Danfoss VLT CDS 803 User manual

MAKING MODERN LIVING POSSIBLE
Quick Guide
VLT®Compressor Drive CDS 803
www.danfoss.com/drives

Contents
1 Quick Guide 2
1.1 Safety 2
1.1.1 Warnings 2
1.1.2 Safety Instructions 2
1.2 Introduction 2
1.2.1 Available Literature 2
1.2.2 Approvals 3
1.2.3 IT Mains 3
1.2.4 Avoid Unintended Start 3
1.2.5 Disposal Instruction 3
1.3 Installation 3
1.3.1 Before Starting Repair Work 3
1.3.2 Enclosure Types 3
1.3.3 Side-by-Side Installation 4
1.3.4 Dimensions 4
1.3.6 Connecting to Mains and Compressor 5
1.3.7 Fuses 7
1.3.8 EMC-Correct Electrical Installation 8
1.3.9 Control Terminals 9
1.4 Programming 11
1.4.2 The Start-up Wizard 12
1.4.3 Main Menu Structure 21
1.5 Acoustic Noise or Vibration 23
1.6 Warnings and Alarms 23
1.7 General Specifications 24
1.7.1 Mains Supply 3x200-240 V AC 24
1.7.2 Mains Supply 3x380-480 V AC 25
1.8 Special Conditions 29
1.8.1 Derating for Ambient Temperature and Switching Frequency 29
1.8.2 Derating for Low Air Pressure 29
1.9 Options for VLT®Compressor Drive CDS 803 29
Contents Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 1

1 Quick Guide
1.1 Safety
1.1.1 Warnings
WARNING
High Voltage Warning
The voltage of the frequency converter is dangerous
whenever it is connected to mains. Incorrect installation
of the compressor or frequency converter may cause
damage to the equipment, serious injury or death.
Consequently, it is essential to comply with the
instructions in this manual as well as local and national
rules and safety regulations.
WARNING
DISCHARGE TIME!
Frequency converters contain DC-link capacitors that can
remain charged even when the frequency converter is
not powered. To avoid electrical hazards, disconnect AC
mains, any permanent magnet type compressors, and
any remote DC-link power supplies, including battery
back-ups, UPS, and DC-link connections to other
frequency converters. Wait for the capacitors to fully
discharge before performing any service or repair work.
The waiting time is listed in the Discharge Time table.
Failure to wait the specified time after power has been
removed before doing service or repair could result in
death or serious injury.
Voltage [V] Cooling capacity [TR] Minimum waiting time
(min)
3x200 4-6.5 15
3x400 4-5 4
3x400 6.5 15
Table 1.1 Discharge Time
CAUTION
Leakage Current
The ground leakage current from the frequency
converter exceeds 3.5 mA. According to IEC 61800-5-1 a
reinforced Protective Earth connection must be ensured
with a min. 10 mm2Cu or an additional PE wire - with
the same cable cross-section as the mains wiring - must
be terminated separately.
Residual Current Device
This product can cause a DC current in the protective
conductor. Where a residual current device (RCD) is used
for extra protection, only an RCD of Type B (time
delayed) shall be used on the supply side of this
product. See also Danfoss Application Note on RCD,
MN90G.
Protective earthing of the frequency converter and the
use of RCDs must always follow national and local
regulations.
WARNING
Installation at High Altitudes
For altitudes above 2000 m, contact Danfoss regarding
PELV.
1.1.2 Safety Instructions
•Make sure the frequency converter is properly
connected to ground.
•Do not remove mains connections, compressor
connections or other power connections while
the frequency converter is connected to power.
•Protect users against supply voltage.
•Protect the compressor against overloading
according to national and local regulations.
•The ground leakage current exceeds 3.5 mA.
•The [Off/Reset] key is not a safety switch. It does
not disconnect the frequency converter from
mains.
1.2 Introduction
1.2.1 Available Literature
This Quick Guide contains basic information necessary for
installing and running the frequency converter. Supple-
mentary publications and manuals are available from
Danfoss. See www.danfoss.com/BusinessAreas/DrivesSo-
lutions/ Documentations/VLT+Technical+Documentation.htm
for listings.
Quick Guide Quick Guide
2 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

1.2.2 Approvals
Certification IP20
EC Declaration of
Conformity ✓
UL Listed ✓
C-tick ✓
Table 1.2 Approvals
The frequency converter complies with UL508C thermal
memory retention requirements. For more information,
refer to the section Motor Thermal Protection in the
product specific design guide.
1.2.3 IT Mains
CAUTION
IT Mains
Installation on isolated mains source, that is, IT mains.
Max. supply voltage allowed when connected to mains:
440 V (3x380-480 V units).
Open the RFI switch by removing the screw on the side of
the frequency converter when at IT grid.
130BB612.10
1
1RFI switch
Illustration 1.1 IP20
CAUTION
If reinserted, only use M3x12 screw.
1.2.4 Avoid Unintended Start
While the frequency converter is connected to mains, the
compressor can be started/stopped using digital
commands, bus commands, references or via the LCP.
•Disconnect the frequency converter from mains
whenever personal safety considerations make it
necessary to avoid unintended start of any
compressors.
•To avoid unintended start, always press [Off/
Reset] before changing parameters.
1.2.5 Disposal Instruction
Equipment containing electrical components
must not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
1.3 Installation
1.3.1 Before Starting Repair Work
1. Disconnect from mains (and external DC supply, if
present).
2. Wait as stated in Table 1.1 for discharge of the
DC-link.
3. Remove compressor cable.
1.3.2 Enclosure Types
Cooling capacity 400 V IP20
Enclosure
4 TR/VZH028 H3
5 TR/VZH035 H3
6.5 TR/VZH044 H4
Table 1.3 H3-H4, 400 V
Cooling capacity 200 V IP20
Enclosure
4 TR/VZH028 H4
5 TR/VZH035 H4
6.5 TR/VZH044 H5
Table 1.4 H4-H5, 200 V
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 3
11

1.3.3 Side-by-Side Installation
The frequency converter can be mounted side-by-side and requires the clearance above and below for cooling.
Frame IP class Clearance above/below [mm/inch]
H3 IP20 100/4
H4 IP20 100/4
H5 IP20 100/4
Table 1.5 Clearance
NOTICE
With IP21/Nema Type1 option kit mounted, a distance of 50 mm between the units is required.
1.3.4 Dimensions
NOTICE
The illustration in Table 1.6 is with LCP, but all
dimensions are the same without LCP.
A
a
b
B
C
D
130BB614.10
e
f
a
e
130BC246.10
Enclosure Height [mm] Width [mm] Depth [mm] Mounting hole [mm] Max.
Weight
Frame IP Class A A1) a B b C d e f kg
H3 IP20 255 329 240 100 74 206 11 5.5 8.1 4.5
H4 IP20 296 359 275 135 105 241 12.6 7 8.4 7.9
H5 IP20 334 402 314 150 120 255 12.6 7 8.5 9.5
Table 1.6 Dimensions
1) Including decoupling plate
The dimensions are only for the physical units, but when installing in an application it is necessary to add space for free air
passage both above and below the units. The amount of space for free air passage is listed in Table 1.5.
Quick Guide Quick Guide
4 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

1.3.5 Electrical Installation in General
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper
conductors required, (75 °C) recommended.
Enclosure Torque [Nm]
Frame IP class Line Compressor
connection
DC connection Control
terminals
Ground Relay
H3 IP20 1.4 0.8 0.8 0.5 0.8 0.5
H4 IP20 1.2 1.2 1.2 0.5 0.8 0.5
H5 IP20 1.2 1.2 1.2 0.5 0.8 0.5
Table 1.7 Enclosure H3-H5
1.3.6 Connecting to Mains and Compressor
The frequency converter is designed to operate Danfoss
VZH Compressors. For maximum cross-section on wires see
chapter 1.7 General Specifications.
•Use a shielded/armored compressor cable to
comply with EMC emission specifications, and
connect this cable to both the decoupling plate
and the compressor metal.
•Keep compressor cable as short as possible to
reduce the noise level and leakage currents.
•For further details on mounting of the
decoupling plate, see VLT
®
Compressor Drive CDS
803 Decoupling Plate Installation Instructions.
•Also see EMC-Correct Installation in the VLT
®
Compressor Drive CDS 803 Design Guide.
1. Mount the ground wires to ground terminal.
2. Connect compressor to terminals U, V and W, see
Table 1.8.
UT1
V T2
W T3
Table 1.8 Connection of Compressor to Terminals
3. Mount mains supply to terminals L1, L2 and L3
and tighten.
130BB634.10
1
2
2
3
4
Motor
UVW-DC+DC
MAINS
1Line
2 Ground
3 Compressor
4 Relays
Illustration 1.2 H3-H5 Frame
IP20 200-240 V 4-6.5 tons
IP20 380-480 V 4-6.5 tons
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 5
11

-DC+DC
BR- BR+ U V W
99
M A I N S
95
RELAY 1 RELAY 2
- LC +
130BA261.10
Illustration 1.3 Mount the 2 screws in the mounting plate,
slide it into place and tighten fully.
MOTOR
MOTOR
U V W
99
130BT302.12
Illustration 1.4 H3-H5 Frame
130BA262.10
M
I N S
+DC
BR- BR+ UVW
RELAY 1 RELAY 2
95
Illustration 1.5 When mounting cables, first mount and tighten
ground cable.
130BA263.10
95
MAINS
+DC
BR- BR+ UVW
91 92 93
L1 L2 L3
RELAY 1 RELAY 2
Illustration 1.6 Mount mains plug and tighten wires.
Quick Guide Quick Guide
6 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

+DC
BR- BR+ UVW
MAINS
L1 L2 L3
91 92 93
RELAY 1 RELAY 2
99
- LC -
130BA264.10
Illustration 1.7 Tighten support bracket on mains wires.
1.3.7 Fuses
Branch circuit protection
To protect the installation against electrical and fire hazard, all branch circuits in an installation, switch gear, machines etc.,
must be short-circuit and overcurrent protected according to national and local regulations.
Short circuit protection
Danfoss recommends using the fuses listed in Table 1.9 to protect service personnel or equipment in case of an internal
failure in the unit or short-circuit on DC-link. The frequency converter provides full short circuit protection in case of a short-
circuit on the compressor.
Overcurrent protection
Provide overload protection to avoid overheating of the cables in the installation. Overcurrent protection must always be
carried out according to local and national regulations. Circuit breakers and fuses must be designed for protection in a
circuit capable of supplying a maximum of 100,000 Arms (symmetrical), 480 V maximum.
UL/Non UL compliance
Use the fuses listed in Table 1.9 to ensure compliance with UL or IEC 61800-5-1.
NOTICE
In the event of malfunction, failure to follow the protection recommendation may result in damage to the frequency
converter.
Fuse
UL Non UL
Bussmann Bussmann Bussmann Bussmann Max fuse
CDS 803 Type RK5 Type RK1 Type J Type T Type G
3x200-240 V IP20
4 TR/VZH028 FRS-R-50 KTN-R50 JKS-50 JJN-50 50
5 TR/VZH035 FRS-R-50 KTN-R50 JKS-50 JJN-50 50
6.5 TR/VZH044 FRS-R-80 KTN-R80 JKS-80 JJN-80 65
3x380-480 V IP20
4 TR/VZH028 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
5 TR/VZH035 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
6.5 TR/VZH044 FRS-R-50 KTS-R50 JKS-50 JJS-50 50
Table 1.9 Fuses
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 7
11

1.3.8 EMC-Correct Electrical Installation
General points to be observed to ensure EMC-correct electrical installation.
•Use only screened/armoured motor cables and screened/armoured control cables.
•Connect the screen to ground at both ends.
•Avoid installation with twisted screen ends (pigtails), since this ruins the screening effect at high frequencies. Use
the cable clamps provided instead.
•Ensure the same potential between frequency converter and ground potential of PLC.
•Use starwashers and galvanically conductive installation plates.
B
a
c
k
OK
Com.
On
Warn.
Alarm
Hand
On
O
Reset Auto On
Menu Status Quick
Menu Main
Menu
L1
L2
L3
PE
Min. 16 mm2
Equalizing cable
Control cables
All cable entries in
one side of panel
Earthing rail
Cable insula-
tion stripped
Output con-
tactor etc.
Motor cable
Motor, 3 phases and
PLC etc. Panel
Mains-supply
Min. 200mm
between control
cable, mains cable
and between mains
motor cable
PLC
Protective earth
Reinforced protective earth
130BB761.11
Illustration 1.8 EMC-correct Electrical Installation
Quick Guide Quick Guide
8 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

1.3.9 Control Terminals
130BB622.10
Illustration 1.9 Location of Control Terminals
1. Place a screwdriver behind the terminal cover to
activate the snap.
2. Tilt the screwdriver outwards to open the cover.
Control terminals
To make the compressor run:
1. Apply start signal on terminal 18
2. Connect terminals 12, 27 and terminal 53, 54 or
55
18 19
12 20 55
27 29 42 45 50 53 54
DIGI IN DIGI IN DIGI IN DIGI IN
61 68 69
N P COMM. GND
+24V
0/4-20mA A OUT / DIG OUT 0/4-20mA A OUT / DIG OUT
GND
GND
10V/20mA IN 10V/20mA IN 10V OUT
130BB625.10
BUS TER.
OFF ON
Illustration 1.10 Control Terminals
Set the functions of digital input 18, 19 and 27 in
5-00 Digital Input Mode (PNP is default value). Set the
function of digital input 29 in 5-03 Digital Input 29 Mode
(PNP is default value).
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 9
11

1.3.10 Electrical Overview
L1
L2
L3
3 Phase
power
input
PE PE
+10 V DC
0-10 V DC-
0-10 V DC-
50 (+10 V OUT)
54 (A IN)
53 (A IN)
55 (COM A IN/OUT)
0/4-20 mA
0/4-20 mA
42 0/4-20 mA A OUT / DIG OUT
45 0/4-20 mA A OUT / DIG OUT
18 (DIGI IN)
19 (DIGI IN)
27 (DIGI IN)
29 (DIGI IN)
12 (+24 V OUT)
24 V (NPN)
20 (COM D IN)
O V (PNP)
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
Bus ter.
Bus ter.
RS-485
Interface RS-485
(N PS-485) 69
(P RS-485) 68
(Com RS-485 ) 61
(PNP)-Source
(NPN)-Sink
ON=Terminated
OFF=Unterminated
ON
1 2
240 V AC 3 A
Not present on all power sizes
Do not connect shield to 61
01
02
03
relay1
relay2
UDC+
UDC-
Motor
U
V
W
130BD467.10
06
05
04
240 V AC 3 A
Illustration 1.11 Basic Wiring Schematic Drawing
Quick Guide Quick Guide
10 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

1.4 Programming
1.4.1 Local Control Panel (LCP)
NOTICE
LCP is NOT supported in SW 1.0X!
The LCP is divided into 4 functional sections.
A. Display
B. Menu key
C. Navigation keys and indicator lights (LEDs)
D. Operation keys and indicator lights (LEDs)
130BB765.11
Com.
1-20 Motor Power
[5] 0.37kW - 0.5HP
Setup 1
A
B
1
12
13 14 15
11
11
10
9
8
7
6
5
4
3
2
C
D
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset
Auto
On
Alarm
Warn.
On
11
Back
O
Illustration 1.12 Local Control Panel (LCP)
A. Display
The LCD-display is back-lit with 2 alphanumeric lines. All
data is displayed on the LCP.
Information can be read from the display.
1Parameter number and name.
2 Parameter value.
3 Set-up number shows the active set-up and the edit set-
up. If the same set-up acts as both active and edit set-up,
only that set-up number is shown (factory setting). When
active and edit set-ups differ, both numbers are shown in
the display (set-up 12). The number flashing, indicates the
edit set-up.
4 Compressor direction is shown to the bottom left of the
display – indicated by a small arrow pointing either
clockwise or counterclockwise.
5 The triangle indicates if the LCP is in Status, Quick Menu
or Main Menu.
Table 1.10 Legend to Illustration 1.12
B. Menu key
Press [Menu] to select between Status, Quick Menu or
Main Menu.
C. Navigation keys and indicator lights (LEDs)
6 Com LED: Flashes when bus communication is communi-
cating.
7 Green LED/On: Control section is working.
8 Yellow LED/Warn.: Indicates a warning.
9 Flashing Red LED/Alarm: Indicates an alarm.
10 [Back]: For moving to the previous step or layer in the
navigation structure
11 [▲] [▼] [►]: For maneuvering between parameter groups,
parameters and within parameters. Can also be used for
setting local reference.
12 [OK]: For selecting a parameter and for accepting changes to
parameter settings
Table 1.11 Legend to Illustration 1.12
D. Operation keys and indicator lights (LEDs)
13 [Hand On]: Starts the compressor and enables control of
the frequency converter via the LCP.
NOTICE
Terminal 27 Digital Input (5-12 Terminal 27 Digital
Input) has stop inverse as default setting. This
means that [Hand On] does not start the
compressor if there is no 24 V to terminal 27.
Connect terminal 12 to terminal 27.
14 [Off/Reset]: Stops the compressor (Off). If in alarm mode,
the alarm is reset.
15 [Auto On]: Frequency converter is controlled either via
control terminals or serial communication.
Table 1.12 Legend to Illustration 1.12
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 11
11

1.4.2 The Start-up Wizard
The built-in wizard menu guides the installer through the
set-up of the frequency converter in a clear and structured
manner to set-up an open loop application. An open loop
application is here an application with a start signal,
analog reference (voltage or current) and optionally also
relay signals (but no feed back signal from the process
applied).
FC
+24 V
DIG IN
DIG IN
DIG IN
DIG IN
COM DIG IN
A OUT/D OUT
A OUT/D OUT
18
19
27
29
42
55
50
53
54
20
12
01
02
03
04
05
06
R2 R1
+
0-10 V
Start
+10 V
A IN
A IN
COM
130BD872.10
45
Reference
15
PRESSURE SWITCH
Illustration 1.13 Open Loop Application
The wizard is initially be shown after power-up until any
parameter has been changed. The wizard can always be
accessed again through the Quick Menu. Press [OK] to start
the wizard. Press [Back] to return to the status screen.
130BB629.10
Press OK to start Wizard
Push Back to skip it
Setup 1
Illustration 1.14 Start-up/Quit Wizard
Quick Guide Quick Guide
12 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

English
OK
5
if
Select Language
... the CDS 803 Wizard starts
Size related
Select Grid Type
4
Select Main Menu Password 6
[0]
[0]
OK
B
a
c
k
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset Auto
On
Alarm
Warn.
On
Status Screen
The Wizard can always be
reentered via the Quick Menu!
Power Up Screen
At power up the user is
asked to choose the
prefered laguage.
Select language
[1] English
0.0 Hz
0.0 kW
Setup 1
Setup 1
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset Auto
On
Alarm
Warn.
On
Press OK to start Wizard
Press Back to skip it
Setup 1
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset Auto
On
Alarm
Warn.
On
The next screen will be
the Wizard screen.
Wizard Screen
1
2
if
3
B
a
c
k
B
a
c
k
B
a
c
k
Com.
Com.
Com.
130BD873.11
Size related
Select Compressor Selection 7
200 Hz
Select Max. reference 8
Analog in 53
Select Reference 1 Source 9
[1]
30 s
Select Ramp 1 Ramp Up Time 10
30 s
Select Ramp 1 Ramp Down Time 11
Stop inverse
Select Terminal 27 Digital In 12
Alarm
Select Relay 1 13
Drive Running
Select Relay 2 14
0.07 V
Select Terminal 53 Low Voltage 15
10 V
Select Terminal 53 High Voltage 16
Digital and ctrl.word
Select Control Site 17
[0]
FC
Select Protocol 18
[0]
Setup 1
9600
Select Baud Rate 19
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Illustration 1.15 Open Loop Applications
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 13
11

The Start-up Wizard for open loop applications
Parameter Option Default Function
0-01 Language [0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
[0] English Select the language for the display.
0-06 GridType [0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
Size related Select operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
0-60 Main Menu Password 0-999 0 Define the password for access to the LCP.
1-13 Compressor Selection [24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
Size related Select the used compressor.
3-03 Maximum Reference 0-200 Hz 200 Hz The maximum reference is the lowest
obtainable by summing all references.
3-15 Reference 1 Source [0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
3-41 Ramp 1 Ramp Up Time 0.05-3600.0 s 30.00 s Ramp-up time from 0 to 1-25 Motor Nominal
Speed.
3-42 Ramp 1 Ramp Down Time 0.05-3600.0 s 30.00 s Ramp down time from rated motor speed to
0.
Quick Guide Quick Guide
14 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

Parameter Option Default Function
5-12 Terminal 27 Digital Input [0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[6] Stop inverse Select the input function for terminal 27.
5-40 Function Relay [0] Function relay See 5-40 Function Relay Alarm Select the function to control output relay 1.
5-40 Function Relay [1] Function relay See 5-40 Function Relay Drive running Select the function to control output relay 2.
6-10 Terminal 53 Low Voltage 0-10 V 0.07 V Enter the voltage that corresponds to the low
reference value.
6-11 Terminal 53 High Voltage 0-10 V 10 V Enter the voltage that corresponds to the
high reference value.
8-01 Control Site [0] Digital and ctrl.word
[1] Digital only
[2] Controlword only
[0] Digital and
ctrl. word
Select if digital, bus, or a combination of both
should control the frequency converter.
8-30 Protocol [0] FC
[2] Modbus RTU
[0] FC Select the protocol for the integrated RS-485
port.
8-32 Baud Rate [0] 2400 Baud [1]
4800 Baud
*[2] 9600 Baud
[3] 19200 Baud
4] 38400 Baud
5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
9600 Select the baud rate for the RS-485 port.
Table 1.13 Open Loop Applications Set-up
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 15
11

The Start-up Wizard for compressor functions
28-13 Boost Duration
60 s
5
6
28-01 Interval between Starts
130BD874.11
28-11 Low Speed Running Time
20 min
28-02 Minimum Run Time
3
28-00 Short Cycle Protection
[1] Enabled
1
28-10 Oil Return Management
[1] On
4
2
300 s
60 s
Illustration 1.16 Compressor Function Wizard
Compressor function wizard
Parameter Option Default Function
28-00 Short Cycle Protection [0] Disabled
[1] Enabled
[1] Enabled Select if short cycle protection is to be used.
28-01 Interval between Starts 0-3600 s 300 s Enter the minimum allowed time between
starts.
28-02 Minimum Run Time 10-3600 s 60 s Enter the minimum allowed time to run
before stop.
28-10 Oil Return Management [0] Off
[1] On
[1] On Select if Oil Return Management is to be used.
28-11 Low Speed Running Time 1-1400 min 20 min Enter the low speed running time.
28-13 Boost Duration 10-3600 s 60 s Enter the boost duration for the oil return.
Table 1.14 Compressor Function
Quick Guide Quick Guide
16 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1

The Start-up Wizard for compressor closed loop applications
6-24 Terminal 54 Low Ref./Feedb.
0
6-23 Terminal 54 High Voltage
6-22 Terminal 54 Low Voltage
0.07
6-15 Terminal 53 High Ref./Feedb.
200
6-10/12 Terminal 53 Low Voltage
0003 s
6-11 Terminal 53 High Voltage
13
14
15
16
18
19
21
22
5-40 Function Relay 1
5-40 Function Relay 2
Drive running
130BD875.11
6-25 Terminal 54 High Ref./Feedb.
0-60 Main Menu Password
[0]
3
0-01 Language
[0] English
1
4
20-06 Grid Type
Size related
3-10 Preset Reference
0%
3-02 Minimum Reference
0 Hz
1-00 Conguration Mode
Open loop
3-03 Maximum Reference
200
3-42 Ramp 1 Ramp Down Time
5
5-12 Terminal 27 Digital Input
3-41 Ramp 1 Ramp Up Time
5
6
7
8
9
10
11
12
3-15 Reference 1 Source
6-14 Terminal 53 Low Ref./Feedb.
30
17
20
8-30 Protocol
[0] FC
8-01 Control Site
20-81 Normal/Inverse Control
20-00 Feedback 1 Source
0.00
23
24
26
27
8-32 Baud Rate
Digital and ctrl.word
25
[0]
Hz
Analog in 53
[1]
10 V
[0]
30.00
s
30.00
s
Stop inverse
[6]
V
10.00 V
50.000
No function
[0]
Normal
[0]
9600
1-13 Compressor Selection
Size related
Alarm
Illustration 1.17 Closed Loop Wizard
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 17
11

Closed loop wizard
Parameter Option Default Function
0-01 Language [0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
0 Select the language for the display.
0-06 GridType [0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
Size related Select the operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
0-60 Main Menu Password 0-999 0 Define the password for access to the LCP.
1-00 Configuration Mode [0] Open loop
[3] Closed loop
[0] Open loop Select closed loop.
1-13 Compressor Selection [24] VZH028
[25] VZH035
[26] VZH044
Size related Select the used compressor.
3-02 Minimum Reference -4999.0 - 200 Hz 0 Hz The minimum reference is the lowest value
obtainable by summing all references.
3-03 Maximum Reference 0 - 200 Hz 200 Hz The maximum reference is the highest
obtainable by summing all references
3-10 Preset Reference -100 - 100 % 0 % Setup a fix set point n preset reference [0].
3-15 Reference 1 Source [0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
3-41 Ramp 1 Ramp Up Time 0.05-3600.0 s 30.00 s Ramp up time from 0 to 1-25 Motor Nominal
Speed.
3-42 Ramp 1 Ramp Down Time 0.05-3600.0 s 30.00 s Ramp-down time from rated motor speed to
0.
Quick Guide Quick Guide
18 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
1
1
