Danby DTAC080BAUWDB User manual

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
AIR CONDITIONER
Owner’s Manual.............................1 - 10
CLIMATISEUR
Manual du propriétaire.................11 - 20
AIRE ACONDICIONADO
Manual del propietario..................21 - 30
2017.12.01
MODEL •MODÈLE •MODELO
DTAC080BAUWDB
DTAC120BAUWDB

Welcome
Welcome to the Danby family. We are proud of our quality products and we believe in
dependable service. We suggest that you read this owner’s manual before plugging in your new
appliance as it contains important operation information, safety information, troubleshooting and
maintenance tips to ensure the reliability and longevity of your appliance.
Visit www.Danby.com to access self service tools, FAQs and much more. For additional assistance
call 1-800-263-2629.
Note the information below; you will need this information to obtain service under warranty.
You must provide the original purchase receipt to validate your warranty and receive service.
Model Number: _________________________________________________
Serial Number: _________________________________________________
Date of Purchase: _______________________________________________
Need Help?
Before you call for service, here are a few things you can do to help us serve you better.
Read this owner’s manual:
It contains instructions to help you use and maintain your appliance properly.
If you receive a damaged appliance:
Immediately contact the retailer or builder that sold you the appliance.
Save time and money:
Check the troubleshooting section at the end of this manual before calling. This section
will help you solve common problems that may occur.
1-800-26- Danby
(1-800-263-2629)
1

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
ELECTRICAL REQUIREMENTS
All wiring must comply with local and national
codes and must be installed by a qualified
electrician. Check the available power supply and
resolve any wiring problems before installing and
operating this appliance.
This 115 V appliance may be used in any properly
wired, general purpose household receptacle.
The rating plate located on the right side of the
appliance just above the power cord contains
electrical and other technical data.
SAFETY INSTRUCTIONS
This appliance is not intended for use by persons,
including children, with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Do not install the appliance where leakage of
combustible gas is suspected.
POWER CORD INSTRUCTIONS
The power supply cord contains a current device
that senses damage to the power cord. To test the
power supply cord:
1. Plug in the appliance.
2. Press the TEST button on the power supply cord.
The RESET button will click and pop out.
3. Press the RESET button until it clicks into place.
4. The power supply cord is now supplying
electricity to the appliance.
Do not use this device to turn the appliance on or
off. Ensure that the RESET button is pushed in for
correct operation. The power supply cord must be
replaced if it fails to reset when the TEST button is
pushed.
2
GROUNDING INSTRUCTIONS
This appliance must be grounded. Grounding
reduces the risk of electrical shock by providing an
escape wire for the electrical current.
This appliance has a cord that has a grounding
wire with a 3-prong plug. The power cord must be
plugged into an outlet that is properly grounded.
If the outlet is a 2-prong wall outlet, it must be
replaced with a properly grounded 3-prong wall
outlet.
WARNING - Improper use of the grounding
plug can result in a risk of electric shock.
Consult a qualified electrician or service agent
if the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
Do not connect your appliance to extension
cords or together with another appliance in the
same wall outlet. Do not splice the power cord.
Do not under any circumstances cut or remove the
third ground prong from the power cord. Do not
use extension cords or ungrounded (two prongs)
adapters.
If the power supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similar qualified person in order to avoid hazard.

INSTALLATION INSTRUCTIONS - AIR CONDITIONER WALL SLEEVE
3
WALL SLEEVE ACCESSORIES
1. Top panel
2. Bottom panel
3. Left side panel
4. Right side panel
5. Front cover panel
6. Rear cover panel
7. Bracket (x4)
8. Clasp (x4)
9. Screw (x28)
10.Washer (x8)
1
2
3
4
5
6
7
8
9
10
4” min
1/2” min
Assembled dimensions:
• 25 1/2” (64.8 cm) wide
• 15 1/4” (38.8 cm) tall
• 17 1/2” (44.4 cm) deep
The sleeve must be installed a minimum of 4”
above any floor or heat source such as baseboard
heaters or radiators. The sleeve must be installed a
minimum of 1/2” outside the building.
1. Use four screws to
fasten the side panels
to the bottom panel.
The arrow marks
on the bottom panel
indicate the direction
of the indoor side.
2. Attach the top panel
using four screws.
3. Insert the four clasps
into the holes in the
side panels.
Expanded rear grille Louvered rear grille
4. Insert the louvered rear grille or the expanded
rear grille that was packed with the air
conditioner.
• The wall sleeve must be securely fastened to the
wall before installing the air conditioner.
• After the sleeve is installed, caulk where
necessary around the entire interior and exterior
wall opening.

INSTALLATION INSTRUCTIONS - DIRECT MOUNTING
4
DIRECT MOUNTING
It is preferable to mount the rear grille on the sleeve
as the appliance’s performance is increased and
the possibility of air drafts is reduced. If this is not
possible, the grille can be directly mounted on
the appliance. The grille must be installed prior to
installing the appliance in the wall sleeve.
1. Attach two seal pieces as shown below.
2. Position the grille over the rear of the appliance
ensuring that the double set of screw holes are
at the bottom and that the fins of the grille are
pointed away from the appliance.
3. Align the top of the grille with the top of the
appliance. The overhang on each side is equal.
4. If the appliance has not be pre-drilled, carefully
drill 4 1/8” holes through the grille and into the
side flange of the appliance approximately 1
1/2” - 2” from the top and bottom. Be careful
not to drill into the copper heat exchanger coils.
5. Install 4 #8 self tapping screws to attach the
grille to the appliance.
6. Insert the appliance into the sleeve.
7. Install the long seal between the wall sleeve and
the appliance. A flat bladed screwdriver or putty
knife is recommended.
8. Assemble the trim frame by inserting the top and
bottom pieces into the side pieces and snapping
into place.
9. Pull the power cord through the trim frame and
then slide the frame over the appliance until it is
flush with the wall.
AIR CONDITIONER ACCESSORIES
1. 17” long Tapered spacer blocks (x2)
2. 4 1/2” x 3 1/2” x 1 1/2” Centering support
blocks (x4)
3. 1/8” x 4 1/2” x 14 1/2” Plastic divider (x2)
4. 1” x 1 1/2” x 84” Stuffer seal
5. 1” x 1 1/2” x 25” Seal (x3)
6. 1” x 1 1/2” x 14” Seal (x2)
7. 1” x 3/8” x 25” Seal (x3)
8. 1” x 3/8” x 14” Seal (x2)
9. 1” x 3/4” x 14” Seal (x2)
10.Side trim frame (x2)
11.Top and bottom trim frame (x2)
12.Green ground wire
13.Toothed washer for grounding screw (x2)
14.Grounding screw
15.Plastic grille
16.Aluminum grille
17.Plastic nuts (x4)
18.Screw washer (x4)
19.Screw (x4)
