to access mailbox server.
FTP: Choose SFTP, and set up strong passwords.
AP hotspot: Choose WPA2-PSK encryption mode, and set up strong passwords.
10. Audio and Video Encrypted Transmission
If your audio and video data contents are very important or sensitive, we recommend that you
use encrypted transmission function, to reduce the risk of audio and video data being stolen
during transmission.
Reminder: encrypted transmission will cause some loss in transmission efficiency.
11. Secure Auditing
Check online users: we suggest that you check online users regularly to see if the device is
logged in without authorization.
Check device log: By viewing the logs, you can know the IP addresses that were used to log
in to your devices and their key operations.
12. Network Log
Due to the limited storage capacity of the device, the stored log is limited. If you need to save the
log for a long time, it is recommended that you enable the network log function to ensure that
the critical logs are synchronized to the network log server for tracing.
13. Construct a Safe Network Environment
In order to better ensure the safety of device and reduce potential cyber risks, we recommend:
Disable the port mapping function of the router to avoid direct access to the intranet devices
from external network.
The network should be partitioned and isolated according to the actual network needs. If
there are no communication requirements between two sub networks, it is suggested to use
VLAN, network GAP and other technologies to partition the network, so as to achieve the
network isolation effect.

User’s Manual
6
Establish the 802.1x access authentication system to reduce the risk of unauthorized access
to private networks.
Enable IP/MAC address filtering function to limit the range of hosts allowed to access the
device.
More information
Please visit Dahua official website security emergency response center for security announcements
and the latest security recommendations.

User’s Manual
7
Product Warranty Card
Hello! Thank you for purchasing Dahua Corporation products. Thank you very much!
In order to protect your legitimate rights and interests and relieve your worries, please purchase Dahua Shares'
products through legitimate channels. Dahua Shares will make a standard warranty service commitment to your
products and provide you with three guarantees of service when you need them. Please refer to Dahuatech's
official website (www.dahuatech. com) for relevant after-sales service policies and product warranty period.
Product malfunctions caused by the following circumstances are not covered by the warranty:
Exceeding the specified warranty period;
Damage caused by intentional or negligent use, including damage caused by improper use in an
abnormal environment or failure to follow the instructions;
Unexpected situations caused by force majeure (such as fires, floods, earthquakes, lightning strikes, etc.);
The deterioration of service conditions caused by social issues (such as unrest, war, strikes, government
regulation, etc.);
The inability to implement services caused by energy supply interruptions (such as electricity, water
supply, oil, etc.);
Failure or damage caused by third-party products, software, services, or behaviors;
The normal discoloration, wear, and consumption that occur during the use of the product can ensure
uninterrupted or error free normal operation;
Accessories (such as documents, product accessories, installation accessories, tools, etc.), consumables
(such as packaging boxes, batteries, or protective films that are worn out over time, unless caused by
material or process defects), and faults caused by structural components (such as protective shields,
brackets, etc.);
Unable to present valid product warranty certificates and valid original shopping invoices or receipts, the
original serial number label of the product has been altered, replaced, or torn, the product does not have
a serial number, or the product model or number on the warranty certificate does not match the actual
product;
Failure to use the product according to the instructions and operating manual provided with the product,
or failure to use the product for the intended function or environment, as confirmed by Dahua Group, in
any other case where the customer violates the operating manual;
The completeness and appearance status of the product are not within the scope of warranty. Customers
should inspect the product on the spot and raise objections to any discrepancies when accepting it.
NOTE：
1. Dahua Group does not guarantee customer data stored in its products or in any other form related to the
products, and customers are responsible for backing up the relevant data to prevent loss.
2. Dahua Corporation reserves the right to modify or cancel the warranty process at any time without prior
notice.

User’s Manual
8
Dahua Stock Customer Service official account Dahua Group's official WeChat account
Dahua Group 400 hotline: [phone]
Dahua Group Service Email: [e-mail]

User’s Manual
