DANGO CR-01 User manual

OPERATION MANUAL

PUSH-BUTTON A
START / STOP TIMER
RUNNING
SECONDS
ELAPSED SECONDS
SUB-DIAL
CR-01
ELAPSED
MINUTES
SUB-DIAL
CHRONOGRAPH
HAND
PUSH-BUTTON B
RESET TIMER
123
CROWN
POSITIONS
POSITION 3B: SETTING CHRONOGRAPH HANDS
& SUB-DIALS
- PULL CROWN OUT TO POSITION 3
- KEEP PUSH BUTTONS A & B DEPRESSED
SIMULTANEOUSLY FOR AT LEAST 2 SECONDS UNTIL
CHRONOGRAPH HAND MAKES A FULL ROTATION.
THIS PUTS YOU IN SETTING MODE.
- BY PRESSING PUSH BUTTON A, YOU CAN NOW
SET YOUR CHRONOGRAPH HAND POSITION.
- BY PRESSING PUSH BUTTON B YOU CAN CHOOSE
BETWEEN SUB-DIALS AND BACK TO CHRONOGRAPH HAND.
- BY PRESSING AND HOLDING DOWN PUSH-BUTTON A,
YOU CAN RAPIDLY ROTATE THE SUB-DIAL HANDS.
- PUSH THE CROWN BACK INTO POSITION 1 TO
CONTINUE RUNNING TIME.

CR-01
POSITION 1: WATCH IS RUNNING
PUSHED ALL THE WAY IN, WATCH IS RUNNING, DATE IS
ACTIVE. ROTATING THE CROWN IN THIS POSITION
YIELDS NO RESULTS.
POSITION 2: SETTING THE DATE
- PULL THE CROWN OUT TO POSITION 2.
(WATCH IS STILL RUNNING)
- ROTATE THE CROWN COUNTER CLOCKWISE UNTIL
THE REQUIRED DATE APPEARS.
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE REQUIRED DATE.
POSITION 3A: SETTING THE TIME
- PULL THE CROWN OUT TO POSITION 3.
(WATCH IS STOPPED)
- ROTATE THE CROWN FORWARD & BACKWARD
UNTIL THE DESIRED TIME IS DISPLAYED
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE DESIRED TIME.
STOP WATCH
- PRESS PUSH-BUTTON A ONCE TO START YOUR TIMER.
PRESS PUSH-BUTTON A AGAIN TO STOP.
- PRESS PUSH-BUTTON B TO RESET THE STOP WATCH
POSITION 3B: SETTING CHRONOGRAPH HANDS
& SUB-DIALS
- PULL CROWN OUT TO POSITION 3
- KEEP PUSH BUTTONS A & B DEPRESSED
SIMULTANEOUSLY FOR AT LEAST 2 SECONDS UNTIL
CHRONOGRAPH HAND MAKES A FULL ROTATION.
THIS PUTS YOU IN SETTING MODE.
- BY PRESSING PUSH BUTTON A, YOU CAN NOW
SET YOUR CHRONOGRAPH HAND POSITION.
- BY PRESSING PUSH BUTTON B YOU CAN CHOOSE
BETWEEN SUB-DIALS AND BACK TO CHRONOGRAPH HAND.
- BY PRESSING AND HOLDING DOWN PUSH-BUTTON A,
YOU CAN RAPIDLY ROTATE THE SUB-DIAL HANDS.
- PUSH THE CROWN BACK INTO POSITION 1 TO
CONTINUE RUNNING TIME.

ROTATING BEZEL
ROTATE COUNTER-
CLOCKWISE ONLY
DV-01
TK-01
CROWN
POSITIONS
CROWN
POSITIONS
1 2 3
1 2 3
CR-01
POSITION 1: WATCH IS RUNNING
PUSHED ALL THE WAY IN, WATCH IS RUNNING, DATE IS
ACTIVE. ROTATING THE CROWN IN THIS POSITION
YIELDS NO RESULTS.
POSITION 2: SETTING THE DATE
- PULL THE CROWN OUT TO POSITION 2.
(WATCH IS STILL RUNNING)
- ROTATE THE CROWN COUNTER CLOCKWISE UNTIL
THE REQUIRED DATE APPEARS.
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE REQUIRED DATE.
POSITION 3A: SETTING THE TIME
- PULL THE CROWN OUT TO POSITION 3.
(WATCH IS STOPPED)
- ROTATE THE CROWN FORWARD & BACKWARD
UNTIL THE DESIRED TIME IS DISPLAYED
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE DESIRED TIME.
STOP WATCH
- PRESS PUSH-BUTTON A ONCE TO START YOUR TIMER.
PRESS PUSH-BUTTON A AGAIN TO STOP.
- PRESS PUSH-BUTTON B TO RESET THE STOP WATCH

DV-01 & TK-01
POSITION 1: WATCH IS RUNNING
PUSHED ALL THE WAY IN, WATCH IS RUNNING, DATE IS
ACTIVE. ROTATING THE CROWN IN THIS POSITION
YIELDS NO RESULTS.
POSITION 2: SETTING THE DATE
- PULL THE CROWN OUT TO POSITION 2.
(WATCH IS STILL RUNNING)
- ROTATE THE CROWN COUNTER CLOCKWISE UNTIL
THE REQUIRED DATE APPEARS.
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE REQUIRED DATE.
POSITION 3: SETTING THE TIME
- PULL THE CROWN OUT TO POSITION 3.
(WATCH IS STOPPED)
- ROTATE THE CROWN FORWARD & BACKWARD
UNTIL THE DESIRED TIME IS DISPLAYED
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE DESIRED TIME.
SCREW DOWN CROWN (DV-01 ONLY)
THE CROWN WILL HAVE TO BE TURNED
COUNTERCLOCKWISE UNTIL IT RELEASES FROM THE
CASE TO ADJUST THE TIME/DATE.
THE CROWN MUST BE SCREWED DOWN COMPLETELY
TO ACHIEVE WATER RESISTANCE.

LOCK UNLOCK
QUICK RELEASE STRAPS
INTERCHANGEABLE LUGS
WITH A FLAT-HEAD, TURN SCREW-HEAD FROM
HORIZONTAL POSITION TO VERTICAL POSITION TO UNLOCK
NOTE: DO NOT OVER TURN THE SCREW-HEAD
MORE THAN A QUARTER ROTATION
WITH THE HANDLE SQUEEZED IN,
PLACE THE STRAP INTO POSITION.
RELEASE THE HANDLES TO SECURE
NOTE: TUG AT THE STRAPS TO MAKE
SURE THE PINS ARE ENGAGED.

MICRO ADJUSTMENT BUCKLE
BUCKLE RELEASE BUTTON
MICRO ADJUSTMENT BUTTONS
SLIDE MICRO-ADJUSTMENT BUTTONS
IN TO TIGHTEN AND OUT TO LOOSEN

ATM 5
50 100 200
10 20
METERS

WARRANTY
DANGO PRODUCTS OFFERS A LIMITED WARRANTY FOR
DEFECTS IN MATERIALS AND WORKMANSHIP FOR A
PERIOD OF 1 YEAR AFTER ORIGINAL PURCHASE FROM
DANGO OR ANY AUTHORIZED DANGO DEALER. DANGO
WILL EITHER REPAIR OR REPLACE THE WATCH, AT OUR
DISCRETION IF THE WATCH IS DEEMED DEFECTIVE. THE
WARRANTY DOESN’T COVER ABUSE, MISUSE OR NORMAL
WEAR AND TEAR. DAMAGE CAUSED BY NOT SECURELY
FASTENING THE STRAP AND/OR LOCKING MECHANISM IS
NOT COVERED. DAMAGE CAUSED BY NOT PROPERLY
SEALING THE CASE BACK AND/OR CROWN IS NOT
COVERED. PROOF OF PURCHASE IS REQUIRED FOR ALL
WARRANTY CLAIMS AND SERVICE REQUESTS. DANGO
HAS THE OPTION TO DENY A WARRANTY CLAIM OR
REPAIR REQUEST IF A WATCH SHOWS EVIDENCE OF
EXCESSIVE WEAR AND/OR MISUSE.

CONTACT
WEBSITE: www.dangoproducts.com
EMAIL: [email protected]
SOCIAL MEDIA
www.facebook.com/dangoproducts
@dango_products
@dango_products

DV-01 & TK-01
POSITION 1: WATCH IS RUNNING
PUSHED ALL THE WAY IN, WATCH IS RUNNING, DATE IS
ACTIVE. ROTATING THE CROWN IN THIS POSITION
YIELDS NO RESULTS.
POSITION 2: SETTING THE DATE
- PULL THE CROWN OUT TO POSITION 2.
(WATCH IS STILL RUNNING)
- ROTATE THE CROWN COUNTER CLOCKWISE UNTIL
THE REQUIRED DATE APPEARS.
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE REQUIRED DATE.
POSITION 3: SETTING THE TIME
- PULL THE CROWN OUT TO POSITION 3.
(WATCH IS STOPPED)
- ROTATE THE CROWN FORWARD & BACKWARD
UNTIL THE DESIRED TIME IS DISPLAYED
- PUSH THE CROWN BACK INTO POSITION 1 TO SET
THE DESIRED TIME.
SCREW DOWN CROWN (DV-01 ONLY)
THE CROWN WILL HAVE TO BE TURNED
COUNTERCLOCKWISE UNTIL IT RELEASES FROM THE
CASE TO ADJUST THE TIME/DATE.
THE CROWN MUST BE SCREWED DOWN COMPLETELY
TO ACHIEVE WATER RESISTANCE.
