Danfoss FP75 User manual

1
FP75 - CP75 - FP15 - CP15
USER GUIDE
FP75 - 7 day programmer with separate output for Heating & Hot Water, which can be set at independent times.
CP75 - 7 day programmer with separate output for Heating & Hot Water.
FP15 - 24 hour programmer with separate output for Heating & Hot Water, which can be set independent times.
CP15 - 24 hour programmer with separate output for Heating & Hot Water.
Features include:
- Simple change 5 day/2day mode
- Simple change between GMT & BST
- 12 hour or 24 hour clock
- 3 on’s/3 off with manual over-rides
- Battery back-up
SELECTING THE OPERATING MODE
Behind the flap are two SELECT buttons, one each for Central
Heating (diagram) and Hot Water (diagram)
The operating modes available are:
ON The output is on constantly.
OFF The output is off constantly. Unless + 1HR is
pressed.
AUTO The output switches on and off to the set pro-
gramme.
ALLDAY The output switches on at Setting 1, then stays on
until Setting 6.
RESET
Should the unit be disconnected from the mains a small
battery symbol will blink on the left hand side of the display.
After the second midnight, i.e. between 24 and 48 hours, the
display will go blank and the will lose its setting. When mains
power is restored it is recommended that the unit be reset by
lowering the front flap and using a small non-metallic object,
e.g. matchstick, press and release the recessed reset button
(marked R/S). This installs the factory pre-set programme and
sets the time to 12.00pm and Monday (MO). The outputs will
be OFF, (see Fig. 1). Note that the colon between the hours
and minutes is blinking. This means the unit is in RUN mode
and will switch the Central Heating and Hot Water on and off
is accordance with the programme. The colon only blinks in
RUN mode.
CHOICE OF 12-HR OR 24-HR CLOCK
At any time during RUN mode the time displayed can be tog-
gled between a 12 hour clock with am/pm indication or a 24
hour clock by pressing and holding both DAY and NEXT ON/
OFF button for 1.5 seconds.
G.M.T./B.S.T.
While in RUN mode the change from Greenwich Mean Time
to British Summer Time and back is achieved by pressing
and holding the + button to add one hour in the Spring or
the – button to put the clock back in the Autumn. After the
first time this change has been made this feature will only
allow the clock to be changed in the correct direction. Take
care when making this change for the first time. If it is made
in the wrong direction the unit will have to be reset and any
user-settings re-entered.
SETTING THE CLOCK & PROGRAMMES
1. Pressing PROG once enters SET TIME mode, (see Fig 2)
while setting the time, pressing and releasing the + or –
button will change the time by one minute; pressing and
holding down + or – will change the time quickly in ten
minute steps. (This also applies when adjusting the ON/
OFF times). Use DAY button to set day. When the time
and day are correct, press the PROG button once to start
the clock and go to SET ON TIME mode.
2. CHECKING/ADJUSTING PROGRAMMES: Pre-set pro-
grammes maybe checked using the NEXT ON/OFF
button to step through the six available settings, which
can be changed if required using the + of – button. The
display now shows SET (CH) OFF TIME, with OFF blink-
ing. NOTE: CH appears only on FP75 and FP15 models.
3. PROGRAMMING NEXT DAY: Press DAY to advance to
next (not 24 hour mode), repeat step 2 each day (7 day
mode) or SAT-SUN (5 day mode). ALTERNATIVELY follow
COPYING PROGRAMMES instructions below.

2
4. COPYING PROGRAMMES: When a day’s settings are as
required they may all be copied to the following day
with just two button presses. Press DAY to change the
day, then press COPY. When used with any model that
has been converted to 5 day/2 day operation the pro-
gramme set for Monday to Friday (MOTUWETHFR on the
display) can be copied to the weekend (SASU).
5. CHECKING/ADJUSTING HOT WATER PROGRAMMES (FP75
& FP15 ONLY): Press PROG to display SET, HW, ON, TIME,
use NEXT ON/OF button to step through the six avail-
able setting, which can be changed if required using the
+ or – buttons.
6. RUN MODE: Having completed the programming for
each day, press PROG to go to the run mode
RUN MODE
OPERATION: In RUN mode the unit will automatically switch
the Central Heating and Hot Water on and off at the times
set. However, useful over-rides are provided which enable the
user to make temporary changes to the ON/OFF times with-
out having to re-programme the unit. The facilities offered by
the over-rides are detailed on the back cover.
REVIEWING PROGRAMMES FROM THE RUN MODE: Press PROG
twice, follow step 2,3,5 & 6 above (Note: step 5 applies only to
FP75 and FP15).
MANUAL OVER-RIDES
While in OFF, AUTO or ALLDAY modes the plus one hour
(+1HR) button can be used to switch from off to on for just
one hour, or to extend and existing on period by one hour.
The extra hour is cancelled by pressing the button again,
pressing the MAN button, or when an on event is reached.
While in AURO of ALLDAY modes pressing the manual (MAN)
button will switch an output which is on to off, and vice
versa. This over-ride will last only until the next programmed
switching event is reached, when the automatic programme
will resume control, or until the button is presses again.
When the above over-ride are selected a bar appears in the
display against the appropriate legend.
ERROR FREE PRORAMMING
ON/OFF times cannot be set out of sequence. The limits of
adjustment are: Setting 1 (first ON) 12.00am to 11.59pm (nor-
mally in the morning).
Settings 2 to 6 (first OFF to last OFF) anywhere between the
previous setting and 23 hours 59, minutes after Setting 1.
The – button stops responding when the pervious Setting is
reached, but the + button continues to its limit, also chang-
ing any later Setting that would have been overlapped.
While becoming familiar with Setting Sequence the ON/OFF
times may become grouped together. If this should happen
use NEXT ON/OFF to select Setting 1, then check/alter each
Setting in turn, using + or – until the desired programme is
entered .
When programming 7 day models, FP75 & CP75, the day be-
ing set appears in the display (see typical displays). With 24
hour models, FP15 & CP15, the day only appears in SET TIME
mode. When models are being programmed in 5 day/2day
mode then the days will show as MOTUWETHFR of SASU.
Should the unit be disconnected from the mains a small bat-
tery symbol will blink on the left hand side of the display.
FACTORY PRE-SET PROGRAMME
The following ON/OFF times are programmed at the fac-
tory and are re-instated by pressing the recessed R/S button
behind the flap.
NOTES ON TYPICAL DISPLAYS (see page 3)
Fig 1. Immediately following a manual RESET (RUN mode
with colon blinking)
Fig 2. SET TIME and DAY mode (colon steady, day, hours
and minutes blink)
Fig 3. SET FIRST ON TIME (‘CH’on models FP75 & FP15)
(setting number and day shown,‘ON’blinks)
Fig 4. SET FIRST OFF TIME (‘CH’on models FP75 & FP15)
(setting number and day shown,‘OFF’blinks)
Fig 5. SET LAST OFF IMR AFTER MIDNIGHT
(day when output will switch off blinks)
Fig 6. SET ‘HW’ FIRST ON TIME (models FP75 & FP15 only)
(setting number and day shown,‘ON’blinks)
Fig 7. Typical"CH" ALLDAY, "HW" AUTO programme with
"HW" +1 HOUR selected.

3
Sequence of button presses whilst adjusting time, day and programme setting
Read the section ‘Error free programming’ first.
Press and release + or – to change the time by one minute.
Press and hold down + or – to change the time quickly.
Danfoss Randall can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss
Randall reserves the right to alter its products without notice. This also applies to products already on order provided that
such alterations can be made subsequent changes being necessary in specifications already agreed.
Part No: FP75, CP75, FP15, CP15 - 1993
