Dangrill 5709386873530 User manual

Fire Ring & Rotisserie Kit
Installation Manual
Read and follow all the instructions for assembly and pay attention to the warnings when
using ，and save it for future reference.
Warning:
·Connect the motor to properly grounded power outlets only to ensure continued
protection against risk of electric shock..
·Do not expose the motor to rain and use it in the dry area.
·Always use a heat-resistant oven glove or long handled barbecue tools when using and
cooking.
·Do not attempt to move the barbecue when the product is on the grill and hot.
·Keep small children and pets clear of the cooking area.
·Let the product cool down completely before cleaning.
·Always take great care!
ATTN: this product is designed to be used on 57cm kettle grills only. Please measure the
outside max diameter of the rounded bottom of your 57cm kettle grills to make sure when
purchase, it shall be no less than 57cm.

Parts List:
①. 1 x Fire ring
②. 3 x Fire ring support chip
③. 3 x M6* 12 Bolt
④. 3 x M6 Flat washer
⑤. 3 x M6 Spring Washer
⑥. 3xM6 Nut
⑦. 1 x Motor support
⑧. 2 x M5* 20 Bolt
⑨. 2xM5 Nut
⑩. 2 x M5 Flat washer
⑾. 1 x Left spit rod
⑿. 1 x Right spit rod
⒀ ．2 x Meat fork
⒁ .1 x Roller
⒂ .1 x Electric Motor
Technical Specification:
Rotisserie Motor with water-proof switch:
Europe: CE certification AC Electric motor. North America: CSA certification AC Electric motor.
Europe: 220-240V ~ 50/60Hz，4W; North Amercia: 110-120V ~ 50/60Hz，4W;
Torque: 20KGF.cm; RPM: 2-2.3RPM;
Cable length: 800mm;
Reverse rotation when meet resistance ;
Fire Ring:
1. Dia 57cm, Height:15cm
2. Material: High-temperature heat resistance black coated steel

Assembly Steps:
6 5 4 9 10
2 3
7 8
11
12
13
14
15

。
Environmental recommendation
An electrical/electronic product should be disposed of in a manner that minimises environmental impact as much as possible. The
device should be disposed of according to local guidelines. The device can usually be disposed of at the local recycling station.
Environmental consideration and battery disposal
It is important to consider the environment in terms of battery disposal.
Never dispose used batteries with household waste..Used batteries must be handed in at one of the special indicated
a uthorised collection points in your municipality. Remove batteries before disposing the device. Further，make surethat the
batteries are not too old or used ， since they may start to leak acid. Check the expiry date on the batteries.
Device disposal
The law requires that electric and electronic devices are collected，and that ↑the devices are partially recycled. Electric and electronic
devices， marked with the waste management symbol， must be handed in at a municipal recycling centre.
Complaints
You have the right to complain according to applicable law. In case of complaints，please enclose a machine marked receipt/purchase.
receipt with purchase date.
Further ， please hand in the device at the retailer in question.
The RoHS Directive
On July 1, 2006, the RoHS Directive(www.thiim.com/pdf/rohs.pdf) (2002/95/EC) came into effect. The aim of this
Directive is to limit the use of hazardous substances in electrical and electronic equipment and to contribute to human health
protection as well as environmentally sound utilization and disposal of electrical and electronic waste.
The guarantee is invalid
· If the above is not observed.
· It the device has been abused， exposed to force or other type of damage.
· Agk Nordic A/ S is not liable for loses or damages of any kind ， neither indirectly nor directly ， as a consequence of wrong use or
unauthorized operation of the unit.
