Daihan Scientific VM-100 User manual

Man247 (18 Jul. 2017)
VM-100
Mini Vortex Mixer
Certifications by - - -
ISO 9001 Certified.
PL Insurance
User Manual
(Version 2.1.1)
written for
VM-100 model
“VM-100” Mini Vortex Mixer.
Sales & Basic A/S :
DAIHAN
-
Sci.com or
ALL
for
LAB.com
Shopping Mall

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 2/12
Table of Contents
Page
1. Precautions Before Use ………………………………………..…………….……………………3
2. Product Introduction …………………………………………………….…………………………. 4
3. Product Configuration ……………………………………………………………………………… 4
4. Product Installation ………………………..………………………………………….………. 5
5. Precautions when using …………………………………………………………………………… 6
6. Names of Each Part ………………………………………………………………………….. 9
7. Usage Instructions ……………………………………………………………………………. 9
8. Product Specifications …………………………………………………………………………….. 10
9. Maintenance and Management ………………………………………………………... 10
10. Troubleshooting …………………………………………………………………………………… 11
11. Quality Assurance ………………………………………………………………………………. 12

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 3/12
Precautions Before Use 1
Thank you for purchasing Mini Vortex Mixer This manual describes the performance,
usage, and handling precautions of the product you have purchased. Be sure to read
it carefully before using the product. There are warning signs below where user's
attention is required, so read and understand each warning sign and its meaning to
use it safely
Warning
Failure to follow the instructions may result in injury.
Caution
Failure to follow the instructions may result in product failure.
Notification
Do not disassemble or modify the product or use it for purpose other than
its intended function.
Danger of Explosion
If volatile, explosive chemicals are used, there is a danger of explosion.

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 4/12
Product Introduction 2
Mini Vortex Mixer can be conveniently used for various fields (fields of chemistry, life science,
medical science, pharmacology etc.).
The advantages of Mini Vortex Mixer are as follows:
nAchieved robust design and very stable grounding force
nRealized strong power, stable operation and low noise (Up to 3,200 rpm).
nMaximized the space efficiency of the workbench with the minimum size
nEnabled various speed controls and applied the automatic push start
function
nUp to 50ml tube available
nIn the event of an accident, this product may be compensated by products
liability insurance (PL insurance). (100 million won for person and object,
respectively)
Product Configuration 3
VM-100, Mini Vortex Mixer ......................................................................................... [ 1 ]
Power Adapter .......................................................................................................... [ 1 ]
Operation Manual ..................................................................................................... [ 1 ]

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 5/12
Product Installation 4
1. This product is manufactured to operate normally at rated voltage.
Check the voltage before installing the product.
2. Install the product on a firm and even floor.
3. Do not install in direct sunlight.
4. If water or organic solvents flow into the part of the controller of the product or
body, it may cause short-circuit, so do not install in such places.
5. Do not install in hazardous places.
6. Be careful not to drop the product when carrying it.
7. Do not lay the product down or shock it. Damage to the inside may occur.
8. Install at a place away from the corner to prevent it from falling off the testing
bench.
9. When installing and using the product, be sure to use the POWER Adapter
provided with the product.
¨Products liability insurance (PL insurance)
Daihan Scientific Co., Ltd. took out a products liability insurance (PL insurance) as
described below so that our customers can trust and use our products in preparation
for accidents that may occur during the use of products produced on our own.
[Contents] ………………………………………………………………………………………
Insurance name: Products Liability Insurance
Issuing agency: Machinery Insurance Cooperative
Compensation limit: 100 million won for person and object, respectively
Security area: Worldwide (Excluding North America)
Emergency contact number: Daihan Scientific Co., Ltd. (TEL : [phone], FAX : 02-
967-5231)
Machinery Insurance Cooperative (TEL : [phone], FAX : [phone])

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 6/12
Safety Instructions 5
Please read following warning for safety and proper use.
Please be familiar with the user manual before using this product, and
operation should be performed only by qualified personnel
Install the product in a place where the floor is hard and flat. Failure to do so
can cause accidents. by negligence.
This product should be connected to a appropriate power source that it is
generally used. Please use a lower power source than the regulation load
permitted.
(AC 120V, 50/60Hz or AC 230V, 50/60Hz, Single phase)
Installing the device (repeated in the Section 6)
WARNING
Place the device on a level, horizontal surface to support the capacity of the
device without vibration. If there is vibration, install the device on a support
material with enough space. Small place may cause the device to drop.
Do not install at a dangerous place.
Do not operate the device where there are flammables. It could be caused
serious accidents like explosion or fire.
Do not operate the device outside.
Avoid areas where the sun shines or rain directly on the device. It is very
dangerous as cause over-heat or a short circuit.
Do not install the device where it can get damp or dust.
It may be caused overheating, a short circuit or a fire by damp or dust inside of
the device.

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 7/12
Do not use this device if the ambient temperature is below 5°C or above 40°C.
Do not use the device at a place with high temperature. Do not operate the
device near a heater, blowing an air-conditioner. It may be caused an accident
by over-heating.
The device should be set at a well ventilated place.
Be sure the holes on the side or rear surface of the body are blocked by a wall
or an object. And do not operate the device at a poor ventilated place or use
closed.
It may cause a fire or damage of the device as not to release heat or
insufficient ventilation may result.
Set the device a lightening place.
When you set the device at a dark place, it may cause an unexpected accident
by mistake in operation.
lWarnings
- Please observe the following precautions
WARNING
Be careful to operate the device.
You should read this manual carefully before using.
The device should only be operated by laboratory personnel especially trained for
this purpose and familiar with all precautionary measures required for working in a
laboratory.
Operate after check the safety of the device.
If there is generated a slight shock or a poisonous gas from a sample, figure it out
and make sure the safety using dustproof or a gas mask.
If unexpected sound, smell or smog is generated, pull out the mains plug and
contact manufacturer or a supplier.
Do not put any objects insides the machine.
When an object that is easy to be combustible is like a stone, a metal or paper
goes insides, it may cause a fire, an electric shock or a break down.
If do, pull out the mains plug from a socket and contact a manufacturer or a
supplier.

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 8/12
Do not disassemble or remodeling by yourself.
It may cause damage to the designed safety.
We do not have any duties for an accident, quality deterioration or a defect
caused by a customer..
All the mechanisms and electric/electronic devices in this machine are designed
and developed by the manufacturer. The devices could be disassembled and
serviced only by the engineers of manufacturer or by engineers approved by
manufacturer.
Do not touch the device with wet hand while operation.
CAUTION
This device must be connected to an earthed power supply.
If you use radiation or contaminated samples, the responsibility is to the customer.
Do not use this product to sterilization or disinfection.
Avoid a sample that is poisonous or flammable.
Never use for a explosive sample.
Please avoid ultraviolet lamps.
It could be cracked or faded.
Disconnect the power supply plug if the unit is not going to be used for an
extended period of time.
※All of the circuits, electrical or mechanical parts and configurations used in this product are
the technical assets of DAIHAN Scientific (Co., Ltd.). Only technicians of the technical support
team at DAIHAN Scientific (Co., Ltd.) or technicians approved through the education from
DAIHAN Scientific should be allowed to repair this product.

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 9/12
Names of Each Part 6
Usage Instructions 7
1. Preparation for use
lConnect the power to the socket with the proper voltage appropriate for the standard.
lPlace it on a flat and stable place.
2. How to operate
Mixing head
Speed control knob
1. Insert the test tube into the mixing holder
and press it to start mixing.
2. Adjust the proper speed via the speed
control knob (Clockwise switching -
acceleration)
3. Lift the test tube to stop mixing
push

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 10/12
Product Specifications 8
Technical Information
Models
VM
-
100
Tube Capacity
U
p
to 50
ml
Platform Dimension
w300×d115 mm
Speed
3,200
rpm
Overall Dimension &
Weight(N.W./G.W.) W55×d173×h81 mm, 0.77 / 0.9 kg
Power Supply
AC 220V 50/60Hz
Maintenance and Management 9
1. If not used for a long time, unplug the power plug, dry it, and wrap it for storage.
2. If parts need to be replaced due to failure during use, you should use only
genuine parts provided by us.
3. Failure due to usage beyond normal limits cannot be maintained
4. When cleaning the product, unplug the power plug and wipe it with a soft towel.
In case of a non-erasable part, wipe only dirt with a towel soaked in a solvent
with low freezing point.

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 11/12
Troubleshooting 10
State Checking and action
Vortexing is not done Check that the accessory is correctly seated in the mount.
Check that the power switch is in the ON position
No power
Check that the power cord is plugged in correctly.
Check that there is no problem in the supplied power.
Check the fuse short.
※If you have any problem other than the above, please call technical service of manufacturer
or an official agent.

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 12/12
CERTIFICATE
of
Quality Tested by Manufacturer
and Free Warranty up to 2 years
for Laboratory Instrument
Limited Warranty
1. This instrument has gone through our testing process about all functions
before shipment.
2. This instrument is warranted for 2 years from purchasing date.
3. A breakdown caused by customer’s improper use or natural disaster is
excepted from this warranty.
4. This certification is only for international customers.
Item Mini Vortex Mixer
Model No. VM-100
Serial No.
Date
Customer
DAIHAN Scientific Co., Ltd.
326, Sinpyeongseokhwa-ro, jijeong-myeon,
Wonj-si, Gangwon-do, Korea
Tel : [phone]
Fax : [phone]
email : [e-mail]
www.DAIHAN-Sci.com
www.ALL forLAB.com

Man247 (27 Jul. 2015)
VM-100
Mini Vortex Mixer
Certifications by - - -
ISO 9001 Certified.
PL Insurance. (제조물 배상책임보험)
사용자 설명서
(Version 2.1.1)
written for
VM-100 model
“VM-100” Mini Vortex Mixer.
Sales & Basic A/S :
By the Nearest Official Distributors.
판매 및 기본 A/S :
㈜대한과학 전국 대리점.
I N N O B I Z ( 기술혁신형 중소기업 )인 증 !
VENTURE Company( 벤처기업 )인증!
DAIHAN
-
Sci.com or
ALL
for
LAB.com
Shopping Mall

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 2/14
목 차
Page
1. 사용하기 전에……………………………………………..…………….……………………3
2. 용도및특징……………………………………………..…………….…………………………. 4
3. 제품 내용물 ………………………………………………………………………………………… 4
4. 제품의 설치……………………………………..………………………………………….………. 5
5. 사용 시 주의사항……………………………………………………………………………… 6
6. 각 부의 명칭……………………………………………………………………………………….. 10
7. 사용법…………………………………………………………………………………………………. 10
8. 제품의 규격……………………………………………………………………………………….. 11
9. 유지 및 관리……………………………………………………………………………………... 11
10. 고장 증상…………………………………………………………………………………………… 12
11. 품질 보증서…………………………………………………………………………………………. 13
12. ㈜대한과학 전국 대리점 ………………………………………………………………… 14

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 3/14
사용하기 전에 1
Mini Vortex Mixer 를 구입해 주셔서 감사합니다. 본 설명서는
구입하신 제품의 성능 및 사용법, 취급상의 주의사항에 대하여 기술하고 있습니다.
제품 사용 전에 반드시 주의 깊게 읽어 주시기 바랍니다.
사용자의 주의가 반드시 필요한 부분에는 아래와 같은 경고 표시가 있으니
각 경고 표시와 그 의미를 숙지 하시어 사용 시 안전하게 사용하십시오.
경 고
주의사항을 지키지 않았을 경우 사용자가 부상을 입을 수 있음을
알립니다.
주 의
이 표시는 주의사항을 지키지 않았을 경우 기기의 고장의 원인이
됨을 알립니다.
알 림
이 표시는 기능상 주요한 사항으로 임의로 사용자가 기기의 분해
하거나 변형 해서는 안됨을 알립니다.
폭 발 위 험
이 표시는 휘발성, 폭발성 화학물질을 사용할 경우 폭발의 위험이
있음을 알립니다.
접 근 금 지
기기의 사용 중에 사용자의 접근을 제한함을 알립니다.
열 주 의
이 표시는 열 주의를 표시합니다

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 4/14
용도 및 특징 2
Mini Vortex Mixer는 다양한 분야(화학 분야, 생명과학 분야, 의료과학 분야, 약리학 분야
등)에 사용이 편리합니다.
Mini Vortex Mixer의 장점은 다음과 같습니다.
n견고한 디자인과 매우 안정적인 접지력을 실현했습니다.
n강력한 힘과 안정된 동작, 저소음 실현했습니다. (최대 3,200rpm).
n최소한의 크기로 작업대의 공간효율을 극대화 했습니다.
n다양한 속도 제어가 가능하고 자동 Push start 기능을 적용했습니다.
n50ml의 튜브까지 사용이 가능합니다.
n본 제품은 제조물 배상책임보험(PL 보험)에 의해 불의의 사고 시 보 상을 받
을 수 있습니다. (대인, 대물 각각 1억원)
제품 내용물 3
VM-100, Mini Vortex Mixer ......................................................................................... [ 1 ]
Power Adapter .......................................................................................................... [ 1 ]
Operation Manual ..................................................................................................... [ 1 ]

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 5/14
제품 설치 4
1. 본 제품은 정격전압에서 정상 동작하도록 제작되어있습니다.
제품을 설치하시기 전에 전압 상태를 확인하십시오.
2. 바닥이 단단하고 수평인 평면에 제품을 설치하십시오.
3. 직사광선이 있는 곳에 설치하지 마십시오.
4. 제품의 조절기 부분이나 본체 내부에 수분이나 유기용제 등이 유입되면 합선
의 우려가 있으므로 이런 장소에는 설치하지 마십시오.
5. 위험한 장소에는 설치하지 마십시오.
6. 제품의 운반 시 떨어트리지 않도록 주의하십시오.
7. 제품을 눕히거나 충격을 가하지 마십시오. 내부에 손상이 올 수 있습니다.
8. 실험대에서 떨어지지 않도록 모서리에서 떨어진 곳에 설치하십시오.
9. 제품 설치 및 사용시 반드시 제품과 함께 제공된 POWER Adapter를 사용하십
시오.
¨제조물배상책임보험(PL 보험)가입
㈜대한과학은 자체 생산하는 제품의 사용 중 발생할 수 있는 사고에 대비하여
고객분들이 믿고 제품을 사용하실 수 있도록, 하기 내용과 같이 제조물배상책임보험
(PL 보험)에 가입하였습니다
[내 용] ………………………………………………………………………………………
보험명: 제조물배상책임보험 (Products Liability Insurance)
발행처: 기계공제조합 (Machinery Insurance Cooperative)
배상 한도 : 대인, 대물 각각 1억원
담보 지역 : 전세계(북미주 제외)
긴급연락처 : ㈜대한과학 (TEL : [phone], FAX : [phone])
기계공제조합 (TEL : [phone], FAX : [phone])

DAIHAN-Sci.com or ALL for LAB.com Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 6/14
사용 시 주의 사항 5
l사용하기 전에
본 장비를 사용하시기 전에는 꼭 사용자 매뉴얼을 숙지하여 주시고
실험실의 매뉴얼을 숙지하여 인가된 사람 외에 사용을 금해주시기
바랍니다.
바닥이 단단하고 평평한 곳에 설치하십시오. 그렇지 않을 경우, 부주의에
의한 사고의 원인이 됩니다.
본 장비는 꼭 일반적으로 사용되는 적절한 전원을 사용하여 주십시오.
(AC 120V, 50/60Hz or AC 230V, 50/60Hz, Single phase) 반드시 허용된
규정 부하 이하에서만 사용하십시오
l설치 시 주의사항
WARNING
장비를 진동이 없고 수평 한 위치에 위치하시기 바랍니다. 만약 진동이 있는
위치의 경우 충분한 공간과 보조 장치를 이용하여 장비를 설치하시기
바랍니다. 작은 공간 또는 협소한 공간에서는 장비의 고장의 원인이 될 수
있습니다.
위험한 장소에는 장치를 설치하지 마십시오.
가연성 위험 또는 화재의 위험이 있는 장소에서는 장비를 동작시키지
마십시오. 이것은 폭발이나 화재와 같은 심각한 사고가 발생할 수 있습니다.
장비를 실외에서 작동하지 마십시오.
장비를 직사광선 또는 비가 직접적으로 내리는 위치에 설치를 하시면
안됩니다. 그것은 과열이나 누전으로 발생하여 매우 위험합니다.
