Daxys Fox User manual

USER MANUAL v1.0

FOX

Electric XC Bike

FOX USER MANUAL

Please read this manual very carefully before using the product. The

manual contains important instructions for the safe use and longevity

of your bike.

DAXYS FOX - USER MANUAL

CONTENTS

Riding Introduction .......................................................................................................................................... 2

Safety Information ........................................................................................................................................... 2

Statement of Responsibility............................................................................................................................. 3

Product Disclaimer.......................................................................................................................................... 3

Before You Ride............................................................................................................................................... 4

Battery Disposal.............................................................................................................................................. 5

Meet Your Bike ................................................................................................................................................ 6

Display Guide.................................................................................................................................................. 7

Handlebar Guide ............................................................................................................................................. 8

Product Specifications .................................................................................................................................... 9

Assembly Instructions ....................................................................................................................................11

Charging The Battery .................................................................................................................................... 16

Battery and Charger Information.....................................................................................................................17

Operating Your Bike....................................................................................................................................... 18

Guide to Electric Pedal Assistance Modes..................................................................................................... 20

Your eBike Keys............................................................................................................................................. 20

Maintenance

Tyres.......................................................................................................................................................... 21

Cleaning Your e bike ................................................................................................................................... 21

Troubleshooting ............................................................................................................................................ 22

F.A.Q’s .......................................................................................................................................................... 23

Warranty........................................................................................................................................................ 24

Technical Support Contact information .......................................................................................................... 25

RIDING INTRODUCTION

Do not use the product before carefully reading the instructions and understanding the performance of the product;

Before cycling, check whether the brakes work. When braking, please brake rear first and then front. Pay attention to

the brake tightness. If the brake is too loose, use an Allen wrench to tighten it. Pay attention to increase the braking

distance when riding in rain and snow. Applicable age: 16 ~ 65 years old. Please wear safety helmets and obey the

traffic rules when cycling. It is not allowed to drive in motor lanes and roads with more pedestrians. Please check

the tyre pressure before cycling. The recommended tyre pressure is 30-80(max) PSI. When using the motor, pay

attention not to hit it vigorously and keep the rotating shaft lubricated. The maximum load is 125kg.

SAFETY INFORMATION:

ALWAYS WEAR A HELMET AND SAFETY

EQUIPMENT

Helmets significantly reduce the number and severity of

head injuries. Always wear a helmet that complies with

your state laws when riding your eBike. Make yourself

more visible by wearing bright reflective clothing. Keep

your reflectors clean and properly aligned. Use head

and tail lights in reduced lighting conditions. Wear sturdy

shoes and eye protection. Also check your state laws

concerning other protective gear that may be required

when riding your eBike.

KNOW YOUR EBIKE

Your new eBike incorporates many features and

functions that you may be unfamiliar with. Read this

manual thoroughly to understand how those features

enhance your riding pleasure and safety.

RIDE WITHIN YOUR LIMITS

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety. Not

to be used by children without adult supervision.

Take it slow until you are familiar with the riding conditions, as traction can

be greatly reduced and brakes become less effective. Never ride faster than

conditions warrant or beyond your riding abilities. Remember that fatigue, and

inattention can significantly reduce your ability to make good judgments and

ride safely.

KEEP YOUR EBIKE IN SAFE CONDITIONS

For your safety and enjoyment, and to ensure a long life for your eBike,

inspect and maintain your eBike regularly.

Follow the inspection and maintenance guidelines throughout this manual.

Check critical safety equipment before each and every ride.

DAXYS FOX - USER MANUAL

STATEMENT OF RESPONSIBILITY:

After riding, please store in a place without direct sunlight and away from rain; Check the motor and brakes

frequently; Regularly check the screws of the eBike and the places to be tightened, and tighten them regularly.

The front and rear wheels of the vehicle shall be located at the center of the front fork or frame; Frequently

check whether there are scars, cracks or excessive wear in the rotation. The inner tube and air nozzle should be

perpendicular to the wheel hub and should not be tilted. Damage or excessive worn outer tyres needs to be replaced

immediately. Please find a professional technician to replace your outer tyre. If your outer tyre accidentally punctures

and leaks, please contact a professional technician to repair or replace it.

PRODUCT DISCLAIMER:

The contents of the user manual shall not be copied, modified, reproduced, transmitted or published in any form with-

out the prior written permission of the company.

Please read this manual carefully before using the product and operate in accordance with it, otherwise, the company

will not be responsible for product damage or personal and property losses caused by improper and wrong use.

The company reserves the right to modify and finally interpret the product models, specifications or relevant

information mentioned in this manual; The functions of the specific model mentioned in this manual are only

applicable to the specific model; The product models, specifications or relevant information mentioned in this manual

are subject to any modification or change without notice; Please read this manual carefully before using the product

and operate in accordance with it. Otherwise, the company will not be responsible for product damage or personal

and property losses caused by improper and wrong use.

BEFORE YOU RIDE

Perform Regular checks and maintenance as outlined below

COMPONENT OR

CONDITION

INSPECT BEFORE

EVERY RIDE

INSPECT

PERIODICALLY

CLEAND AND/OR

LUBRICATE

ADJUST /

TIGHTEN

REPAIR /

REPLACE

(IF NECESSARY)

Tyre presure

Tyre wear/damage

Brake pad

adjustment

Wheel quick

release adjustment

Head and tail lights

Controls and

displays

Seat post quick

release adjustment

Brake pad wear

Brake cable

tension wear

Spoke tension

Wheel true /

Alignment

Hub bearings

Chain lubrication

Derailleur

adjustment

Reflectors

Battery and

charger

All bolts, nuts &

mounting hardware

DAXYS FOX - USER MANUAL

BATTERY DISPOSAL

According to directive AS/NZS 5139:2019 (Safety of battery systems for use with power conversion

equipment) and AS IEC 62619:2017 (Secondary cells and batteries containing alkaline or other

non-acid electrolytes), defective or used batteries, battery packs or single cells must be collected sepa-

rately and disposed of in an environmentally friendly manner.

Used cells and batteries are recyclable economic goods. In accordance with the marking showing a

crossed-out waste bin, these batteries may not be disposed of as domestic waste.

NOTICE:

• Used batteries must be treated as hazardous waste.

• Batteries must be disposed of in accordance with the relevant national environmental protection

regulations.

• Return batteries to a recycling facility, or an authorised Daxys dealer.

• In case of uncertainty contact Daxys customer service department.

MEET YOUR BIKE:

14. Battery

15. Motor

16. Crankset

17. Pedal

18. Derailleur

19. Rear wheel reector

20. Gear casette (9 speeds/gears)

21. Back reector

22. Seat

1. Stem

2. Controller

3. LCD display

4. Rear brake lever

5. Rear speed shifter

6. Front brake lever

7. Headlight

8. Shock-absorbing front fork

9. Tyres

10. Brake disc

11. Brake caliper

12. Front wheel reector

13. Wheel rim

1 2

1415171819

DAXYS FOX - USER MANUAL

DISPLAY GUIDE:

1. Battery level

2. Headlight (ON if visible)

3. Current speed

4. KM/H MP/H

5.Walk mode (ON if visible)

6. Trip / Cadence / Total

7. KM / Miles / RPM

8. Trip time / Total riding time since last reset

9. PAS (pedal assist system) indicator

HANDLEBAR GUIDE:

1 3

9. On/Off button

10. Down / Decrease button

11. Up / Increase button

12. Set button

13. Rear brake lever

14. LCD display

1. Handlebar

2. Other Shifter (Lower Gear)

3. Main Shifter (Upper Gear)

4. Grip

5. Front brake lever

6. Stem bolts

7. Cables

8. Stem rotation bolts

DAXYS FOX - USER MANUAL

PRODUCT SPECIFICATIONS:

Parameter Value

Appearance Dimension Body material Aluminum alloy

Vehicle colour Black

Bike size Length*width*height:

1760mm*700mm*1060mm

Hub form spoke wheel

Hub size 27.5”

Package size Length*width*height:

1400mm*220mm*790mm

Performance Parameters Gross / net weight 20.5kgs/28kgs

Maximum payload 125kg

Top speed 50Km/h

Endurance Mileage 40-75KM (the lower value is closer to real-life performance)

Maximum climbing angle 25 degree

Service temperature range -0~+45° C

Charger Parameters Input AC 180-240V, 50/60 Hz, 2A MAX

Output DC 42V 3A 126W MAX

Battery parameters Battery type 18650 Lithium ion power battery

Battery capacity 13Ah

Battery rated voltage 36V

Under-voltage protection value 29V

Over-current protection value 15±1 A

Charging time 4-5h

Parameter Value

Electrical Specifications Motor mode Moped

Motor type 27.5”/36V/High speed gear / pedal sprocket motor

Motor rated power 350W (Standard)

Product Features Instrument display Multi-functional color LCD screen

Front lighting Yes

Brakes Front and Rear hydraulic disc brakes

Tyre style Pneumatic tyre

Tyre size specification 27.5x1.95”

Air nozzle: The inner tube valve is AV

Front fork suspension Yes

Middle(rear)shock absorption No

Speed gear 9 Speed

Headlights Yes

DISCLAIMER:

THE PRODUCT WAS TESTED FULLY CHARGED, WITH AN AVERAGE LOAD OF 75KG-85KG, AT A NORMAL TEMPERATURE ON A NORMAL

PAVED ROAD BETWEEN THE SPEEDS OF 0-25KM/H. THE RESULTS MAY VARY BASED ON DIFFERENCES IN TEMPERATURE, LOAD, WIND

SPEED, ROAD CONDITIONS AND OTHER FACTORS.

DAXYS FOX - USER MANUAL

ASSEMBLY INSTRUCTIONS:

1. Unpack your new Daxys Fox eBike. 2. Have the tools and parts ready.

3.Remove packing materials.

* Be careful not to scratch the paint

4. Remove front wheel.

*Be careful not to cut the tyre

1. UNBOXING & TOOLS

2. Remove the 4 front stem bolts, then the stem cover.

3. Place handlebar in stem, put the cap and screw 2 bolts to 90% to help

with position adjustment

* It is recommended to angle the brake handles at aprox. 45°

2. HANDLEBAR INSTALLATION

1. Turn the fork in the correct position

* Rear brake is on the left, front brake is on the right side of the bike.

4. Adjust to the desired position using the markings on the handle-

bar and the stem cap to guide you.

5. Tighten the 4 bolts.

DAXYS FOX - USER MANUAL

1. Turn the bike upside-down. 2. Remove the fork protector.

4. Remove the protective plastic cap then put the wheel on and insert

the front wheel pin.

5.Tighten using the front wheel screw. 6. Secure with the quick release.

3. FRONT WHEEL

3. Remove the brake pads protector.

1. Spin the wheel and listen for rubbing sounds. 2. Loosen A, B with the hex key and adjust brake pads.

3. Spin the wheel to check. 4. Tighten A, B.

4. BRAKE ADJUSTMENT

1. Place the back reflector on the seat tube and tighten. 2. Place the front reflector on the handlebar and tighten.

5. REFLECTORS

DAXYS FOX - USER MANUAL

1. Flip the bike in the normal position. 2. Identify Left & Right pedals.

3. Screw in “L” and “R” pedals 4. Tighten the pedals using an Allen key.

5. Insert and adjust saddle height.

6. PEDALS & SADDLE

6. Secure with the quick release.

1. Install the mount on the display 2. Loosen the mount bolts

3. Loosen the controller bolt 4. Place the display on the handlebar and tighten the bolts

5. Place the controller on the handlebar and tighten the bolt 6. Connect the display cable with the battery cable, paying attention

that the 2 arrows match before connecting.

7. CONTROLLER AND DISPLAY

DAXYS FOX - USER MANUAL

CHARGING THE BATTERY:

Using the charger and Battery guide, charging indicators, level indicators etc.

1. Connect the charger to the battery charging port first.

2. Plug in a power source

3. Check if the LED is RED. If the LED is GREEN, unplug from power source and repeat steps 1. and 2.

4. A full charge will require 4-5 hours, depending on current battery level.

5. Disconnect the charger when the LED turns green, it indicates Full Charge.

6. Pressing and holding the power button on the battery, will indicate it’s charging level (GREEN means charged).

1 3

5 6

BATTERY AND CHARGER INFORMATION:

GOOD PRACTICES

Control the temperature

Avoid charging in extreme temperatures that are outside normal comfort range.

If your battery does get very hot or cold, allow it to come to room temperature before you plug in the charger. Batteries get warm even during normal

use - wait a few minutes post-ride before you start charging.

Use the right charger

For best performance, use the original charger that was supplied with your eBike. If you must use a different charger (for example: if the original

charger is lost or damaged and replacements are no longer available) check carefully to ensure a 100% match before you charge.

Don’t take it to 0%

Lithium-Ion batterieshave the longest service life when kept in the middle of their capacity. Sometimes, draining is unavoidable, but when possible,

top offbefore 0%. Use the display or the battery indicator on your eBike’s battery to monitor the charge level.

Don’t overcharge

You can extend the lifespan of your lithium-ion batteries by charging to 80%, when possible.

Epic ride coming up tomorrow? Go ahead and charge to 100%. It’s totally OK and is an expected, normal use of your battery.

Keep it dry

Never charge in a damp or wet environment. If your eBike was ridden in the rain, ensure every component is completely dry before you charge.

Don’t pressure wash your battery, and never submerge it.

Give it some room

Both chargers and batteries can get warm during use. Make sure that anyvents on the charger aren’t blocked and ensure that air can circulate

around all the components. Place chargers on a hard surfaces only.

Don’t use an extension cord

Extension cords adds resistance. While extension cords can be convenient, some chargers may work poorly, or not at all, when plugged into exten-

sion cords. Plug your eBike charger directly into a wall outlet instead for best results. If required to use an extension cord, use the shortest length
