Daikin DM92SE Operating instructions

Our continuing commitment to quality products may mean a change in specications without notice.
©2019
19001 Kermier Rd., Waller, TX 77484
www.daikincomfort.com
DM92SE
Single Stage Gas Furnaces and Accessories
Service Instructions
RSD6612014r1
December 2019
This manual is to be used by qualied, professionally trained HVAC technicians only.
Daikin does not assume any responsibility for property damage or personal injury due to
improper service procedures or services performed by an unqualied person.
The material in this manual does not supercede manufacturer's installation and operation instructions.
Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
O NLY PERSONNEL THAT
HAVE BEEN TRAINED TO INSTALL , ADJUST , SERVICE OR
REPAIR ( HEREINAFTER , “
SERVICE ”) THE EQUIPMENT SPECIFIED
IN THIS MANUAL
SHOULD SERVICE THE EQUIPMENT
. T HE MANUFACTURER WILL
NOT BE
RESPONSIBLE FOR ANY INJURY OR PROPERTY
DAMAGE ARISING FROM
IMPROPER
SERVICE OR SERVICE PROCEDURES . I
F YOU SERVICE THIS UNIT ,
YOU ASSUME
RESPONSIBILITY FOR
ANY INJURY OR PROPERTY DAMAGE
WHICH MAY RESULT . I N
ADDITION , IN JURISDICTIONS THAT REQUIRE ONE
OR MORE LICENSES TO SERVICE
THE EQUIPMENT SPECIFIED IN THIS MANUAL
, ONLY LICENSED PERSONNEL
SHOULD SERVICE THE EQUIPMENT . I MPROPER INSTALLATION , ADJUSTMENT ,
SERVICING
OR REPAIR OF THE EQUIPMENT SPECIFIED IN
THIS MANUAL , OR
ATTEMPTING TO INSTALL , ADJUST
, SERVICE OR REPAIR THE EQUIPMENT SPECIFIED
IN THIS MANUAL WITHOUT PROPER TRAINING MAY RESULT IN PRODUCT
DAMAGE , PROPERTY DAMAGE , PERSONAL INJURY OR DEATH .

2
IMPORTANT INFORMATION
Pride and workmanship go into every product to provide our customers with quality products. It is possible, however,
that during its lifetime a product may require service. Products should be serviced only by a qualied service technician
who is familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts, testing
instruments and the appropriate service manual. REVIEW ALL SERVICE INFORMATION IN THE APPROPRIATE
SERVICE MANUAL BEFORE BEGINNING REPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
Table of Contents
IMPORTANT INFORMATION ..........................2 - 4
PRODUCT IDENTIFICATION .........................5 - 8
INSTALLATION CONSIDERATIONS ............9 - 27
SYSTEM OPERATION .......................................28
ACCESSORIES...........................................29 - 31
ACCESSORY WIRING DIAGRAMS ...........32 - 34
SERVICING ...................................................35-37
TROUBLESHOOTING ................................38 - 40
SERVICING ........................................................41
SERVICING TABLE OF CONTENTS .................42
SERVICING ...................................................43-53
MAINTENANCE ..........................................54 - 56
WIRING DIAGRAMS ..........................................57
WARNING
HIGH VOLTAGE
DISCONNECT ALL POWER BEFORE SERVICING OR
INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY
BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH.
WARNING
T
O PREVENT THE RISK OF PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH,
DO NOT STORE COMBUSTIBLE MATERIALS OR USE GASOLINE OR OTHER
FLAMMABLE LIQUIDS OR VAPORS IN THE VICINITY OF THIS APPLIANCE.

3
To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this prod-
uct. For further assistance, please contact:
CONSUMER INFORMATION LINE
DAIKIN BRAND PRODUCTS
TOLL FREE
1-855-770-5678 (U.S. only)
email us at:
[email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.) Your telephone company will bill you for the call.
IMPORTANT INFORMATION
B10259-216
CO can cause serious illness including permanent brain
damage or death.
Advertencia especial para la instalación de calentadores ó manejadoras
de aire en áreas cerradas como estacionamientos ó cuartos de servicio.
B10259-216
El monóxido de carbono puede causar enfermedades severas
como daño cerebral permanente ó muerte.
Las emisiones de monóxido de carbono pueden circular a través
del aparato cuando se opera en cualquier modo.
B10259-216
RISQUE D'EMPOISONNEMENT AUMONOXYDE DE CARBONE
Le monoxyde de
des carbone peut causer des maladies graves tellesque dommages permanents au cerveau et meme la mort.
Cette ventilationestnécessaire pouréviterle danger d'intoxication
au CO pouvant survenir si un appareil produisant du monoxyde
de carbone continue de fonctionner au sein de la zone confinée.

4
IMPORTANT INFORMATION
4
devicewhichautomaticallylights theburner.
inthesafety.informationabove
systémedecontrôleettoute commandequiontété
instructionsintituléesCommentcouperl'admission
1.Réglerle thermostatàla température la plusbassé.
l'eau,mêmepartiellement. Faire inspecterl'appareil
2.Réglerle thermostatàla température la plusbasse.
Donottryto lightanyappliance.
qu'àla main.Nejamais emploerd'outil àcette fin.
if serviceis to beperformed.
hand,don't try to repair it, call aqualifiedservice
7.Pushgascontrollever
servicetechnicianorgascompany.
munid'undispositif d'allumagequiallume
theapplianceandto replaceanypart ofthecontrol
certainsgazsontpluslourdsquel'air et
appelezle service desincendies.»
qualifiéoule fournisseurdegaz.
C.Useonly yourhandto push in orturn thegascontrollever.
AVERTISSEMENT:
to
Immediately call yourgassupplierfromaneighbor's
S'il n'y apasd'odeurdegaz,passeràl'etàpesuivante.
9.Turn on all electric
BEFOREOPERATING
POURCOUPERL'ADMISSION
paruntechnicienqualifiéetremplacertoutrpartiedu
Donotforce.

powerto theappliance.
tente deforcerla manette oudela réparerpeut
automatiquementle brûleur. Nepastenter
Nepastenterd'allumerd'appareils.
exactly,a fireor
Nepasforcer.
4.Remettre enplacele panneaud'accés.
donotuseanyphonein yourbuilding.
allumerle brûleurmanuellement.
2.Setthethermostatto lowestsetting.
TOTURNOFFGASTOAPPLIANCE
Passeràl'etapeBdesinstructionsdesecurite
5.Poussele levierducontrÔle dugaza
7.Pousselelevierducontrôle dugazà
B.smell all aroundtheappliance
Cetappareil necomporte pasdeveilleuse.Il est
"ON".
Appelezimmédiatementvotrefournisseurdegazdepuis
4.Cetappareil menageretantdote d'unsysteme
withanignitiondevicewhichautomatically lights
3.Pousselelevierducontrôledugazà
degazdel'appareil etappeleruntechnicien
3.Pushthegascontrolleverto Position.
position.
ARRÊTEZ
.
8.Remettre enplacele panneaud'accés.
tolighttheburnerbyhand.
OPERATINGINSTRUCTIONS
smell forgas,includingnearthefloor. If you
"OFF"
QUEFAIRES'IL YAUNEODEURDEGAZ
technician.Forceorattemptedrepairmayresultinafire
11.If theappliancewill notoperate,
callthefiredepartment.
plongéesdansl'eau.»
unvoisin.Suivezlesinstructionsdufournisseurdegaz
thislabel.
d'allumerle brûleurmanuellement.
"ON/MARCHE"
explosionmayresultcausingproperty
reniflertoutautourdel'apparielpourdecéler
"OFF/ARRET"
corporellesoula pertedevieshumaines.
d'allumageautomatique,nepasessayerà
4.Replacecontrolaccesspanel.
followtheinstructions"ToTurn
la lettrelesinstructionsdansle preséntmanuel
D.Donotusethisapplianceifanyparthasbeenunderwater.
position.
6.Attendrecinq(5)minutespourlaisserechappertoutle
WHATTODOIF YOUSMELLGAS
5.Pushthegascontrolleverto Position.
"OFF/ARRET"
settleonthefloor.
sectionsupérieure decetteétiquette.
D.Nepasseservirdecetappareils'ilaétéplongédans
provoqueruneexplosionouunincendie.»
destéléphonesdansle bâtiment.
8.Replaceaccesspanel.
Donottrytolightthe burnerbyhand.
damage,personalinjuryor
areaforgas.Besure to smell nexttothefloor
Neverusetools.Iftheleverwillnotpushinorturnby
READBEFOREOPERATING
Silamanetterestecoincé
e,netenterpasdela
ENMARCHELIRE
position.
peuvents'accumulerauniveaudusol.
ré
parer;appelezuntechnicienqualifié
.Quiconque
Sivousnepouvezrejoindrelefournisseurdegaz,
1.Setthethermostattolowestsetting.
4.Thisapplianceisequippedwithanignition
10.Setthermostattodesiredsetting.
A.
STOP.
LIREAVANTDEMETTRE
C.Nepousseroutournerlamanetted'admissiondugaz
gaz.Reniflertoutautourdel'appareil, ycomprisprésdu
10.Réglerle thermostatàlatempérature désirée.
lossoflife.
Ifyoucannotreachyourgassupplier,
Off GasToAppliance"andcall your
plancher, pourdéceleruneodeurdegaz.Sic'estle cas,
0140F01905-A
Donottouchanyelectric switch;
6.Wait five(5)minutesto clearoutanygas.Then
becausesomegasisheavierthanair andwill
1.Lisezlesinstructionsdesécuritédansla
thensmell gas,Follow
3.Couperl'alimentationélectriquedel'appareil.
Netoucheràaucuninterrupteur; nepasvousservir
9.Mettrel'appareil soustension.
MISEENMARCHE
uneodeurdegaz.Reniflerprésduplancher, car
ARRÊTEZ.
Ifyoudonotfollowtheseinstructions
surla portionsuperieuredecette etiquette.
3.Turn off all electricpowerto theappliance.
fautprocéderàdesoperationsd'entretien.
gas,gotonextstep.
orexplosion.
FORYOURSAFETY
entraînantdesdommagesmatériels,deslesions
2.Turnoff allelectricpowertotheappliance
A.This appliancedoesnothaveapilot.It isequipped
theburner. Donottry
DEGAZDEL'APPAREIL
phone.Followthegassupplier'sinstructions.
onthislabelif youdon't smell
systemandanygascontrolwhichhasbeenunderwater.
Quiconquenerespectepasà
2.Couperl'alimentationélectriquedel'appareil s'il
0140F01905-A
risquededéclencherunincendieouuneexplosion
1.Readthesafetyinformationaboveon
"OFF"
Immediatelycallaqualifiedservicetechniciantoinspect
STOP."B"
11.Sil'appareil nesemetpasenmarche,suivreles
B.AVANTDELEFAIREFONCTIONNER,
Donotforce.
DUGAZ
ARRIVEE
INLET
GAS
IN"ON"POS
LEVERSHOWN
MANUALGAS
"ON/MARCHE"
MANUEL,ENPOS
ROBINETAGAZ
IN "ON"POS
LEVERSHOWN
MANUALGAS
DUGAZ
ARRIVEE
INLET
GAS
DUGAZ
ARRIVEE
INLET
GAS
IN "ON"POS
LEVERSHOWN
MANUALGAS
"ON/MARCHE"
MANUEL,ENPOS
ROBINETAGAZ
IN"ON"POS
LEVERSHOWN
MANUALGAS
DUGAZ
ARRIVEE
INLET
GAS
IMPORTANT INFORMATION

PRODUCT IDENTIFICATION
5
The model and manufacturing number are used for positive identication of component parts used in manufacturing.
Please use these numbers when requesting service or parts information.
M S E 3 B N A AD 9 2 0 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Brand Minor Revision
D- Daikin A - Initial Release
B
- 1st Revision
Configuration
M- Upflow/Horizontal MajorRevision
C- Downflow/Horizontal
A - Initial Release
B
- 1st Revision
Nox
AFUE
N - Natural Gas
97- 97% AFUE
X - Low NOx
80- 80% AFUE
Cabinet Width
GasValve
A-14" M- Modulating
B-17.5" V - 2Stage
C-21"
D-24.5"
S - Single Stage
Maximum CFM Motor
3-1200 CFM
C- Variable Speed/ComfortNet
4-1600 CFM
E- HighEfficiency
5-2000 CFM
S - Single Speed
MBTU/h
040- 40,000BTU/h
060- 60,000BTU/h
080- 80,000BTU/h
100- 100,000BTU/h

PRODUCT IDENTIFICATION
6
MODEL# MFG# DESCRIPTION
DM92SE
DM92SE0403AN
DM92SE0603BN
DM92SE0803BN
DM92SE0804CN
DM92SE0805CN
DM92SE1004CN
DM92SE1005CN
DM92SE1205DN
Daikin Brand 92% Single Stage furnace. 34.5" tall , Upow/Horizontal
Installaon, 1-stage gas valve induced dra. Mul-speed ECM motor.
120-volt nitride hot surface ignion. Le or right gas pipe entry.
The furnace also features a stainless tubular heat exchanger.

PRODUCT IDENTIFICATION
7
MODEL # MFG # DESCRIPTION
AFE18-60A N/A
Fossil Fuel Kit. The AFE18-60A control is designed for use where the indoor coil is locat-
ed above/downstream of a gas or fossil fuel furnace when used with a heat pump. It will
operate with single and two stage heat pumps and single and two stage furnaces
AMU1620
AMU1625
AMU2020
AMU2025
P1251305F
P1251306F
P1251307F
P1251308F Media Air Cleaner. A high e󰀩ciency air ltration device designed to remove dirt, dust,
pollen and other microscopic particles from the air passing through it. Flexible perfor-
mance range up to 2,000 CFM capacity. The air cleaner should be installed in t
GMU1620
GMU1625
GMU2020
GMU2025
N/A
ASAS-10
ASAS-11
ASAS-12
ASAS-18
P1251301F
P1251302F
P1251303F
P1251304F
Electronic Air Cleaner. The High-E󰀩ciency Electronic Air Cleaner is designed to remove
air contaminants down to .01 microns. Carbon lters (optional) remove odors. Dual indi-
cator lights show unit operation at a glance. Electronic proving switch cycle

PRODUCT IDENTIFICATION
8
MODEL # MFG # DESCRIPTION
DCVK-20
(CVENT-2)
DCVK-30
(CVENT-3)
N/A
Concentric Vent Kit. This kit is designed to allow terminations of a direct vent furnace
to be “concentrically” vented through a wall or roof. This kit allows a single penetration to
support terminations for both the vent/ue and the combustion air intak
EFR02 N/A
External Filter Rack Kit. For use with 34.5” up ow gas furnaces. This kit is intended to
provide a location, external to the furnace casing for installation of a permanent lter. The
rack is mounted over the indoor air blower compartment area of either
0170K00000S N/A
Side Wall Only Concentric Vent Kit. This kit is to be used with 2” - 3” vent systems.
The vent kit must terminate outside the structure. This kit is NOT intended for use with
single pipe (indirect vent) installations.
0170K00001S N/A
Side Wall Only Concentric Vent Kit. This kit is to be used with 2” vent systems. The
vent kit must terminate outside the structure. This kit is NOT intended for use with single
pipe (indirect vent) installation
LPLP03 N/A
LP Gas Low Pressure Kit. Designed for use with furnaces converted to LP gas. The
kit monitors gas line pressure with a pressure switch and will open the circuit to the gas
valve if the LP tank pressure gets low.
LPM-07 N/A LP Conversion Kit Converts a 34.5” single stage furnace to operate on L.P. gas. The
kit contains an L.P. gas valve and a set of six L.P. orices.
RF000142 N/A
Drain Coupling Kit For use when the drain/vent elbow has been removed in a horizon-
tal left installation. This kit prevents condensate from getting in the inducer and routes the
condensate to a drain.

INSTALLATION CONSIDERATIONS
9
Safety
Please adhere to the following warnings and cautions when
installing, adjusting, altering, servicing, or operating the furnace.
T
O PREVENT PERSONAL INJURY OR DEATH DUE TO IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE, REFER TO THIS
MANUAL. FOR ADDITIONAL ASSISTANCE OR INFORMATION, CONSULT A
QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
WARNING
WARNING
T
HIS PRODUCT CONTAINS OR PRODUCES A CHEMICAL OR CHEMICALS WHICH
MAY CAUSE SERIOUS ILLNESS OR DEATH AND WHICH ARE KNOWN TO THE
S
TATE OF
C
ALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM.
WARNING
TO PREVENT POSSIBLE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH
DUE TO ELECTRICAL SHOCK, THE FURNACE MUST BE LOCATED TO PROTECT
THE ELECTRICAL COMPONENTS FROM WATER.
Charge (ESD) Precautions
NOTE: Discharge body’s static electricity before touching
unit. An electrostatic discharge can adversely a󰀨ect electrical
components.
Use the following precautions during furnace installation and
servicing to protect the integrated control module from dam-
age. By putting the furnace, the control, and the person at the
same electrostatic potential, these steps will help avoid expos-
ing the integrated control module to electrostatic discharge.
This procedure is applicable to both installed and uninstalled
(ungrounded) furnaces.
1. Disconnect all power to the furnace. Do not touch the inte-
grated control module or any wire connected to the control
prior to discharging your body’s electrostatic charge to
ground.
2. Firmly touch a clean, unpainted, metal surface of the fur-
nace near the control. Any tools held in a person’s hand
during grounding will be discharged.
3. Service integrated control module or connecting wiring
following the discharge process in Step 2. Use caution
not to recharge your body with static electricity; (i.e., do
not move or shu󰀪e your feet, do not touch ungrounded
objects, etc.). If you come in contact with an ungrounded
object, repeat Step 2 before touching control or wires.
4. Discharge any static electricity from your body to ground
before removing a new control from its container. Follow
Steps 1 through 3 if installing the control on a furnace.
Return any old or new controls to their containers before
touching any ungrounded object.
Product Application
This product is designed for use as a residential home gas
furnace. It is not designed or certied for use in mobile home,
trailer, or recreational vehicle applications.
In the U.S.A., this furnace can be used in the following non-
industrial commercial applications: Schools, O󰀩ce buildings,
Churches, Retail stores, Nursing homes, Hotels/motels, Common
or o󰀩ce areas. In all applications, the furnace must be installed
per the installation instructions.
Daikin DM92SE furnaces are ETL certied. All furnaces are
built for use with Natural gas but can be converted for use
with LP gas.
(NOTE: If using propane gas, a propane conversion kit is
required).
Daikin DM92SE high e󰀩ciency furnaces are dual certied.
Dual certication means that the combustion air inlet pipe is
optional and the furnace can be vented as a:
Non-direct vent (single pipe) central forced air furnace in
which combustion air is taken from the installation area
or from air ducted from the outside or,
Direct vent (dual pipe) central forced air furnace in which
all combustion air supplied directly to the furnace burners
through a special air intake system outlined in this manual
and the installation instructions.
To ensure proper installation, operation and servicing, thor-
oughly read the installation and service manuals for specics
pertaining to the installation, servicing and application of this
product.
WARNING
POSSIBLE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH DUE TO FIRE,
EXPLOSION, SMOKE, SOOT, CONDENSTAION, ELECTRICAL SHOCK OR CARBON
MONOXIDE MAY RESULT FROM IMPROPER INSTALLATION, REPAIR, OPERATION,
OR MAINTENANCE OF THIS PRODUCT.
WARNING
T
O PREVENT PROPERTY DAMAGE, PERSONAL INJURY OR DEATH DUE TO FIRE,
DO NOT INSTALL THIS FURNACE IN A MOBILE HOME, TRAILER, OR RECREATIONAL
VEHICLE.
To ensure proper furnace operation, install, operate, maintain
and service the furnace in accordance with the installation,
operation and service instructions, all local building codes
and ordinances. In their absence, follow the latest edition of
the National Fuel Gas Code (NFPA 54/ANSI Z223.1), and/or
CAN/CGA B149 Installation Codes, local plumbing or waste
water codes, and other applicable codes.
A copy of the National Fuel Gas Code (NFPA 54/ANSI Z223.1)
can be obtained from any of the following:
American National Standards Institute
25 West 43rd Street, 4th Floor
New York, NY 10036

INSTALLATION CONSIDERATIONS
10
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
CSA International
8501 East Pleasant Valley
Cleveland, OH 44131
A copy of the CAN/CGA B149 Installation Codes can be
obtained from:
CSA International
178 Rexdale Boulevard
Etobicoke, Ontario, Canada M9W, 1R3
The rated heating capacity of the furnace should be greater
than or equal to the total heat loss of the area to be heated. The
total heat loss should be calculated by an approved method
or in accordance with “ASHRAE Guide” or “Manual J-Load
Calculations” published by the Air Conditioning Contractors
of America.
Location Requirements and Considerations
WARNING
TO PREVENT POSSIBLE EQUIPMENT DAMAGE, PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH, THE FOLLOWING BULLET POINTS MUST BE OBSERVED
WHEN INSTALLING THE UNIT.
Follow the instructions listed below when selecting a furnace
location. Refer also to the guidelines provided in the Combus-
tion and Ventilation Air Requirements section in this manual
or the installation instructions for details.
• Centrally locate the furnace with respect to the proposed
or existing air distribution system.
• Ensure the temperature of the return air entering the
furnace is between 55°F and 100°F when the furnace
is heating.
• If the furnace is installed in an application where the
typical operating sound level of a furnace is deemed
objectionable, an optional sound reduction kit is avail-
able. Consult your local distributor for more details.
• Provide provisions for venting combustion products
outdoors through a proper venting system. Special
consideration should be given to vent/ue pipe routing
and combustion air intake pipe when applicable.
90% Furnaces: Refer to the Vent/Flue Pipe and Com-
bustion Air Pipe -Termination Locations section in this
manual or the installation instructions for appropriate
termination locations. Also for 90% furnaces, refer to the
Vent/Flue Pipe and Combustion Air Pipe -Termination
Locations section in this manual or the installation in-
structions to determine if the piping system from furnace
to termination can be accomplished within the guidelines
given. NOTE: The length of ue and/or combustion
air piping can be a limiting factor in the location of the
furnace.
• Locate the 90% furnace so that the condensate can be
piped at a downward slope away from the furnace to
the drain. Do not locate the furnace or its condensate
drainage system in any area subject to below freezing
temperatures without proper freeze protection. Refer
to the Condensate Drain Lines and Trap section in this
manual or the installation instructions for further details.
• Set the 90% furnace on a level oor to enable proper
condensate drainage. If the oor becomes wet or damp
at times, place the furnace above the oor on a concrete
base sized approximately 1-1/2" larger than the base
of the furnace. Refer to the Horizontal Applications and
Considerationssectionin this manual or theinstallation
instructions for leveling of horizontal furnaces.
• Ensure upow or horizontal furnaces are not installed
directly on carpeting, or any other combustible material.
The only combustible material allowed is wood.
• A special accessory subbase must be used for upright
counterow unit installations over any combustible
material (including wood). Refer to subbase instructions
for installation details. (NOTE: A subbase will not be
required if an air conditioning coil is located beneath
the furnace between the supply air opening and the
combustible oor.
• Exposure to contaminated combustion air will result in
safety and performance-related problems. Do not install
the furnace where the combustion air is exposed to the
following substances:
chlorinated waxes or cleaners
chlorine-based swimming pool chemicals
water softening chemicals
deicing salts or chemicals
carbon tetrachloride
halogen type refrigerants
cleaning solutions (such as perchloroethylene)
printing inks
paint removers
varnishes
hydrochloric acid
cements and glues
antistatic fabric softeners for clothes dryers
and masonry acid washing materials

INSTALLATION CONSIDERATIONS
11
• Isolate a nondirect furnace from an area contaminated
by any of the above substances. This protects the
non-direct vent furnace from airborne contaminants.
To ensure that the enclosed non-direct vent furnace
has an adequate supply of combustion air, vent from a
nearby uncontaminated room or from outdoors. Refer
to the Combustion and Ventilation Air Requirements
section in this manual or the installation instructions
for details.
• If the furnace is used in connection with a cooling
unit, install the furnace upstream or in parallel with
the cooling unit coil. Premature heat exchanger failure
will result if the cooling unit coil is placed ahead of the
furnace.
• If the furnace is installed in a residential garage, posi-
tion the furnace so that the burners and ignition source
are located not less than 18 inches (457 mm) above
the oor. Protect the furnace from physical damage by
vehicles.
• If the furnace is installed horizontally, the furnace
access doors must be vertical so that the burners re
horizontally into the heat exchanger. Do not install the
unit with the access doors on the “up/top” or “down/
bottom” side of the furnace.
Clearances and Accessibility
Installations must adhere to the clearances to combustible
materials to which this furnace has been design certied. The
minimum clearance information for this furnace is provided on
the unit’s clearance label. These clearances must be perma-
nently maintained. Refer to Specication Sheet for minimum
clearances to combustible materials. Clearances must also
accommodate an installation’s gas, electrical, and drain trap
and drain line connections. If the alternate combustion air
intake or vent/ue connections are used on a 90% furnace,
additional clearances must be provided to accommodate
these connections. Refer to Vent Flue Pipe and Combustion
Air Pipe section in this manual or the installation instructions
for details. NOTE: In addition to the required clearances
to combustible materials, a minimum of 24 inches service
clearance must be available in front of the unit.
A furnace installed in a conned space (i.e., a closet or utility
room) must have two ventilation openings with a total min-
imum free area of 0.25 square inches per 1,000 BTU/hr of
furnace input rating. One of the ventilation openings must be
within 12 inches of the top; the other opening must be within
12 inches of the bottom of the conned space. In a typical
construction, the clearance between the door and door frame
is usually adequate to satisfy this ventilation requirement.
Furnace Suspension
If suspending the furnace from rafters or joist, use 3/8" thread-
ed rod and 2”x2”x1/8” angle iron as shown in the following
gure. If the furnace is installed in a crawl space it must also
be suspended from the oor joist or supported by a concrete
pad. Never install the furnace on the ground or allow it to
be exposed to water. The length of rod will depend on the
application and the clearances necessary.
2" 2" 1/8"
ANGLE IRON
(3 PLACES )
X X
GAS
PIPING
90% Suspended Furnace Shown

NOTE: When an existing furnace is removed from a venting
system serving other appliances, the venting system may be
too large to properly vent the remaining attached appliances.
The following vent testing procedure is reproduced from the
American National Standard/National Standard of Canada
for Gas-Fired Central Furnaces ANSI Z21.47, latest edition,
CSA-2.3b, latest edition Section 1.23.1.
The following steps shall be followed with each appliance connected
to the venting system placed in operation, while any other appliances
connected to the venting system are not in operation:
a. Seal any unused openings in the venting system;
b. Inspect the venting system for proper size and horizontal pitch,
as required by the National Fuel Gas Code,ANSI Z223.1 or the
CSAB149 Installation Codes and these instructions. Determine
that there is no blockage or restriction, leakage, corrosion and
other deciencies which could cause an unsafe condition;
c. In so far as practical, close all building doors and windows and
all doors between the space in which the appliance(s) connected
totheventingsystemarelocatedandotherspacesofthebuilding.
Turn on clothes dryers and any appliance not connected to the
venting system. Turn on any exhaust fans, such as range hoods
andbathroomexhausts,sotheyshalloperateatmaximumspeed.
Do not operate a summer exhaust fan. Close replace dampers;
d. Follow the lighting instructions. Place the appliance being in-
spectedinoperation.Adjustthermostatsoapplianceshalloperate
continuously;
e. Test for draft hood equipped spillage at the draft hood relief
opening after 5 minutes of main burner operation. Use the ame
of a match or candle;
f. After it has been determined that each appliance connected to
theventingsystemproperlyventswhentestedasoutlinedabove,
return doors, windows, exhaust fans, replace dampers and any
other gas burning appliance to their previous conditions of use;

INSTALLATION CONSIDERATIONS
12
g. If improper venting is observed during any of the above tests,
the common venting system must be corrected.
Corrections must be in accordance with the latest edition of
the National Fuel Gas Code NFPA 54/ANSI Z223.1 and/or
CSA B149 Installation Codes.
If resizing is required on any portion of the venting system,
use the appropriate table in Appendix G in the latest edition of
the National Fuel Gas Code ANSI Z223.1 and/or CSA B149
Installation Codes.
Thermostat Requirements
A high quality single stage thermostat with a "C" terminal is
recommended to control the DM92SE furnace.
Thermostat Location
In an area having good air circulation, locate the thermostat
about ve feet high on a vibration-free inside wall. Do not
install the thermostat where it may be inuenced by any of
the following:
• Drafts, or dead spots behind doors, in corners, or under
cabinets.
• Hot or cold air from registers.
• Radiant heat from the sun.
• Light xtures or other appliances.
• Radiant heat from a replace.
• Concealed hot or cold water pipes, or chimneys.
• Unconditioned areas behind the thermostat and dehu-
midistat, such as an outside wall.
COMBUSTION AND VENTILATION AIR
REQUIREMENTS
WARNING
P
OSSIBLE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH MAY OCCUR
IF THE FURNACE IS NOT PROVIDED WITH ENOUGH FRESH AIR FOR PROPER
COMBUSTION AND VENTILATION OF FLUE GASES. MOST HOMES REQUIRE
OUTSIDE AIR BE SUPPLIED TO THE FURNACE AREA.
Improved construction and additional insulation in buildings
have reduced heat loss by reducing air inltration and escape
around doors and windows. These changes have helped in
reducing heating/cooling costs but have created a problem
supplying combustion and ventilation air for gas red and
other fuel burning appliances. Appliances that pull air out of the
house (clothes dryers, exhaust fans, replaces, etc.) increase
the problem by starving appliances for air.
When the furnace is installed as a direct vent (2-pipe) furnace,
no special provisions for air for combustion are required. How-
ever, if this furnace is to be installed in the same space with
other gas appliances, such as a water heater, ensure there is
an adequate supply of combustion and ventilation air for the
other appliances. Refer to the latest edition of the National
Fuel Gas Code NFPA 54/ANSI Z223.1 (Section 9.3), or CAN/
CGA B149 Installation Codes (Sections 7.2, 7.3, or 7.4), or
applicable provisions of the local building codes for determining
the combustion air requirements for the appliances.
Most homes will require outside air be supplied to the furnace
area by means of ventilation grilles or ducts connecting directly
to the outdoors or spaces open to the outdoors such as attics
or crawl spaces.
The following information on air for combustion and ventilation
is reproduced from the National Fuel Gas Code NFPA 54/ANSI
Z223.1 Section 9.3.
9.3* Air for Combustion and Ventilation.
9.3.1 General.
9.3.1.1 Air for combustion, ventilation, and dilution of ue gases for
appliances installed in buildings shall be obtained by application of one
of the methods covered in 9.3.2 through 9.3.6. Where the requirements
of 9.3.2 are not met, outdoor air shall be introduced in accordance with
methods covered in 9.3.3 through 9.3.6.
Exception No. 1: This provision shall not apply to direct vent appliances.
9.3.1.2 Appliances of other than natural draft design and other than
Category 1 vented appliances shall be provided with combustion, venti-
lation, and dilution air in accordance with the appliance manufacturer’s
instructions.
9.3.1.3 Appliances shall be located so as not to interfere with proper
circulation of combustion, ventilation, and dilution air.
9.3.1.4 Where used, a draft hood or a barometric draft regulator shall
be installed in the same room or enclosure as the appliance served so
as to prevent any dierence in pressure between the hood or regulator
and the combustion air supply.
9.3.1.5 Makeup air requirements for the operation of exhaust fans,
kitchen ventilation systems, clothes dryers, and replaces shall be con-
sidered in determining the adequacy of a space to provide combustion
air requirements.
9.3.2 Indoor CombustionAir. The required volume of indoor air shall
be determined in accordancewith the method in 9.3.2.1 or9.3.2.2 except
that where the air inltration rate is known to be less than 0.40 ACH, the
method in 9.3.2.2 shall be used. The total required volume shall be the
sum of the required volume calculated for all appliances located within
the space. Rooms communicating directly with the space in which the
appliances are installed through openings not furnished with doors, and
through combustion air openings sized and located in accordance with
9.3.2.3, are considered a part of the required volume.
9.3.2.1*StandardMethod.The minimum required volume shall be 50
ft 3 per 1,000/Btu/hour (4.8m3/kW).

INSTALLATION CONSIDERATIONS
13
9.3.2.2* Known Air Inltration Rate Method. Where the air inltra-
tion rate of a structure is known, the minimum required volume shall
be determined as follows:
(1) For appliances other than fan-assisted, calculate using the following
equation:
Required Volumeother ≥21 ft3(Iother )
ACH 1000 Btu/hr
(2) For fan-assisted appliances, calculate using the following equation:
Required Volumefan ≥15 ft3(Ifan )
ACH 1000 Btu/hr
where:
I other = allappliancesotherthanfan-assisted input in Btu perhour
I fan = fan-assisted appliances input in Btu per hour
ACH = air changeper hour (percent ofvolume of spaceexchanged
per hour, expressed as a decimal)
(3) For purposes of this calculation, an inltration rate greater than 0.60
ACH shall not be used in the equations in 9.3.2.2(1) and 9.3.2.2(2).
9.3.2.3 Indoor Opening Size and Location. Openings used to connect
indoorspacesshall be sizedandlocatedin accordancewiththefollowing:
(1)*Combining spaces on the same story. Each opening shall have a
minimum free area of 1 in.2/1000Btu/hr (2200 mm2/kW) of the total
input rating of all appliances in the space but not less than 100 in.2
(0.60m2). One opening shall commence within 12 in. (300 mm) of
the top, and one opening shall commence within 12 in. (300 mm) of
thebottom,of the enclosure [seeFigure A.9.3.2.3(1)].The minimum
dimension of air openings shall be not less than 3 in. (80 mm).
Furnace
Water
Heater
Opening
Chimney or Gas Vent
Opening
NOTE: Each opening must have
a free area of not less than one
square inch per 1000 BTU of
the total input rating of all equip-
ment in the enclosure, but not
less than 100 square inches.
Figure A.9.2.3.3.(1) All Combustion Air from Adjacent
Indoor Spaces through Indoor CombustionAir Openings.
(2) Combining spaces in dierent stories.The volumes of spaces in
dierent stories shall be considered as communicating spaces where
such spaces are connected by one or more openings in doors or oors
having a total minimum free area of 2 in.2/1000 Btu/hr (4400 mm2/
kW) of total input rating of all appliances.
9.3.3 Outdoor Combustion Air. Outdoor combustion air shall be
provided through opening(s) to the outdoors in accordance with the
methods in 9.3.3.1 or 9.3.3.2. The minimum dimension of air openings
shall not be less than 3 in. (80 mm).
9.3.3.1 Two Permanent Openings Method. Two permanent openings,
one commencing within 12 in. (300 mm) of the top and one commencing
within 12 in. (300 mm) of the bottom, of the enclosure shall be provided.
The openings shall communicate directly, or by ducts, with the outdoors
or spaces that freely communicate with the outdoors, as follows:
(1)*Where directly communicating with the outdoors or where commu-
nicating to the outdoors through vertical ducts, each opening shall
have a minimum free area of 1 in.2/4000 Btu/hr (550 min2/kW) of
total input rating of all appliances in the enclosure. [See Figure
A.9.3.3.1(1)(a) and Figure A.9.3.3.1(1)(b).]
Furnace
Water
Heater
Outlet Air
Chimney or Gas Vent
NOTE: The inlet and outlet air
openings must each have a free
area of not less than one square
inch per 4000 BTU of the
total input rating of all equipment
in the enclosure.
Inlet Air
Ventilation louvers for
unheated crawl space
Alternate
air inlet
Ventilation louvers
(each end of attic)
FigureA.9.3.3.1(1)(a)All Combustion Air From Outdoors -
Inlet Air from Ventilated Crawl Space and Outlet Air
to Ventilated Attic.
Furnace
Water
Heater
Outlet Air
Chimney or Gas Vent
NOTE: The inlet and outlet air
openings must each have a free
area of not less than one square
inch per 4000 BTU of the
total input rating of all equipment
in the enclosure.
Inlet air duct
[ends 1 ft (300 mm)
above floor]
Ventilation louvers
(each end of attic)
Figure A.9.3.3.1(1)(b) All Combustion Air
From Outdoors through Ventilated Attic.
(2)*Where communicating with the outdoors through horizontal ducts,
each opening shall have a minimum free area of 1 in.2/2000 Btu/
hr (1100 min2/kW) of total input rating of all appliances in the
enclosure. [See Figure A.9.3.3.1(2).]
Required Volumeother ≥21 ft3(Iother )
ACH 1000 Btu/hr

INSTALLATION CONSIDERATIONS
14
Furnace
Water
Heater
Chimney or Gas Vent
NOTE: The air duct openings
must have a free area of not
less than one square inch per
2000 BTU of the total input
rating of all equipment in the
enclosure*.
Outlet air duct
Inlet air duct
Figure A.9.3.3.1(2) All Combustion Air From Outdoors
through Horizontal Ducts.
9.3.3.2*OnePermanentOpeningMethod.One permanent openings,
commencing within 12 in. (300 mm) of the top of the enclosure, shall
be provided. The appliance shall have clearances of at least 1 in. (25
mm) from the sides and back and 6 in. (150 mm) from the front of the
appliance. The opening shall directly communicate with the outdoors
or shall communicate through a vertical or horizontal duct to the out-
doors or spaces that freely communicate with the outdoors (see Figure
A.9.3.3.2) and shall have a minimum free area of the following:
(1) 1 in.2/3000 Btu/hr (700 mm2per kW) of the total input rating of all
appliances located in the enclosure, and
(2) Not less thanthesumof the areas of allventconnectorsin the space.
Furnace
Water
Heater
Opening
Chimney or Gas Vent
NOTE: The single opening must have
a free area of not less than one
square inch per 3000 BTU of
the total input rating of all equip-
ment in the enclosure, but not less than
the sum of the areas of all vent
connectors in the confined space.
Alternate
Opening
Location
Figure A.9.3.3.2 All Combustion Air
From Outdoors through Single Combustion Air Opening.
9.3.4 Combination Indoor and Outdoor Combustion Air. The use
of a combination of indoor and outdoor combustion air shall be in
accordance with (1) through (3) (see example calculation in Annex J]:
(1) Indoor Openings: Where used, openings connecting the interior
spaces shall comply with 9.3.2.3.
(2) Outdoor Opening(s) Location. Outdoor opening(s) shall be located
in accordance with 9.3.3.
(3) Outdoor Opening(s) Size. The outdoor opening(s) size shall be
calculated in accordance with the following:
(a) The ratio of the interior spaces shall be the available volume
of all communicating spaces divided by the required volume.
(b) The outdoor size reduction factor shall be 1 minus the ratio
of interior spaces.
(c) The minimum size of outdoor opening(s) shall be the full size
of outdoor opening(s) calculated in accordance with 9.3.3,
multiplied by the reduction factor. The minimum dimension
of air openings shall not be less than 3 in. (80 mm).
9.3.5 Engineered Installations. Engineered combustion air installa-
tions shall provide an adequate supply of combustion, ventilation, and
dilution air and shall be approved by the authority having jurisdiction.
9.3.6 Mechanical CombustionAir Supply. Where all combustion air
is provided by a mechanical air supply system, the combustion air shall
be supplied form outdoors at the minimum rate of 0.35 ft3/min per 1000
Btu/hr (0.034 m3/min per kW) for all appliances located within the space.
9.3.6.1Where exhaust fans areinstalled, additional air shall be provided
to replace the exhausted air.
9.3.6.2 Each of the appliances served shall be interlocked to the me-
chanical air supply system to prevent main burner operation where the
mechanical air supply system is not in operation.
9.3.6.3 Where combustion air is provided by the building’s mechanical
ventilation system, the system shall provide the specied combustion
air rate in addition to the required ventilation air.
9.3.7 Louvers, Grilles, and Screens.
9.3.7.1 Louvers and Grilles. The required size of openings for com-
bustion, ventilation, and dilution air shall be based on the net free area
of each opening. Where the free area through a design of louver or
grille or screen is known, it shall be used in calculating the size open-
ing required to provide the free area specied. Where the louver and
grille design and free area are not known, it shall be assumed that wood
louvers will have 25 percent free area, and metal louvers and grilles
will have 75 percent free area. Nonmotorized louvers and grilles shall
be xed in the open position.
9.3.7.2 Minimum Scree Mesh Size. Screens shall not be smaller than
1/4 in. mesh.
9.3.7.3 Motorized Louvers. Motorized louvers shall be interlocked
with the appliance so they are proven in the full open position prior to
main burner ignition and during main burner operation. Means shall
be provided to prevent the main burner form igniting should the louver
fail to open during burner startup and to shut down the main burner if
the louvers close during burner operation.
9.3.8 CombustionAir Ducts. Combustion air ducts shall comply with
9.3.8.1 through 9.3.8.8.
9.3.8.1 Ducts shall be constructed of galvanized steel or a material
having equivalent corrosion resistance, strength, and rigidity.
Exception: Within dwellings units, unobstructed stud and joist spaces
shall not be prohibited from conveying combustion air, provided that
not more than one reblock is removed.
9.3.8.2 Ducts shall terminate in an unobstructed space, allowing free
movement of combustion air to the appliances.
9.3.8.3 Ducts shall serve a single space.
9.3.8.4Ducts shall not serve both upper and lower combustion air open-

INSTALLATION CONSIDERATIONS
15
ings where both such openings are used. The separation between ducts
servicing upper and lower combustion air openings shall be maintained
to the source of combustion air.
9.3.8.5 Ducts shall not be screened where terminating in an attic space.
9.3.8.6Horizontal upper combustion air ducts shall not slope downward
toward the source of combustion air.
9.3.8.7 The remaining space surrounding a chimney liner, gas vent,
special gas vent, or plastic piping installed within a masonry, metal, or
factory built chimney shall not be used to supply combustion air.
Exception: Direct vent appliances designed for installation in a solid
fuel-burning replace where installed in accordance with the manufac-
ture’s installation instructions.
9.3.8.8 Combustion air intake openings located on the exterior of the
building shall have the lowest side of the combustion air intake openings
located at least 12 in. (300 mm) vertically from the adjoining grade level.
Horizontal Applications and Considerations
Horizontal applications, in particular, may dictate many of
the installation’s specics such as airow direction, ductwork
connections, ue and/or combustion air pipe connections, etc.
The basic application of this furnace as a horizontal furnace
di󰀨ers only slightly from an upright installation. When installing
a furnace horizontally, additional consideration must be given
to the following:
Drain Trap and Lines
In horizontal applications the condensate drain trap is secured
to the furnace side panel, suspending it below the furnace. A
minimum clearance of 5.5" below the furnace must be provided
for the drain trap. Additionally, the appropriate downward pip-
ing slope must be maintained from the drain trap to the drain
location. Refer to Condensate Drain TrapandLinessectionin
this manual or the installation instructions for further details. If
the drain trap and drain line will be exposed to temperatures
near or below freezing, adequate measures must be taken to
prevent condensate from freezing. NOTE: The use of insu-
lation and/or heat tape is recommended. Failure to provide
proper condensate drainage can result in property damage.
Leveling
Leveling ensures proper condensate drainage from the heat
exchanger and induced draft blower. For proper ue pipe
drainage, the furnace must be level lengthwise from end to
end. The furnace should also be level from back to front or have
a slight tilt with the access doors downhill (approximately 3/4")
from the back panel. The slight tilt allows the heat exchanger
condensate, generated in the recuperator coil, to ow forward
to the recuperator coil front cover.
In horizontal installations with the furnace laying on the left
hand side, the alternate vent connection may be used. In this
conguration the internal elbow is removed. The standard
piping connections may also be used in these positions. Refer
to Vent/Flue Pipe and Combustion Air Pipe section in the
installation instructions for details concerning the conversion
to the alternate vent/ue and combustion air connections on
the 90% furnace.
The 34.5" single stage furnace is one of the products in our
newly redesigned line of shorter chassis furnaces. It is avail-
able in 92% AFUE upow/horizontal model.
The upow/horizontal 34.5" single stage furnace is available
in the following models:
DM92SE0403AN
DM92SE0603BN
DM92SE0803BN
DM92SE0804CN
DM92SE0805CN
DM92SE1004CN
DM92SE1005CN
DM92SE1205DN
AIR
DISCHARGE
Bottom
Return
Duct
Connection
Side
Return
Duct
Connection
Side
Return
Duct
Connection
UPFLOW
UPRIGHT
AIR
DISCHARGE
Bottom
Return
Duct
Connection
UPFLOW HORIZONTAL
RIGHT AIR DISCHARGE
UPFLOW HORIZONTAL
LEFT AIR DISCHARGE
AIR
DISCHARGE
AIR
DISCHARGE
Bottom
Return
Duct
Connection
Bottom
Return
Duct
Connection
COUNTERFLOW HORIZONTAL
RIGHT AIR DISCHARGE
COUNTERFLOW HORIZONTAL
LEFT AIR DISCHARGE
90% Furnace Recommended Installation Positions
NOTE: Alternate "vertical" piping connections can not be
used when an upow 90% furnace is installed with supply
air discharging to the right or when a counterow furnace is
installed with supply discharging to the left. In this case, use
the standard ue and combustion air piping connections
Alternate Electrical and Gas Line Connections
Furnaces have provisions allowing for electrical and gas line
connections through either side panel. In horizontal applica-

INSTALLATION CONSIDERATIONS
16
tions the connections can be made either through the “top” or
“bottom” of the furnace.
Drain Pan
A drain pan must be provided if the furnace is installed above
a conditioned area. The drain pan must cover the entire area
under the furnace (and air conditioning coil if applicable).
Freeze Protection
If the drain trap and drain line will be exposed to temperatures
near or below freezing, adequate measures must be taken to
prevent condensate from freezing. NOTE: The use of insu-
lation and/or heat tape is recommended. Failure to provide
proper condensate drainage can result in property damage.
Propane Gas and/or High Altitude Installations
WARNING
P OSSIBLE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH MAY OCCUR IF
THE CORRECT CONVERSION KITS ARE NOT INSTALLED.
T
HE APPROPRIATE KITS
MUST BE APPLIED TO INSURE SAFE AND PROPER FURNACE OPERATION.
A
LL
CONVERSIONS MUST BE PERFORMED BY A QUALIFIED INSTALLER OR SERVICE
AGENCY.
This furnace is shipped from the factory congured for natural
gas at standard altitude. Propane gas installations require an
orice change to compensate for the energy content di󰀨erence
between natural and propane gas.
High altitude installations may require both a pressure switch
and an orice change. These changes are necessary to com-
pensate for the natural reduction in the density of both the gas
fuel and the combustion air at higher altitude.
Refer to the Accessories Charts in this manual or product
Specication Sheet for a tabular listing of appropriate manu-
facturer’s kits for propane gas and/or high altitude installations.
The indicated kits must be used to insure safe and proper
furnace operation. All conversions must be performed by a
qualied installer, or service agency.
VENT/FLUE PIPE AND COMBUSTION AIR PIPE
WARNING
F
AILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN BODILY INJURY OR
DEATH.
C
AREFULLY READ AND FOLLOW ALL INSTRUCTIONS GIVEN IN THIS
SECTION.
WARNING
UPON COMPLETION OF THE FURNACE INSTALLATION, CAREFULLY INSPECT THE
ENTIRE FLUE SYSTEM BOTH INSIDE AND OUTSIDE THE FURNACE TO ASSURE IT
IS PROPERLY SEALED. LEAKS IN THE FLUE SYSTEM CAN RESULT IN SERIOUS
PERSONAL INJURY OR DEATH DUE TO EXPOSURE TO FLUE PRODUCTS,
INCLUDING CARBON MONOXIDE.
This manual will refer to the pipe that discharges products of
combustion to the outdoors as the "vent" pipe or "ue" pipe.
The pipe that supplies air for combustion to the furnace will
be referred to as the "intake" pipe or "combustion air" pipe.
A condensing gas furnace achieves its high level of e󰀩ciency
by extracting almost all of the heat from the products of com-
bustion and cooling them to the point where condensation
takes place. Because of the relatively low ue gas temperature
and water condensation requirements, PVC pipe is used as
venting material.
This furnace must not be connected to Type B, BW, or L vent
or vent connector, and must not be vented into any portion
of a factory built or masonry chimney except when used as
a pathway for PVC as described later in this section. Never
common vent this appliance with another appliance or use a
vent which is used by a solid fuel appliance.
It is the responsibility of the installer to follow the manufac-
turers’ recommendations and to verify that all vent/ue piping
and connectors are compatible with furnace ue products.
Additionally, it is the responsibility of the installer to ensure
that all piping and connections possess adequate structural
integrity and support to prevent ue pipe separation, shifting,
or sagging during furnace operation.
D
Furnaces Only)
The 90% furnace is dual certied and may be installed as a
non-direct vent (single pipe) or direct vent (dual pipe) appli-
ance. A non-direct vent installation requires only a vent/ue
pipe. A direct vent installation requires both a vent/ue pipe
and a combustion air intake pipe. Refer to the appropriate
section for details concerning piping size, length, number of
elbows, furnace connections, and terminations.
WARNING
T
O AVOID BODILY INJURY, FIRE OR EXPLOSION, SOLVENT CEMENTS MUST BE
KEPT AWAY FROM ALL IGNITION SOURCES (I.E., SPARKS, OPEN FLAMES, AND
EXCESSIVE HEAT) AS THEY ARE COMBUSTIBLE LIQUIDS.
A
VOID BREATHING
CEMENT VAPORS OR CONTACT WITH SKIN AND/OR EYES.
Precautions should be taken to prevent condensate



extended periods of time should be insulated with 1/2”

outdoors in excess of the terminations shown in this
manual (or in unheated areas) should be insulated with
1/2” thick closed cell foam. Inspect piping for leaks prior
to installing insulation.

INSTALLATION CONSIDERATIONS
17
The following bullets and diagram describe the restrictions
concerning the appropriate location of vent/ue pipe and
combustion air intake pipe (when applicable) terminations.
Refer to the installation instructions for specic details on
termination construction.
• All terminations must be located at least 12 inches above
ground level or the anticipated snow level.
• Vent terminations must terminate at least 3 feet above
any forced air inlet located within 10 feet.
NOTE: This provision does not apply to the combustion
air intake termination of a direct vent application.
• The vent termination of a non-direct vent application
must terminate at least 4 feet below, 4 feet horizontally
from, or 1 foot above any door, window, or gravity air
inlet into any building.
• The vent termination of a direct vent application must
terminate at least 12 inches from any opening through
which ue gases may enter a building (door, window,
or gravity air inlet).
• The vent termination of vent pipe run vertically through
a roof must terminate at least 12 inches above the roof
line (or the anticipated snow level) and be at least 12
inches from any vertical wall (including any anticipated
snow build up).
• A vent termination shall not terminate over public walk-
ways or over an area where condensate or vapor could
create a nuisance or hazard or could be detrimental
to the operation of regulators, relief valves, or other
equipment.
• The combustion air intake termination of a direct vent
application should not terminate in an area which is
frequently dusty or dirty.
NOTE: In Canada, the B149 Fuel Gas Code takes precedence
over the preceding termination restrictions.
Direct Vent Installations
On upow units secure the combustion air intake pipe directly
to the air intake coupling. On counterow units secure the
combustion air intake pipe to the air intake coupling using the
rubber coupling and worm gear hose clamps provided with the
unit. The counterow rubber coupling allows service removal
of air intake piping internal to the furnace blower compartment.
The combustion air intake pipe can also be secured directly
to the counterow unit air intake pipe coupling.
Non-Direct Vent Installations
A minimum of one 90° elbow must be installed on the combustion
air intake “coupling” to guard against inadvertent blockage.
WARNING
T
HE RUBBER ELBOW IS NOT DESIGNED TO SUPPORAT A LOAD.
W
HEN THE
RUBBER ELBOW IS MOUNTED EXTERNALLY TO THE FURNACE CABINET,
EXTREME CARE MUST BE TAKEN TO ADEQUATELY SUPPORT FIELD-SUPPLIED
VENT/FLUE PIPING, AS DAMAGE CAN RESULT IN LEAKS CAUSING BODILY
INJURY OR DEATH DUE TO EXPOSURE TO FLUE GASES, INCLUDING CARBON
MONOXIDE.
CAUTION
BE SURE NOT TO DAMAGE INTERNAL WIRING OR OTHER COMPONENTS WHEN
REINSTALLING COUPLING AND SCREWS.
Vent/Flue Pipe Lengths and Diameters
Refer to the following tables for applicable length, elbows, and
pipe diameter for construction of the vent/ue pipe system of a
non-direct vent installation. In addition to the vent/ue pipe, a
single 90° elbow must be secured to the combustion air intake
to prevent inadvertent blockage. The tee or elbows used in the
vent/ue termination must be included when determining the
number of elbows in the piping system.
DM92SE* Direct Vent (2-Pipe) and Non-Direct Vent (1-Pipe) (6)
Maximum Allowable Length of Vent/Flue Pipe and
Combustion Air Pipe (Ft) (1) (2)
ELBOWS
MODEL
PIPE
SIZE
12345678
DM92SE0402BN
2165 160 155 150 154 140 135 130
3 168 161 154 147 140 133 126 119
DM92SE0603BN
255 50 45 40 35 30 25 20
3 127 120 113 106 99 92 85 78
DM92SE0803BN
2^ 30 25 20 15 10 5 N/A N/A
3^ 72 65 58 51 44 37 30 23
DM92SE0804CN
2^ 30 25 20 15 10 5 N/A N/A
3^ 72 65 58 51 44 37 30 23
DM92SE0805CN
2^ 40 35 30 25 20 15 8 1
3 72 67 62 57 52 47 40 33
DM92SE1004CN
2 60 55 50 45 40 35 28 21
3 168 163 158 153 148 143 136 129
DM92SE1005CN
2 30 25 20 15 10 5 N/A N/A
3 113 106 99 92 85 78 71 64
DM92SE1205DN
2N/A N/A N/A N/A N/A N/A N/A N/A
3 65 58 51 44 37 30 23 16
1) Maximum allowable limits listed on individual lengths for inlet and ue and NOT a
combination.
2) Minimum requirement for each vent pipe is ve (5) feet in length and one elbow/tee.
3) Tee used in the vent/ue termination must be included when determining the number
of elbows in the piping system.
4) 2 1/2” or 3” diameter pipe can be used in place of 2” diameter pipe.
5) Increased Clearance Congurations using (2) 45 deg. Long Sweep elbows should
be considered equivalent to one 90 deg. elbow.
6) One 90° elbow should be secured to the combustion air intake connection.
Vent/Flue and Combustion Air Pipe Lengths and Diameters
Refer to the preceding table for applicable length, elbows, and
pipe diameter for construction of the vent/ue and combus-
tion air intake pipe systems of a non-direct vent (single pipe)
installation. The number of elbows tabulated represents the
number of elbows and/or tees in each (Vent/Flue & Combustion

INSTALLATION CONSIDERATIONS
18
installation. The number of elbows tabulated represents the
number of elbows and/or tees in each (Vent/Flue & Combustion
Air Intake) pipe. Elbows and/or tees used in the terminations
must be included when determining the number of elbows in
the piping systems.
If the combustion air intake pipe is to be installed above a
nished ceiling or other area where dripping of condensate
will be objectionable, insulation of the combustion air pipe may
be required. Use 1/2” thick closed cell foam insulation such
as Armaex or Insultube where required.
Vent/Flue Pipe Terminations
The vent/ue pipe may terminate vertically, as through a roof,
or horizontally, as through an outside wall.
Vertical vent/ue pipe termination should be as shown in the
following gures. Refer to Vent/Flue Pipe and Combustion
Air Pipe - Termination Locations section in this manual or the
installation instructions for details concerning location restric-
tions. The penetration of the vent through the roof must be
sealed tight with proper ashing such as is used with a plastic
plumbing vent.
NOTE: Terminate both pipes in the same pressure zone
(same side of roof, no major obstacles between pipes,
etc.).
ROOFLINE
COMBUSTION AIR INTAKE
(OPTIONAL)
*Not required for
single pipe installation
TEE (OPTIONAL)
96”MAX.-3”MIN.
12” MIN
HEIGHT DIFFERENCE
BETWEEN
INTAKE AND VENT
12” MIN TO ROOF OR HIGHEST
ANTICIPATED SNOW LEVEL
STRAIGHT
ELBOWS
Horizontal vent/ue pipe terminations should be as shown in
the following gure. Refer to Vent/Flue Pipe and Combustion
Air Pipe - Termination Locations section in this manual or the
installation instructions for details concerning location restric-
tions. A 2 3/8" diameter wall penetration is required for 2"
diameter pipe while a 3 1/2" diameter hole is required for 3"
diameter pipe. To secure the pipe passing through the wall and
prohibit damage to piping connections, a coupling should be
installed on either side of the wall and solvent cemented to a
length of pipe connecting the two couplings. The length of pipe
should be the wall thickness plus the depth of the socket ttings
to be installed on the inside and outside of the wall. The wall
penetration should be sealed with silicone caulking material.
VENT/FLUE TEE (
or

TURNED DOWN or

DOWN
OPTIONAL)
12" MIN. ABOVE
HIGHESTANTICIPATED
SNOW LEVEL
12" MIN.
Horizontal Termination (Single Pipe)
Above Highest Anticipated Snow Level

ELBOW
12" MIN. TO GRADE OR
HIGHEST ANTICIPATED
SNOW LEVEL
6” MAX
4” MIN
Standard Horizontal Terminations (Dual Pipe)

INSTALLATION CONSIDERATIONS
19

ELBOWS
12" MIN. ABOVE
HIGHEST ANTICIPATED
SNOW LEVEL
3” - 24”
Alternate Horizontal Vent Termination (Dual Pipe)

ELBOWS
12" MIN. ABOVE
HIGHEST ANTICIPATED
SNOW LEVEL
3”-24” BETWEEN PIPES
Combustion Air Intake may also be snorkeled to obtain 12” min ground
clearance.
Alternate Vent Termination Above Anticipated Snow Level
(Dual Pipe)
12" MINIMUM
VENT/FLUE TEE
OR

DOWN
12" MINIMUM ABOVE
HIGHEST ANTICIPATED
SNOW LEVEL
90% Furnace Horizontal Termination
(Single Pipe)
Above Highest Anticipated Snow Level
In a basement installation, the vent/ue pipe can be run be-
tween joist spaces. If the vent pipe must go below a joist and
then up into the last joist space to penetrate the header, two
45° elbows should be used to reach the header rather than
two 90° elbows.
Direct Vent (Dual Pipe) Piping
Direct vent installations require both a combustion air intake
and a vent/ue pipe. The pipes may be run horizontally and
exit through the side of the building or run vertically and exit
through the roof of the building. The pipes may be run through
an existing unused chimney; however, they must extend a
minimum of 12 inches above the top of the chimney. The
space between the pipes and the chimney must be closed
with a weather tight, corrosion resistant ashing. Both the
combustion air intake and a vent/ue pipe terminations must
be in the same atmospheric pressure zone. Refer to Vent/Flue
and CombustionAir Pipe - Termination Locations or Concen-
tric Vent Termination section in this manual or the installation
instructions for specic details on termination construction.
Concentric Vent Kits (DCVK) Application
The DCVK-20 and DCVK-30 kit is designed to allow the termi-
nations of a direct vent furnace to be “concentrically” vented
through a wall or roof. This kit allows a single penetration
to support terminations for both the vent/ue pipe and the
combustion air intake pipe.
(DCVK) Vent Termination Clearances
1. Determine termination locations based on clearances
specied in furnace installation instructions, and following
steps as shown in Figures 1,3,6,7,8 and 9.

INSTALLATION CONSIDERATIONS
20
Direct Vent
Terminal
50,000 Btuh
or less
9"
12"
12" 12"
Direct Vent Terminal
More than 50,000 Btuh
Forced Air Inlet
3'
GRADE
FIGURE 1
2. The vent termination must be located at least 12” above
ground or normally expected snow accumulation levels.
3. Do NOT terminate over public walkways. Avoid areas
where condensate may cause problems such as above
planters, patios, or adjacent to windows where steam may
cause fogging.
4. The vent termination shall be located at least 4’ horizon-
tally from any electric meter, gas meter, regulator and any
relief equipment. These distances apply ONLY to U.S.
Installations.
5. The vent termination shall be located at least 3’ above any
forced air inlet located within 10’; and at least 10’ from a
combustion air intake of another appliance, except another
direct vent furnace intake.
6. In Canada, the Canadian Fuel Gas Code takes precedence
over the preceding termination instructions.
3" or 4" Diameter
SDR-26 Pipe
2 or 2 1/2" Diameter
SDR-26 Pipe
2" or 3" Diameter
Y Concentric Fitting
2" or 3" Diameter
Rain Cap
FIGURE 2
These kits are for vertical or horizontal termination of the
combustion air inlet and the exhaust vent pipes on Category
IV gas-red condensing furnaces. The DCVK-30 kit can be
used for 3” diameter pipe systems. The DCVK-20 kit can be
used for the 2” diameter pipe system. For the correct pipe size
for the furnace. Both the combustion air inlet and the exhaust
vent pipes must attach to the termination kit. The termination
kit must terminate outside the structure and must be installed
per the instructions outlined below for vertical or horizontal
termination. Vertical termination is preferred. Field supplied
pipe and ttings are required to complete the installation.
1. Determine the best location for the termination kit. Roof
termination is preferred since it is less susceptible to
damage, has reduced intake contaminants and less visible
vent vapors. For side termination, consideration should
be given to:
a. Possible damage from the vapors to plants/shrubs,
other equipment and building materials
b. Possible damage to the terminal from foreign objects
c. Wind e󰀨ects that may cause recirculation of ue prod-
ucts, debris or light snow
d. Visible vent vapors.
Vent
Maintain 12" (18" for Canada)
minimum clearance above highest
anticipated snow level. Maximum of
24" above roof.
Combustion Air
Roof Boot/Flashing
(Field Supplied)
Support (Field Supplied)
45 Elbow
(Field Supplied)
Combustion Air
Vent
FIGURE 3
WARNING
D
O NOT OPERATE THE FURNACE WITH THE RAIN CAP REMOVED AS
RECIRUCLATION OF THE FLUE GASES MAY OCCUR.
W
ATER MAY ALSO
COLLECT INSIDE THE LARGER COMBUSTIN AIR PIPE AND FLOW TO THE
BURNER ENCLOSURE.
F
AILURE TO FOLLOW THIS WARNING CAN RESULT IN
PROPERTY DAMAGE, EQUIPMENT DAMAGE, PERSONAL INJURY OR DEATH.
Concentric Sidewall Vent Kit (0170K00000S)
This (sidewall only) vent kit is to be used with 2” - 3” vent
systems. The vent kit must terminate outside the structure and
may be installed with the intake and exhaust pipes located
side-by side or with one pipe above the other. This kit is NOT
intended for use with single pipe (non-direct vent) installations.
