Danfoss H Series User manual

© Copyright Danfoss | Commercial Compressors | 2014.12FRCC.PI.015.A4.02 - December 2014 - 8510274P01A
H series compressors
Instructions
70
65
60
SH 11K
55
50
45
40
35
30
25
20
-30 -20 -15-25 -10 -5 50 10 15
Condensing Temperature (°C)
Evaporating Temperature (°C)
70
65
60
SH 5K
SH 11K
HCJ120 & HCJ121
55
50
45
40
35
30
25
20
-30 -20 -15-25 -10 -5 50 10 15
Condensing Temperature (°C)
Evaporating Temperature (°C)
70
65
60
SH 11K
55
50
45
40
35
30
25
20
-30 -20 -15-25 -10 -5 50 10 15
Condensing Temperature (°C)
Evaporating Temperature (°C)
SH 5K
SH 10K
70
65
60
55
50
45
40
35
30
25
20
Condensing Temperature (°C)
-30 -20 -15-25 -10 -5 50 10 15
Evaporating Temperature (°C)
A: Model number
B: Technical number
C: Serial Number
D: Manufacturing year
E: Internal protection
F: Supply voltage range
G: Run capacitor
H: Locked rotor current
Maximum operating current
I: Lubricant type and nominal charge
J: Approved Refrigerant
HRM/HLM/HCMHRP/HLP/HCP Model variation T
(R22/407C)
HRH/HLH/HLJ/HCJ
Model variation T (R410A)
HRM/HLM/HCM  HRH/HLH/HLJ/HCJ
Model variation U (R22 / R410A)
HHP (R407C)
Installation and servicing of the compressor by qualied personnel only. Follow these
instructions and sound refrigeration engineering practice relating to installation,
commissioning, maintenance and service.
The compressor must only be
used for its designed purpose(s)
and within its scope of application
(refer to «operating limits»). Consult
Application guidelines and datasheet
available from cc.danfoss.com
Never operate
compressor without
terminal box cover in
place and secured.
Under all circumstances, the
EN378 (or other applicable local
safety regulation) requirements
must be fullled.
Wear protective goggles and
work gloves.
The compressor is delivered under nitrogen gas pressure
(between 0.3 and 0.4 bar / 4 and 6 psi). Do not disassemble
bolts, plugs, ttings, etc... unless all pressure has been
relieved from the compressor.
The compressor must be handled
with caution in the vertical
position (maximum oset from
the vertical : 15°).
C
S
R
Line Run
Capacitor
Start
Capacitor
Potential
Relay
1
2
5
C
S
R
Line Run
Capacitor
Quick connect spade terminals
P terminal box type
push
push
push
A
B
C
D
E
F
G
H
I
J
PSC wiring
CSR wiring
Operating limits
Electrical connections Single phase
C
T₁
Ring connect screw terminals
C terminal box type
S
T₂
R
T₃
Quick connect spade terminals
P & T terminal box type
Ring connect screw terminals
C & Q terminal box type
When HRM compressors are used with R417A, the
factory charged oil must be replaced by PVE oil 320HV
(120Z5034).
Brazed connection Rotolock connection
Models Connec.
size Models Connec. size
HRM032-042
HRP034-042
HRM/HRP045-047
HRH029-040
Suction
3/4"
Disch. 1/2" - -
HRM/HRP048-060
HLM/HLP068-075
HRH041-056
HLH061-068
HLJ061-068
Suction
7/8"
Disch. 1/2"
HRH044-
056
HLH061-
068
HLJ072-083
Suct. 1"1/4
Disch. 1"
HLM/HLP078-081 Suction 7/8"
Disch. 3/4" - -
HCM/HCP094-120
HCJ090-121 Suct. 1"1/8 Disch. 7/8" - -
1 – Introduction
These instructions pertain to the Danfoss scroll
compressors used for HVAC systems. They provide
necessary information regarding safety and proper
usage of this product.
2 – Handling and storage
•
Handle the compressor with care. Use the dedicated
handles in the packaging. Use the compressor lifting
lug and use appropriate and safe lifting equipment.
• Store and transport the compressor in an upright
position.
• Store the compressor between -35°C and 70°C
(31°F and 158°F).
• Don’t expose the compressor and the packaging
to rain or corrosive atmosphere.
3 – Safety measures before assembly
Never use the compressor in a ammable atmosphere.
• Mount the compressor on a horizontal at surface
with less than 7° slope.

© Copyright Danfoss | Commercial Compressors | 2014.12FRCC.PI.015.A4.02 - December 2014 - 8510274P01A
• Verify that the power supply corresponds to the
compressor motor characteristics (see nameplate).
• When installing a compressor model, use
equipment specically reserved for HFC
refrigerants which was never used for CFC or
HCFC refrigerants.
• Use clean and dehydrated refrigeration-grade
copper tubes and silver alloy brazing material.
• Use clean and dehydrated system components.
•
The piping connected to the compressor must be
exible in 3 dimensions to dampen vibrations.
• The compressor must always be mounted with the
rubber grommets supplied with the compressor.
4 – Assembly
• Slowly release the nitrogen holding charge
through discharge and suction ports.
• Connect the compressor to the system as soon as
possible to avoid oil contamination from ambient
moisture.
•
Avoid material entering into the system while cutting
tubes. Never drill holes where burrs cannot be removed.
• Braze with great care using state-of-the-art technique
and vent piping with nitrogen gas ow.
• Connect the required safety and control devices.
When the schrader port, if any, is used for this,
remove the internal valve.
• For parallel assemblies of the compressors in
version C8, contact Danfoss.
5 – Leak detection
Never pressurize the circuit with oxygen or dry
air. This could cause re or explosion.
• Do not use leak detection dye.
•
Perform a leak detection test on the complete system.
• The low side test pressure must not exceed 31 bar
/450 psi.
• When a leak is discovered, repair the leak and
repeat the leak detection.
6 – Vacuum dehydration
• Never use the compressor to evacuate the system.
•
Connect a vacuum pump to both the LP & HP sides.
• Pull down the system under a vacuum of 500 µm
Hg (0.67 mbar) / 0.02 inch Hg absolute.
• Do not use a megohmmeter nor apply power to
the compressor while it is under vacuum as this
may cause internal damage.
7 – Electrical connections
• Switch o and isolate the main power supply.
•
All electrical components must be selected as per
local standards and compressor requirements.
• Refer to page 1 for electrical connections
details.For three phase applications, the
terminals are labeled T1, T2, and T3. For single-
phase applications the terminals are labeled C
(common), S (start), and R (run).
• Danfoss scroll compressors will only compress gas
while rotating counter-clockwise (when viewed
from the compressor top). Since single-phase
motors will start and run in only one direction,
reverse rotation is not a major consideration.
Three-phase motors, however, will start and
run in either direction, depending on the phase
angles of the supplied power. Care must be taken
during installation to ensure that the compressor
operates in the correct direction.
•
Use ø 4.8 mm / #10 - 32 screws and ¼”ring terminals
for the power connection with ring connect screw
terminal (C type). Fasten with 3 Nm torque.
• Use ø 6.3 mm tabs for quick connect spade
terminals (P type).
• Use a self tapping screw to connect the
compressor to earth.
8 – Filling the system
• Keep the compressor switched o.
• Keep the refrigerant charge below the indicated
charge limits if possible. Above this limit; protect
the compressor against liquid ood-back with a
pump-down cycle or suction line accumulator.
•
Never leave the lling cylinder connected to the circuit.
Compressor models Refrigerant
charge limit
HRM032-034-038-040-042-045-047
3.6 kg / 8 lb
HRP034-038-040-042-045-047
HHP015-019-021-026
HRH031-032-034-036-038-040
HRM048-051-054-058-060 /
HLM068-072-075-078-081
5.4 kg / 12 lb
HRP048-051-054-058-060 /
HLP068-072-075-081
HHP030-038-045
HRH044-049-051-054-056 /
HLH061-068 - HLJ072-083
HCM094-109-120
7.2 kg / 16 lbHCP094-109-120
HCJ090-091-105-106-120-121
9 – Verification before commissioning
Use safety devices such as safety pressure switch
and mechanical relief valve in compliance with both
generally and locally applicable regulations and
safety standards. Ensure that they are operational
and properly set.
Check that the settings of high-pressure
switches don’t exceed the maximum service
pressure of any system component.
• A low-pressure switch is recommended to avoid
low pressure operation.
Minimum setting for R22 1.5bar (absolute)/22 psia
Minimum setting for R407C
Minimum setting for R410A 2.5bar (absolute)/36 psia
•
Verify that all electrical connections are properly
fastened and in compliance with local regulations.
• When a crankcase heater is required, it must be
energized at least 24 hours before initial start-up
and start-up after prolonged shutdown.
• Please respect a 90 Nm ± 20 Nm for tightening
torque of all rotolock nut.
10 – Start-up
• Never start the compressor when no refrigerant is
charged.
• Do not provide any power to the compresor
unless suction and discharge service valves are
open, if installed.
•
Energize the compressor. It must start promptly.
If the compressor does not start, check wiring
conformity and voltage on terminals.
• Eventual reverse rotation can be detected by
following phenomena; the excessive noise, no
pressure dierential between suction and discharge,
and line warming rather than immediate cooling.
A service technician should be present at initial
start-up to verify that supply power is properly
phased and that the compressor is rotating in the
correct direction. H-series Scroll compressors are
designed to operate for a maximum of 150 hours
in reverse, but as a reverse rotation situation can go
unnoticed for longer periods, phase monitors are
recommended. For compressors HLM078, HLP081,
HLJ083 and larger, phase monitors are required for all
applications. Danfoss recommends phase protection
for residential compressors.
• If the internal overload protector trips out, it must cool
down to 60°C / 140°F to reset. Depending on ambient
temperature, this may take up to several hours.
11 – Check with running compressor
Check current draw and voltage. Measurement of
amps and volts during running conditions must be
taken at other points in the power supply, not in the
compressor electrical box.
• Check suction superheat to reduce risk of slugging.
• Observe the oil level in the sight glass (if provided)
for about 60 minutes to ensure proper oil return to
the compressor.
• Respect the operating limits.
•
Check all tubes for abnormal vibration. Movements
in excess of 1.5 mm / 0.06 in require corrective
measures such as tube brackets.
• When needed, additional refrigerant in liquid phase
may be added in the low-pressure side as far as
possible from the compressor. The compressor must
be operating during this process.
• Do not overcharge the system.
• Never release refrigerant to atmosphere.
• Before leaving the installation site, carry out
a general installation inspection regarding
cleanliness, noise and leak detection.
• Record type and amount of refrigerant charge
as well as operating conditions as a reference for
future inspections.
12 – Maintenance
Internal pressure and surface temperature
are dangerous and may cause permanent injury.
Maintenance operators and installers require
appropriate skills and tools. Tubing temperature may
exceed 100°C / 212°F and can cause severe burns.
Ensure that periodic service inspections to
ensure system reliability and as required by local
regulations are performed.
To prevent system related compressor problems,
following periodic maintenance is recommended:
• Verify that safety devices are operational and
properly set.
• Ensure that the system is leak tight.
• Check the compressor current draw.
• Conrm that the system is operating in a way
consistent with previous maintenance records
and ambient conditions.
• Check that all electrical connections are still
adequately fastened.
• Keep the compressor clean and verify the absence
of rust and oxidation on the compressor shell,
tubes and electrical connections.
• Acid / moisture content in system and oil should
be checked regularly.
13 - Warranty
Always transmit the model number and serial
number with any claim led regarding this product.
The product warranty may be void in following
cases:
• Absence of nameplate.
• External modications; in particular, drilling,
welding, broken feet and shock marks.
• Compressor opened or returned unsealed.
• Rust, water or leak detection dye inside the
compressor.
• Use of a refrigerant or lubricant not approved by
Danfoss.
• Any deviation from recommended instructions
pertaining to installation, application or
maintenance.
• Use in mobile applications.
• Use in explosive atmospheric environment.
• No model number or serial number transmitted
with the warranty claim.
14 – Disposal
Danfoss recommends that compressors
and compressor oil should be recycled by
a suitable company at its site.
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products
already on order provided that such alterations can be made without subsequential changes being necessary in specications already agreed.
All trademarks in this material are property of the respective companies. Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.

© Copyright Danfoss | Commercial Compressors | 2014.12FRCC.PI.015.A4.41 - December 2014 - 8510274P01A
H 系列压缩机
说明
70
65
60
SH 11K
55
50
45
40
35
30
25
20
-30 -20 -15-25 -10 -5 50 10 15
Condensing Temperature (°C)
Evaporating Temperature (°C)
70
65
60
SH 5K
SH 11K
HCJ120 & HCJ121
55
50
45
40
35
30
25
20
-30 -20 -15-25 -10 -5 50 10 15
Condensing Temperature (°C)
Evaporating Temperature (°C)
70
65
60
SH 11K
55
50
45
40
35
30
25
20
-30 -20 -15-25 -10 -5 50 10 15
Condensing Temperature (°C)
Evaporating Temperature (°C)
SH 5K
SH 10K
70
65
60
55
50
45
40
35
30
25
20
Condensing Temperature (°C)
-30 -20 -15-25 -10 -5 50 10 15
Evaporating Temperature (°C)
A： 型号
B： 技术编号
C： 序列号
D： 生产年份
E： 内部保护
F： 供电电压范围
G： 工作电容
H： 堵转电流
最大运行电流
I： 润滑剂类型和额定充注量
J： 认可的制冷剂
HRM/HLM/HCMHRP/HLP/HCP 型号类型 T
(R22/407C)
HRH/HLH/HLJ/HCJ
型号类型 T (R410A)
HRM/HLM/HCM  HRH/HLH/HLJ/HCJ
型号类型 U (R22 / R410A)
HHP (R407C)
C
S
R
Line Run
Capacitor
Start
Capacitor
Potential
Relay
1
2
5
C
S
R
Line Run
Capacitor
Quick connect spade terminals
P terminal box type
push
push
push
A
B
C
D
E
F
G
H
I
J
PSC 接线
CSR 接线
使用限制
电气连接 单相
C
T₁
Ring connect screw terminals
C terminal box type
S
T₂
R
T₃
快连型叉片端子
P & T 型接线盒
环接型螺钉端子
C & Q 型接线盒
当 HRM 压缩机与 R417A 一起使用时，必须将出
厂充注的油脂更换为 PVE 油 320HV (120Z5034)
。
1 – 概述
这些说明同用于 HVAC 系统的 Danfoss HRM/
HLM/HCM - HRP/HLP/HCP/HHP - HRH/HLH/HLJ/
HCJ 涡旋压缩机有关。 它们提供了有关该产
品的安全和正确使用的必要信息。
2 – 处理和存储
• 处理压缩机时请小心。 请使用包装箱内的
专用把手。 请使用压缩机的吊环，并采用
恰当且安全的起重设备。
• 请将压缩机竖直存储和运输。
• 压缩机应存放在 -35°C 到 70°C /-31°F
到 158°F 的温度范围内。
• 请勿让压缩机和包装箱淋雨或是放在腐蚀
性环境中。
3 – 组装前的安全措施
切勿在易燃环境中使用压缩机。
• 将压缩机安装在坡度小于 7° 的水平面
上。
本压缩机只能由合格人员安装和维护。遵照下面的说明和相关的安装，调试，维护
及服务的噪声制冷工程惯例 。
该压缩机只能用于指定用途及其
应用范围之内（请参考«使用限制»
）。 请查阅 cc.danfoss.com 提供
的应用指南和数据表
如果未安装且
固定接线盒盖，切
勿操作压缩机。
在所有情况下都必须达到
EN378（或其他适用的当地安全
规定）要求。
请佩戴护目镜和工作手套。
该压缩机在交付时带有加压氮气（0.3 到 0.4 bar/4 到
6 psi）。 请勿拆卸螺栓、管堵、管件等，除非 压缩机
的所有压力 都已卸除。
搬运压缩机时必须注意使其保
持垂直（最多可偏离垂直位置
15°）。
焊接 螺纹连接
型号
连接管大小 型号 连接管大小
HRM032-042
HRP034-042
HRM/HRP045-047
HRH029-040
吸气口 3/4"
排气口1/2"
- -
HRM/HRP048-060
HLM/HLP068-075
HRH041-056
HLH061-068
HLJ061-068
吸气口 7/8"
排气口1/2"
HRH044-056
HLH061-068
HLJ072-083
吸气口
1"1/4
排气口 1"
HLM/HLP078-081
吸气口 7/8"
排气口 3/4"
- -
HCM/HCP094-120
HCJ090-121
吸气口
1"1/8
排气口 7/8"
- -

© Copyright Danfoss | Commercial Compressors | 2014.12FRCC.PI.015.A4.41 - December 2014 - 8510274P01A
• 确保电源与压缩机的电动机特性一致（请
参见铭牌）。
• 安装 HRP/HLP/HCP/HHP - HRH/HLH/HLJ/HCJ
型压缩机时，请使用专为 HFC 制冷剂设计
的设备。此类设备不得使用 CFC 或 HCFC
作为制冷剂。
• 请使用干净且已脱水的制冷级铜管和银钎
焊合金。
• 请使用干净且已脱水的系统组件。
• 与压缩机相连的管道三维必须富有弹性，
以降低震动。
• 务必使用压缩机附随的橡胶垫来安装压缩
机。
4 – 组装
• 通过排放和吸入端口缓慢释放为了起保护
作用而充注的氮气。
• 尽快将压缩机连接至系统，以避免周围环
境中的水分污染润滑油。
• 切割管道时，避免材料进入系统。 若无法
去除毛刺，切勿钻孔。
• 采用最新技术、利用通风管中的氮气流进
行铜焊，并且要格外小心。
• 连接所需的保护装置和控制器。 当使用
可能配备的 schrader 端口来实现这一点
时，请拆掉内阀。
• 有关 C8 型压缩机的并行组装，请与
Danfoss 联系。
5 – 泄漏检测
切勿用氧气或干燥空气对回路加压。 这
会酿成火灾或爆炸。
• 请勿使用检漏染料。
• 对整个系统进行泄漏检测。
• 低侧测试压力不得超过 31 bar/450 psi。
• 如果发现泄漏，则检修泄漏并再次进行泄
漏检测。
6 – 真空脱水
• 切勿使用压缩机将系统排空。
• 将真空泵连接至 LP 和 HP 端。
• 使系统达到下述真空度：500 µm Hg (0.67
mbar) / 0.02 inch Hg（绝对值）。
• 在压缩机处于真空状态时，请勿使用兆欧
表给压缩机供电，因为这样会内部损伤。
7 – 电气连接
• 关闭主电源并将其绝缘。
• 所有电气组件的选择必须依据当地标准和
压缩机要求进行。
• 有关电气连接的详细信息，请参考第 1
页。用于三相应用的端子分别标有 T1、T2
和 T3。 用于单相应用的端子分别标有 C（
公用）、S（启动）和 R（运行）。
• Danfoss 涡旋压缩机仅在逆时针旋转（从压
缩机顶部看）时才会对气体进行压缩。 由
于单相电动机仅单向启动和运行，因此反转
并不是一个需要特别考虑的问题。 但根据
供电的相位角，三相电动机可能双向启动和
运行。 为确保压缩机以正确方向工作，在
安装期间须给予注意。
• 使用环接型螺钉端子（C 型）进行电源连
接时，请使用 ø 4.8 mm/#10 - 32 螺钉和
¼” 环形端子。 以 3 Nm 的扭矩拧紧。
• 对于快连型叉片端子（P 型），请使用 ø
6.3 mm 连接片。
• 使用自攻螺钉将压缩机接地。
8 – 填充系统
• 切断压缩机。
• 如果可能的话，让制冷剂充注量保持在指
定的充注限制以下。 如果超出该限制；请
防止压缩机的抽气周期或吸入管累加器出
现液体回液。
• 切勿让充注气瓶一直与回路连接。
压缩机型号 制冷剂充注
限量
HRM032-034-038-040-042-045-047
3.6 千克/8 磅
HRP034-038-040-042-045-047
HHP015-019-021-026
HRH031-032-034-036-038-040
HRM048-051-054-058-060 /
HLM068-072-075-078-081
5.4 千克/12
磅
HRP048-051-054-058-060 /
HLP068-072-075-081
HHP030-038-045
HRH044-049-051-054-056 /
HLH061-068 - HLJ072-083
HCM094-109-120 7.2 千克/16
磅
HCP094-109-120
HCJ090-091-105-106-120-121
9 – 运行前的核查工作
依照通用和当地相关的规定和安全标准，
使用安全压力开关和机械卸压阀等保护装
置。 确保她们运行且状态良好。
检查高压开关的设置，确保未超出任何系
统组件的最大工作压力。
• 建议采用低压开关来避免低压工作状态。
针对 R22 的最低设置 1.5 bar（绝对值）/22
psia
针对 R407C 的最低设置
针对 R410A 的最低设置 2.5 bar（绝对值）/36
psia
• 确保所有电气连接均已正确固定，且符合
当地规定。
• 如果需要曲轴箱加热器，则在初次启动之
前或长期关闭后再启动之前，必须至少通
电 24 个小时。
• 请对所有的螺纹接口螺母用紧固力矩 90 Nm
± 20 Nm。
10 – 启动
• 切勿在未充注制冷剂的情况下启动压缩
机。
• 如果安装了吸入和排出检修阀，则除非这
些阀门已打开，否则请勿给压缩机供电。
• 给压缩机通电。 它应会立即启动。 如果
压缩机没有启动，请检查端子电压以及布
线是否一致。
• 可以通过下述现象来确定反转情况：过大噪
音；吸入端和排出端之间无压差；以及管路
变热而不是立即冷却。 为验证供电的相位
正确，并且压缩机以正确方向旋转，在初始
启动时，应有技术服务人员在场。 H 系列
涡旋压缩机在设计上最长可以反向工作 150
小时，但由于反转情况可能无觉察地持续
更长时间，因此建议采用相位监视器。 对
HLM078、HLP081、HLJ083 和更大规格的压缩
机来说，相关的所有应用都必须配备相位监
视器。 Danfoss 建议为民用压缩机提供相位
保护。
• 如果内部过载保护器断开，则必须待其冷
却至 60°C / 140°F 后才能复位。 这可
能需要几个小时，具体取决于环境温度。
11 – 检查压缩机的运行情况
检查电流和电压。 在工作状态下测量电
流和电压时，必须在供电线路的其他位置执
行测量（不能在压缩机电气盒中执行测量）
。
• 检查抽吸过热情况，降低水击风险。
• 观察视液镜（如果配备的话）中的油位约
60 分钟，确保有适当油量返回压缩机。
• 请遵守运行限制。
• 检查所有管道是否存在异常震动。 如果位
移幅度超过 1.5 毫米/0.06 英寸，则须采
用管道托架等纠正措施。
• 如有需要，请向低压端添加更多的液相制
冷剂，并尽可能远离压缩机。 必须在压缩
机运行过程中执行该过程。
• 请勿对系统进行过量充注。
• 切勿将制冷剂排到大气中。
• 立刻安装场地之前，执行常规安装检查，
涉及清洁度、噪音和泄漏检测。
• 记录制冷剂的类型和充注量以及工作条
件，以供将来检查参考。
12 – 维护
内部压力和表面温度均具有危险性，并可
能造成永久性伤害。 维护操作员和安装人员
需具备适当技能和工具。 管道温度可能超过
100°C/212°F，会造成严重烫伤。
务必根据当地规定定期进行维修检查，以
确保系统的可靠性。
• 检查保护装置是否正确安装和运行。
• 确保系统无漏损。
• 检查压缩机的最大电流。
• 确保系统按照先前的维护记录和周围环境
持续运行。
• 检查所有电气连接是否依然紧固。
• 保持压缩机的清洁，确保压缩机壳体、管
道和电气连接没有生锈或氧化。
• 应定期检查系统和油脂中的酸度/湿度。
13 – 保修
对该产品进行索赔时，始终需提供其型号和
序列号。
产品保修在下列情况下无效：
• 无铭牌。
• 外部改装，尤其是钻孔、焊接、脚垫破损
以及撞击痕迹。
• 压缩机已打开或返还时未密封。
• 压缩机内生锈，存在水渍或泄漏检测染
料。
• 使用未经 Danfoss 批准的制冷剂或润滑
剂。
• 任何违背有关安装、应用或维护的建议指
示的行为。
• 用于移动应用。
• 在爆炸性环境中使用。
• 进行保修索赔时未提供型号或序列号。
14 – 处理
Danfoss 建议由适当的公司在自身设
施处回收压缩机和压缩机油。
对于目录、手册及其他印刷材料中可能出现的错误，Danfoss 不承担任何责任。 Danfoss 保留修改产品的权利，怒不另行通知。 这也适用于已经订购的产品，前提是此类修改不会对已确定的
产品规格带来极大的改动。
本材料的所有商标是相应公司的财产。 Danfoss 和 Danfoss 徽标是 Danfoss A/S 的商标。 保留所有权利。
