Daikin DM96SE User manual
SS-DM96SE www.daikincomfort.com 12/21
Supersedes 03/20
DM96SE / DC96SE
Single-Stage, Multi-Speed
ECM Gas Furnace
Up to 96% AFUE
Heating Input: 40,000 –120,000 BTU/h
■ Contents
Nomenclature........................................ 2
Product Specicaons........................... 3
Dimensions ............................................ 5
Airow Data ........................................... 7
−DM96SE.............................................. 7
−DC96SE ............................................. 10
Wiring Diagram.................................... 14
Accessories .......................................... 15
* Complete warranty details available from your local dealer or at www.daikincomfort.com. To receive the Lifeme Heat Exchanger Limited
Warranty (good for as long as you own your home), the 6-Year Unit Replacement Limited Warranty and the 12-Year Parts Limited Warranty,
online registraon must be completed within 60 days of installaon. Addional requirements for annual maintenance are required for the Unit
Replacement Limited Warranty. Online registraon and some of the addional requirements are not required in California or Québec.
■ Standard Features ■ Cabinet Features
• Heavy-duty stainless-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Single-stage gas valve
• Durable Silicon Nitride igniter
• Mul-speed blower motor
• Self-diagnosc control board with constant
memory fault code history output to a LED
• California Low NOx emissions-compliant models available
• Can no longer be installed in California's South Coast Air
Quality Management District (SCAQMD) on or aer
October 1, 2019.
• AHRI Cered; ETL Listed
• Designed for mul-posion installaon:
DM96SE: upow, horizontal le or right
DC96SE: downow, horizontal le or right
• Cered for direct vent (2-pipe) or non-direct vent (1-pipe)
• Easy-to-install top venng with oponal side venng
• Convenient le or right connecon
for gas and electrical service
• Cabinet air leakage (QLeak) ≤ 2%
• Heavy-gauge steel cabinet with durable nish
• Fully insulated heat exchanger and blower secon
• Airght solid boom or side return with easy-cut tabs
for eortless removal in boom air-inlet applicaons
2 DM96SE DM96SE 3
Nomenclature
D M 96 SE060 3 B N A A
1 2 3,4 5 6 7,8,9 10 11 12 13 14
Brand MinorRevision
DDaikinBrand AInitialRelease
B1stRevision
Configuration
MUpflow/Horizontal MajorRevision
CDownflow/Horizontal AInitialRelease
B1stRevision
AFUE
97–9798%AFUE 9292%AFUE NOx
96–96%AFUE NLowNox(40ng/J)
GasValve CabinetWidth
MModulating A14"
VTwoStage
S - SingleStage
B17½"
C21"
Motor D24½"
C- VariableSpeedECM/Communicating
EMultiSpeedECM S - Multi-Speed PSC MaximumCFM
2800CFM
MBTU/h 31200CFM
04040,000BTU/h 100100,000BTU/h 41600CFM
06060,000BTU/h 120120,000BTU/h 52000CFM
08080,000BTU/h
2www.daikincomfort.com SS-DM96SE SS-DM96SE www.daikincomfort.com 3
DM96SE
0403AN
DM96SE
0603BN
DM96SE
0803BN
DM96SE
0804CN
DM96SE
0805CN
DM96SE
1005CN
DM96SE
1205DN
Heating Data
High Fire Input¹ 40,000 60,000 80,000 80,000 80,000 100,000 120,000
High Fire Output¹ 38,440 57,660 76,880 76,880 76,880 96,100 115,320
AFUE² 96 96 96 96 96 96 96
Temperature Rise Range (°F) 25-55 35-65 35-65 25-55 25-55 30-60 35-65
Vent Diameter³ 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 3"
2 3 4 4 4 5 6
Circulator Blower
Available AC @ 0.5" ESP 1.5 - 3 1.5 - 3 1.5 - 3 1.5 - 4 3 - 5 3 - 5 3 - 5
Size (D x W) 11" x 6" 11" x 8" 11" x 8" 11" x 10" 11" x 10" 11" x 10" 11" x 11"
Horsepower @ 1075 RPM ½ ½ ½ ¾ 111
No. of Speeds 5555555
Electrical Data
Min. Circuit Ampacity10.3 10.3 10.3 14.1 16.93 16.93 16.93
15 15 15 15 20 20 20
Shipping Weight (lbs) 113 116 118 141 142 144 156
ENERGY STAR® Certified
May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.
•
•
•
DM96SE Product Specifications
4www.daikincomfort.com SS-DM96SE SS-DM96SE www.daikincomfort.com 5
Specifications – DC96SE
DC96SE
0403BN
DC96SE
0603BN
DC96SE
0804CN
DC96SE
1005CN
DC96SE
1205DN
Heating Data
High Fire Input¹ 40,000 60,000 80,000 100,000 120,000
High Fire Output¹ 38,440 57,660 76,880 95,000 114,000
AFUE² 96 96 96 95 95
Temperature Rise Range (°F) 35-65 35-65 40-70 40-70 45-75
Vent Diameter³ 2" - 3" 2" - 3" 2" - 3" 2" - 3" 3"
2 3 4 5 6
Circulator Blower
Available AC @ 0.5" ESP 1.5 - 3 1.5 - 3 2.5 - 4 3 - 5 3 - 5
Size (D x W) 11" x 8" 11" x 8" 11" x 10" 11" x 10" 11" x 11"
Horsepower @ 1075 RPM ½ ½ ¾ 1 1
No. of Speeds 55555
Filter Size (in²)
Permanent 10.3 10.3 14.05 16.93 16.93
Disposable 15 15 15 20 20
Electrical Data 113 116 141 144 156
Min. Circuit Ampacity9.6 9.6 11.7 16.93 16.93
15 15 14.1 20 20
Shipping Weight (lbs) 111 114 139 142 154
ENERGY STAR® Certified NO NO NO NO NO
May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.
•
•
4 DM96SE DM96SE 5
Minimum Clearances to Combustible Materials
Position Sides Rear Front Bottom Flue Top
0" 0" 3" C0" 1"
6" 0" 3" C0" 6"
DM96SE Dimensions
Air Discharge Air Return
Model A B C D E
DM96SE0403AN 14" 12½" 10½"
17½" 16"
17½" 16"
DM96SE0804CN 21" 19½" 16" 17½"
DM96SE0805CN 21" 19½" 16" 17½"
DM96SE1005CN 21" 19½" 16" 17½"
DM96SE1205DN 24½" 23"
5
9¼
19⅝
34½
¾
19½
⅞
¾
B
C
23
2⅜
1⅞
2½
2
6½
5
9¼
19⅝
23
24⅞
31⅞
A
21⅛
2⅝
14
23
1
½
1⅜
¾
287/8
2⅜
1⅞
2½
2
2¾
6½
1⅞
26½
23½
Folded Flanges
22
Unfolded Flanges
D
Unfolded Flanges
E
Folded Flanges
Air
Discharge
Air
Discharge
LEFT SIDE VIEW FRONT VIEW RIGHT SIDE VIEW
Condensate Drain
Trap Exterior
Connecon
(Right or Le Side)
¾PVC
Vent/ Flue Pipe
2" PVC Alternate
Vent/ Flue
Locaon
Right-Side
Drain Trap
Exterior Holes
High-Voltage
Electrical Outlet
Alternate
Gas Supply
Low-Voltage
Electrical Outlet
Standard
Gas Supply
Locaon
Center Dimple
For Alternate
Air Intake Pipe
3" OD Hole
Air Intake
2" Pipe
Le-Side
Drain Trap
Exterior Holes
High-Voltage
Electrical Outlet
Low-voltage
Electrical Outlet
6 DM96SE DM96SE 7
DC96SE Dimensions
A
34½
4⅛
11⅜
14¾
25⅛
28¾
C
6⅞ 6⅞
11⅜
14⅞
14¾
25⅛
3½
2½
2
1⅞
2⅝
23
14
1⅜
1½
1⅝
E
D
Unfolded Flanges
18⅛
Unfolded Flanges
20⅛
Folded Flanges
2⅝
1⅞
2½
6½
2
Front View
Right-Side View
Low-Voltage
Electrical Outlet
Alternate Gas
High-Voltage
Electrical Outlet
Standard Drain Trap
Drain Trap Holes
Alternate
Gas Supply
Alternate Vent/
High-Voltage
Electrical Outlet
Right Side Exterior
Drain Trap Holes
Low-Voltage
Electrical Outlet
Air
Discharge
Air
Discharge
Folded Flanges
B
18¼
Minimum Clearances to Combustible Materials
Position Sides Rear Front Bottom Flue Top
0" 0" 3" NC 0" 1"
6" 0" 3" C0" 6"
Air Return Air Discharge
Model A B C D E
17½" 14" 14½" 16"
17½" 14" 14½" 16"
DC96SE0804CN 21" 17½" 18" 19½"
DC96SE1005CN 21" 17½" 18" 19½"
DC96SE1205DN 24½" 21" 21½" 23"
6 DM96SE DM96SE 7
DM96SE Airflow Data
CFM & TEMPERATURE RISE VS. EXTERNAL STATIC PRESSURE
Model DIP SWITCHES
S2-1 , S2-2
External Static Pressure, (Inches Water Column)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
CFM Rise CFM Rise CFM Rise CFM Rise CFM Rise CFM CFM CFM
DM96SE
0403A
715 50 666 53 609 558 500 438 386 333
1110 32 1081 33 1042 34 1003 35 965 37 933 893 856
913 39 871 41 833 43 807 44 765 46 722 675 629
1191 1168 1135 1112 1081 1055 1024 998
DM96SE
785 717 648 587 520 457 400 327
1240 43 1194 45 1153 46 1104 48 1069 50 1019 971 929
972 55 922 58 864 62 811 767 718 651 597
1155 1105 1056 1006 958 908 857 808
DM96SE
747 676 602 529 453 386 329 281
1206 57 1157 59 1111 61 1059 62 1009 65 966 913 863
985 931 875 823 782 723 673 606
1149 1095 1051 1003 951 900 845 812
DM96SE
0804C
1010 935 861 785 721 631 553 483
1621 44 1570 45 1521 47 1467 48 1414 50 1378 1327 1274
1439 49 1400 51 1347 53 1291 55 1234 1182 1125 1065
1826 1775 1726 1684 1634 1588 1538 1492
DM96SE
0805C
1012 937 861 801 722 630 552 485
1836 39 1787 40 1746 41 1699 42 1653 43 1607 1561 1514
1431 50 1389 51 1335 53 1283 55 1226 1176 1117 1055
1836 39 1787 40 1746 41 1699 42 1653 43 1607 1561 1514
DM96SE
1005C
1012 940 863 800 715 627 561 496
1826 49 1783 50 1730 51 1685 53 1642 54 1596 1548 1504
1465 1402 1360 1306 1250 1197 1138 1073
1602 55 1556 57 1510 59 1460 1411 1372 1315 1261
DM96SE
1205D
1121 1018 933 839 762 671 592 519
1969 54 1913 56 1862 57 1807 59 1756 61 1705 1647 1599
1688 63 1626 1564 1500 1448 1393 1334 1267
1865 57 1812 59 1755 61 1692 63 1638 65 1587 1527 1476
Notes
•
•
•
•
•
•
Minimum Filter Sizes
DM96SE
0403ANA
DM96SE
0603BNA
DM96SE
0803BNA
DM96SE
0804CNA
DM96SE
0805CNA
DM96SE
1005CNA
DM96SE
1205DNA
8www.daikincomfort.com SS-DM96SE SS-DM96SE www.daikincomfort.com 9
CIRCULATION AIRFLOW DATA
Model DIP SWITCHES
S2-3 , S2-4
External Static Pressure, (Inches Water Column)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
CFM CFM CFM CFM CFM CFM CFM CFM CFM CFM
DM96SE
0403A
OFF OFF 715 666 609 558 500 438 386 333 276 220
ON OFF 1110 1081 1042 1003 965 933 893 856 820 803
OFF ON 1191 1168 1135 1112 1081 1055 1024 998 978 N/A
ON ON 1344 1312 1278 1247 1215 1178 1143 1114 1081 1049
DM96SE
0603B
OFF OFF 785 717 648 587 520 457 400 327 269 206
ON OFF 1240 1194 1153 1104 1069 1019 971 929 893 N/A
OFF ON 1155 1105 1056 1006 958 908 857 808 772 723
ON ON 1384 1338 1300 1257 1215 1169 1125 1080 1040 994
DM96SE
0803B
OFF OFF 747 676 602 529 453 386 329 281 186 N/A
ON OFF 1206 1157 1111 1059 1009 966 913 863 834 784
OFF ON 1149 1095 1051 1003 951 900 845 812 762 707
ON ON 1414 1380 1333 1305 1260 1223 1180 1137 1091 1047
DM96SE
0804C
OFF OFF 1010 935 861 785 721 631 553 483 423 350
ON OFF 1621 1570 1521 1467 1414 1378 1327 1274 1221 1167
OFF ON 1826 1775 1726 1684 1634 1588 1538 1492 1448 1398
ON ON 1843 1798 1753 1710 1666 1618 1574 1526 1481 1432
DM96SE
0805C
OFF OFF 1012 937 861 801 722 630 552 485 420 353
ON OFF 1836 1787 1746 1699 1653 1607 1561 1514 1471 1419
OFF ON 1836 1787 1746 1699 1653 1607 1561 1514 1471 1419
ON ON 2215 2171 2137 2098 2060 2022 1986 1948 1908 1869
DM96SE
1005C
OFF OFF 1012 940 863 800 715 627 561 496 437 374
ON OFF 1826 1783 1730 1685 1642 1596 1548 1504 1455 1406
OFF ON 1602 1556 1510 1460 1411 1372 1315 1261 1207 1156
ON ON 2225 2180 2141 2105 2070 2033 1996 1957 1923 1883
DM96SE
1205D
OFF OFF 1121 1018 933 839 762 671 592 519 447 371
ON OFF 1969 1913 1862 1807 1756 1705 1647 1599 1544 1481
OFF ON 1865 1812 1755 1692 1638 1587 1527 1476 1411 1351
ON ON 2268 2214 2173 2117 2068 2022 1978 1924 1874 1832
¹ at 0.5" ESP
Notes
• CFM in chart is without lter(s). Filters do not ship with this furnace, but must be provided by the installer. If the furnace requires
two return lters, this chart assumes both lters are installed.
• All furnaces ship as high-speed cooling and medium-speed heang. Installer must adjust blower cooling & heang speed as needed.
• For most jobs, about 400 CFM per ton when cooling is desirable.
• INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE.
• This chart is for informaon only. For sasfactory operaon, external stac pressure should not exceed value shown on the rang plate.
The shaded area indicates ranges in excess of maximum stac pressure allowed when heang.
• The above chart is for U.S. furnaces installed at 0-2000 feet. At higher altudes, a properly derated unit will have approximately
the same temperature rise at a parcular CFM, while ESP at the CFM will be lower.
DM96SE Airflow Data
8 DM96SE DM96SE 9
COOLING AIRFLOW DATA
Model DIP SWITCHES
S1-1 , S1-2 , S1-3
External Static Pressure, (Inches Water Column)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
CFM CFM CFM CFM CFM CFM CFM CFM CFM CFM
DM96SE
0403A
715 666 609 558 500 438 386 333 276 220
715 666 609 558 500 438 386 333 276 220
715 666 609 558 500 438 386 333 276 220
715 666 609 558 500 438 386 333 276 220
1110 1081 1042 1003 965 933 893 856 820 803
913 871 833 807 765 722 675 629 574 535
1191 1168 1135 1112 1081 1055 1024 998 978
1344 1312 1278 1247 1215 1178 1143 1114 1081 1049
DM96SE
785 717 648 587 520 457 400 327 269 206
785 717 648 587 520 457 400 327 269 206
785 717 648 587 520 457 400 327 269 206
785 717 648 587 520 457 400 327 269 206
1240 1194 1153 1104 1069 1019 971 929 893
972 922 864 811 767 718 651 597 556 511
1155 1105 1056 1006 958 908 857 808 772 723
1384 1338 1300 1257 1215 1169 1125 1080 1040 994
DM96SE
747 676 602 529 453 386 329 281 186
747 676 602 529 453 386 329 281 186
747 676 602 529 453 386 329 281 186
747 676 602 529 453 386 329 281 186
1206 1157 1111 1059 1009 966 913 863 834 784
985 931 875 823 782 723 673 606 548 508
1149 1095 1051 1003 951 900 845 812 762 707
1414 1380 1333 1305 1260 1223 1180 1137 1091 1047
DM96SE
0804C
1010 935 861 785 721 631 553 483 423 350
1010 935 861 785 721 631 553 483 423 350
1010 935 861 785 721 631 553 483 423 350
1010 935 861 785 721 631 553 483 423 350
1621 1570 1521 1467 1414 1378 1327 1274 1221 1167
1439 1400 1347 1291 1234 1182 1125 1065 1000 930
1826 1775 1726 1684 1634 1588 1538 1492 1448 1398
1843 1798 1753 1710 1666 1618 1574 1526 1481 1432
DM96SE
0805C
1012 937 861 801 722 630 552 485 420 353
1012 937 861 801 722 630 552 485 420 353
1012 937 861 801 722 630 552 485 420 353
1012 937 861 801 722 630 552 485 420 353
1836 1787 1746 1699 1653 1607 1561 1514 1471 1419
1431 1389 1335 1283 1226 1176 1117 1055 993 924
1836 1787 1746 1699 1653 1607 1561 1514 1471 1419
2215 2171 2137 2098 2060 2022 1986 1948 1908 1869
DM96SE
1005C
1012 940 863 800 715 627 561 496 437 374
1012 940 863 800 715 627 561 496 437 374
1012 940 863 800 715 627 561 496 437 374
1012 940 863 800 715 627 561 496 437 374
1826 1783 1730 1685 1642 1596 1548 1504 1455 1406
1465 1402 1360 1306 1250 1197 1138 1073 1016 947
1602 1556 1510 1460 1411 1372 1315 1261 1207 1156
2225 2180 2141 2105 2070 2033 1996 1957 1923 1883
DM96SE
1205D
1121 1018 933 839 762 671 592 519 447 371
1121 1018 933 839 762 671 592 519 447 371
1121 1018 933 839 762 671 592 519 447 371
1121 1018 933 839 762 671 592 519 447 371
1969 1913 1862 1807 1756 1705 1647 1599 1544 1481
1688 1626 1564 1500 1448 1393 1334 1267 1199 1125
1865 1812 1755 1692 1638 1587 1527 1476 1411 1351
2268 2214 2173 2117 2068 2022 1978 1924 1874 1832
DM96SE Airflow Data
10 DM96SE DM96SE 11
DC96SE Airflow Data
CFM & TEMPERATURE RISE VS. EXTERNAL STATIC PRESSURE
Model DIP SWITCH-
ES S2-1 , S2-2
External Static Pressure, (Inches Water Column)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
CFM Rise CFM Rise CFM Rise CFM Rise CFM Rise CFM CFM CFM
DC96SE
629 566 509 450 388 327 269 228
949 37 899 40 853 42 809 44 786 45 742 697 652
733 49 672 53 613 563 512 454 404 349
1126 1086 1044 1006 968 925 885 849
DC96SE
754 684 615 542 471 411 343 276
1332 40 1291 41 1252 43 1218 44 1173 45 1134 1088 1049
972 55 922 58 864 62 811 767 718 651 597
1155 46 1105 48 1056 51 1006 53 958 56 908 857 808
DC96SE
0804C
760 686 613 542 459 376 310 266
1390 51 1342 53 1292 55 1254 57 1201 59 1157 1112 1072
1397 51 1361 52 1318 54 1266 56 1224 58 1181 1139 1095
1581 1537 1492 1452 1413 1387 1347 1305
DC96SE
1005C
1211 1129 1045 964 890 812 764 702
1650 54 1592 56 1530 58 1478 60 1428 62 1389 1327 1270
1457 61 1394 64 1338 66 1294 69 1236 1171 1110 1048
1860 1810 1755 1702 1656 1611 1553 1511
DC96SE
1205D
1296 1190 1076 960 839 760 653 559
1917 56 1843 58 1759 61 1686 63 1600 67 1513 1420 1348
1611 66 1521 70 1433 74 1347 1246 1145 1044 953
2011 1936 1858 1779 1692 1610 1531 1442
Notes
•
•
•
•
•
•
Minimum Filter Sizes
DC96SE
0403BNA
DC96SE
0603BNA
DC96SE
0804CNA
DC96SE
1005CNA
DC96SE
1205DNA
10 DM96SE DM96SE 11
CIRCULATION AIRFLOW DATA
Model DIP SWITCHES
S2-3 , S2-4
External Static Pressure, (Inches Water Column)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
CFM CFM CFM CFM CFM CFM CFM CFM CFM CFM
DC96SE
629 566 509 450 388 327 269 228 195 153
949 899 853 809 786 742 697 652 609 575
1126 1086 1044 1006 968 925 885 849 827 792
1359 1321 1284 1251 1218 1181 1147 1114 1080 1045
DC96SE
754 684 615 542 471 411 343 276 214
1332 1291 1252 1218 1173 1134 1088 1049 1013
1155 1105 1056 1006 958 908 857 8080 772 723
1384 1338 1300 1257 1215 1189 1169 1125 1080 1040
DC96SE
0804C
760 686 613 542 459 376 310 266 224 190
1390 1342 1292 1254 1201 1157 1112 1072 1022 985
1581 1537 1492 1452 1413 1387 1347 1305 1267 1225
1800 1758 1716 1678 1636 1601 1565 1529 1491 1457
DC96SE
1005C
1211 1129 1045 964 890 812 764 702 639 583
1650 1592 1530 1478 1428 1389 1327 1270 1213 1159
1860 1810 1755 1702 1656 1611 1553 1511 1454 1405
2230 2176 2125 2086 2038 1999 1958 1917 1880 1829
DC96SE
1205D
1296 1190 1076 960 839 760 653 559 452 351
1917 1843 1759 1686 1600 1513 1420 1348 1258 1173
2011 1936 1858 1779 1692 1610 1531 1442 1365 1266
2317 2257 2196 2122 2061 1990 1914 1762 1523 1232
Notes
•
•
•
•
•
•
DC96SE Airflow Data
12 DM96SE DM96SE 13
COOLING AIRFLOW DATA
Model DIP SWITCHES
S1-1 , S1-2 , S1-3
External Static Pressure, (Inches Water Column)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
CFM CFM CFM CFM CFM CFM CFM CFM CFM CFM
DC96SE
629 566 509 450 388 327 269 228 195 153
629 566 509 450 388 327 269 228 195 153
629 566 509 450 388 327 269 228 195 153
629 566 509 450 388 327 269 228 195 153
949 899 853 809 786 742 697 652 609 575
733 672 613 563 512 454 404 349 306 261
1126 1086 1044 1006 968 925 885 849 827 792
1359 1321 1284 1251 1218 1181 1147 1114 1080 1045
DC96SE
754 684 615 542 471 411 343 276 214
754 684 615 542 471 411 343 276 214
754 684 615 542 471 411 343 276 214
754 684 615 542 471 411 343 276 214
1332 1291 1252 1218 1173 1134 1088 1049 1013
972 922 864 811 767 718 651 597 556 511
1155 1105 1056 1006 958 908 857 808 772 723
1384 1338 1300 1257 1215 1189 1169 1125 1080 1040
DC96SE
0804C
760 686 613 542 459 376 310 266 224 190
760 686 613 542 459 376 310 266 224 190
760 686 613 542 459 376 310 266 224 190
760 686 613 542 459 376 310 266 224 190
1390 1342 1292 1254 1201 1157 1112 1072 1022 985
1397 1361 1318 1266 1224 1181 1139 1095 1050 1003
1581 1537 1492 1452 1413 1387 1347 1305 1267 1225
1800 1758 1716 1678 1636 1601 1565 1529 1491 1457
DC96SE
1005C
1211 1129 1045 964 890 812 764 702 639 583
1211 1129 1045 964 890 812 764 702 639 583
1211 1129 1045 964 890 812 764 702 639 583
1211 1129 1045 964 890 812 764 702 639 583
1650 1592 1530 1478 1428 1389 1327 1270 1213 1159
1457 1394 1338 1294 1236 1171 1110 1048 986 919
1860 1810 1755 1702 1656 1611 1553 1511 1454 1405
2230 2176 2125 2086 2038 1999 1958 1917 1880 1829
DC96SE
1205D
1296 1190 1076 960 839 760 653 559 452 351
1296 1190 1076 960 839 760 653 559 452 351
1296 1190 1076 960 839 760 653 559 452 351
1296 1190 1076 960 839 760 653 559 452 351
1917 1843 1759 1686 1600 1513 1420 1348 1258 1173
1611 1521 1433 1347 1246 1145 1044 953 876 790
2011 1936 1858 1779 1692 1610 1531 1442 1365 1266
2317 2257 2196 2122 2061 1990 1914 1762 1523 1232
12 DM96SE DM96SE 13
Temperature Rise Range Chart
30 40 50 60 70 80 90 110 120
100 130 140 150
100
90
80
70
60
50
40
30
20
10
OUTPUT BTU/HR x 1000
BTU OUTPUT vs TEMPERATURE RISE CHART
TEMPERATURE RISE
600 CFM
700
900
1000
1100
1200
1400
1600
1800
2000
2200
2400 CFM
FORMULAS
BTU OUTPUT = CFM x 1.08 x RISE
RISE =
BTU OUTPUT
1.08
÷ CFM
800
Output BTU/h x 1,000
BTU Output Vs. Temperature Rise Chart
14 www.daikincomfort.com SS-DM96SE SS-DM96SE www.daikincomfort.com 15
Wiring Diagram
Wiring is subject to change. Always
refer to the wiring diagram on the
unit for the most up-to-date wiring. ⚠Warning High Voltage: Disconnect all power before servicing or installing this unit. Mulple power
sources may be present. Failure to do so may cause property damage, personal injury, or death. ⚡
YLYELLOW
ORORANGE
PUPURPLE
GRGREEN
BKBLACK
BRBROWN
WHWHITE
BLBLUE
GYGRAY
RDRED
COLORCODES:
LOWVOLTAGE(24V)
LOWVOLTAGEFIELD
HIVOLTAGE(115V)
HIVOLTAGEFIELD
NOTES:
1.SETHEATANTICIPATORONROOMTHERMOSTATAT0.7 AMPS.
2.MANUFACTUR'S SPECIFIEDREPLACEMENTPARTSMUSTBEUSEDWHENSERVICING.
GASVALVE
C2
INTERNALTO
INTEGRATEDCONTROL
JUNCTION
EQUIPMENTGND
FIELDGND
DIAGNOSTIC
LED
2CIRCUIT
CONNECTOR
HOT
SURFACE
IGNITER
OVERCURRENT
PROT.DEVICE
IGNITER
TH(3)
INTEGRATED
CONTROLMODULE
JUNCTIONBOX
LINE-H
XFMR-H
INTEGRATED CONTROL MODULE
INTEGRATED CONTROL MODULE
GND
DISCONNECT
LN
DISCONNECTPOWER
BEFORESERVICING.
WIRINGTOUNIT
MUSTBE
PROPERLY
POLARIZED
ANDGROUNDED.
OVERCURRENTPROTECTIONDEVICE
BL
4.BLOWERSPEEDSSHOULDBEADJUSTEDBYINSTALLERTOMATCHTHEINSTALLATIONREQUIREMENTSSO
ASTOPROVIDETHECORRECTHEATINGTEMPERATURERISEANDTHECORRECTCOOLINGCFM.
3.IFANYOFTHEORIGINALWIREASSUPPLIEDWITHTHEFURNACEMUSTBEREPLACED,IT MUSTBE
HAVINGATEMPERATURERATINGOFATLEAST
TERMINAL
SWITCH(PRESS.)
5.UNIT MUSTBEPERMANENTLYGROUNDEDANDCONFORMTON.E.C.ANDLOCALCODES.
PKPINK
FLAME
SENSOR
(SINGLECONTROLON40KBTU)
BK
PLUGCONNECTION
FIELDSPLICE
SWITCH(TEMP.)
BLOWER
COMPARTMENT
DOORSWITCH
(OPENWHEN
DOOROPEN)
DOOR
SWITCH
WARNING:D IS CONNECTPOWERBEFORE
SERVIC ING.WIRINGTOUNIT MUSTBE
PROPERLYPOLARIZEDANDGROUNDED.
POWER SUPPLY WITH
OVERCURRENT PROTECTION
DEVICE
1
TO 115 VAC / 1Ø / 60HZ
OR
ID BLOWER
PRESSURE
SWITCH
RD
WH
BURNERCOMPARTMENT
BLOWERCOMPARTMENT
NO
YL
CONTROL
PRIMARYLIMIT
AUTORESET
BL
PU
MANUALRESETROLLOUTLIMIT CONTROL(S)
RD
OR
PK
BK
WHWH
BLOWER
INDUCEDDRAFT
AUXILIARY
LIMIT
CONTROLS
C
FS
LIMIT CONTROLS
AUXILIARY
IGNITER
HOTSURFACE
IND
IGN
BLWR
CIRCULATOR
BLWR
ID
FLAMESENSOR
115VAC
TRANSFORMER
40VA
24VAC
GND
CONTROL
LIMIT
PRIMARY
AUTORESET
(SINGLECONTROLON40KBTU)
LIMITCONTROL(S)
MANUALRESETROLLOUT
RO1(5)
RO2(11)
HLO(1)
HLI(7)
MVC(9)
GND(8)
TR(6)
OR
WH
BL
YL OR
RD
GR BR
PK
PK
BK
BK
24V THERMOSTAT CONNECTIONS N.E.C. CLASS 2 WIRE
MICRO
TO
C
G
Y
W
R
2
OR
BL
YL
OR
PK
RD
OR
WH
XFMR- H
BL
GY
GR
1
2
3
121110
987
654
WARNING:
105°C.USECOPPERCONDUCTORSONLY.
PSO(4)
MV(12)
PS(10)CNO
ID BLOWER
PRESSURE
SWITCH
0
C
6
5
4
3
2
1
OFF=CONTROLFAILURE
STEADYON=NORMALOPERATION
1FLASH=
2FLASHES=PRESSURESWITCHSTUCKCLOSED
3FLASHES=PRESSURESWITCHSTUCKOPEN
4FLASHES=OPENHIGHLIMIT
5FLASHES=FLAMESENSEWITHOUTGASVALVE
OPENROLLOUT
6FLASHES=
SYSTEMLOCKOUT(RETRIESEXCEEDED)
CONTINUOUS/RAPID FLASHES=REVERSED115VACPOLARITY
CONTROL
MODULE
INTEGRATED
FUSE
MI
GY
GY
M1
GAS
VALVE
C2
TO115VAC/1Ø/60HZPOWERSUPPLYWITH
PU
BR
GY
BR
LINE NEUTRALS
NOC
FRONTCOVER
PRESSURESWITCH
C
N
O
FRONTCOVER
PRESSURESWITCH
YL
7FLASHES=
8FLASHES=
LOWFLAMESIGNAL
IGNITERRELAYFAULT
7
8
ELECTRONIC
AIR CLEANER
EAC-H
HUMIDIFIER
HUMIDIFIER
R
CGWY
24VTHERMOSTAT
CONNECTIONS
N.E.C.CLASS2WIRE
RD
OR
115VAC
24VAC
BK
GY
40VA
TRANSFORMER
WH
GR
GND
RD
5
2
143
G
C
WH
L
N
BLOWER
CIRCULATOR
HARNESS
ECMMTR
RDBK
OR
BL
BK
RD
WH
WH
WH
BL
RD
OR
BK
WH
BK
GND
DISCONNECT
L
N
WH
JUNCTIONBOX
GND
GR
GR
GND
GND
E9
E36
IG N-N
IG N-N
IG N-N
E8
120V
E7
HUM-N
E6
IG N-N
E5
XFMR-N
IGN-N
E4
E32
E25
E3
E1 E2
LINE-H XFMR-H CIRC-H 120V
HUM-H EAC-H T1T2T3T4XCOM
BK
RC
MICRO
CONTROLLED
0140F02509-A
9FLASHES=
9
10FLASHES=
10
11FLASHES=
11
12FLASHES=
12
REPLACED WITH WIRING MATERIAL
TWINNINGFAULT
OPENFUSE
IGNITEROPEN
INDUCERRELAYERROR/IMPROPERGROUNDING
BK
CIRC-H
14 www.daikincomfort.com SS-DM96SE SS-DM96SE www.daikincomfort.com 15
Accessories – DM96SE / DC96SE
Model Description DC96SE
0403BN
DC96SE
0603BN
DC96SE
0804CN
DC96SE
1005CN
DC96SE
1205DN
72950 Concentric Vent Kit (2") √√√√---
72951 Concentric Vent Kit (3") √√√√√
CFSB17 Downow Sub-Base 17.5" √ √ --- --- ---
CFSB21 Downow Sub-Base 21" ―--- √ √ ---
CFSB24 Downow Sub-Base 24" ―--- --- --- √
RF000142 Drain Kit -Horizontal Le Vercal Flue √--- --- --- ---
EFR02 External Filter Rack with 16"x25"
Permanent Filter √√√--- ---
0170K00000S Flush Mount Vent Kit - 3" or 2" √√√√√
0170K00001S Flush Mount Vent Kit - 2" √√√√---
AFE18-60A Fossil Fuel (Dual Fuel) Kit √√√√√
HASFK High-Altude Natural Gas Kit HASFK-4 HASFK-4 HASFK-4 HASFK-4 HASFK-4
HASFK High-Altude LP Gas Kit HASFK-5 HASFK-5 HASFK-5 HASFK-4 HASFK-4
0270F05405 Horizontal Drain Tubing Kit √√√√√
LPLP03 Low LP Gas Pressure Switch √√√√√
LPM-07 LP Conversion Kits √√√√√
Notes
√ Indicates available for this model ² Indicates 9,001' to 11,000' altude
¹ Indicates 7,001' to 9,000' altude ³ Indicates 7,001' to 11,000' altude
• All installaons above 7,000' require a pressure switch change.
• For installaon in Canada, gas furnaces are cered only to 4,500'.
Model Description DM96SE
0403AN
DM96SE
0603BN
DM96SE
0803BN
DM96SE
0804CN
DM96SE
0805CNA
DM96SE
1005CN
DM96SE
1205DN
72950 Concentric Vent Kit (2") √√√√√ √ ―
72951 Concentric Vent Kit (3") √√√√√√√
RF000142 Drain Kit Horizontal Le Vercal Flue √√√√√√√
EFR02 External Filter Rack with 16"x25"
Permanent Filter √√√√―――
0170K00000S Flush Mount Vent Kit - 3" or 2" √√√√√√√
0170K00001S Flush Mount Vent Kit - 2" √√√√√ √ ―
AFE18-60A Fossil Fuel (Dual Fuel) Kit √√√√√√√
HASFK High-Altude Natural Gas Kit TBD HASFK-4 HASFK-4 HASFK-4 HASFK-4 HASFK-4 HASFK-4
HASFK High-Altude LP Gas Kit TBD HASFK-6 HASFK-6 HASFK-6 HASFK-5 HASFK-5 HASFK-5
0270F05404 Horizontal Drain Tubing Kit √√√√√√√
LPLP03 Low LP Gas Pressure Switch √√√√√√ √
LPM-07 LP Conversion Kits √√√√√√√
16 www.daikincomfort.com SS-DM96SE SS-DM96SE www.daikincomfort.com PB
Our connuing commitment to quality products may mean a change in specicaons without noce.
©2021 • Houston, Texas
Notes
Other manuals for DM96SE
1
This manual suits for next models
13
Other Daikin Furnace manuals
Daikin
Daikin DM96SN User manual
Daikin
Daikin DM80SE Operating instructions
Daikin
Daikin DM80SE Operating instructions
Daikin
Daikin DM92SN Operating instructions
Daikin
Daikin DM80SN Operating instructions
Daikin
Daikin 90 Plus AFUE Guide
Daikin
Daikin DM92SE Operating instructions
Daikin
Daikin DM80VC User manual
Daikin
Daikin DM80HS0403A User manual
Daikin
Daikin DM97MC Operating instructions
Daikin
Daikin DC96SN User manual
Daikin
Daikin DC96VE User manual
Daikin
Daikin DM96VE User manual
Daikin
Daikin FC Series Instruction Manual
Daikin
Daikin DC97MC User manual
Daikin
Daikin DM96SE User manual
Daikin
Daikin DM80VC Operating instructions
Daikin
Daikin DM80TN Operating instructions
Daikin
Daikin DM80HS User manual
Daikin
Daikin DM92SS User manual
Popular Furnace manuals by other brands
International comfort products
International comfort products F96VTN installation instructions
Bryant
Bryant 926TA Product data
Thermo Pride
Thermo Pride OC2-56 Installation and operation manual
Bullfinch
Bullfinch 1360 Operating, Maintenance and Servicing Instructions
Lennox
Lennox Allied Air A80DF installation instructions
M-TI
M-TI GSL-1500X-OTF Operation manual
Fire Chief
Fire Chief FCOS1600 owner's manual
Grandaire
Grandaire WFAR installation instructions
Comfortaire
Comfortaire GUH80C Service manual
HYC
HYC Fire Chief FC1000E manual
Comfortaire
Comfortaire Century HEAT CONTROLLER ODF Series Installation and operation manual
Drieaz
Drieaz Dragon K85 Mobile owner's manual
