DAY 6 Dream8 User manual

Owner’s Manual
The most comfortable upright
bicycles ever made.

At Day 6, we hope you will enjoy riding our bicycles as
much as we enjoy designing them. We have truly
combined the best features of a recumbent (feet on the
ground; wide, comfortable seat and backrest; upright
head position; reduced stress on the wrists, shoulders,
low back, and crotch; easy on and off) with the best
features of a traditional bike (dual 26” wheels, positive
steering, classic styling, great visibility, easy to find
replacement parts) to give you one exceptional biking
experience!
If you have any questions about your bicycle, please call
the dealer you purchased it from or call Day 6 Bicycles at
406/570-1927, or email Day 6 at [e-mail].
For most accessories and replacement parts, call your
local bicycle dealer.
Warranty Activation
Email us at [e-mail]. We will need the se-
rial number from the bottom bracket along with your
name, address, phone number, name of dealer you pur-
chased the bike from, copy of receipt, and the date
the bicycle was purchased. Or you can put this infor-
mation on a piece of paper and mail to us at:
Day 6 Bicycles, 414 W 7th St, Logan,IA 51546
Page 1

Bicycle Assembly
All Day 6 bicycles must be assembled by a
professional bicycle dealer for proper set-up.
Failure to do this voids all warranties and could
result in damage to the bike or serious injury.
Important: Dream8, Dream24, and
Journey have a weight limit of 250
pounds. Patriot and Cyclone have
weight limits of 300 pounds. Samson
has a weight limit of 400 pounds.
Anyone weighing more than these
weight limits voids all warranties and
assumes all responsibility.
Page 2

Bicycle Set Up
Seat.
Seat Height. When the seat height is properly
adjusted, the balls of your feet should easily touch the
ground, but more importantly, your leg should have a
slight bend when the pedal is in the extended position.
If your legs are completely straight when pedaling, you
need to lower the seat. If your legs have more than a
slight bend or your opposite knee and femur go above
parallel with the ground when pedaling, you need to
raise the seat.
Seat too low
Seat too high
Seat just right
CAUTION:
There is a maximum height for extending the seat post .
The horizontal backrest tube should never be more than
6” above the seat post collar.
Page 3
6”

Seat Angle and Depth. Newer Day 6’s have two bolts
at the top of the seat post. Loosen them. (If the Horizontal
Backrest Tube is attached to the seat post, you will first need
to move it out of the way by loosening the two bolts that
attach it to the seat post.)
Seat post 1” back
from bend
Contour Seat attaches
to mounting base with
four 1/4-20 bolts
Place seat post about 1” from the seat
pan bend (see above) and allow seat
post to tilt back as far as it will go.
Tighten the two seat post bolts
securely, going back and forth
between them until they are tight. This
will put the bottom of the seat parallel to the ground
which is correct for most people. If not, loosen bolts
and readjust angle. Securely tighten the bolts after
finding the correct seat position and then reinstall the
Horizontal Backrest Tube.
NOTE: It is CRITICAL that the 2 seat post bolts are
tight at ALL times. Check your seat before each
ride. Failure to do this can cause serious injury.
Horizontal Backrest Tube
Proper seat angle
Page 4

NOTE: Older Day 6 bicycles have a quick release to
secure the seat post. If you are concerned about someone
stealing your seat or you can’t get the quick release tight
enough to secure the seat post, you may want to purchase a
seat collar that uses a bolt instead of a quick release. These
are available at most bicycle dealers or you can get one
from Day 6. They are easy to
install on your bicycle. The
seat post on Day 6 bicycles is
30.4mm and the seat collar
size would be 34.9mm.
Seat post collar on new Day 6
Backrest.
Backrest can be adjusted horizontally and vertically using
the quick releases. After adjusting the seat; slide the
backrest forward until it rests comfortably against your
back. Lock the quick release. Next, move the back
cushion up and down until it fits comfortably in your lumbar
area. Lock the quick release. You may need to readjust
these after you ride for a while and find out what works
best for you.
Handlebars.
Height and angle can be adjusted to fit your size and riding
preference. When the handlebars are adjusted correctly,
you should be able to push comfortably against the back
(you should not have to lean forward at all) and the
handlebars should not hit your knees when turning. If you
feel the handlebars are not tall enough, see your local
bicycle dealer about getting an A-head style extension. If
they are too tall and you have an older Day 6, you can get
an adjustable stem at your local bicycle dealer.
Page 5

Handlebar height adjustment.
Newer Day 6’s have an adjustable stem which allows you
to raise and lower the handlebar so you get a perfect fit.
To change the height of the handlebars simply loosen the
bolt on the side of the stem until you can raise and lower
the stem. Once it is at the correct height, tighten securely.
Handlebar angle adjustment
Loosen the four stem bolts on the stem at the base of the
handlebars. Move handlebars to desired angle by pulling
them toward you or pushing them away from you. Be sure to
securely tighten all four bolts after desired angle is set.
You may have to loosen the adjustable stem and the stem
bolts and move bars and stem to the desired position and
then securely tighten all bolts.
Stem all the way up.
Stem in the middle
Stem all the way down.
Page 6

Proper way to set up back and bars Improper set up
If you choose not to inspect your bike and breakage or
failure occurs, you are responsible and not Day 6 Bicycles
or the dealer you purchased it from. Be responsible and
safe – check your bike before each ride.
Bicycle Inspection
Before riding your Day 6, always inspect it to make sure all
parts are adjusted and working properly. The frame and
components are designed to be used in a responsible
manner on streets and trails. Day 6 bicycles are not
designed for racing, mountain biking, jumping, stunt riding,
riding with more than one rider, riding with heavy loads, or
any extreme type of riding or non-standard use and the
warranty will not cover any of the above riding types. You
are responsible for checking your bike before each ride and
on a regular basis to make sure that the frame and parts
are not cracked, loose, or broken and that they are working
in a proper fashion. Failure to inspect your bike could lead
to bike damage, severe injury, or even death.
NOTE:
For optimal performance the handlebars should be almost
parallel with the head tube. Having the handlebars too far
forward or backward will affect the steering and can be
dangerous. If they are too far back, they can hit your knees
while pedaling.
Page 7

General Inspection:
Check for loose parts by raising your bicycle about 3” off the
ground and dropping it on the tires.
Make sure ALL quick release mechanisms/clamps are
locked and tight.
Make sure wheels, fork, headset, and seat post are tight.
Check frame/welds for cracks and bends.
Immediately replace a damaged frame as this can cause a
crash and lead to a severe injury.
Take immediately to your local bicycle dealer.
The Big 4
These are the things people overlook most often
when it comes to regular maintenance.
Underinflated tires. Check tires weekly to prevent
premature aging of tires, hard pedaling, accidents, and
getting stranded.
Over lubricated chains. Lubrication sounds good but
too much attracts dust and dirt which wears out chains,
derailleurs, and chain rings.
Loose spokes. Check spokes regularly. Loose spokes
lead to broken spokes which can cause accidents and, at
the least, lead to large repair bills.
Seat post too high. NEVER have more than 6” of seat
post showing between the top of the seat post collar and
the bottom of the horizontal backrest tube. A seat post
pulled out too far can lead to serious injury if the seat post
or frame breaks while riding.
Page 8

Wheels and Tires:
Check for loose or missing spokes. See your local dealer
to get them fixed or replaced immediately.
Check front and rear wheel quick release levers every time
you ride. Pick up end of bike and strike top of wheel
with a few sharp blows to check for looseness.
Spin wheels to make sure they are centered and do not
wobble.
Make sure tires are properly inflated to pressure listed on
sidewall or just below that. Tires can lose a lot of air in
just a week. Riding with under inflated tires is
dangerous, hard on the tires, and it makes pedaling
more difficult. If possible, avoid curbs, potholes, railroad
tracks, and other hazards.
Quick Release Levers:
Quick release levers are used on both wheels and the
backrest. Quick releases can be replaced with bolts if you
are concerned about theft or having your settings changed.
It is very important that all quick releases/bolts are tight.
The quick release lever should never be tightened like a
nut.
To tighten, open the quick release lever, turn the nut
clockwise and then close the quick release lever by
pushing it in.
If the lever can be easily pushed closed, repeat above step
until it takes a firm push to close it.
Page 9

Cleaning the frame:
To remove dirt, wash lightly with a hose. (Never use
a pressure washer or take to a car wash as water can
penetrate the bearings.)
Use warm soapy water and a SOFT brush to finish
cleaning. (Never wipe the dirt with a rag as the dirt
will scratch your bike’s paint.)
Lightly rinse with hose.
Page 10
Chain and Derailleur:
Look for wear on chain rings, chain, or links that don’t
swivel easily.
If chain comes off chain ring, have your local dealer adjust
derailleur.
Bicycle Cleaning
It is important that you keep your bicycle clean –
especially the moving parts (chain, derailleur, gears,
etc) since grit and dirt can damage these and shorten
their useful life. If you are riding continually, it is best
to wash your bike monthly or if it is noticeably dirty.
Brakes and Pads:
While rolling slowly, squeeze brake levers. Bike should stop
quickly and levers should be at least ¾” from hand grips.
Since brake cables stretch, it will be necessary to adjust
cables periodically. See your local dealer for this.
Make sure pads are aligned correctly on rims.
Replace worn or hardened pads.

Chain: Lubricate with bicycle chain lube every
week, more often during wet conditions. It is best
to do this in the evening so the lubricant has a
chance to soak into the chain before riding again.
Derailleur: Oil pivot points each month.
Hubs, headset, bottom bracket bearings, cables:
It is recommended that your local bicycle dealer
lubricate these items every 6 months.
Riding Rules
Always wear a helmet – most serious accidents
involve the head.
Ride defensively – NEVER assume drivers of
vehicles see you.
Lubrication
Proper lubrication of moving parts means a longer life for the
components of your bicycle. The chain, in particular, needs
to be inspected frequently. Be sure to use lubricants
especially designed for bicycles. Never over-lubricate and
be sure to wipe off any excess as this will attract dirt.
Cleaning greasy chains and drive train
components:
Apply a degreaser and allow it to soak for 10 minutes.
Scrub greasy area with an old brush.
Lightly rinse with a hose.
Page 11

Watch for turning and stopping cars and opening car
doors
Be especially cautious at intersections and driveways
Watch for hazards – pot holes, sand, curbs, RR tracks,
manhole covers
Watch for deep cracks running parallel with the road.
Your front tire can get wedged in there and throw you
Be careful when passing motor vehicles
Obey all traffic rules and signs
Use the proper hand signals when turning and stopping
Don’t ride on sidewalks unless necessary – be courteous
to pedestrians
Do not hitch rides on motor vehicles
Ride on the side of the road going the same direction as
the traffic
Riding Tips
Wear comfortable clothing - but not loose clothing
Wear bright colored clothing
Layer your clothing so you can add or remove depending
on the temperature
Never ride with bare feet. (If you are not convinced I will
show you where my friend Terry used to have a little toe.)
Don’t wear head phones – you won’t be able to hear traffic
Use a rear view mirror to see what is going on behind you
At night, wear clothing with reflective material in it
At night, use an appropriate lighting system
Use extra caution when riding at night, in rain, on snow or
ice – give yourself plenty of time to stop
Never ride with more than one person on your bike
Page 12

Do not disturb wildlife
Slow down when approaching another rider or pedestrian
Respect all public and private property
Be extra alert when cycling with children – make sure they
know the rules!
Day 6 Bicycles Limited Warranty
Day 6 Bicycles, (an Iowa corporation) located in Logan,IA
makes the following Limited Warranty concerning Day 6
Bicycles:
Limited Lifetime Warranty on Frames. Subject to the
following limitations, terms, and conditions, Day 6 Bicycles
warrants to the original owner of each new aluminum frame
that the frame is free from defects in workmanship and
materials for as long as they own the bicycle. This Limited
Warranty does not apply to damage or failure due to:
accident, neglect, abuse (such as jumping, acrobatics, stunt
riding or similar activities, competitive riding, riding over the
weight limit, having seat post out further than 4”, carrying
excessive weight) and/or improper maintenance, alteration,
collision, or normal wear and tear.
Limited Six (6) Month Warranty: Subject to the following
limitations, terms, and conditions, Day 6 Bicycles warrants
to the original owner of each new Day 6 bicycle that all
other original parts attached to the frame (forks, seats, seat
posts, drive train, wheels, brakes, stem, etc) are free from
defects in workmanship and materials for a period of 180
days. This Limited Warranty does not apply to damage or
failure due to: accident, neglect, abuse (such as jumping,
acrobatics, stunt riding or similar activities, having seat post
out further than 4”, competitive riding, riding over the weight
limit, carrying excessive weight) and/or improper
maintenance, alteration, collision, or normal wear and tear.
This warranty does not include tires or tubes.
Page 13

Additional conditions:
All warranties are in effect for the original owner only
and are NOT transferable
In order to exercise your rights under this warranty, the
Day 6 bicycle must be presented to a dealer or Day 6
Bicycles along with a receipt or other proof of purchase
which includes a serial number.
Should any part of your bicycle, as determined by Day 6,
be covered under this warranty, it shall be repaired or
replaced, at Day 6 Bicycle’s sole discretion, which will be
conclusive and binding.
The original owner shall pay all labor charges connected
with repair/replacement of parts.
This warranty does not cover any transportation costs to
and from place of repair.
Day 6 does not authorize or permit anyone, including its
dealers, to make any other warranties, expressed or
implied, for Day 6.
Day 6 will not be responsible for incidental or
consequential damages.
This warranty is expressly limited to the repair or re-
placement of a defective frame, fork, or other part and is
the sole remedy of the warranty.
Day 6 Bicycles
414 W 7th St
Logan,IA 51546
406/570-1927
[email protected]m
www.day6bikes.com
