Danfoss H1P Series User manual

MAKING MODERN LIVING POSSIBLE
Electrical Installation
H1 Pump
3-Position (FNR) Electric Control
powersolutions.danfoss.com

Revision history Table of revisions
Date Changed Rev
September 2015 Converted to Danfoss layout BA
February 2009 Removed Tandem pump, added Single pump AD
January 2009 Corrected single and tandem pump tables AC
April 2007 Minor revision AB
March 2007 First edition AA
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
211025001 • Rev BA • September 2015

Literature references H1 Pump 3-Position (FNR) Electric Control literature references....................................................................................4
Latest version of technical literature.........................................................................................................................................4
Product overview Product image................................................................................................................................................................................... 5
Nomenclature....................................................................................................................................................................................5
Theory of operation.........................................................................................................................................................................6
Pump displacement versus electrical signal..................................................................................................................... 6
Hydrostatic drive line power...................................................................................................................................................6
Hydraulic schematics...................................................................................................................................................................... 6
Electrical specifications.................................................................................................................................................................. 6
Electrical installation Pinout....................................................................................................................................................................................................7
DEUTSCH connector.................................................................................................................................................................. 7
Pin compatibility...............................................................................................................................................................................7
Input/output matrix........................................................................................................................................................................ 8
Mating connector.............................................................................................................................................................................8
DEUTSCH connector parts list ............................................................................................................................................... 8
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
Contents
11025001 • Rev BA • September 2015 3

H1 Pump 3-Position (FNR) Electric Control literature references
Literature title Description Literature number
H1 Single and Tandem Axial Piston Pumps, Basic
Information Complete product electrical and mechanical
specifications
11062168
PLUS+1®Compliant FNR Control Function Blocks User
Manual Compliant function block set-up information 11022881
Latest version of technical literature
Danfoss product literature is online at: http://powersolutions.danfoss.com/literature/
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
Literature references
411025001 • Rev BA • September 2015

Product image
H1 Pump 3-Position (FNR) Electric Control
Nomenclature
Single pump
A B D F E G H J K M N S T V W X Y
H1 P A G N N N N N N N N
Tandem pump
A B C D F E G H J K M N P R S T V W X Y
H1 T A N N F N P N N N N N N N N
Code D Options
Option Description
A9 FNR control, 12 V, manual override
B1 FNR control, 24 V, manual override
Only certain control options for the H1 pump utilize 3-Position (FNR) Electric Controll. Please refer to the
pump’s nomenclature to determine if the pump is equipped with the proper option. The nomenclature
can be found on the pump’s nametag.
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
Product overview
11025001 • Rev BA • September 2015 5

Theory of operation
The 3-position (FNR) Electric Control uses an electric input signal to switch the pump to a full stroke
position.
Pump displacement versus electrical signal
100 %
0
100 %
Voltage Vdc
Displacement
Hydrostatic drive line power
W
Warning
Unintended vehicle or machine movement hazard. The loss of hydrostatic drive line power, in any mode
of operation (forward, neutral, or reverse) may cause the system to lose hydrostatic braking capacity. You
must provide a braking system, redundant to the hydrostatic transmission, sufficient to stop and hold the
vehicle or machine in the event of hydrostatic drive power loss.
Hydraulic schematics
C1C2
F00A
M14
T PF00B
Electrical specifications
H1 pump 3-position (FNR) electrical specifications
Voltage 12V 24V
Minimum supply voltage 9.5 Vdc 19 Vdc
Maximum supply votage 14.6 Vdc 27 Vdc
Rated power 17 W 17 W
Coil resistance at 20º C [70º F] 8.4 Ω 34.5 Ω
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
Product overview
611025001 • Rev BA • September 2015

Pinout
DEUTSCH connector
Pin location
1 2
Pinout
Pin Function
1 PWM signal
2 Ground
Pinout (alternative)
Pin Function
1 Ground
2 PWM signal
Pin compatibility
PLUS+1®module pin type
Pin Function
1,2 DOUT
1,2 DOUT/PVG Power
1, 2 PWMOUT/DOUT/PVG Power supply
1, 2 PWMOUT/DOUT/PVGOUT
1, 2 Power ground
W
Warning
Unintended vehicle or machine movement hazard. Verify the wiring harness to ensure the correct PLUS
+1®pin is properly connected to each control pin.
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
Electrical installation
11025001 • Rev BA • September 2015 7

Input/output matrix
3-position FNR/C1 and C2 location
C1
C2
Single pump output flow direction versus control signal
Shaft rotation CW CCW
Front Rear Front Rear
Coil energized C1 C2 C1 C2 C1 C2 C1 C2
Port A in out — — out in — —
Port B out in — — in out — —
Servo port pressurized M5 M4 M5 M4 M5 M4 M5 M4
Tandem pump output flow direction versus control signal
Shaft rotation CW CCW
Front Rear Front Rear
Coil energized C1 C2 C1 C2 C1 C2 C1 C2
Port A in out — — out in — —
Port B out in — — in out — —
Port C — — in out — — out in
Port D — — out in — — in out
Servo port pressurized M5 M4 M5 M4 M5 M4 M5 M4
Mating connector
DEUTSCH connector parts list
Description Quantity Ordering number
Connector 1 DEUTSCH DT06-2S
Wedge lock 1 DEUTSCH W2S
Socket contact (16 and 18 AWG) 2 DEUTSCH 0462-201-16141
Mating connector kit 1 Danfoss K29657
Electrical Installation H1 Pump 3-Position (FNR) Electric Control
Electrical installation
811025001 • Rev BA • September 2015

Electrical Installation H1 Pump 3-Position (FNR) Electric Control
11025001 • Rev BA • September 2015 9

Electrical Installation H1 Pump 3-Position (FNR) Electric Control
10 11025001 • Rev BA • September 2015

Electrical Installation H1 Pump 3-Position (FNR) Electric Control
11025001 • Rev BA • September 2015 11
