Danby DWC040A3BSSDD Assembly instructions

OWNER’S USE AND CARE GUIDE
GUIDE D’UTILISATION ET SOIN DE PROPRIÈTAIRE
GUÍA DE UTILIZACION Y CUIDADO PARA EL PROPIETARIO
MODEL • MODÈLE • MODELO
WINE COOLER
REFROIDISSEUR À VIN
ENFRIADOR DE VINO
DWC040A3BSSDD
2016.05.03

TO OBTAIN WARRANTY SERVICE YOU MUST PROVIDE A VALID PROOF OF
PURCHASE. PLEASE STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE
REFERENCE.
-------------------------------------------------------------------------------------------------------------------
POUR OBTENIR LE SERVICE SUR GARANTIE VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. VEUILLEZ AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.
-------------------------------------------------------------------------------------------------------------------
PARA OBTENER SERVICIO DE GARANTÍA, DEBE PROVEER UN RECIBO
ORIGINAL. POR FAVOR ENGRAPE SU RECIBO A ÉSTA PÁGINA EN CASO QUE
NECESITE HACER UN RECLAMO.
This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must
be plugged into a mating grounding type receptacle in accordance with the National Electrical Code and
applicable local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the
responsibility and obligation of the customer to exchange the existing receptacle in accordance with the
National Electrical Code and applicable local codes and ordinances. The third ground prong should not,
under any circumstances, be cut or removed. Never use the cord, the plug or the appliance when they show
any sign of damage. Do not use your appliance with an extension cord unless it has been checked and
tested by a qualified electrician or electrical supplier.
IMPORTANT - GROUNDING METHOD
Ce produit arrive d’origine avec un cordon d’alimentation équipé d’une prise à trois fiches. Il doit être
branché dans une prise avec une fiche de mise à la terre en conformité avec le Code National de l’Électricité
et les codes et règles locales applicables. Si le prise murale n’a pas de mise à la de terre, il est de la
responsabilité et l’obligation du client de changer la prise existante pour la rendre conforme aux Codes
Nationaux de l’Électricité, aux codes et règles locaux applicables. La fiche de la mise à la terre ne doit pas,
en aucune circonstance, être coupée ou retirée. Si vous apercevez des signes de dommage, n’utilisez jamais
le cordon d’alimentation, la prise ou l’appareil. N’utilisez jamais l’appareil avec une rallonge sauf si elle a été
vérifiée et testée par un électricien qualifié ou un fournisseur de matériel électrique.
IMPORTANT - MÉTHODE POUR LA MISE À LA TERRE
Este producto viene equipado con un cable eléctrico que tiene un enchufe de tres patas con conexión
a tierra. Este debe colocarse en una toma de corriente con conexión a tierra de acuerdo con el Código
nacional de electricidad y códigos y ordenanzas locales correspondientes. Si el circuito no cuenta con
una toma de corriente con conexión a tierra, es responsabilidad y obligación del cliente sustituir la toma
de corriente actual de acuerdo con el Código nacional de electricidad y códigos y ordenanzas locales
correspondientes. Bajo ninguna circunstancia se debe cortar o eliminar la tercera pata de conexión a tierra.
Nunca utilice el cable, el enchufe o el artefacto cuando muestre un signo de daño visible. No utilice el
artefacto con una extensión salvo que un proveedor eléctrico o electricista calificado la inspeccione y la
pruebe.
IMPORTANTE - MÉTODO DE CONEXIÓN A TIERRA

WINE COOLER
Owner’s Use and Care Guide ................................1-10
• Welcome
• Important Safety Information
• Installation Instructions
• Features
• Operation
• Care and Maintenance
• Troubleshooting
• Warranty
REFROIDISSEUR A VIN
Guide d’utilisation et soin de propriètaire ................11-20
• Bienvenue
• Consignes de Sécurité Importantes
• Instructions d’installation
• Caracteristiques
• Opération
• Soins et Entretien
• Dépannage
• Garantie
ENFRIADOR DE VINO
Guía de utilización y cuidado para el propietario.....21-30
• Bienvenido
• Instrucciones de Seguridad Importantes
• Instrucciones de instalación
• Caracteristicas
• Operación
• Cuidado y Mantenimiento
• Diagnosticos de Problemas
• Garantia
CAUTION
PRÉCAUTION
PRECAUCIÓN
Read and follow all safety rules and
operating instructions before first use of this
product.
Veuillez lire attentivement les consignes de
sécurité et les intructions d’utilisation avant
l’utilisation intiale de ce produit.
Lea y observe todas las relgas de seguri-
dad y las instrucciones de operación antes
de usar este producto por la primera vez.
WARNING :
Improper connection of the grounding plug can result in risk of fire, electric shock
and/or injury to persons associated with the appliance. Check with a qualified
service representative if in doubt that the appliance is properly grounded.
AVERTISSEMENT :
Une fiche de mise à la terre mal branchée peut entraîner un risque d’incendie, de
choc électrique ou de blessures aux personnes qui utilisent l’appareil. Si vous
n’êtes pas certain que l’appareil est correctement mis à la terre, consultez un
préposé du service qualifié.
ADVERTENCIA :
Una instalación inadecuada de la conexión a tierra puede dar como resultado un
riesgo de incendio, descarga eléctrica o lesiones a las personas asociadas con
el artefacto. Verifique con un representante calificado de servicio en caso de
dudas sobre si el artefacto tiene una buena conexión a tierra.
CONTENTS

1
Thank you for choosing Danby
We know you’re excited. We are too! However, the more familiar you are with your new appliance, the better experience you will
have. We therefore strongly suggest that you read this Owner’s Manual before plugging in your new appliance. It contains
important operational information that will help you make full use of the technical features available in your Danby appliance. The
manual also contains information designed to enhance operating reliability and safety, as well as tips to maintaining your new
appliance so that it brings you happiness for years to come.
Please visit www.danby.com to access self-service tools, FAQs and more. Should you need additional assistance, please call
1-800-26-DANBY (1-800-263-2629).
Note: You will need the below information to obtain service under warranty.
To receive service, you must provide the original receipt.
Model Number:
Serial Number:
Date of Purchase:
NEED HELP?
Before you call for service, here are a few things you can do to help us serve you
better:
Read this Owner’s Manual:
It contains instructions to help you use and maintain your appliance properly.
If you received a damaged appliance:
Immediately contact the retailer (or builder) that sold you the appliance.
Save time and money:
Check the Troubleshooting section at the end of the guide before calling. This section
helps you solve common problems that may occur.
If you do need service, you can relax, knowing help is only a phone call away.
Tel:1-800-26-
(1-800-263-2629)

Please ensure that component parts shall be replaced with like components and that servicing shall be done
by factory authorized service personnel, so as to minimize the risk of possible ignition due to incorrect parts or
improper service.
IMPORTANT WARNING
DANGER, RISK OF CHILD ENTRAPMENT!
An empty wine cooler is a very dangerous attrac-
tion to children. Remove either the gasket latches,
lids, lock and/or doors from unused or discarded
appliances, or take some other action
to guarantee it harmless.
Leave the shelves in place so that children may
not easily climb inside.
DON’T WAIT, DO IT NOW!
WARNING
To reduce the risk of fire, burns, electric shock, or
injury to persons when using your appliance,
follow basic precautions, including the following
sections below.
SAFETY
PRECAUTIONS
• This appliance must be
grounded. Connect only to a
properly grounded outlet.
See “Grounding Instructions”
section on page 3.
• Do not operate this appliance
if it has a damaged power cord
or plug, if it is not working
properly, or if the appliance has
been damaged or dropped.
• Do not splice the power cord
that is equipped with this
appliance.
• Keep power cord away from
heated surfaces.
• Do not immerse power cord,
plug or the appliance itself in
water.
• Do not use this product near
water-for example, in a wet
basement, near a swimming
pool or near a sink.
• Do not use corrosive
chemicals or vapors in this
appliance.
• Use this appliance only for
its intended use, as described
in this manual.
• Do not store perishable food
items such as (but not limited
to) meats and dairy products
in your wine cooler.
• Store wine in sealed
containers only.
• See door surface cleaning
instructions in the Care and
Cleaning section(s) of this
manual.
• Do not cover or block any
openings on the appliance.
• This appliance is intended for
household use only. Do not
attempt to operate or store this
appliance outdoors.
• This appliance should be
serviced only by qualified service
personnel. Contact nearest
authorized service facility for
examination, repair or adjustment.
SAVE THESE INSTRUCTIONS
2
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION

Please ensure that component parts shall be replaced with like components and that servicing shall be done
by factory authorized service personnel, so as to minimize the risk of possible ignition due to incorrect parts or
improper service.
GROUNDING
INSTRUCTIONS
WARNING
Improper use of the
grounding plug can
result in a risk of electric
shock.
This appliance must be
grounded. In the event of an
electrical short circuit, grounding
reduces the risk of electric
shock by providing an escape
wire for the electric current.
This appliance is equipped
with a power cord having a
grounding wire with a grounding
plug. The plug must be
plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician
or service technician if the
grounding instructions are not
completely understood, or if
doubt exists as to whether the
appliance is properly grounded.
If the outlet is a standard 2-
prong wall outlet, it is your per-
sonal responsibility and obligation
to have it replaced with a
properly grounded 3-prong
wall outlet.
For best operation, plug this
appliance into its own
electrical outlet to prevent
flickering of lights, blowing of
fuse or tripping of circuit breaker.
Do not under any circumstances
cut or remove the third (ground)
prong from the power cord.
Do not use an adapter plug
with this appliance.
Do not use an extension
cord with this appliance. If the
power cord is too short, have
a qualified electrician or service
technician install an outlet
near the appliance.
LOCATION DO...
• Select a location with a
strong, level floor.
• Allow 5 inches of space
between the back of the
appliance and any adjacent
wall.
• Avoid direct sunlight and
heat. Direct sunlight may
affect the acrylic coating,
heat sources nearby will
cause higher electricity
consumption.
DO NOT...
• DO NOT use this appliance
outdoors. This appliance is
intended for household use
only. Do not attempt to
operate or store this
appliance outdoors.
• DO NOT build this appliance
into an enclosure: This
appliance is designed for a
free-standing application
only and is not intended to
be “built-in”.
3
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
INSTALLATION INSTRUCTIONS
Pull the unit forward 2”
for proper door swing
clearance and to avoid
hitting the gasket when
pulling the shelves out.

FEATURES OF YOUR
WINE COOLER
2
3
4
6
5
1
1. Handle
2. Magnetic Door Gaskets: Tight fitting
seals retain all the cooling power and
humidity levels.
3. Tempered Glass Door: Tinted for UV
protection while maintaining easy
interior viewing.
4. Black wire shelves with stainless steel color trim
5. Electronic Display and Controls: For viewing and
regulating the temperature for both compartments of the
wine cooler.
6. Leveling Legs
Width 19 7/16” (493mm) Temperature Range
(Minimum ~Maximum) 41-64°F / 5-18°C
Height 33 2/16” (841mm) Net Weight 41 kgs / 90.4 lbs
Depth 24 15/16” (633mm) Refrigerant R134a
Specifications
4
INSTALLATION INSTRUCTIONS

DOOR SWING
REVERSAL
Phillips #2 screwdriver and an adjustable wrench.
TOOLS REQUIRED
WARNING
To reduce the risk of fire, burns, electric
shock, or injury to persons when using
your appliance, follow basic precautions,
including the following sections below.
1
2
3
4
5
7
8
9
Fig.1 Fig.2
6
Fig.4
Fig.5
Fig.3
Fig.6
11
10
1
2
3
4
5
6
7
8
9
10
11
Rubber screw covers
Screws
Decorative cover
Screws
Top hinge
Plug
Screws
Lower hinge
Cabinet leg
Extrusion-board for
lamp switch
Screws
1. Close the door and remove rubber screw covers (1), unscrew two screws (2) and remove decorative cover (3). (Fig.1)
2. Unscrew screws (4) and take out top hinge (5), then remove the door. (Fig. 2)
3. Put door aside safely, take out 2 screws (11) at bottom, pull out extrusion-board for lamp switch (10) and reattach it at the
top of the door. (Fig. 3)
4. Pull out plugs (6) from left top of cabinet. (Fig.4)
5. Unscrew 3 screws (7) from right bottom of cabinet and remove lower hinge (8). (Fig.5)
6. Unscrew cabinet leg (9) from left bottom of cabinet and fix it onto right bottom of cabinet. (Fig.5)
7. Fix the lower hinge (8) onto left bottom of cabinet with screws (7). (Fig. 5)
8. The door revolves 180 degrees, put lower door axis to aim at lower hinge (8) and install the door onto lower hinge (8), then
close the door carefully. (Fig.3)
9. Fix top hinge (5) onto left top of cabinet with screws (4), adjust door and install decorative cover (3) and rubber
cover (1). (Fig.6)
10. Block 3 screw holes at right top of cabinet with spare plugs.
5
INSTALLATION INSTRUCTIONS

THE CONTROLS OF
YOUR WINE COOLER
1
23456
: Indicator light illuminates to signify the
cooling mode is currently in operation.
Window: For viewing the temperature of the
upper zone.
Window: For viewing the temperature of the
lower zone.
°C / °F: Indicates what scale the temperatures will
be displayed in.
1
2
3
4
5
6
Button : Used to set the temperature in the
upper zone (see ‘Setting the Temperature’ below).
Button : Used to set the temperature in the
lower zone (see ‘Setting the Temperature’ below).
To control the inner light turn ON/OFF.
Switch: Continuous illumination.
Switch: Illumination only when the door is
open.
I
O
SETTING THE
TEMPERATURE
IMPORTANT
In the event of a power
failure, wait 3 to 5 minutes
before restarting.
• To switch the display between the Fahrenheit (°F) and Celsius
(°C) scale, press the and control buttons simultaneously for
approximately five(5) seconds.
• The temperature range can be set as low as 41°F (5°C) or as high
as 64°F (18°C) to suit your specific storage requirements. Each
press of the or button will allow you to adjust the
temperature in 1° increments within the aforementioned range.
6
OPERATING INSTRUCTIONS

WINE STORAGE
IMPORTANT
Store wine in sealed
bottles only.
The maximum* wine capacity
of your wine cooler is 38
(750 ml) bottles.
*When stocked as per
instructions.
7
In order to achieve the maxi-
mum capacity of thirty-eight (38)
bottles, it will be necessary to
position the bottles alternately
on the upper four (4) racks, as
shown in Fig. A. This will allow
for the storage of seven (7) 750
ml bottles per rack in each of
the top four (4) racks, and five
(5) bottles on the bottom
two (2) racks (Fig. B). For a fully
loaded unit please see Fig. C
below.
Fig. A
Full shelves
Fig. B
Half shelves
F
CC
F
7 bottles
7 bottles
7 bottles
7 bottles
5 bottles
5 bottles
Total 38 bottles
Fig.C (Fully loaded unit)
OPERATING INSTRUCTIONS
