1. Safety VLT Micro Drive FC 51
2 MG.02.C2.02 - VLT®is a registered Danfoss trademark
1

1. Safety
1.1.1. High Voltage Warning
The voltage of the frequency converter is dangerous whenever it is connected to
mains. Incorrect installation of the motor or frequency converter may cause damage
to the equipment, serious injury or death. Consequently, it is essential to comply
with the instructions in this manual as well as local and national rules and safety
regulations.
1.1.2. Safety Instructions
• Make sure the frequency converter is properly connected to earth.
• Do not remove mains connections, motor connections or other power connections while
the frequency converter is connected to power.
• Protect users against supply voltage.
• Protect the motor against overloading according to national and local regulations.
• The earth leakage current exceeds 3.5 mA.
• The [OFF] key is not a safety switch. It does not disconnect the frequency converter from
mains.
1.1.3. Approvals
1.1.4. General Warning
Warning:
Touching the electrical parts may be fatal - even after the equipment has been dis-
connected from mains.
Also make sure that other voltage inputs have been disconnected, (linkage of DC
intermediate circuit).
Be aware that there may be high voltage on the DC link even when the LEDs are
turned off.
Before touching any potentially live parts of the VLT Micro Drive, wait at least 4
minutes for all sizes.
Shorter time is allowed only if indicated on the nameplate for the specific unit.
VLT Micro Drive FC 51 1. Safety
MG.02.C2.02 - VLT®is a registered Danfoss trademark 3
1

Leakage Current
The earth leakage current from the VLT Micro Drive FC 51 exceeds 3.5 mA. According
to IEC 61800-5-1 a reinforced Protective Earth connection must be ensured by
means of a min. 10mm² Cu or an addtional PE wire - with the same cable cross
section as the Mains wiring - must be terminated separately.
Residual Current Device
This product can cause a D.C. current in the protective conductor. Where a residual
current device (RCD) is used for extra protection, only an RCD of Type B (time de-
layed) shall be used on the supply side of this product. See also Danfoss Application
Note on RCD, MN.90.GX.YY.
Protective earthing of the VLT Micro Drive and the use of RCDs must always follow
national and local regulations.
Motor overload protection is possible by setting Parameter 1-90 Motor thermal pro-
tection to the value ETR trip. For the North American market: ETR functions provide
class 20 motor overload protection, in accordance with NEC.
Installation in high altitudes:
By altitudes above 2km, please contact Danfoss Drives regarding PELV.
1.1.5. IT Mains
IT Mains
Installation on isolated mains source, i.e. IT mains.
Max. supply voltage allowed when connected to mains: 440 V.
As an option, Danfoss offers line filters for improved harmonics performance.
1.1.6. Avoid unintended Start
While the frequency converter is connected to mains, the motor can be started/stopped using
digital commands, bus commands, references or via the Local Control Panel.
• Disconnect the frequency converter from mains whenever personal safety considerations
make it necessary to avoid unintended start of any motors.
• To avoid unintended start, always activate the [OFF] key before changing parameters.
1.1.7. Disposal Instruction
Equipment containing electrical components must not be disposed of
together with domestic waste.
It must be separately collected with electrical and electronic waste
according to local and currently valid legislation.
1. Safety VLT Micro Drive FC 51
4 MG.02.C2.02 - VLT®is a registered Danfoss trademark
1

1.1.8. Before Commencing Repair Work
1. Disconnect FC 51 from mains (and external DC supply, if present.)
2. Wait for 4 minutes for discharge of the DC-link.
3. Disconnect DC bus terminals and brake terminals (if present)
4. Remove motor cable
VLT Micro Drive FC 51 1. Safety
MG.02.C2.02 - VLT®is a registered Danfoss trademark 5
1

2. Introduction VLT Micro Drive FC 51
6 MG.02.C2.02 - VLT®is a registered Danfoss trademark
2

2. Introduction
2.1.1. FC Identification
Below is an example of an identification sticker. This sticker is situated on the frequency converter
and shows the type and options fitted to the unit. See following tables for details, how to read the
Type code string.
Illustration 2.1: This example shows the identification sticker.
2.1.2. Type Code
Description Pos Possible choice
Product group 1-3 Adjustable Frequency Converters
Series and product type 4-6 Micro Drive
Power size 7-10 0.18 - 7.5 kW
Mains voltage 11-12 S2: Single phase 200 - 240 V AC
T 2: Three phase 200 - 240 V AC
T 4: Three phase 380 - 480 V AC
Enclosure 13-15 IP20/Chassis
RFI filter 16-17 HX: No RFI filter
H1: RFI filter class A1/B
H3:RFI filter A1/B (reduced cable length)
Brake 18 B: Brake chopper included
X: No brake chopper included
Display 19 X: No Local Control Panel
N: Numerical Local Control Panel (LCP)
P: Numerical Local Control Panel (LCP) with potentiom-
eter
Coating PCB 20 C: Coated PCB
X. No coated PCB
Mains option 21 X: No mains option
Adaptation A 22 No adaptation
Adaptation B 23 No adaptation
Software release 24-27 Latest release - std. software
Table 2.1: Type code description
VLT Micro Drive FC 51 2. Introduction
MG.02.C2.02 - VLT®is a registered Danfoss trademark 7
2

2.1.3. Symbols
Symbols used in this Programming Guide.
NB!
Indicates something to be noted by the reader.
Indicates a general warning.
Indicates a high-voltage warning.
* Indicates default setting
2.1.4. Abbreviations and Standards
Terms: Abbreviations: SI-units: I-P units:
Acceleration m/s² ft/s²
American wire gauge AWG
Automatic Motor Tuning AMT
Current A Amp
Current limit I
LIM
Energy J = N·m ft-lb, Btu
Fahrenheit ˚F
Frequency Converter FC
Frequency Hz Hz
Kilohertz kHz
Local Control Panel LCP
Milliampere mA
Millisecond ms
Minute min
Motion Control Tool MCT
Motor Type Dependent M-TYPE
Newton Metres Nm
Nominal motor current I
M,N
Nominal motor frequency f
M,N
Nominal motor power P
M,N
Nominal motor voltage U
M,N
Parameter par.
Protective Extra Low Voltage PELV
Power W Btu/hr, hp
Pressure Pa = N/m² psi, psf, ft of
water
Rated Inverter Output Current I
INV
Revolutions Per Minute RPM
Size Related SR
Temperature ˚C˚F
Time s s,hr
Torque limit T
LIM
Voltage V V
Table 2.2: Abbreviation and Standards table .
2. Introduction VLT Micro Drive FC 51
8 MG.02.C2.02 - VLT®is a registered Danfoss trademark
2

3. Programming
3.1. How to Programme
3.1.1. Programming with MCT-10
The frequency converter can be programmed from a PC via RS485 com-port by installing the
MCT-10 Set-up Software.
This software can either be ordered using code number 130B1000 or downloaded from the Dan-
foss Web site: www.danfoss.com, Business Area: Motion Controls.
Please refer to manual MG.10.RX.YY.
3.1.2. Programming with LCP 11 or LCP 12
The LCP is divided into four functional groups:
1. Numeric display.
2. Menu key.
3. Navigation keys.
4. Operation keys and indicator lights (LEDs).
Illustration 3.1: LCP 12 with potentiometer Illustration 3.2: LCP 11 without potentiometer
The display:
A number of information can be read from the display.
Set-up number shows the active set-up and
the edit set-up. If the same set-up acts as
both active and edit set-up, only that set-up
number is shown (factory setting).
When active and edit set-up differ, both num-
bers are shown in the display (Setup 12). The
number flashing, indicates the edit set-up.
Illustration 3.3: Indicating Set-up
VLT Micro Drive FC 51 3. Programming
MG.02.C2.02 - VLT®is a registered Danfoss trademark 9
3

The small digits to the left are the selected
parameter number .
Illustration 3.4: Indicating selected par. no.
The large digits in the middle of the display
show the value of the selected parameter.
Illustration 3.5: Indicating value of selected par.
The right side of the display shows the unit
of the selected parameter. This can be either
Hz, A, V, kW, HP, %, s or RPM.
Illustration 3.6: Indicating unit of selected par.
Motor direction is shown to the bottom left
of the display - indicated by a small arrow
pointing either clockwise or counterclockwise.
Illustration 3.7: Indicating motor direction
Use the [MENU] key to select one of the following menus:
Status Menu:
The Status Menu is either in
Readout Mode or Hand on Mode . In Readout Mode the value of the
currently selected readout parameter is shown in the display.
In
Hand on Mode the local LCP reference is displayed.
Quick Menu:
Displays Quick Menu parameters and their settings. Parameters in the Quick Menu can be accessed
and edited from here. Most applications can be run by setting the parameters in the Quick Menus.
Main Menu:
Displays Main Menu parameters and their settings. All parameters can be accessed and edited
here. A parameter overview is found later in this chapter.
3. Programming VLT Micro Drive FC 51
10 MG.02.C2.02 - VLT®is a registered Danfoss trademark
3

Indicator lights:
• Green LED: Power is on the frequency converter.
• Yellow LED: Indicates a warning.
• Flashing red LED: Indicates an alarm.
Navigation Keys:
[Back]: For moving to the previous step or layer in the navigation structure.
Arrows [▲] [▼]: For manoeuvring between parameter groups, parameters and within parame-
ters.
[OK]: For selecting a parameter and for accepting changes to parameter settings.
Operation Keys:
A yellow light above the operation keys indicates the active key.
[Hand on]: Starts the motor and enables control of the frequency converter via the LCP.
[Off/Reset]: The motor stops except in alarm mode. In that case the motor will be reset.
[Auto on]: The frequency converter is controlled either via control terminals or serial communi-
cation.
[Potentiometer] (LCP12): The potentiometer works in two ways depending on the mode in
which the frequency converter is running.
In
Auto Mode the potentiometer acts as an extra programmable analog input.
In
Hand on Mode the potentiometer controls local reference.
3.2. Status Menu
After power up the Status Menu is active. Use
the [MENU] key to toggle between Status,
Quick Menu and Main Menu.
Arrows [▲] and [▼] toggles between the
choices in each menu.
The display indicates the status mode with a
small arrow above “Status”.
Illustration 3.8: Indicating Status mode
3.3. Quick Menu
The Quick Menu gives easy access to the most frequently used parameters.
1. To enter the Quick Menu, press
[MENU] key until indicator in display
is placed above
Quick Menu , then
press [OK].
2. Use [▲] [▼] to browse through the
parameters in the Quick Menu.
3. Press [OK] to select a parameter.
4. Use [▲] [▼] to change the value of a
parameter setting.
5. Press [OK] to accept the change.
6. To exit, press either [Back] twice to
enter
Status , or press [Menu] once
to enter
Main Menu .
Illustration 3.9: Indicating Quick Menu mode
VLT Micro Drive FC 51 3. Programming
MG.02.C2.02 - VLT®is a registered Danfoss trademark 11
3

3.4. Main Menu
The Main Menu gives access to all parameters.
1. To enter the Main Menu, press
[MENU] key until indicator in display
is placed above
Main Menu .
2. Use [▲] [▼] to browse through the
parameter groups.
3. Press [OK] to select a parameter
group.
4. Use [▲] [▼] to browse through the
parameters in the specific group.
5. Press [OK] to select the parameter.
6. Use [▲] [▼] to set/change the pa-
rameter value.
7. Press [OK] to accept the value.
8. To exit, press either [Back] twice to
enter
Quick Menu , or press [Menu]
once to enter
Status .
Illustration 3.10: Indicating Main Menu mode
3. Programming VLT Micro Drive FC 51
12 MG.02.C2.02 - VLT®is a registered Danfoss trademark
3

4. Parameter Descriptions
4.1. Parameter group 0: Operation/Display
0-03 Regional Settings
Option: Function:
In order to meet the needs for different default settings in dif-
ferent parts of the world, par. 0-03,
Regional Settings , is imple-
mented in the frequency converter. The selected setting
influences the default setting of the motor nominal frequency.
[0 ]
*
International Sets default of par. 1-23, Motor Frequency , to 50 Hz.
[1] US Sets default of par. 1-23,
Motor Frequency , to 60 Hz.
NB!
This parameter cannot be adjusted while motor
runs.
0-04 Operating State at Power-up (Hand Mode)
Option: Function:
This parameter controls whether or not the frequency converter
should start running the motor when powering up after a power
down in Hand mode.
NB!
If LCP with potmeter is mounted, reference is set
according to actual potmeter value.
[0] Resume Frequency converter starts in same Hand or Off State as when
powered off.
Local reference is stored and used after power-up.
[1]
*
Forced Stop, Ref=Old Frequency converter powers up in Off State meaning that motor
is stopped after power up.
Local reference is stored and used after power-up.
[2] Forced Stop, Ref=0 Frequency converter powers up in Off State meaning that motor
is stopped after power up.
Local reference is set to 0. Thus motor will not start running
before local reference has been increased.
4.1.1. 0-1* Set-up Handling
User defined parameters and miscellaneous external inputs (eg. bus, LCP, analog/digital inputs,
feedback, etc.) controls the functionality of the frequency converter.
A complete set of all parameters controlling the frequency converter is called a set-up. The Micro
Drive FC 51 contains 2 set-ups,
Set-up1 and Set-up 2 .
VLT Micro Drive FC 51 4. Parameter Descriptions
MG.02.C2.02 - VLT®is a registered Danfoss trademark 13
4

Furthermore, a fixed set of factory settings can be copied into one or more set-ups.
Some of the advantages of having more than one set-up in the frequency converter are
• Run motor in one set-up (Active Set-up) while updating parameters in another set-up
(Edit Set-up)
• Connect various motors (one at a time) to frequency converter. Motor data for various
motors can be placed in different set-ups.
• Rapidly change settings of frequency converter and/or motor while motor is running (eg.
ramp time or preset references) via bus or digital inputs.
The
Active Set-up can be set as Multi Set-up where the active set-up is selected via input on a
digital input terminal and/or via the bus control word.
NB!
FactorySet-up cannot be used as Active Set-up .
0-10 Active Set-up
Option: Function:
Active Set-up controls the motor.
Shifts between set-ups can only happen when
•themotoriscoasted
OR
• the set-ups between which the shift happens are linked
to each other (see par. 0-12,
Linked Set-ups ).
If changing between set-ups that are not linked, the change will
not happen before motor is coasted.
NB!
The motor is only considered stopped when it is
coasted.
[1 ] *
Set-up 1 Set-up 1 is active.
[2] Set-up 2
Set-up 2 is active.
[9] Multi Set-up Select the active set-up via digital input and/or bus, see par.
5-1* choice [23].
0-11 Edit Set-up
Option: Function:
The
Edit Set-up is for updating parameters in the frequency
converter from either LCP or bus. It can be identical or different
from the
Active Set-up .
All set-ups can be edited during operation, independently of the
active set-up.
[1 ]
*
Set-up 1 Update parameters in Set-up 1 .
[2] Set-up 2 Update parameters in
Set-up 2 .
4. Parameter Descriptions VLT Micro Drive FC 51
14 MG.02.C2.02 - VLT®is a registered Danfoss trademark
4

[9] Active Set-up Update parameters in set-up selected as Active Set-up (see par.
0-10).
0-12 Link Set-ups
Option: Function:
The link ensures synchronizing of the “not changeable during
operation” parameter values enabling shift from one set-up to
another during operation.
If the set-ups are not linked, a change between them is not
possible while the motor is running. Thus the set-up change
does not occur until the motor is coasted.
[0] Not linked Leaves parameters unchanged in both set-ups and cannot be
changed while motor runs.
[1 ]
*
Linked Copy parameters “not changeable during operation” parameter
values into presently selected
Edit Set-up .
NB!
This parameter cannot be changed while motor
runs.
4.1.2. 0-4* LCP Keypad
The frequency converter can operate in the following three modes: Hand , Off and Auto .
Hand: The frequency converter is locally operated and does not allow any remote control. By
activating Hand a start signal is given.
OFF: The frequency converter stops with a normal stop ramp. When Off is chosen the frequency
converter can only be started by pressing either Hand or Auto on the LCP.
Auto: In Auto-mode the frequency converter can be remote controlled (bus/digital).
0-40 [Hand on] Key on LCP
Option: Function:
[0] Disabled Hand-on key has no function.
[1 ]
*
Enabled Hand-on key is functional.
0-41 [Off/Reset] Key on LCP
Option: Function:
[0] Disable Off/Reset Off/reset key has no function.
[1 ]
*
Enable Off/Reset Stop signal and reset of any faults.
[2] Enable Reset Only Reset only. Stop (Off) function is disabled.
0-42 [Auto on] Key on LCP
Option: Function:
[0] Disabled Auto-on key has no function.
[1 ]
*
Enabled Auto-on key is functional.
VLT Micro Drive FC 51 4. Parameter Descriptions
MG.02.C2.02 - VLT®is a registered Danfoss trademark 15
4

4.1.3. 0-5* Copy/Save
0-50 LCP Copy
Option: Function:
The detachable LCP of the frequency converter can be used for
storing setups, and thus for transferring data when moving pa-
rameter settings from one frequency converter to another.
NB!
LCP Copy can only be activated from the LCP and
ONLY when the motor is coasted.
[1] All to LCP Copy all setups from the frequency converter into the LCP.
[2] All from LCP Copy all setups from LCP to frequency converter.
[3] Size indep. from LCP Copy non motor size dependent data from LCP to frequency
converter
0-51 Set-up Copy
Option: Function:
Use this function to copy a set-up content into the
Edit Set-up .
In order to be able to make a set-up copy ensure that
•themotoriscoasted
• par. 0-10,
Active Set-up , is set to either Set-up 1 [1]
or
Set-up 2 [2]
NB!
The keyboard/parameter database are blocked
while Set-up Copy is running.
[0 ] *
No Copy Copy function is inactive
[1] Copy from Set-up 1 Copy from
Set-up 1 to edit set-up chosen in par. 0-11, Edit Set-
up
.
[2] Copy from Set-up 2 Copy from
Set-up 2 to edit set-up chosen in par. 0-11, Edit Set-
up
.
[9] Copy from Factory
Set-up
Copy from Factory Settings to edit set-up chosen in par. 0-11,
Edit set-up .
4.1.4. 0-6* Password
0-60 (Main) Menu Password
Range: Function:
Use password for protection against unintended change of sen-
sitive parameters, eg. motor parameters.
Password protected parameters can always be read, but cannot
be edited without entering the password.
4. Parameter Descriptions VLT Micro Drive FC 51
16 MG.02.C2.02 - VLT®is a registered Danfoss trademark
4

0 *
[0 - 999] Enter the password for access to Main Menu via the [Main Menu]
key. Select the number that should allow for changing other
parameter values.
0 means there is no password.
NB!
A password only has affect on the LCP - not on the bus communication.
VLT Micro Drive FC 51 4. Parameter Descriptions
MG.02.C2.02 - VLT®is a registered Danfoss trademark 17
4

4.2. Parameter Group 1: Load/Motor
1-00 Configuration Mode
Option: Function:
Use this parameter for selecting the application control principle
to be used when a Remote Reference is active.
NB!
Changing this parameter will reset parameters
3-00, 3-02 and 3-03 to their default values.
NB!
This parameter cannot be adjusted while motor
runs.
[0 ] *
Speed Open Loop For normal speed control (References).
[3] Process Closed Loop Enables process closed loop control. See par. group 7-3* for
further information on PI-controller.
When running in process closed loop, par. 4-10
Motor Speed
Direction
must be set to Clockwise [0]
1-01 Motor Control Principle
Option: Function:
[0] U/f Is used for parallel connected motors and/or special motor ap-
plications. The U/f settings are set in parameters 1-55 and 1-56.
NB!
When running U/f control slip- and load compen-
sations are not included.
[1] *
VVC+ Normal running mode, including slip- and load compensations.
1-03 Torque Characteristics
Option: Function:
With more torque characteristics it is possible to run low energy
consuming, as well as high torque applications.
[0 ]
*
Constant Torque Motor shaft output provides constant torque under variable
speed control.
[2] Automatic Energy Op-
tim.
This function automatically optimizes energy consumption in
centrifugal pump and fan applications. See par. 14-41
AEO Min-
imum Magnetisation
.
4. Parameter Descriptions VLT Micro Drive FC 51
18 MG.02.C2.02 - VLT®is a registered Danfoss trademark
4

1-05 Hand Mode Configuration
Option: Function:
This parameter is only relevant when parameter 1-00
Configu-
ration Mode
is set to Process Closed Loop [3]. The parameter is
used for determining the reference or setpoint handling when
changing from Auto Mode to Hand Mode on the LCP.
[0] Speed Open Loop In Hand Mode the drive always runs in Open Loop configuration
regardless of setting in par. 1-00
Configuration Mode . Local po-
tentiometer (if present) or Arrow up/down determines output
frequency limited by Motor Speed High/Low Limit (parameters
4-14 and 4-12).
[2]
*
As configuration in
par. 1-00
If par. 1-00 Configuration Mode is set to Open Loop [1] function
is as described above.
If par. 1-00 is set to
Process Closed Loop [3] changi ng from Auto
mode to Hand mode results in a setpoint change via local po-
tentiometer or Arrow up/down. The change is limited by Refer-
ence Max/Min (parameters 3-02 and 3-03).
4.2.1. 1-2* Motor Data
Enter the correct motor nameplate data (power, voltage, frequency, current and speed).
Run AMT, see par. 1-29.
Factory settings for advanced motor data, par. 1-3*, are automatically calculated.
NB!
Parameters in parameter group 1.2* cannot be adjusted while motor runs.
1-20 Motor Power [kW]/[HP] (P
m.n
)
Range: Function:
Enter motor power from nameplate data.
[0.09 kW/0.12 HP -
11 kW/15 HP]
Two sizes down, one size up from nominal VLT rating.
NB!
Changing this parameter affects par. 1-22 to 1-25,
1-30, 1-33 and 1-35.
1-22 Motor Voltage (U
m.n
)
Range: Function:
230/400
V
[50 - 999 V] Enter motor voltage from nameplate data.
1-23 Motor Frequency (f
m.n
)
Range: Function:
50 Hz
*
[20-400 Hz] Enter motor frequency from nameplate data.
VLT Micro Drive FC 51 4. Parameter Descriptions
MG.02.C2.02 - VLT®is a registered Danfoss trademark 19
4

1-24 Motor Current (I
m.n
)
Range: Function:
M-type
depend-
ent
*
[0.01 - 26.00 A] Enter motor current from nameplate data.
1-25 Motor Nominal Speed (n
m.n
)
Range: Function:
M-type
Depend-
ent
*
[100 - 9999 RPM] Enter motor nominal speed from nameplate data.
1-29 Automatic Motor Tuning (AMT)
Option: Function:
Use AMT to optimize motor performance.
NB!
This parameter cannot be changed while motor
runs.
1. Stop VLT – make sure motor is at standstill
2. Choose [2] Enable AMT
3. Apply start signal
– Via LCP: Press Hand On
- Or in Remote On mode: Apply start signal on terminal
18
[0]
*
Off AMT function is disabled.
[2] Enable AMT AMT function starts running.
NB!
To gain optimum tuning of frequency converter,
run AMT on a cold motor.
4.2.2. 1-3* Adv. Motor Data
Adjust advanced motor data using one of these methods:
1. Run AMT on cold motor. Frequency converter measures value from motor.
2. Enter X
1
value manually. Obtain value from motor supplier.
3. Use X
1
default setting. Frequency converter establishes setting based on motor name-
plate data.
NB!
This parameter cannot be changed while motor runs.
4. Parameter Descriptions VLT Micro Drive FC 51
20 MG.02.C2.02 - VLT®is a registered Danfoss trademark
4
