OWNER’S USE AND CARE GUIDE
GUIDE D’UTILISATION ET D'ENTRETIEN
MODEL • MODÈLE
DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
DPA060C2WDB
PORTABLE AIR CONDITIONER
CLIMATISEUR PORTATIF
2015.01.12

DO NOT RETURN THIS UNIT TO THE RETAILER
WITHOUT FURTHER INSTRUCTIONS
Dear valued customer, we hope your Danby product purchase fulfills all
your requirements. Your satisfaction is our priority!
Please contact us at our toll free consumer service number for any inquiries
you may have about your new unit.
NE PAS RETOURNER CET APPAREIL CHEZ LE
DÉTAILLANT SANS CONSIGNES SUPPLÉMENTAIRES
Cher(ère) client(e) important(e), nous espérons que votre produit Danby
répond à tous vos besoins. Votre satisfaction est notre priorité!
Veuillez nous contacter au numéro gratuit de service après-vente, si
vous avez des questions quelconques à propos de votre nouvel appareil.
NO DEVUELVA ESTA UNIDAD A LA TIENDA SIN
INSTRUCCIONES ADICIONALES
Estimado cliente, esperamos que el producto Danby que ha comprado
satisfaga completamente sus necesidades. Su satisfacción
es nuestra prioridad!
Por favor, contáctenos gratuitamente a nuestro número de Servicio al
Cliente para cualquier pregunta que tenga sobre su nuevo electrodoméstico.
1-800-263-2629
(1-800-26-DANBY)
Danby 28.08.2014

TO OBTAIN WARRANTY SERVICE YOU MUST PROVIDE A VALID PROOF OF
PURCHASE. PLEASE STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE
REFERENCE.
POUR OBTENIR LE SERVICE SUR GARANTIE, VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. VEUILLEZ AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.
This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must
be plugged into a mating grounding type receptacle in accordance with the National Electrical Code and
applicable local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the
responsibility and obligation of the customer to exchange the existing receptacle in accordance with the
National Electrical Code and applicable local codes and ordinances. The third ground prong should not,
under any circumstances, be cut or removed. Never use the cord, the plug or the appliance when they show
any sign of damage. Do not use your appliance with an extension cord unless it has been checked and test-
ed by a qualified electrician or electrical supplier.
IMPORTANT - GROUNDING METHOD
Ce produit arrive d’origine avec un cordon d’alimentation équipé d’une prise à trois fiches. Il doit être
branché dans une prise avec une fiche de mise à la terre en conformité avec le Code national de l’électricité
et les codes et règles locaux applicables. Si la prise murale n’a pas de mise à la terre, il est de la
responsabilité et l’obligation du client de changer la prise existante pour la rendre conforme au Code
national de l’électricité et aux codes et règles locaux applicables. La fiche de mise à la terre ne doit pas, en
aucune circonstance, être coupée ou retirée. Si vous apercevez des signes de dommage, n’utilisez jamais le
cordon d’alimentation, la prise ou l’appareil. N’utilisez jamais l’appareil avec une rallonge sauf si elle a été
vérifiée et testée par un électricien qualifié ou un fournisseur de matériel électrique.
IMPORTANT - MÉTHODE POUR LA MISE À LA TERRE

PORTABLE AIR CONDITIONER
Owner’s Use and Care Guide .................................
• Welcome
• Important Safety Information
• Features
• Installation Instructions
• Operation Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
CLIMATISEUR PORTATIF
Guide d’utilisation et d’entretien................................
• Bienvenue
• Consignes de sécurité importantes
• Caractéristiques
• Consignes d’installation
• Consignes d’utilisation
• Soins et entretien
• Dépannage
• Garantie
CONTENTS
CAUTION:
Read and follow all safety rules and operating
instructions before first use of this product.
AVERTISSEMENT :
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.
TABLE DES MATIÈRES
Model • Modèle
WARNING
Improper connection of the grounding plug can
result in risk of fire, electric shock and/or injury to
persons associated with the appliance. Check with
a qualified service representative if in doubt that
the appliance is properly grounded.
AVERTISSEMENT
Une fiche de mise à la terre mal branchée peut
entraîner un risque d’incendie, de choc électrique
ou de blessures aux personnes qui utilisent
l’appareil. Si vous n’êtes pas certain que l’appareil
est correctement mis à la terre, consultez un
préposé du service qualifié.
1-17
18-34
DPA060C2WDB
2
3

Welcome
Welcome to the Danby family. We are proud of our quality products, and we believe in dependable service, like you will
find in this Owner’s Use and Care Guide, and like you will receive from our friendly customer service department. Best
of all, you will experience these values each and every time you use your Danby appliance. That is important, because
your new appliance will be a part of your family for a long time.
Note the information below; you will need this information to obtain service under warranty.
To receive service, you must provide the original receipt.
Serial Number:
Date of Purchase:
NEED HELP?
Before you call for service, here are a few things you can do to help
us serve you better:
Read this Owner’s Use and Care Guide:
It contains instructions to help you use and maintain your
appliance properly.
If you received a damaged appliance:
Immediately contact the retailer (or builder) that sold you the
appliance.
Save time and money:
Check the Troubleshooting section at the end of the guide before call-
ing. This section helps you solve common problems that may occur.
If you do need service, you can relax, knowing help is only a phone
call away.
1-800-26-
(1-800-263-2629)
1

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation resulting from ignoring these instructions may cause harm or damage.
SAFETY
PRECAUTIONS ALWAYS DO THIS
Your air conditioner should be used in such a way that it is protected from
moisture. e.g. condensation, splashed water, etc. Do not place or store
your air conditioner where it can fall or be pulled into water or any other
liquid. Unplug unit immediately if this occurs.
Always transport your air conditioner in a vertical position and place on a
stable, level surface during use. If the unit is transported laying on its side it
should be stood up and left unplugged for 4 hours.
Turn off the unit when not in use.
Always contact a qualified person to perform repairs. If the power cord is
damaged it must be repaired by a qualified technician.
Keep the unit away from walls, furniture and curtains with a clearance of at
least 30 cm all around.
If the air conditioner is knocked over during use, turn off the unit and
unplug it immediately.
Always use the switch on the control panel to turn the unit on or off.
Portable air conditioners exhaust large amounts of room air. Always ensure
an adequate supply of make-up air to operate efficiently.
NEVER DO THIS
Do not operate your air conditioner in a wet room such as a bathroom or
laundry room.
Do not touch the unit with wet or damp hands.
Do not press the buttons on the control panel with anything other than your
fingers.
Do not remove any fixed components. Never use this appliance if it is not
working properly, or if it has been dropped or damaged.
Never use the plug to start and stop the unit.
Do not cover or obstruct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or come into contact with the unit.
Do not use the unit in the presence of inflammable substances or vapour
such as alcohol, insecticides, gasoline, etc.
Do not allow children to operate the unit unsupervised.
Do not use this product for functions other than those described in this
instruction manual.
2

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation resulting from ignoring these instructions may cause harm or damage.
ENERGY SAVING
TIPS
OPERATING
CONDITIONS
TOOLS FOR
WINDOW KIT
INSTALLATION
• Use the unit in the recommended room size.
• Locate the unit where furniture cannot obstruct the air flow.
• Keep blinds/curtains closed during the sunniest part of the day.
• Keep the filters clean.
• Keep doors and windows closed to keep cool air in and warm air out
(cooling mode)
MODE ROOM TEMPERTURE
Air conditioning 16°C ~ 35°C (61°F ~ 95°F)
The air conditioner must be operated within the temperature range
indicated below:
Note: Performance may be reduced outside of these operating tempera-
tures.
1. Screwdriver (medium size, Phillips)
2. Tape measure or ruler
3. Knife or scissors
4. Saw (In the event that the window kit needs to be cut down in size
because the window is too narrow for direct installation).
See www.danby.com for general instruction guide
3
The power cord supplied with this air conditioner contains a device that senses damage to the power cord. To test if your
power cord is working properly, you must do the following:
1. Connect the power supply cord to an electrical outlet.
2. The power supply cord has two buttons located on the head of the plug. One button is marked “TEST”, and the other
is marked “RESET”. Press the “TEST” button; you will hear a click as the “RESET” button pops out.
3. Press the “RESET” button; you will hear a click as the button engages.
4. The power supply cord is now energized and supplying electricity to the air conditioner (on some products this is also
indicated by a light on the plug head).
NOTE: The power cord supplied with this air conditioner contains a current leakage detection device designed to reduce
the risk of fire. In the event the power supply cord is damaged, it cannot be repaired and must be replaced with a new
cord from the product manufacturer.
• Under no circumstances should this device be used to turn the unit on or off.
• The “RESET” button must always be pushed in (engaged) for correct operation.
• The power supply cord must be replaced if it fails to reset when the “TEST” button is pushed in.
NOTE: Some plugs have buttons on the top.
POWER SUPPLY CORD
Plug in and press
RESET
TEST
RESET

Identifying Parts
WARNING
• Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other
appliance.
• Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any
prong from the power cord.
ELECTRICAL INFORMATION
WARNING
• Be sure the electrical supply is adequate for the model you have chosen. This information can be found
on the serial plate, which is located on the side of the cabinet and behind the grille.
• Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding
is important. The power cord is equipped with a three-prong grounding plug for protection against
shock hazards.
• Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you
intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a
qualified electrician install the proper receptacle.
• Ensure the receptacle remains accessible after the unit is installed.
4
TABLE 2
Receptacle and Fuse Types
Rated Volts 125
Amps 15
Wall Outlet
Fuse Size 15
Time Delay Fuse Plug Type
(or Circuit Breaker)
TABLE 1
Suggested Individual Branch Circuit
Nameplate Amps
5.4
*AWG Wire Size
18
AWG- American Wire Gauge
*Based on copper wire at 105°C temperature rating
1. All wiring must comply with local and national electrical codes and must be installed by a qualified electrician. If you
have any questions regarding the following instructions, contact a qualified electrician.
2. Check available power supply and resolve any wiring problems BEFORE installing and operating this unit.
3. This 115V air conditioner uses 5.4 or less nameplate amps and may be used in any properly wired, general-purpose
household receptacle. See Table 1 for the specifications for the individual branch circuit.
4. For your safety and protection, this unit is grounded through the power cord plug when plugged into a matching wall
outlet. If you are not sure whether your wall outlet is properly grounded, please consult a qualified electrician.
5. The wall outlet must match the 3-prong plug on the service cord supplied with the unit. DO NOT use plug adapters.
See Table 2 for receptacle and fuse information.

• Ensure that all the accessories are included in the
package and refer to the installation instructions for
their usage.
Note: All the illustrations in this manual are for ex-
planatory purposes only. Your air conditioner may be
slightly different.
Identifying Parts
FEATURES
ACCESSORIES
ELECTRIC SHOCK HAZARD: To avoid the possibility of
personal injury, disconnect power to the unit before installing or
servicing.
Installation Accessories:
• Flexible exhaust hose
• Exhaust nozzle connector (3 pcs) (Connector A, B and C)
• Window door slider kit (3 pcs)
• Screws (5 pcs)
• Pipe Clip
• Pipe Hoop (2)
• Drainage Pipe
• Rubber Plug
• Adhesive foam (2)
• Non-adhesive foam (4)
NOTE: The exhaust / window kit must be installed at all times
when the unit is operating under AIR CONDITIONING mode.
There should be at least 11.8” (30cm) clearance between the
unit and any other objects or building structures, and the unit
should be installed on a level floor. The unit does not have
to be vented outside during dehumidifying or fan only mode
operation. When the unit is in dehumidifying mode, the warm
air exhaust must be vented inside the room.
5
4
8
5
6
7
1. Control Panel
2. Air outlet
3. Caster
4. Remote Control Holder
5. Power Cord
6. Air Filter
7. Upper Air Inlet Grill
8. Lower Air Inlet Grill
Exhaust
Connector A
Exhaust
Connector B
Exhaust
Connector C
Window Slider
Kit
Exhaust
Hose
Screw
(5)
Pipe Clip Pipe Hoop
(2) Drainage Pipe
Rubber
Plug
1
2
3
Foam (adhesive and
non-adhesive) (6)

Installation Instructions
LOCATION • The air conditioner should be placed on a firm foundation to minimize noise
and vibration. For safe and secure positioning, place the unit on a smooth, level
floor strong enough to support the unit.
• The unit has casters to aid placement, but it should only be rolled on smooth,
flat surfaces. Use caution when rolling on carpeted surfaces. Use caution and
protect floors when rolling over wood floors. Do not attempt to roll the unit over
objects.
• The unit must be placed within reach of a properly rated grounded socket.
• Never place any obstacles around the air inlet or outlet of the unit.
• Allow at least 30 cm of space away from the wall for efficient air conditioning.
WINDOW SLIDER KIT
INSTALLATION NOTE: If the window opening is less than the mentioned minimum length of the
window slider kit, cut the end without the hole in it short enough to fit in the window
opening. Never cut out the hole in window slider kit (visit www.danby.com for
general instruction videos).
Your window kit has been designed to fit most “vertical” / “horizontal” windows up
to a maximum height of 80” (203 cm). For vertical window applications, multi lock
positions are provided on the edge of each slider section to secure each sliding
section together.
1. Select a suitable location, making sure you have access to an electrical outlet.
2. Install the flexible hose to the rear of the unit. Insert the hose collar on top of
the exhaust opening.
3. Install the adjustable Window Slider Kit as required.
4. Install the opposite end of the flexible exhaust hose into the window exhaust
adapter.
5. Install the window exhaust adapter into the opening in the slider section, mak-
ing sure the window slider sections are secure.
6. Plug the unit into a 115V/60Hz grounded electrical outlet.
6
Adjusting Plate
Cut if needed
Connector C
Width
Height
Screw
Screw
