Danby DAC5111M Assembly instructions

Danby Products Limited, Ontario, Canada N1H 6Z9
Danby Products Inc., Findlay, Ohio, USA 45840
Model • Modèle • Modelo
• Owner’s Use and Care Guide
• Guide d’utilisation et soins de Propriètaire
AIR CONDITIONER
CLIMATISEUR
V1 11.10 DM
DAC5111M / DAC5211M

Contents
CAUTION:
PRECAUTION:
Read and follow all safety rules and operat-
ing instructions before first use of this prod-
uct.
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.
CLIMATISEUR
Guide d'utilisation et d'entretien ........................
• Bienvenue
• Consignes de Sécurité Importantes
• Caractéristiques
• Installation
• Consignes d’utilisation
• Soins et Entretien
• Dépannage
• Garantie
2-11
AIR CONDITIONER
Owner’s Use and Care Guide .............................
• Welcome
• Important Safety Information
• Features
• Installation
• Operation Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
Model • Modèle DAC5111M / DAC5211M
12-21

Welcome
Thank you for choosing a Danby appliance to provide you and your family with all of the “Home Comfort” requirements
of your home, cottage, or office. This Owner’s Use and Care Guide will provide you with valuable information necessary
for the proper care and maintenance of your new appliance. If properly maintained, your Danby appliance will give you
many years of trouble free operation. Please take a few moments to read the instructions thoroughly and familiarize
yourself with all of the operational aspects of this appliance.
For easy reference, may we suggest you attach a copy of your sales slip/receipt to this page, along with the following
information, located on the manufacturers nameplate on side of the unit.
NOTE: THIS UNIT IS NOT DESIGNED FOR “THROUGH-THE-WALL” INSTALLATION.
Model Number:
Serial Number:
Date of Purchase:
This information will be necessary if your unit requires servicing and/or for general inquiries. To contact a Customer
Service Representative, call Danby TOLL FREE: 1-800-263-2629
2
WARNING
Improper connection of the grounding plug can result in risk of
Fire, Electric Shock and/or injury to Persons associated with the
appliance. Check with a qualified service representative if in doubt
that the appliance is proplery grounded.

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ELECTRICAL
SPECIFICATIONS
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.
1) All wiring must comply with local and national electrical codes and must
be installed by a qualified electrician. If you have any questions
regarding the following instructions, contact a qualified electrician.
2) Check available power supply and resolve any wiring problems
BEFORE installing and operating this unit.
3) This 115V air conditioner uses 4.8 or less nameplate amps and may
be used in any properly wired, general purpose household receptacle.
See Table 1 for specifications for individual branch circuit.
4) For your safety and protection, this unit is grounded through the power
cord plug when plugged into a matching wall outlet. If you are not sure
whether your wall outlet is properly grounded, please consult a qualified
electrician.
5) The wall outlet must match the 3-prong plug on the service cord
supplied with the unit. DO NOT use plug adapters. See Table 2 for
receptacle and fuse information. If it is necessary to use an extension
cord to connect your air conditioner, use an approved “air
conditioner” extension cord only (available at most local hardware
stores).
6) The rating plate on the unit contains electrical and other technical data.
The rating plate is located on the right side of the unit, above the power
cord.
3
TABLE 1
Suggested Individual Branch Circuit
Nameplate Amps *AWG Wire Size
4.5 to 4.8 18
AWG- American Wire Gauge
*Based on copper wire at 60°C temperature rating.
TABLE 2
Receptacle and Fuse Types
Rated Volts 125
Amps 15
Wall Outlet
Fuse Size 15
Time Delay Fuse Plug Type
(or Circuit Breaker)

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ENERGY SAVING TIPS
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.
Your Danby appliance is designed to be highly efficient in energy
savings. Follow these recommendations for greater efficiency.
1) Select a thermostat setting that suits your comfort needs and leave at
that chosen setting.
2) The air filter is very efficient in removing airborne particles. Keep the air
filter clean at all times. (usually cleaned every 2 weeks depending on
indoor air quality).
3) Use drapes, curtains or shades to keep direct sunlight from penetrating
and heating the room, but do not allow drapes or curtains to obstruct
the air flow around the unit.
4) Start your air conditioner before the outdoor air becomes hot and
uncomfortable, to avoid an initial period of discomfort while the unit is
cooling off the room.
5) When outdoor temperatures are cool enough, use HIGH or LOW FAN
only. This circulates indoor air, providing some cooling comfort, and
utilizes less electricity than when operating on a cooling setting.
4
Features
Air FIlter
Exterior
Air Inlet
Cabinet
Interior Air Inlet
Control Panel
Interior Air Outlet
Installation Instructions
CAUTION
Because the compressor is located on the controls side of the unit
(left side), this side will be heavier and more awkward to manipu-
late. Inadequate support on control side of the unit can result in
personal injury and damage to your unit and property. Therefore, it
is recommended that you have someone assist you during the
installation of this unit.
TOOLS NEEDED FOR INSTALLATION:
• Screw Drivers: Phillips and flat head.
• Power Drill: 1/8” (3.2mm) diameter drill bit.
• Pencil
•Measuring Tape
• Scissors
• Carpenters Level
NOTE: Save the shipping carton and packing materials for future storage
or transportation. From carton, remove the plastic bag containing the
installation hardware kit necessary for the installation of your air
conditioner. Please check the contents of hardware kit against the corre-
sponding model check list, prior to installation of the unit. See Fig. 1.
ELECTRIC SHOCK HAZARD
To avoid the possibility of personal
injury, disconnect power to the unit
before installing or servicing.
NOTE: Your Room Air Conditioner is
designed for easy installtion in a single or
double-hung window. This unit is NOT
designed for vertical (slider type) windows
and/or through-the-wall applications.

Installation Instructions
Fig. 1
INSTALLATION
HARDWARE
LOCATION A) This room air conditioner is designed to fit easily into a single or double
hung window. However, since window designs vary, it may be
necessary to make some modifications for safe, proper installation.
B) Make sure window and frame are structurally sound and free from dry
and rotted wood.
C) For maximum efficiency, install the air conditioner on a side of the
house or building which favours more shade than sunlight. If the unit is
in direct sunlight, it is advisable to provide an awning over the unit.
D) Provide sufficient clearance around the cabinet to allow for ample air
circulation through the unit (See Fig. 2). The rear of the unit should be
outdoors and not in a garage nor inside a building. Keep unit as far
away as possible from obstacles/obstructions and at least 30” above
the floor or ground. Curtains and other objects within a room should be
prevented from blocking the air flow.
E) Be certain the proper electrical outlet is within reach of the installation.
Use only a single outlet circuit rated at 15 amps. All wiring should be in
accordance with local and national electrical codes.
F) DO NOT install unit where leakage of combustible gas is suspected.
Your air conditioner may fail to operate in air containing oils (including
machine oils), sulfide gas, near hot springs, etc.
NOTE: Your unit is designed to evaporate condensation under normal
conditions. However, under extreme humidity conditions, excess conden-
sation may cause basepan to overflow to the outside. The unit should be
installed where condensation run-off cannot drip on pedestrains or neigh-
boring properties.
5
3/4in. (19.1mm)
screws (7) Safety Lock (1)
3/8in. (9.5mm) screws
(4) *Factory installed
on some models
“L” Shaped
mounting
bracket (1)
* Factory installed
on some models
Sash bracket (2)
Adhesive
Foam Seal(1)
Side Curtain LH (1)
Side Curtain RH (1)

LOCATION
Installation Instructions
Awning
Fence,
wall, or
other
obstacle
Ground
Side
Obstruction
20”
Min
30”
Min
20”
Min
12” Min
Fig. 2
1) Assembly of the Upper Channel to Cabinet. (Factory installed on some units)
• “L” Shaped Top Channel: Install the “L” shaped channel to the top of the
cabinet as shown in Fig. 3, using four (4) 3/8” screws.
2) Assembly of the Side Curtains to Cabinet.
• Extend the shutter from the shutter frame and slide it into the shutter tabs
on the side channel of the air conditioner, as shown in Fig. 4.
• Slide the shutters into the top (“L” Shaped) and bottom (“U” Shaped)
channels. The shutters are identified (on frame) as left and right.
3) Completing the Installation
• Cut the foam (non adhesive) sealing strip to fit the area of the window sill
that the air conditioner will rest on.
3/8” screws
“L” shaped mounting
bracket
“U” shaped Channel
(Factory Installed)
Slide down into tabs
Shutter tabs
Shutter
Shutter frame
Fig. 3
Fig. 4
6

7
Installation Instructions
3) Completing the Installation (cont’d)
• Carefully place the air conditioner into the window with the “L” shaped
mounting bracket (on top) positioned in front of the upper window sash.
The bottom of the cabinet should be positioned on the “recessed” portion
of the window frame. Pull the window down until it rests just behind the
front flange of the (top) “L” shaped mounting bracket (See Fig. 5).
• Expand the shutter frames (fully) on each side and secure the top of the
frames to the window sash using one 3/4” screw on each side and one in
the “L” shaped mounting bracket (Fig. 5).
• Secure the shutter clamp on each side of the (lower) shutter and secure
to window sill using one 3/4” screw on each side (Fig. 5).
• Place the second foam sealing strip to fit the opening between the inside
and outside windows, then attach the safety lock to the outside window
frame using one 3/4” screw (See Fig. 6).
PLEASE NOTE: Window applications come in a variety of different styles.
Therefore, it may be necessary to modify or improvise your particular
installation.
Window sash
“L” Shaped
Mounting
Bracket
Shutter clamps
3/4” screws
Fig. 5
Safety Lock
3/4” screw
Foam Seal
Fig. 6

Operating Instructions
CONTROLS SELECTOR SWITCH: The selector switch controls fan speed and/or cool-
ing speed. To set desired cooling temperature, simply rotate the
SELECTOR knob to the appropriate setting.
FAN SPEEDS:
• LOW FAN will circulate air at minimum speed without cooling.
• HIGH FAN will circulate air at maximum speed without cooling.
COOLING MODES:
• LOW COOL provides cooling with minimum air circulation.
Recommended for night-time use.
•HIGH COOL provides cooling with maximum air circulation.
Recommended for quick cooling or for extremely hot days. Once room is
cooled, reduce setting to LOW COOL.
• OFF shuts-down the unit completely
NOTE: Always allow 3 minutes before switching from one mode to
another.
THERMOSTAT: The thermostat automatically controls the (compressor)
cooling cycle and maintains the selected room temperature. To set the
thermostat, rotate the thermostat knob to the desired cooling setting (1
warmest - 7 coldest). The fan motor will continue to operate after the com-
pressor (cooling) has cycled off. This is normal.
8
IMPORTANT
When using FAN control, turn selector switch slowly, allowing unit
to adjust. When using THERMOSTAT, be sure to allow three min-
utes before changing temperature. Adjusting too quickly may cause
compressor to overload.
Thermostat
Selector
Switch OFF
arrêt

Care and Maintenance
CLEAING When cleaning the air conditioner, be sure to turn the SELECTOR knob to
the “OFF” position and disconnect the power cord from the electrical
outlet.
1) DO NOT use gasoline, benzene, thinner, or any other chemicals to
clean this unit, as these substances may cause damage to the finish
and deformation of plastic parts.
2) Never attempt to clean the unit by pouring water directly over any of the
surface areas, as this will cause deterioration of electrical components
and wiring insulation.
9
AIR FILTER If the air filter becomes clogged with dust, air flow is obstructed and
reduces efficiency. The air filter should be cleaned every 2 weeks.
AIR FILTER REMOVAL:
The air filter is located behind the air intake front grill. To remove the air
filter, grasp the filter handle on the front of the gril and slide it out to the
right.
To reinstall the air filter, reverse the above procedures. The air filter must
be vacuumed or washed by hand in warm water. Dry thoroughly before
re-installing.
CLEANING AIR FILTER:
1) Use a vacuum cleaner with soft brush attachment
2) Wash the filter in lukewarm water below 40°C (104°F): To get best
results, wash with soapy water or a neutral cleaning agent.
3) Rinse the filter with clean water and dry thoroughly before re-installing.
IMPORTANT
DO NOT forget to install the air filter. If the air conditioner is left to
operate without the air filter, dust is not removed from the room air
and may result in machine failure. When the air inlet grill and cabi-
net are dirty, wipe with lukewarm water (below 40°C). Use of a mild
detergent is recommended.
END OF SEASON
CARE
1) Operate the fan alone for half a day to dry out the inside of the unit.
2) Turn off power and remove plug from wall socket.
3) Clean filter.
4) Store (covered) air conditioner in a dry location.
CAUTION
When installing and/or removing the air conditioner from the win-
dow, ensure that caution is taken to prevent it from falling
backward. It is recommended that installation or removal of the air
conditioner is done with assistance to prevent injury to persons or
damage to the unit or property.
