Data Video DAC-200 User manual

DigitalVideoConverter
D
D
DA
A
AC
C
C

2
2
20
0
00
0
0
InstallationGuide
http://www.datavideotek.com
Rev:140206

1
TableofContents
WarningsandPrecautions 2
Warranty 4
Disposal 4
FCC&CECertification(Radio&TelevisionInterference) 5
What'sintheBox 7
KeyFeatures 7
UserInterfaceFunctions
Frontpanelcontrol/connection 8
Rearpanelcontrol/connection 9
DIPswitchsettings 11
Installation/Connections 12
ConnectingananalogueVCRorCamcordertoaPC/MACNLESystem
ConnectingaPC/MACNLESystemtoananalogueVCR 13
OperationProcedure 10
Specification 12
Service&Support 13

2
WarningsandPrecautions
1. Readallofthesewarningsandsavethemforlaterreference.
2. Followallwarningsandinstructionsmarkedonthisunit.
3. Unplugthisunitfromthewalloutletbeforecleaning.Donotuseliquidor
aerosolcleaners.Useadampclothforcleaning.
4. Donotusethisunitinornearwater.
5. Donotplacethisunitonanunstablecart,stand,ortable.Theunitmayfall,
causingseriousdamage.
6. Slotsandopeningsonthecabinettop,back,andbottomareprovidedfor
ventilation.Toensuresafeandreliableoperationofthisunit,andtoprotectit
fromoverheating,donotblockorcovertheseopenings.Donotplacethisunit
onabed,sofa,rug,orsimilarsurface,astheventilationopeningsonthe
bottomofthecabinetwillbeblocked.Thisunitshouldneverbeplacednear
oroveraheatregisterorradiator.Thisunitshouldnotbeplacedinabuiltin
installationunlessproperventilationisprovided.
7. Thisproductshouldonlybeoperatedfromthetypeofpowersourceindicated
onthemarkinglabeloftheACadapter.Ifyouarenotsureofthetypeof
poweravailable,consultyourDatavideodealeroryourlocalpowercompany.
8. Donotallowanythingtorestonthepowercord.Donotlocatethisunitwhere
thepowercordwillbewalkedon,rolledover,orotherwisestressed.
9. Ifanextensioncordmustbeusedwiththisunit,makesurethatthetotalofthe
ampereratingsontheproductspluggedintotheextensioncorddonot
exceedtheextensioncord’srating.
10.Makesurethatthetotalamperesofalltheunitsthatarepluggedintoasingle
walloutletdonotexceed15amperes.
11.Neverpushobjectsofanykindintothisunitthroughthecabinetventilation
slots,astheymaytouchdangerousvoltagepointsorshortoutpartsthat
couldresultinriskoffireorelectricshock.Neverspillliquidofanykindonto
orintothisunit.

3
12.Exceptasspecificallyexplainedelsewhereinthismanual,donotattemptto
servicethisproductyourself.Openingorremovingcoversthataremarked
“DoNotRemove”mayexposeyoutodangerousvoltagepointsorotherrisks,
andwillvoidyourwarranty.Referallserviceissuestoqualifiedservice
personnel.
13.Unplugthisproductfromthewalloutletandrefertoqualifiedservice
personnelunderthefollowingconditions:
a. Whenthepowercordisdamagedorfrayed;
b. Whenliquidhasspilledintotheunit;
c. Whentheproducthasbeenexposedtorainorwater;
d. Whentheproduct doesnotoperatenormallyundernormaloperating
conditions.Adjustonlythosecontrolsthatarecoveredbythe
operatinginstructionsinthismanual;improperadjustmentofother
controlsmayresultindamagetotheunitandmayoftenrequire
extensiveworkbyaqualifiedtechniciantorestoretheunittonormal
operation;
e. Whentheproducthasbeendroppedorthecabinethasbeen
damaged;
f. Whentheproductexhibitsadistinctchangeinperformance,
indicatinganeedforservice.

4
Warranty
Datavideowarrantsthattheequipmentitmanufacturesshallbefreefromdefects
inmaterialandworkmanshipforaperiodof12monthsfromthedateofproduct
purchased.Ifequipmentfailsduetosuchdefects,Datavideowill,atitsoption,
repairorprovideareplacement forthedefectivepartorproduct.
Equipmentthatfailsafterthewarrantyperiod,hasbeenoperatedorinstalledina
mannerotherthanthatspecifiedbyDatavideo,orhasbeensubjectedtoabuseor
modification,willberepairedfortimeandmaterialchargesattheBuyer’s
expense.ThiswarrantydoesnotaffectyourstatutoryrightswithintheCountryof
purchase.
Disposal
ForEUCustomersonlyWEEEMarking.
Thissymbolontheproductindicatesthatitwillnotbetreatedashousehold
waste.Itmustbehandedovertotheapplicabletakebackschemeforthe
recyclingofelectricalandelectronicequipment.Formoredetailedinformation
abouttherecyclingofthisproduct,pleasecontactyourlocalDatavideooffice.

5
RADIO&TELEVISIONINTERFERENCE
UNITEDSTATES. Theequipmentdescribedinthisguidegeneratesanduses
radiofrequencyenergy.Ifitisnotinstalledandusedinaccordancewiththe
instructionsinthisguide,itmaycauseinterferencewithradioandtelevision
reception.
This equipment has been tested andfound to complywith the limits for a
ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsare
designedtoprovidereasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesandcanradiateradio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation. If this equipment does cause harmful interference to radio or
televisionreception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterferencebyoneor
moreofthefollowingmeasures:
lReorientorrelocatethereceivingantenna.
lIncreasetheseparationbetweentheequipmentandreceiver.
lConnecttheequipmentintoanoutletonacircuitdifferencefromthattowhich
thereceiverisconnected.
lConsultthedealeroranexperiencedradio/TVtechnicianforhelp.
If necessary, you should consult your dealer or experienced radio/television
technicianfor additional suggestions.You mayfind helpful thefollowing booklet,
prepared by the Federal Communications Commission: How to Identify and
ResolveRadioTVInterferenceProblems.ThisbookletisavailablefromtheUnited
StatesGovernmentprintingoffice,Washington,D.C.20402.Thebookletnumberis
004000003454.

6
Note:ChangesorModificationsnotexpresslyapprovedbytheparty
responsibleforcompliancecouldvoidtheusersrighttooperatethis
equipment.
Peripheralusedinconjunctionwiththisequipmentmustbeconnectedviashielded
interfacecables.Useofunshieldedinterfacecablesmayresultininterferenceto
radioandTVreception,andmayvoidtheuser’srighttooperatethisequipment.
DeclarationofConformity
ModelNumber:DAC200
TradeName:Datavideo
Responsible:DatavideoCorporation(USA)
Address:12300UEastWashingtonBlvd.,Whittier,
CA90606USA
Telephone:(562)6962324
ThisdevicecomplieswithPart15oftheFCCRules.Operationis
subjecttothefollowingtwoconditions:
(1) Thisdevicemaynotcauseharmfulinterference.
(2) Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.

7
What’sintheBox
Thefollowingisapackinglist.Ifanyitemsaremissingpleasecontactyour
supplyingdealerassoonaspossible.
1xDAC200
1xACAdapter(5V2.0A)
1xSVideo(Y/C)Cable–4PinMiniDinPlugto4PinMiniDinPlug
1x3PhonoPlug(RCA)to3PhonoPlugCable
1xIEEE1394(DV)Cable6PinPlugto6PinPlug
1xQuickStartGuide
1xInstructionManual
KeyFeatures
BiDirectionalDVtoAnalogVideoConverterDVtoAnalog/AnalogtoDV
TheDAC200isasimplestandaloneboxforconvertingvideoandaudioback
andforthbetweenanaloganddigital(DV).
UsingtheDAC200toconvertanalogtoDVlet’syoumaintainthequalityofyour
analogtapewithoutgenerationloss.
lSupportsDV,SVideo Y/C,Compositeinputsandoutputsforeasy
conversionacrossplatforms
lVideoCombFilterforHighQualityVideo
lSelectabledigitalaudiosamplingrateat12bit32KHzor16bit48KHz
lSelectableAudioDecodingat32KHz,44.1KHzand48KHz
lSelectable0IRE/7.5IREblacklevelsetting
lCompatiblewithDV(iLink),Digital8,Video8,Hi8,VHS,SVHS,VHSCand
SVHSCformats
lEncodetoordecodefromtheMacenvironment
lFireWireInandout
lWorkswithPCWindows98SE/ME/2000andXP
lSmartDV(Pat.Pending)allowsvideomonitoringduringDVtoDVCapture

8
FRONTPANELCONTROL/CONNECTION
Description:
1. 6PinFireWireinterfaceforDVIn/Out
2. VideosourceindicatorsforDVorAVinput
3. LEDindicatorsforAudioencoder12Bitor16Bit
4. SVideo(Y/C)inputconnector.
5. CompositeVideoinputRCAconnector
6. StereoAudioinputRCAconnectors
7. Pushbuttontoselect12Bitor16BitAudioencoding
8. PushbuttontoselectvideoinputsourceDVorAV
Note:Pleasewait5secondsfortheLEDreadystatustocomeonafteryoupush
thevideosourcebutton.Thesystemneedsafewsecondstorecognizea
newvideosourcesetting.
12345 6
7
8

9
REARPANELCONTROL/CONNECTION
Description:
1.StereoAudiooutputPhono(RCA)connectors
2.CompositeVideooutputPhono(RCA)connector
3.SVideo(Y/C)outputconnector
4.ModeDIPswitch(ReboottheDAC200ifyouchangeaDIPSwitch)
(Seepage11formoredetails)
lS1.PALorNTSC(PALON,NTSCOFF)
lS2.7.5IRE/0IRE(0IREON,7.5IREOFF) (NTSCOnly).
Pleasenote:0IREismostoftenusedinJapan.7.5IREisusedelsewhere.
lS3Locked/UnlockedAudio.On–UnlockedAudio/Off–LockedAudio
lS4&S5forNTSCandPALvideosystem
lS6.Reserved,shouldalwaysbe OFF.
5.6PinFireWireinterfaceforDVIn/Out
6.DCInputJack(+5VDC/6Watts)
7.PowerSwitch(Note:TurnonDAC200beforebootingthePC/MACeditingsoftware.)
S5 ON S4ON MACOS
S5 ON S4OFF SmartDV–(Pleaseseedescriptiononpage11)
S5 OFFS4ON WindowsME/XP
S5 OFFS4OFF DVCamera
1234567

10
IMPORTANTNOTICEFORPC/MACEDITINGSYSTEMS
Thefollowingguidelinesaregeneraladviceforvideoeditingonacomputer
platform.Ifyouhavepurchasedacomputerspecifiedforvideoeditingitwill
almostcertainlybesetupcorrectly.Ifyouareinanydoubtpleaseconsultyour
computerreseller,oracomputertechnician.
1.ShutdownallresidentprogramsinyourPCforbettereditingperformance.
SuchastheAntiVirusprogram,screensaver,systempowermanagement
software…etc.
2.Enable the Disk DMA function in windows to improve system HDD
accessperformance
Therearetoomanynonlineareditingplatformstogiveindepthadviseabout
individualsetups.TheDAC200shouldbeseenbyyourPC/MACasthoughitis
aDVCamera/Recorder.Iftherearedevicecontrolsettingsonyourediting
platformpleasesetthemtooff.
Extradetailsofsomenonlinearplatformsareavailableonline,pleasegoto
http://www.datavideo.info/products/dac200.htmforthelatestdetails.
Wewilltrytotestandupdatesysteminformationasitbecomesavailable,
howeverforindepthinformationaboutyourspecificNLEplatformwewould
recommendthatyoucontactyoursupplier,orthemanufacturer.

11
DipSwitchsettingstoworkwithWindows&MACOperationsystem
TheDAC200 usesdipswitches 4and5 tocontroltheclockingfrequencywhenit
isconvertingvideo,ifthedipswitchesarenotconfiguredforyouroperating
systemortypeofdevice,alossinvideocanoccur.Pleaserefertodipswitch
chartbelowandmakesurethatyourDAC200issetupcorrectly.
SMARTDV isapatentpendingfeaturethatallowsmonitoringofthevideoduring
aDVtoDVcapture.
EnablingSMARTDVmakestheconvertertransparenttoanNLEsystem,while
stilltranscodingtheliveDVstreamintoanaloguevideo.Thisenablesusersto
monitoralivedigitalvideofeedfromaDVcamcorderorDVdeckduringcapture,
withoutanyconflict.Itmeansahugesavingoftimeforallvideoeditorsworking
withDVtape.
NTSCSystem(USA)
MACOS
NTSCSystem(USA)
SmartDVon
NTSCSystem(USA)
WindowsXPandWindowsME
NTSCSystem(USA)
Camera
PALSystem(EU)
MACOS
PALSystem(EU)
SmartDVon
PALSystem(EU)
WindowsXPandWindowsME
PALSystem(EU)
Camera

12
Installation/Connections
TherearemanypossiblewaystoconnectaDAC200todifferentsystems.
Illustratedbelowarethetwomostcommonsetups,DVoutputfromanNLE
systemtoananaloguerecorder,andAnalogueoutputtoaPC/MACNLE
system.
IfyouranaloguedevicehasSVideoconnectionsavailableitisadvisabletouse
themasthesignalqualitywillbesuperiortocomposite(RCA/Phono)
connections.IfyouareusingSVideo(Y/C)connectionsdomakesureyoualso
connecttheRedandWhite(RCA/Phono)connectorsforaudio.
ManyanalogueVCRshaveSCARTconnectors,itisnoproblemtousethesewith
aDAC200howeveryouwillneedtouseaSCARTto3Phono/RCAAdaptor,
availablefromhighstreetelectricalstores.Theseadaptorsareavailableinthree
types,INonly,OUTonlyandswitchable(INandOUT),aswitchableadaptor
wouldallowthemostflexibility.
ConnectingananalogueVCRorCamcordertoaPC/MACNLE
System
ConnecttheanalogueoutputfromtheVCRorCamcordertotheinputsonthe
frontoftheDAC200.IfSVideo(Y/C)isavailableitisbesttouseit.
ConnecttheDVOutfromtheDAC200totheIEEE1394/DVInonyourNLE
system.PressthesourcebuttonontheDAC200toensuretheAVlightison.
MakesureyourDIPswitchsettingsarecorrectforyoursetup(seepage11)

13
ConnectingaPC/MACNLESystemtoananalogueVCR
ConnecttheIEEE1394/DVOutfromyourNLEsystemtotheDVIn/Outonthe
DAC200.SomeNLEsystemshave6PinDVout,liketheDAC200,whileothers
usethesmaller4Pinconnection,eithertypeofconnectionwillworkOK.
ConnecttheanalogueAudioandvideooutputsontherearoftheDAC200tothe
inputsonyourrecorddeck.IfyourrecorddeckhasSVideo(Y/C)availableitis
advisabletouseitinpreferencetotheComposite(YellowPhono/RCA
connector).
N.B.Pleaseensurethatyousettheinputofyourrecorddecktotheappropriate
setting.SomeofthenamesusedbyVCRmanufacturersareAUX(Auxillary),
Line1,AV1,F1,EXT(External).
CheckthattheDAC200hastheDVlighton,ifitdoesnotpressthesource
button.
MakesureyourDIPswitchsettingsarecorrectforyoursetup(seepage11)

14
Specifications:
INPUTS
SVHSsources Y/Cin:4—pin75ohmDINconnector
Composite 1.0Vpp75ohmRCAconnector
*DV(iLink)Source DataTransferRate25Mbps,PAL4:2:0/NTSC4:1:1
OUTPUTS
SVHSSource Y/Cout4pin75ohmDINconnector
CompositeVideoSource 1.0Vpp75ohmRCAconnector
FrequencyResponse 4.5MHz+/3dB(DVinput) 20Hz~18KHz<3dB
DG,DP +/3%,3°
AudioSamplingRate 12bit32KHzand16bit48KHzoption
AudioFreq.Response 20Hz~18KHz<3dB
AudioTHD <0.2%
*DV(iLink)Source DataTransferRate25Mbps,PAL4:2:0/NTSC4:1:1
GENERAL
Power(Included) DC5V/6.0WACAdapter
Caution:DAC200requiresDC5Volt+/4%,Useonly
DatavideoapprovedPowerAdaptor.
AmbientTemperature 32°131°F(0°55°C)
AmbientHumidity Lessthan90%
Dimensions 6.15”(W)×6.0”(D)×1.6”(H)
156(W)×150(D)×40(H)m/m
Accessories(included) 1.8mIEEE1394cable(6Pinto6Pin)
3Phonoto3Phono(RCA)cable.
SVideo(Y/C)cable
User’smanual
QuickStartGuide
Powersupply
*.Allthetrademarksarethepropertiesoftheirrespectiveowners

15
ServiceandSupport
Itisourgoaltomakeyourproductsownershipasatisfyingexperience.Our
supportteamisavailabletoassistyouinsettingupandoperatingyoursystem.
Pleaserefertoourwebsitewww.datavideotek.comforanswerstocommon
questions,supportrequestsorcontactyourlocalofficebelow.
DatavideoCorporation(USA)
12300UEastWashingtonBlvd.,Whittier,CA90606USA
Tel:+15626962324 [e-mail] www.datavideo.us
DatavideoTechnologiesEuropeBV
Californiedreef263565BLUtrecht,TheNetherlands
Tel:+31302619656 [e-mail] www.datavideo.info
DatavideoUKLimited
Unit2WatersideBusinessPark,Hadfield,Glossop,DerbyshireSK131BEUK
Tel:+441457851000 [e-mail] www.datavideo.info
DatavideoTechnologiesCo.,Ltd.
10F,176JianYiRd,ChungHoCity,TaipeiHsien,Taiwan235
Tel:+886282272888 [e-mail] www.datavideo.com.tw
DatavideoTechnologiesChinaCo.
2FD,2Lane777,WestGuangzhongRd,ZhabeiDistrict,Shanghai,China
Tel:+862156036599 [e-mail] www.datavideo.cn
DatavideoTechnologies(S)PTELtd.
No.100,Lorong23Geylong,#0103D’CentennialBldg,Singapore388398
Tel:+6567496866 [e-mail] www.datavideo.info
DatavideoHongKongLimited
G/F.,26CROSSLANE,WANCHAI,HK
Tel:+85228331981 [e-mail] www.datavideohk.com
