Daktronics FB-2025 User manual

201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128
Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: [phone]
www.daktronics.com
Multi-Section Outdoor
LED Scoreboards
Display Manual
ED-17610 Rev 10 –23 September 2011
Models
BA-1518
FB-2025
*
BA-1524
FB-2026
*
BA-2013
FB-2027
*
BA-3718
FB-3010
*
BA-3724
MS-2009
FB-2018
MS-2918
FB-2019
SO-2011
FB-2020
SO-2018
FB-2021
SO-2019
FB-2022
SO-2021
FB-2023
*
SO-2022
FB-2024
SO-2023
*Discontinued

ED-17610
Product 1407
Rev 10 –23 September 2011
DAKTRONICS, INC.
Copyright 2009-2011
All rights reserved. While every precaution has been taken in the preparation of this manual, the publisher
assumes no responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be
reproduced or copied in any form or by any means –graphic, electronic, or mechanical, including photocopying,
taping, or information storage and retrieval systems –without written permission of the publisher.
All Sport®and PanaView®are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their
respective owners.
Please fill in the information below to use for reference when calling Daktronics for assistance.
Display Serial No. _______________________________________________________
Display Model No._______________________________________________________
Date Installed___________________________________________________________

Table of Contents i
Table of Contents
Section 1: Introduction ............................................................................................................................1
1.1 Resources..................................................................................................................................1
1.2 Daktronics Nomenclature ......................................................................................................2
1.3 Model Number ........................................................................................................................3
1.4 Scoreboard Controllers...........................................................................................................3
1.5 Product Safety Approval........................................................................................................3
Section 2: Specifications..........................................................................................................................5
Section 3: Mechanical Installation ......................................................................................................11
3.1 Footings & Beams..................................................................................................................11
3.2 Lifting the Scoreboard ..........................................................................................................11
3.3 Scoreboard Mounting...........................................................................................................13
Scoreboard Mounting Using Vertical Spacers ...........................................................14
3.4 Scoreboard Protective Devices ............................................................................................14
3.5 Ad Panel Mounting...............................................................................................................15
Section 4: Electrical Installation ..........................................................................................................17
4.1 Installation Overview ...........................................................................................................17
4.2 Power......................................................................................................................................18
Grounding.......................................................................................................................18
Connection ......................................................................................................................19
4.3 Power-On Self-Test (POST) .................................................................................................20
Radio Settings.................................................................................................................20
4.4 Signal Connection .................................................................................................................21
Fiber Optic ......................................................................................................................21
Multiple Driver Connections........................................................................................21
4.5 Power/Signal Connections Between Sections...................................................................21
4.6 Lightning Protection .............................................................................................................22
Section 5: Scoreboard Troubleshooting .............................................................................................23
5.1 Troubleshooting Table..........................................................................................................23
5.2 Component Locations...........................................................................................................26
5.3 Component Access................................................................................................................26
5.4 Replacing Digits ....................................................................................................................27
5.5 Replacing Digit Segments ....................................................................................................28
5.6 Replacing Colons, Decimals & Indicators..........................................................................28
5.7 LED Drivers ...........................................................................................................................29
Replacing a Driver .........................................................................................................30
Setting the Driver Address ...........................................................................................31
Multiple Drivers.............................................................................................................31
5.8 Power Supplies......................................................................................................................31
Replacing a Power Supply............................................................................................32
5.9 Radio Connections ................................................................................................................32
Radio Interference..........................................................................................................33
5.10 Trumpet Horns......................................................................................................................34
5.11 Segmentation and Digit Designation..................................................................................34
5.12 Schematics..............................................................................................................................34
5.13 Replacement Parts.................................................................................................................35

ii Table of Contents
Section 6: TNMC & Electronic Caption Troubleshooting & Maintenance .................................37
6.1 Display Overview .................................................................................................................37
6.2 Initialization Information at Startup...................................................................................38
6.3 Display Troubleshooting Table ...........................................................................................38
6.4 Power & Signal Summary ....................................................................................................39
6.5 Component Locations & Access..........................................................................................40
For Displays Built Before September 2009..................................................................41
Front Access....................................................................................................................41
Rear Access .....................................................................................................................42
6.6 Display Drivers......................................................................................................................42
For Displays Built Before September 2009..................................................................43
Diagnostic LEDs.............................................................................................................44
Replacing a Driver .........................................................................................................44
6.7 Modules..................................................................................................................................44
Replacing Modules ........................................................................................................44
Weather-stripping..........................................................................................................45
6.8 Power Supplies ......................................................................................................................46
Replacing a Power Supply............................................................................................46
6.9 Display Maintenance ............................................................................................................46
6.10 Replacement Parts List .........................................................................................................47
For Displays Built Before September 2009..................................................................48
Section 7: Daktronics Exchange and Repair & Return Programs ..................................................49
7.1 Exchange Program ................................................................................................................49
Before Contacting Daktronics.......................................................................................49
7.2 Repair & Return Program ....................................................................................................50
Shipping Address...........................................................................................................50
7.3 Daktronics Warranty and Limitation of Liability .............................................................50
Section 8: Scoreboard Options .............................................................................................................51
8.1 Trumpet Horns ......................................................................................................................51
8.2 Radio Control.........................................................................................................................51
8.3 Time Outs Left (T.O.L) Digits..............................................................................................52
8.4 Changeable Caption Kits......................................................................................................52
Appendix A: Reference Drawings ............................................................................................................53
Appendix B: Daktronics Warranty and Limitation of Liability..........................................................55

Introduction 1
Section 1: Introduction
This manual explains the installation of Daktronics multi-section outdoor LED scoreboards and
provides details for maintenance and troubleshooting. For additional information regarding the
safety, installation, operation, or service of this system, refer to the telephone numbers listed in
Section 7. This manual is not specific to a particular installation.
Important Safeguards:
Please read and understand all instructions before beginning the installation process.
Do not drop control equipment or allow it to get wet.
Do not disassemble control equipment or electronic controls of the display; failure to
follow this safeguard will make the warranty null and void.
Disconnect display power when not in use or when servicing.
Disconnect display power before servicing power supplies to avoid electrical shock.
Power supplies run on high voltage and may cause physical injury if touched while
powered.
Do not modify the scoreboard structure or attach any panels or coverings to the
scoreboard without the express written consent of Daktronics, Inc.
Project-specific information takes precedence over any other general information found in
this manual.
1.1 Resources
Figure 1 illustrates a Daktronics drawing
label. The drawing number is located in the
lower-right corner of a drawing. This
manual refers to drawings by listing the last
set of digits and the letter preceding them.
In the example, the drawing would be
referred to as Drawing C-325405.
Reference Drawing:
System Riser Diagram ...........................................................................Drawing C-325405
Daktronics identifies manuals by the DD or ED number located on the cover page of each
manual. For example, this manual would be referred to as ED-17610.
Figure 1: Daktronics Drawing Label

2 Introduction
1.2 Daktronics Nomenclature
Serial and model numbers can be found on the ID label on the display as shown in Figure 2.
Please list the model number, display serial number, and the date this display became
operational in the blanks provided on the second page of this manual. When calling
Daktronics customer service, please have this information available to ensure the request is
serviced as quickly as possible.
Most components within this display carry a white label that lists the part number of the unit.
If a component is not found in the Replacement Parts List in Section 5.13, use the label to
order a replacement. Figure 3 illustrates a typical label. The part number is in bold.
Main Component Labels
Part Type
Part Number
Individual circuit board
0P-XXXX-XXXX
Assembly; a collection of circuit boards
0A-XXXX-XXXX
Wire or cable
W-XXXX
Fuse
F-XXXX
Transformer
T-XXXX
Metal part
M-XXX
Fabricated metal assembly
0S-XXXXXX
Specially ordered part
PR-XXXXX-X
Accessory Labels
Component
Label
Termination block for power
or signal cable
TBXX
Grounding point
EXX
Power or signal jack
JXX
Power or signal plug for the
opposite jack
PXX
Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair &
Return Program. Refer to these instructions if replacing or repairing any display component.
Figure 2: Scoreboard ID Label
Figure 3: Typical Label

Introduction 3
1.3 Model Number
Daktronics scoreboards are differentiated by their model numbers and two-letter prefixes for
each sport. Most Daktronics scoreboards also carry a two-number suffix that refers to the type
of power supply and digit color. Refer to the following tables:
BA
Baseball
-11
120 V, with red digits
FB
Football
-21
120 V, with amber digits
MS
Multisport
-12
240 V, with red digits
SO
Soccer
-22
240 V, with amber digits
-41
120 V, with white digits
1.4 Scoreboard Controllers
Daktronics outdoor scoreboards are designed for use with the All Sport®5000 series control
consoles. Scoreboards with 5 or 6-digit clocks may also be controlled via the OmniSport®2000
console for track timing. Both consoles use keyboard overlays (sport inserts) to control
numerous sports and scoreboard models. Refer to the following manuals for operating
instructions:
All Sport 5000 Series Control Console Operation Manual (ED-11976)
OmniSport 2000 Timing Console Operations Manual (ED-13312)
These control console manuals are available online at www.daktronics.com/manuals.
1.5 Product Safety Approval
Daktronics outdoor scoreboards are ETL listed and tested to CSA standard for outdoor use.
Contact Daktronics with any questions regarding testing procedures.

Specifications 5
Section 2: Specifications
The chart on the following pages details all of the mechanical specifications, circuit specifications and
power requirements for each display in this manual. Models are listed in alphanumeric order.
Notes:
1) All displays require a 120 V AC, 15 A circuit; 240 V AC power also available
2) TNMC and electronic caption LEDs are typically the same color as the LED digits on the
scoreboard. Backlit captions use 120 V AC circular florescent bulbs.
3) Watts and Amps in [brackets] indicate separate power specs for white LED digits.
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
BA-1518
2 Total
Top &
Bottom
H 8'-0", W 16'-0", D 6"
(2438 mm, 4877 mm, 152 mm)
H 4'-0", W 16'-0", D 6"
(1219 mm, 4877 mm, 152 mm)
400 lb
(182 kg)
300 W
[450 W]
2.5 A / 1.25 A
[3.8 A / 1.9 A]
A1 63
w/TNMC
(same)
(same)
480 lb
(218 kg)
600 W
[750 W]
5 A / 2.5 A
[6.3 A / 3.1 A]
TNMC 221
BA-1524
2 Total
Top
Bottom
H 9'-0", W 16'-0", D 6"
(2743 mm, 4877 mm, 152 mm)
H 4'-0", W 16'-0", D 6"
(1219 mm, 4877 mm, 152 mm)
H 5'-0", W 16'-0", D 6"
(1524 mm, 4877 mm, 152 mm)
450 lb
(204 kg)
300 W
[600 W]
2.5 A / 1.25 A
[5 A / 2.5 A]
A1 63
w/TNMC
(same)
(same)
530 lb
(240 kg)
600 W
[900 W]
5 A / 2.5 A
[7.5 A / 3.75 A]
TNMC 221
BA-2013
4 Total
Top 2
Bottom 2
H 9'-4", W 36'-0", D 6"
(2845 mm, 10973 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
H 5' -4", W 18'-0", D 6"
(1626 mm, 5486 mm, 152 mm)
840 lb
(382 kg)
1500 W
12.5 A / 6.25 A
A1 64
A2 65
A3 66
A4 01
A5 01
w/TNMC
(same)
(same)
960 lb
(436 kg)
1800 W
15 A / 7.5 A
TNMC 221
BA-3718
4 Total
Top 2
Bottom 2
H 7'-0", W 28'-0", D 6"
(2134 mm, 8534 mm, 152 mm)
H 3'-0", W 14'-0", D 6"
(914 mm, 4267 mm, 152 mm)
H 4' -0", W 14'-0", D 6"
(1219 mm, 4267 mm, 152 mm)
640 lb
(291 kg)
900 W
7.5 A / 3.75 A
A1 64
A2 65
A3 66
w/TNMC
(same)
(same)
720 lb
(327 kg)
1200 W
10 A / 5 A
TNMC 221

6 Mechanical Installation
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
BA-3724
4 Total
Top 2
Bottom 2
H 9'-4", W 36'-0", D 6"
(2845 mm, 10973 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
H 5'-4", W 18'-0", D 6"
(1626 mm, 5486 mm, 152 mm)
840 lb
(382 kg)
900 W
7.5 A / 3.75 A
A1 64
A2 65
A3 66
w/TNMC
(same)
(same)
960 lb
(436 kg)
1200 W
10 A / 5 A
TNMC 221
FB-2018
FB-2019
FB-2020
2 Total
Top &
Bottom
H 8'-0", W 18'-0", D 6"
(2438 mm, 5486 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
565 lb
(256 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
645 lb
(293 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
805 lb
(365 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
625 lb
(283 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2021
FB-2022
FB-2023
2 Total
Top &
Bottom
H 8'-0", W 25'-0", D 6"
(2438 mm, 7620 mm, 152 mm)
H 4'-0", W 25-0", D 6"
(1219 mm, 7620 mm, 152 mm)
815 lb
(370 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
935 lb
(424 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1095 lb
(496 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
875 lb
(396 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2024
2 Total
Top &
Bottom
H 8'-0", W 32'-0", D 6"
(2438 mm, 9754 mm, 152 mm)
H 4'-0", W 32'-0", D 6"
(1219 mm, 9754 mm, 152 mm)
720 lb
(327 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
840 lb
(381 kg)
900 W
7.5 A / 3.75 A
TNMC 221

Specifications 7
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
w/TNMC +
Electronic
Captions
(same)
(same)
1080 lb
(489 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
T.O.L. 225
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
800 lb
(362 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2025
2 Total
Top &
Bottom
H 8'-0", W 32'-0", D 6"
(2438 mm, 9754 mm, 152 mm)
H 4'-0", W 32'-0", D 6"
(1219 mm, 9754 mm, 152 mm)
780 lb
(353 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
900 lb
(408 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1140 lb
(517 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
T.O.L. 225
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
860 lb
(390 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2026
2 Total
Top
Bottom
H 10'-0", W 32'-0", D 6"
(3048 mm, 9754 mm, 152 mm)
H 6'-0", W 32'-0", D 6"
(1829 mm, 9754 mm, 152 mm)
H 4'-0", W 32'-0", D 6"
(1219 mm, 9754 mm, 152 mm)
880 lb
(400 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
1000 lb
(454 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1240 lb
(562 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
T.O.L. 225
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
940 lb
(426 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2027
2 Total
Top
Bottom
H 10'-0", W 32'-0", D 6"
(3048 mm, 9754 mm, 152 mm)
H 6'-0", W 32'-0", D 6"
(1829 mm, 9754 mm, 152 mm)
H 4'-0", W 32'-0", D 6"
(1219 mm, 9754 mm, 152 mm)
940 lb
(426 kg)
600 W
5 A / 2.5 A
A1 15
A2 19

8 Mechanical Installation
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
w/TNMC
(same)
(same)
1060 lb
(481 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1300 lb
(590 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
T.O.L. 225
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
1020 lb
(462 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-3010
w/TNMC
2 Total
Top &
Bottom
H 8'-0", W 18'-0", D 6"
(2438 mm, 5486 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
600 lb
(272 kg)
1200 W
5 A
(240 V AC only)
A1 1
A2 11
TNMC 221
MS-2009
2 Total
Top
Bottom
H 10’-0”, W 25’-0”, D 6”
(3048 mm, 7620 mm, 152 mm)
H 4’-6”, W 25’-0”, D 6”
(1371 mm, 7620 mm, 152 mm)
H 5’-6”, W 25’-0”, D 6”
(1676 mm, 7620 mm, 152 mm)
770 lb
(349 kg)
600 W
5 A / 2.5 A
A1 71
A2 72
w/TNMC
(same)
(same)
890 lb
(404 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1130 lb
(513 kg)
1200 W
10 A / 5 A
Electronic
Captions 223
MS-2918
2 Total
Top &
Bottom
H 8’-0”, W 16’-0”, D 6”
(2438 mm, 4877 mm, 152 mm)
H 4’-0”, W 16’-0”, D 6”
(1219 mm, 4877 mm, 152 mm)
480 lb
(218 kg)
600 W
5 A / 2.5 A
A1 71
A2 72
w/TNMC
(same)
(same)
560 lb
(254 kg)
900 W
7.5 A / 3.75 A
TNMC 221
SO-2011
2 Total
Top
Bottom
H 7'-0", W 20'-0", D 6"
(2286 mm, 6096 mm, 152 mm)
H 4'-6", W 20'-0", D 6"
(1372 mm, 6096 mm, 152 mm)
H 3'-0", W 20'-0", D 6"
(914 mm, 6096 mm, 152 mm)
450 lb
(204 kg)
600 W
5 A / 2.5 A
A1 17
A2 11
w/TNMC
(same)
(same)
570 lb
(259 kg)
900 W
7.5 A / 3.75 A
TNMC 221

Specifications 9
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
SO-2018
SO-2019
2 Total
Top &
Bottom
H 8'-0", W 18'-0", D 6"
(2438 mm, 5486 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
565 lb
(256 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
645 lb
(293 kg)
900 W
7.5 A / 3.75 A
TNMC 221
SO-2021
SO-2022
SO-2023
2 Total
Top &
Bottom
H 8'-0", W 25'-0", D 6"
(2438 mm, 7620 mm, 152 mm)
H 4'-0", W 25'-0", D 6"
(1219 mm, 7620 mm, 152 mm)
815 lb
(370 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
935 lb
(424 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1095 lb
(496 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
T.O.L. 225
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
875 lb
(396 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19

Mechanical Installation 11
Section 3: Mechanical Installation
Mechanical installation consists of installing concrete footing and steel beams and mounting the
scoreboard and accompanying ad panels to the beams.
3.1 Footings & Beams
The installation specification drawings listed in Appendix A show the recommended number
of beams and spacing between them. The drawings also indicate the size of beams required to
support the scoreboard at different heights and at various wind speeds. Use the following
table to determine which drawings provide the installation specifications for each model:
Models
Drawing Title
Number
BA-1518, BA-1524, MS-2918
16' Width Scoreboard Installation Specs
A-298975
FB-2018, FB-2019, FB-2020,
FB 3010, SO-2018, SO-2019
18' Width Scoreboard Installation Specs
A-302416
SO-2011
20' Width Scoreboard Installation Specs.
A-303616
FB-2021, FB-2022, FB-2023,
MS-2009, SO-2021, SO-2022,
SO-2023
25' Width Scoreboard Installation Specs
A-316750
BA-3718
28' Width Scoreboard Installation Specs
A-316971
FB-2024; FB-2025, FB-2026,
FB-2027
32' Width Scoreboard Installation Specs
A-317264
BA-3724, BA-2013
Installation Specifications, BA-3724
A-126445
The column and footing size dimensions are to assist with estimating installation costs. They
are estimates only and are not intended for actual construction purposes. Be sure that the
installation complies with local building codes and is suitable for the particular soil and wind
conditions. The columns, footings, and all connection details must be designed and certified
by a professional engineer licensed to practice in the state of the scoreboard installation.
Note: Daktronics does not assume any liability for any installation derived from the
information provided in this manual or installations designed and installed by others.
3.2 Lifting the Scoreboard
Larger scoreboard sections and message centers are shipped equipped with eyebolts used to
lift them. The eyebolts are located along the top of the cabinet for each scoreboard or
scoreboard section. Daktronics scoreboards use 1/2" and 5/8" shoulder-type eyebolts mounted
to a 1/8" aluminum plate or steel nut plate.
Daktronics strongly recommends using a spreader bar, or lifting bar, to lift the display.
Spreader bars ensure the force on the eyebolts remains straight up, minimizing lifting stress.

12 Mechanical Installation
Figure 4 illustrates the preferred scoreboard lifting method on the left and an acceptable
alternative lifting method on the right. When lifting the display:
Use a spreader bar if possible.
Use every lifting point provided.
Cables and chains attached to the eyebolts and directly to
a center lifting point, as shown in the right-hand example
in Figure 4, can create a dangerous lateral force on the
eyebolts and may cause the eyebolts to fail. The smaller
the angle between the cable and the top of the display, the
lighter the sign must be to safely lift it. If this method
must be used, ensure a minimum angle between the chain
and scoreboard of at least 45 degrees.
Do NOT attempt to lift the display if the angle is less than
45 degrees. Exceeding load angles or weight limits could
cause the bolts in the scoreboard cabinet to buckle,
resulting in serious damage to the scoreboard or injury to
personnel. Also, loads should be applied directly in the
plane of the eyebolt as shown in Figure 5.
Note: Daktronics assumes no liability for damages resulting from incorrect setup or
lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently
support the display by the eyebolts.
In typical multi-section installations, the lower scoreboard is installed first and secured to the
support beams. The upper section is then placed atop or above the lower section and attached
to the beams. There may be cables extending from the top of the lower section. Guide these
cables into the hole in the bottom of the upper section for later connection. Refer to Section
4.5 for more information on the power/signal connections between sections.
If installers remove the eyebolts, plug the holes with bolts and the rubber washers that are
used with the eyebolts. Apply silicone or another waterproof sealant to the eyebolt openings.
Also inspect the top and sides of the display for any other holes or openings that may allow
moisture to enter the display and plug and seal those openings.
Figure 4: Lifting Methods
Figure 5: Eyebolt Plane Load

Mechanical Installation 13
3.3 Scoreboard Mounting
Mounting hardware includes inner and
outer mounting clamps; clip angles; 1/2-13 x
15" threaded rods; 3/8-16 x 2" bolts, hex nuts
and lock washers; and 1/2" square nuts, hex
nuts, and lock washers. Refer to Figure 6 or
Drawing A-308051 in Appendix A. Each
section of the scoreboard attaches at the top
and the bottom to every beam.
Note: The threaded rods do not pass
through the flanges of the beams, but
instead run along both sides.
1. Using 3/8" bolts, loosely attach the
inner and outer mounting clamps to
the rear flanges of the scoreboard.
Measure the beam spacing and position the clamps to fit on either side of the beams.
2. Insert a 1/2" square nut into each mounting clamp. Screw a threaded rod into each of
the nuts from the rear.
3. Position the scoreboard at the front of the beams with the threaded rods extending
from the rear of the clamps, straddling the beams. Raise the scoreboard section to the
desired height.
4. Slide clip angles over the ends of the rods and loosely install the washers and nuts.
5. Make final adjustments in the positioning of the scoreboard. Tighten the 3/8" bolts in
the mounting clamps.
6. Make sure that the threaded rods are perpendicular to the scoreboard, and tighten all
of the 1/2" hex nuts (Figure 7).
Figure 6: Mounting Hardware
Figure 7: Clamp Mounting Method, Side View

14 Mechanical Installation
Scoreboard Mounting Using Vertical Spacers
Many customers add message centers or advertising panels to the top or bottom of their
scoreboards, and in some cases the depth of the add-on component may not match the depth
of the scoreboard. This will typically be scoreboards that are 8" deep.
To create a uniform appearance for the overall display, Daktronics recommends using
vertical spacers behind the scoreboard so that the front face of the display lines up evenly
with the front face of the added component. The concept is illustrated in Figure 8 and
Drawing A-182909 in Appendix A.
During the installation, spacers are placed between the mounting beams and the back of the
scoreboard cabinet. Spacer size is determined by the height and the extra depth required for
the front surface of the scoreboard to match that of the optional message center or ad panel.
Note: Daktronics does not provide these spacers.
3.4 Scoreboard Protective Devices
Daktronics makes optional protective devices, including screens and netting, to help prevent
damage to the scoreboard due to normal ball impacts.
Note: Some users install devices to protect the scoreboard from projectiles. Scoreboard
protection devices not provided by Daktronics must be approved by Daktronics prior to
installation. Failure to follow this approval procedure will void the scoreboard warranty.
Figure 8: Mounting with Vertical Spacers
