Danfoss ICAD 600A User manual

027R9801
027R9801
© Danfoss | DCS (ms) | 2020.01 AN213086423355en-000501 | 1
Installation Guide
ICAD 600A/ICAD 1200A
Quick Start Guide
Note!
Cross tighten all
3 screws to ensure
equal tightening.
Max 3 Nm torque.
Grease
Terminal box -
not supplied
by Danfoss
Ref. Colour Description
A Black – Common Alarm
B Brown – ICM fully open
C Red – ICM fully closed
D Orange – GND ground
E Yellow + 0/4 – 20 mA Input
F Green + 0/2 – 10 V input or digital input
for on/off control
G Blue + 0/4 – 20 mA Output
I Black + Fail safe supply
Battery / UPS* 19 V DC
II White + Supply voltage
24 V DC
III Brown –
* Uninterruptable Power Supply
24 Volt DC
ON LY
Please observe cable voltage drop
Distance between the applied DC transformer
and the ICAD terminal box may cause
a voltage drop. Cross section of cables and
size of DC transformer must be calculated
so that the voltage at all time at the ICAD
terminal box*, both during standstill and
during operation of ICAD, is within this range:
Prefabricated ICAD cable
length Code number
1.5 m
027H0426
3 m
027H0438
10 m
027H0427
15 m
027H0435
Voltage ICAD terminal
(600A/1200A) [V DC]
Min. 21 22 23 24
Max. 26.4
* Do not measure inside the ICAD itself
24 Volt DC
ON LY
Quick Start Guide
Before you
start using ICAD:
1
3
2

© Danfoss | DCS (ms) | 2020.012 | AN213086423355en-000501
Decrease
value
Edit /
Enter
Increase
value
Note:
If the keypad is not operated within
20 seconds; time out will automatically
exit programming mode.
Programming the ICAD
Valve label ID:
Valve size setup (mandatory)
Hold down for
2 seconds to enter
programming mode
; 01 ; 10
Press and
go to parameter 10.
Press
Press until
you reach 11 (password).
Press
Press until
you reach parameter 26
Press
11 ; 26
Press or
to select ICM size or CVE.
Press
ICM/CVE & ICAD
is now calibrating
0; 26 CA
Hold down for
2 seconds to exit
programming mode
1: ICM 20 with ICAD 600A
2: ICM 25 with ICAD 600A
3: ICM 32 with ICAD 600A
4: ICM 40 with ICAD 1200A
5: ICM 50 with ICAD 1200A
ICM 20 ICM 25-65 ICM 100-150
6: ICM 65 with ICAD 1200A
7: ICM 100 with ICAD 1200A
8: ICM 125 with ICAD 1200A
9: ICM 150 with ICAD 1200A
10: CVE pilot with ICAD 1200A
When powering up the ICAD, A1 will flash in the display
NOTE !
If media temperature is lower than -30 °C (-22 °F) it is mandatory to set parameter i30 an i31.
See separate document attached in ICAD box: document number AN285243155312
Changing analogue input signal (optional)
; 01
; 03
Hold down for
2 seconds to enter
programming mode
; 03
A3
Press until you
reach parameter 03.
Press
Press or
to select analogue
input signal
1: 0 – 20 mA
2: 4 – 20 mA*
3: 0 – 10 V
4: 2 – 10 V
2; 03
Press
* default factory setting
If A3 alarm occurs
the analogue input
signal is out of range
Hold down for
2 seconds to exit
programming mode
For further functions,
programming possibilities
and factory settings;
please see ICAD instruction.
24 Volt DC
O N LY
Factory reset of ICAD
Disconnect power 
Press down and 
simultaneously while
reconnecting power 
Release and 
Note:
If factory reset has been performed the
ICAD will start flashing A1 in the display.
