Danfoss NovoCon L User manual

AQ321852892717en-010301 | 1© Danfoss | 2021.09
NovoCon® L/XL
Operating Guide
NovoCon® L / SU / SD
AB-QM DN 125 - 150HF
NovoCon® XL
AB-QM DN 200 - 250HF
NovoCon® L / SU / SD NovoCon® XL
NovoCon® L/XL / 73690670
5-95 % RH
no condensing
MAINTENANCE
FREE
NovoCon® L NovoCon® XL

AQ321852892717en-0103012 | © Danfoss | 2021.09
NovoCon® L/XL
❶
③
2×
①
②
2×
④
12-15 Nm
2×
2×
①
②
2×
③④
12-15 Nm
2×
❷
AUTO
=
=
13 mm 4 mm
AUTO
=
=
3,5 - 4,5 mm
× 0,7mm 4 mm T 10
①
②
③
3-5 Nm
2×
NovoCon® L

© Danfoss | 2021.09 | 3AQ321852892717en-010301
NovoCon® L/XL
NovoCon® L SU
⑤
⑥
3-5 Nm
2×
1×
②
①③
⑦
④
③
⑧
④
⑥
⑨
1×
②
①
⑤
⑦
3-5 Nm
2×
NovoCon® L SD

AQ321852892717en-0103014 | © Danfoss | 2021.09
NovoCon® L/XL
❸
⑨
①
②
AUTO
=
=
HN 10 5 mm
❹NovoCon® XL
NovoCon® XL
⑩
③
④
⑤
⑥
⑦⑧
⑪
⑫
⑬
⑭⑮
40 Nm
1×
HH10
3-5 Nm
2×

© Danfoss | 2021.09 | 5AQ321852892717en-010301
NovoCon® L/XL
❺
❻
MODE:
Normal
Calibration
Flush
De-Air
⑦
⑥
M16, M20 / MP16 1/2’’
M16
M20
M16
1/2’’
①
⑤
AUTO
=
=
3,5–4,5 mm ×
0,7 mm T 10
GND is common for all signals
②
③
④
0,7-1,1 Nm
2×

AQ321852892717en-0103016 | © Danfoss | 2021.09
NovoCon® L/XL
E100 VXX
281624
0030471
E100 VXX
281624
0030471
MADE IN SLOVENIA
NovoCon
L
003Z8560
Actuator for AB-QM DN125-150
Control signal: BACnet MS/TP, Modbus RTU, 0-10V, 0-20mA
®
6430 Nordborg, Denmark
Power: 24VAC/DC, 50/60 Hz, Operating 9.6 VA
Force: 2000N. Stroke: 50 mm. Speed: 3-24s/m. IP54/40, 10T55
III
01
E100 VXX
281624
0030471
01
01
Serial number and QR code can be removed from the
NovoCon® L/XL label and added to installation drawing.
Device Object
Instance Number
❼
DIP Switch
Dip switches for addressing and bus protocol selection are located under the lid of the actuator.
DIP Switches 1 to 7 are used to assign the MAC address manually. Default MAC address assignment
method is Auto MAC addressing for BACnet MS/TP and DIP Switches for Modbus RTU.
For termination of last unit on the field bus, turn DIP Switch 8 ON.
Dip switch 9 is not used.
Dip switch 10 is used to select between BACnet MS/TP (OFF=Default) and Modbus RTU (ON).
When the protocol is changed on DIP Switch 10, a power cycle is required.
❽
NovoCon® L
Application mode:
MSV:9 / 32810
Digital control (default),
Analog control
Select Valve Type
MSV:3 / 32802
(default AB-QM DN125)
Design Flow Rate
AV:30 / 32796 Heating
AV:31 / 32798 Cooling

Select application
MSV:10 / 32811
Heating (default)
Cooling

❾Initial configuration
NovoCon® XL
Application mode:
MSV:9 / 32810
Digital control (default),
Analog control
Select Valve Type
MSV:3 / 32802
(default AB-QM DN200)
Design Flow Rate
AV:30 / 32796 Heating
AV:31 / 32798 Cooling

Select application
MSV:10 / 32811
Heating (default)
Cooling

12345678910
ON
OFF
Activate calibration
MSV:0 / 33284 state 2
or use manual calibration
Activate calibration
MSV:0 / 33284 state 2
or use manual calibration


© Danfoss | 2021.09 | 7AQ321852892717en-010301
NovoCon® L/XL
To avoid injury and damage to persons and devices, it is
absolutely necessary these instructions are carefully read
and observed prior to assembly and commissioning.
Necessaryassembly, start-up,andmaintenanceworkmust
be performed only by qualified, trained and authorised personnel.
Switch off the pump and the power line before mounting and wiring
the actuator.
Connect via safety isolating transformer.
Galvanic separations shall be provided for segments crossing
buildings.
Safety Note
Safety Note
❿
If the NovoCon® L/XL network is supplied with two or more AC
power boosters, caution must be observed when disconnecting
one of the transformers from the high voltage power line. As
the NovoCons may be connected in a daisy chain, there may be
high voltage on the primary side of the disconnected power supply.
Disconnect always both the primary and secondary side of the
transformer.
Safety Note
Firmware update
We recommend to validate the firmware version before installation.
The latest firmware can be downloaded at www.novocon.com by
selecting the tab: Support files.

73690670 / AQ321852892717en-0103018 | © Danfoss | DCS-S/SI | 2021.09
NovoCon® L/XL
ІМПОРТЕР:
UA: ТОВ з ІІ «Данфосс ТОВ», вул. Вікентія Хвойки, 15/15/6, м. Київ, 04080, Україна
Part Name Hazardous Substances Table
Lead (Pb) Mercury (Hg) Cadmium (Cd) Hexavalent Chromium (Cr(VI)) Polybrominated biphenyls (PBB) Polybrominated diphenyl ethers (PBDE)
Motor X O O O O O
O: Indicates that this hazardous substance contained in all of the homogeneous material for this part is below the limit requirement in GB/T 26572;
X: Indicates that this hazardous substance contained in at least one of the homogeneous material for this part is above the limit requirement in GB/T 26572;
