MATTS S3-W User manual

HANDLEIDING

USER INSTRUCTIONS
Welcome to the family of S3-W owners! We will guide you to know each function for the right and safe
use of Electric scooters. To ensure your safety, please read this manual carefully before riding and make
sure you are always following the requirements below:
• Fully understand the information in this manual, including but not limited to the relevant instructions, precautions
and warnings.
• Fully understand the operation and contingency measures of electric scooters.
• Be fully aware of warning labels of S3-W electric scooters.
• We will not take any responsibility resulting from the unauthorized modification,failure to use original spare
parts,or installation of components that affect the performance and safety of the scooter.
Please contact the Local Customer Service Center if you have any questions about this bike. We are at
our service at any time. Wish you safe and pleasant riding experience!
SAFETY INSTRUCTIONS
To ensure the safety of you and others, please make sure to observe the following matters:
• Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell.
• Observe traffc regulations and traffc signs and confirm the surrounding road conditions and scooter conditions at
any time, so as to actively avoid danger.
• Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots.
• Perform a basic check each time before riding, so as to confirm the light, brake, tread and tire pressure and check
other parts for looseness or abnormal noise, and regularly go to Local Service Center for maintenance.
• In order to ensure the safety of you and others, please DO NOT use high beam in good lighting conditions. The
continuous use of high beamwill cause the visual disturbance to vehicles and pedestrians on the opposite side,
thus affecting normal driving.
• Please do not make or answer any call during riding, which is likely to cause traffc accidents.

DISCRIPTION OF COMPONENTS AND PARTS
SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS
mirror
Handle Bar
Rear backres
Saddle
Swingram
Motor
Front Fork
Front Tyre
Fender
Headlight
Windglass

DISCRIPTION OF COMPONENTS AND PARTS
DIAGRAM OF INSTRUMENT PANEL
Economical Gear, corresponding to number ”1”
Cruising Gear, corresponding to the number “2”
Sport Gear, corresponding to the number “3”
Winker indicator, flashing in synchronization
with the left and right winker.
High beam indicator, indicating highbeam on.
Parking indicator, indicating the parking state.
Charging
1. Speed display
display current speed.
2. Ambient temperature
Display current ambient temperature
3. driving time
Display Single driving time
4. ODO/TRIP
Total ODO Distance/ TRIP distance
5. Power display bar
Display current battery level
6. Gear display
Display current gear
7. Failure warning display
current failure (motor, controller,
brake, accelerator)
8. Left indicator light
Left indicator for turning
9. READY light
Ready for driving
10. Under-voltage of Battery
Under-voltage warning Display of
current battery
11. Right indicator light
Left indicator for turning
12. Parking gear
Parking de scooter
13. Recover display
Recover current failure
The charge indicating lamp lights up when less
than 10%electricity remains.
The start indicator lights up when the motor
can be started.
normal
sport
eco
READY

OPERATIONGUIDE
DETAILS OF INSTRUMENT PANEL

OPERATIONGUIDE
LEFT START BUTTON RIGHT START BUTTON
1. High/low beam switch button
Press up to turn on the high beam.
Press down to turn on the low beam.
2. Winker button
Dial to the left side to turn on the Left winker.
Dial to the right side to turn on the Right winker.
3. Horn button
Press to make a sound and release to sto
1.Gear shift button
The bike has three(3) Gear modes,
1 “Eco”, 2 “Cruise”, and 3 “Sport”. Dial rightwards for “Eco”, middle for
“normal”and left for “sport”.
2. Headlamp button
Dial up to turn on the headlamp.Turn downward to AUTO to automa-
tically turn on the headlights. The headlights turn on automatically
according to the brightness of the environment.
Dail down to to turn off the headlamp.
3. Parking button
Parking button has two modes: press to park the bike and
parking indicator P goes on; and press again to exit the parking status.
4. Recover button
When the scooter have failure warning on the motor/Controller/Brake/
Accelerator, always press this button, slow driving to nearby service
center for repairs.

OPERATIONGUIDE
HOW TO OPERATE THE SMART REMOTE CONTOL
With the advanced Smart Remote Controller, you can
easily lock or unlock your electric scooter by simply
pressing the button within 50 meters.
1. Unlock
Press the unlock button, and the start button stays on. The
scooter enters into the [Unlocked State].
2. Lock
When the scooter is in the [Static State], press the lock
button, and the start button flashes. The scooter enters the
[Locked State].
3. Remote keyless entry
After unlock the scooter,press this button twice within two(2)
seconds, and the scooter will be in the “Powered” state
without key.
4. Search key
Press this witch within 50m, “Bi Bi” sounds searching the
scooter.

OPERATIONGUIDE
OPEN THE STORAGE BOX AND SADDLE
1. After the scooter stops, turn the handlebar to the far left, ins-
ert the key into the physical handlebar lock, push and rotate it
leftwards to lock the scooter.
Insert the key into the physical handlebar lock, and rotate it
rightwards to unlock the scooter.
2. Insert the key and rotate it leftwards, open the saddle and the
storage box will be opened when you hear a
[Click] sound.
3. Insert the key and rotate it rightwards, to start the scooter for
driving.

OPERATIONGUIDE
OPERATION OF AIR SWITCH / BATTERY CONNECTING
As the protection switch for the main power of electric scooter, the air switch will automatically disconnect to ensure
safety when the scooter circuit is abnormal or the current caused by short circuit exceeds the set safe value.
1. Open the small cap of battery case, plug the
battery cable inside the socket, connecting the
battery with scooter.
2. Air switch ON/OFF
Before open the key,please turn ON this Air switch
in advance.
Notes: In order to protect your safety, please turn
off the air switch when cleaning, storing the
scooter for a long time, or re-moving the battery
pack.
3. Battery case anti-theft lock / unlock
When you put down the battery case into the
scooter, it is locked automatically.
4. Connecting the battery with scooter cable.
5. Unlock and Remove the battery case
Open the small cap of the battery case, unplug the
power cable,Insert the key and rotate it rightwards,
then pull up the battery case with one hand.

RIDING GUIDE
CHECKS BEFORE RIDING
Make sure to check the following items before riding a Electric Scooter, which will guarantee your safety
on the road.
1. Whether the handlebar is stable and flexible when turning.
2. Whether the switches on the right and left handlebars can work normally.
3. Whether the speed accelerator can work normally. Make sure the tire pressure is normal.
The suggested tire pressure is 26-29psi for front wheel and 29-32 psi for rear wheel.
4. Checktiresurface forcracks,damage, wear,and foreignmatterpuncture orattachment
5. Whether the tread depth is sufficient (>0.8 mm).
6. Whether any fault warning light on the instrument panel goes on after being powered.
7. Whether the battery is fully charged.
8. Whether the head and tail lights, brake lights and winkers can work normally.
9. Whether the horn can work normally.
10. Whether the rear mirrors are clean. Adjust them to the appropriate angle.
11. Whether the brake oil is sufficient, and whether the handlebars and brake system can work normally.
12. For any abnormality or operational concern, please contact local Customer Service Center.

CHECKS BEFORE RIDING
CHECKS BEFORE RIDING
Make sure to check the following items
before riding, which will guarantee your
safety on the road.
1. Insert the key and turn rightwards, Open
the saddle, Turn On the Air switch.
2. Put on the helmet, and retract the
electronic side stand.
3. Insert the key and turn leftwards, “Powered” state is started,
the Instrument is opened, and the “READY” light is ON, scooter is
ready for driving now.
4. Press the “P” button with three(3) seconds, to exit the Parking
state, and the “P” indicator goes off, then you can start driving.
Gently turn the handlebar to ride on the road.
TIPS: Before riding,make sure the electronic side stand retracted and
rotate the handlebar to ensure that the handlebar lock is closed.If the
Parking button is pressed when riding, the bike will be dis- energized. So
DO NOT press it when riding for avoiding danger caused by the sudden
loss of power.
If the electronic side stand is extended when riding, the bike will be
dis- energized. So DO NOT extend the electronic side stand when riding
for avoiding danger caused by the sudden loss of power.
The scooter must be fully stopped before starting. In case of abnormality
during riding, please ride carefully or push it to a safe place. DO NOT try
restarting the bike during riding or on the lane so as to avoid danger.

BATTERY USE INSTRUCTIONS
HOW TO CHARGE THE BATTERY
1. Insert the main charger plug into the charging port of the scooter.
Insert the chargers AC power plug into the home power socket, and the battery
starts charging when the charger indicator turns red. The battery is fully charged if
the charger indicator turns from red to green.

BATTERY USE INSTRUCTIONS
HOW TO CHARGE THE BATTERY
2. Pull up the battery from scooter, Insert the main charger plug into the charging
socket of the battery. Insert the chargers AC power plug into the home power
socket, and the battery starts charging when the charger indicatorturns red.
The battery is fully charged if the charger indicator turns from red to green.
TIPS:
Short circuit of the cathode and the anode at the battery’s input. Keep it away from children, fire
and heat source. It is strictly forbidden to throw it into the fire;Violent movements, shock and
extrusion are prohibited; Only the specified charger can be used, and other chargers are prohibited
to charge the battery;
This product has been subject to strict inspection before leaving factory, and it is strictly prohibited
to dismantle it. Please contact our company’s after-sales department for any question.

BATTERY USE INSTRUCTIONS
HOW TO CHARGE THE BATTERY
STORAGE, MAINTENANCE AND TRANSPORTATION
TIPS:
Do not expose the battery to water, and prevent it from being damped by water or rained.
Charge temperature: 0-45 °C, discharge temperature: -20-45 °C;
Battery capacity will be reduced when placed in a low-temperature environment;
Charge the battery when you use it, but make sure to charge it before the capacity is lower than 20%.
When it is not used for a long time, please remove it from the scooter;
Please charge the battery to half-saturation state when storing or transporting it (after the battery is
discharged, charge it for 3 hours). Place it in a dry and ventilated place;
Battery and charger should be kept in a clean, dry, and ventilated place. Keep them away from corrosive
materials, power source and heat source;
Storage conditions: ambient temperature -20-35 °C, humidity < 65% RH; When storing the charger,
please disconnect it from the battery.

MAINTENANCE
ROUTINE CLEANING AND MAINTENANCE
Regular maintenance can enhance the service life and driving safety of the electric scooter. Please refer
to the following suggestions and take care of your scooter.
Cleaning: Please use clean water and neutral detergent to clean it, and use soft cloths and sponges to clean the sur-
face; it is prohibited to use metal brushes, sandpaper or the like to clean it, in order not to scratch the parts surface.
After cleaning, dry it with soft cloths.
TIPS:
Please disconnect the air switch before cleaning. Do not use strong water jet to directly
wash it, so as to avoid the default of mechanical parts caused by water invasion.
Storage: try to park it in a dry and cool room to reduce the exposure to sun and rain and avoid the reduction of ser-
vice life due to corrosion of parts. When left unused for a long time, please turn off the air switch and disconnect the
power supply circuitto prevent over discharging. After long-term storage, please fully charge it before use.
REGULAR INSPECTION AND MAINTENANCE
The new scooter must be subject to the first inspection and maintenance in the Service Center when it reaches
1,000 km or two months (whichever comes first).
The scooter is recommended to be subject to regular inspection and maintenance in the Service Center at every
3,000 kmor six months (whichever comes first).
TIPS:
Please disconnect the air switch before cleaning.Do not use strong water jet to directly
wash it, so as to avoid the fault of mechanical parts caused by being damped.

ROUTINE CLEANINGANDMAINTENANCE
Regular maintenance can improve the service life and driving safety of the electric scooters. Please refer
to the fol-lowing suggestions and take care of your scooter.
Failure Causes Solutions
The scooter has no electricity, and
the READY lamp does not shine.
Battery is poorly connected.
Air switch is not turned on.
Connect the battery properly at its main plug. Turn
on the air switch.
When turning the speed
regulating steering handle-bar, the
motor does not turn after being
powered,
Low battery volume.
Side stand is not retracted.
Brake handle does not reach the
right position.
Steering handlebar failure.
The controller plug is loose. Con-
troller failure.
Charge the battery.
Put away the side stand.
Close the parking key.
Place the brake handle at the right
position. Change handlebar.
Re-plug controller.
Change controller.
Speed is slow or mileage is short. Low battery.
Under-inflated tire.
Heavily overloaded.
Brake pads interference. Battery
aging or normal scrap.
Charge the battery.
Inflate the tire, and check the tire pressure before
riding.
Foster a good habit, and keep the appropriate load
Change the brake pads and check the brake system
before riding.
Change battery.
Check whether the main plug is in a right place Use
the special charger.
Battery can not be charged. Poor contact of the main plug of
the charger.
Do not use the wrong charger.
Battery aging or normal scrap.
Battery low-voltage protection.
Contact of the main plug again. Contact with local
service office of battery.

ROUTINE CLEANINGANDMAINTENANCE
Table of contents
