DAKO SmartStick User manual

Please follow these steps:
1.
2.
3.
4.
5.
6.
Connect the SmartStick to your PC via the included USB-C cable and start the
SmartStick-Transfer application.
Under Download period you can define the data period to be downloaded from
the tachograph. You can choose between a download period of 92 days and a
complete download.
Under Download data source you can define whether you want to download
data from the driver card, the tachograph or both.
Under Download speed data you can define whether the existing speed profile
of the tachograph should also be read out.
When you have adjusted all settings, complete the process by clicking on the
button Save Config on SmartStick.
You can reset your SmartStick to the factory settings by clicking on the button
Reset SmartStick.
The SmartStick is pre-configured. This configuration should only be
changed in case of problems or specific use cases.
Admin rights on the computer on which the software is to be installed.
Public user account on the Windows computer
Microsoft Windows at least version 8.1
Internet access
TachoWeb user name and password
Conguring your SmartStick with
SmartStick-Transfer
Technical Requirements for the Application
SmartStick-Transfer
i
Read Out your Data – Simple, Safe, Swift
Operating Manual
The DAKO
SmartStick is Here!
The Smart Key for Reading Out your Driver Cards And Tachographs
The new DAKO SmartStick makes accessing tachograph data easier than ever.
With an optimised pre-configuration, all functions are automatically activated
when plugged into the tachograph or the DAKO TachoStation.
By downloading the tachograph, all data from the respective driver card and the
activities of the vehicle unit in the last 3 months (92 days), as well as its technical
data, incidents and malfunctions are collected. All you have to do, is watching the
LED signal to identify the current status of the data transfers.
More information on how to use the DAKO SmartStick
and LED signals can be found here:
www.telematics.dako.de/en/the-dako-smartstick/
Customer Service
P+49 3641 22778 700
M[email protected]
Wtelematics.dako.de/en/contact/
DAKO GmbH | CEO: Thomas Becker
Court of Registration: Amtsgericht Jena HRB
512470
VAT: DE 237 198 855
Registered in: Jena
Brüsseler Str. 22 | 07747 Jena
P+49 3641 22778 0
F+49 3641 22778 199
[e-mail]
Wwww.dako.de
Download SmartStick-Transfer
https://downloads.dako.de/Programme/SmartStick-Transfer.zip

Simply Follow these Steps:
Download SmartStick-Transfer
1.
2.
3.
4.
5.
Install the SmartStick-Transfer software and ensure that there is an active
internet connection. Software download at:
https://downloads.dako.de/Programme/SmartStick-Transfer.zip
Connect the SmartStick to your PC via the included USB-C cable and start the
SmartStick-Transfer application.
Enter your TachoWeb user name in User name and click on Password valida-
tion. We recommend creating a separate SmartStick user account for data
protection reasons. Then enter the user password of your TachoWeb account
and click on Verify. After the check has been completed, the saved alternative
company will be displayed (if necessary, adjust via the drop-down menu) and
the password validation will be ticked off.
Save a location on your computer (Error path) to store data records that were
evaluated as incorrect and rejected during the check in TachoWeb (e.g. incor-
rect chassis number). Example: C:\Users\Public\Documents\Dako
Start the data upload by clicking the button Upload container data. During the
data upload the SmartStick lights up blue pulsing. After the upload the
SmartStick will be permanently lit green and a confirmation will appear. After
the process is finished, all data will be deleted from the SmartStick.
https://downloads.dako.de/Programme/SmartStick-Transfer.zip
Data Transmission / Upload to TachoWeb
via SmartStick-Transfer
SmartStick
Tr ansfe
r
Download
42%
Simply Follow these Steps:
To begin accessing any tachograph with your SmartStick, turn your
ignition switch to position 1 (accessory).
Insert the company card into slot 2 on the tachograph. The data can only be
downloaded when the company card is inserted.
You can now insert the SmartStick into the corresponding access socket on
the tachograph. The stick will start downloading immediately and automati-
cally. Wait until card authentication is completed.
During the download, the colour of the LED signal on the SmartStick will
inform you of the current status. Only remove the SmartStick from the tacho-
graph when the LED‘s signal is permanently green.
1.
2.
3.
4.
Reading Out Data / Downloading from
Tachograph
Pulsing yellow light SmartStick storage is full
Pulsing red light Download error/communication error/
storage error
LED Signal
Permanent blue light
Permanent green light
Permanent red light
Blue pulsing light Download in progress
Unknown hardware error
Download successful, SmartStick can be
removed from the device
SmartStick inserted, waiting mode
Meaning
Simply Follow these Steps:
1.
2.
3.
4.
Insert the SmartStick into the
corresponding port on the TachoStation (bottom right-hand side).
You will automatically be logged in to the TachoStation. Wait for instructions
on the display.
Manually confirm the data transmission on the screen to start.
The LED colour on the SmartStick will inform you of its status during the
uploading process on the TachoStation. Please only remove the SmartStick
when the LED signal on the TachoStation is permanently green. Successfully
transferred files will be deleted from the SmartStick; faulty files (see feedback
on the TachoStation) will remain on the SmartStick.
Data Transmission / Upload to TachoWeb
via TachoStation
LED-Signal
Permanent blue light
Permanent green light
Permanent red light
Blue pulsing light Data transmission from the SmartStick started
Data transmission failed, error information
will be shown on the TachoStation‘s
display
Successful completion of data transfer,
SmartStick can be removed from the device
SmartStick inserted, waiting mode
Meaning
