Whyte e-MTB HardTail Series User manual

e-MTB HardTail Range
e-504: 27.5” eMTB Hardtail
e-505: 29” eMTB Hardtail
e-506: 27.5” eSUV
Supplementary Service Manual 2021 Edition 1

Table of Contents
1.0 Introduction
2.0 Geometry
3.0 Preparations for riding:
3.1 Making Adjustments
3.2 Seat Clamp Adjustments.
3.3 Set up of Fork
4.0 Safety.
5.0 Lubrication:
5.1 General Lubrication
6.0 Servicing the Whyte Modular Dropout Systems:
6.1 Whyte 12mm QR Shaft
7.0 Removal of Bosch Power Tube Battery
7.1 DownTube Plastic Battery Cover Removal and Installation:
7.2 Location of Bosch Battery On/Off Button.
7.3 Location of Bosch Battery Charge Port.
8.0 Torque Settings.
9.0 Owner’s Notes

1.0: INTRODUCTION
Thanks for choosing to purchase this Whyte product. We hope you will enjoy all the benefits its advanced design and engineering
will bring to your riding experience.
This manual will guide you through the set-up, safety and maintenance procedures that are specific to your Whyte bike. For
other more general information, we strongly advise that you also read thoroughly the General Instruction Manual that is also
supplied with your new bike. It is also available to download at www.whyte.bike
Also, please note that the specification of all the components that are fitted to your bike as standard may be obtained from the
Whyte Bikes website www.whyte.bike
Please remember, if you are in any doubt about your ability to safely service or repair your Whyte bike, do not ride it and instead
arrange for a professional bicycle mechanic at your local Whyte dealer to do the job correctly.
Bundled with this manual, are the respective manufacturers instructions and manuals for the branded parts that are fitted to
your Whyte bike. Please take time to study all the relevant instruction manuals to ensure you have a continually safe and well
set-up bike before every ride, and to help you build up a relationship of knowledge between you and your Whyte Dealer.
Happy and safe riding,
Whyte design team.
2.0: GEOMETRY
The geometry of the Whyte Bikes e505, e504 and e506 is available from the Whyte Bikes website www.whyte.bike
3.0: PREPARATIONS FOR RIDING
3.1: MAKING ADJUSTMENTS
Please refer to the specific component manufacturers manual or published technical information about adjusting the compo-
nents on your Whyte bike. Instructions may be downloaded from the relevant manufacturer’s internet site, as shown in the
table below. In addition, make sure you download and read and understand the recommendations contained in the Whyte Bikes
General Instructions Manual, available to Download at www.whyte.bike
CAUTION! If you are uncertain in any way, about making adjustments to any components on you Whyte bike, then DO
NOT RIDE YOUR BIKE.
Contact your Whyte dealer who will be able to advise you on how to go about setting up you Whyte bike for riding, and or mak-
ing adjustments to the components fitted to your Whyte bike.
Bosch eBike Systems www.bosch-ebike.biz
DT Swiss www.dtswiss.com
Easton www.eastonbike.com
Formula www.formulahubs.com
Fox www.foxracingshox.com
Joytech www.joytech.co.tw
Maxxis www.maxxis.com
Race Face www.raceface.com
Schwalbe www.schwalbe.com
Shimano www.shimano.com
SR Suntour www.srsuntour-cycling.com
SRAM www.sram.com
Tektro www.tektro.com
WTB www.wtb.com

3.2: SEAT CLAMP ADJUSTMENT & SERVICE
CAUTION! Avoid over-tightening the seat clamp.
In particular “dropper” seat-posts may not work correctly if the seat clamp is over tightened.
CAUTION! When adjusting the saddle height you MUST obey the Minimum insertion depth requirement marked on the Seat
Post. Also consult the relevant seat-pin manufacturers instructions in conjunction with these notes.
IMPORTANT SAFETY Always stop riding when making adjustments of any kind to the bicycle!
3.3: SET UP OF FORK
Tools Required: Good Quality Shock Pump for Air Spring Suspension Fork
Small Ruler
IMPORTANT SAFETY NOTE: Always stop riding when making adjustments of any kind to the bicycle!
The front suspension fork fitted to your Whyte bike will be pre-set with the standard settings. Before riding, you may need to
adjust these setting. First is the Sag setting on the fork. This is to ensure the forks are set-up correctly for your own body
weight, so the fork will perform as intended.
To set Sag on the front fork, you need to measure the amount the fork compresses when you sit on the bike in the normal riding
position. See the table on the right for our recommendation of front fork sag on your Whyte bike. To achieve this you will need to
adjust the air spring pressure inside the fork.
Refer to the specification tables in this manual, and then to the relevant fork manufacturers set up instructions to find how to
adjust the air spring pressure in the fork. Using a shock pump, either add or remove air until Sag is correctly set.
Please note that for the detailed instructions for servicing and all matters relating to the forks fitted to your Whyte bike, please
refer to the manufacturers instructions.
Rebound Damping adjustment:
This adjustment fine-tunes the speed at which the wheel returns to its normal ride height after hitting a bump. Refer to the rele-
vant manufacturers instructions to find out how to adjust the rebound damping. To demonstrate the effect of this function, turn
the adjuster to its slowest setting. Press down on the handlebars to compress the forks, then release the load. The suspension
recovers very slowly to its original position.
Repeat the above with the adjuster turned to the fastest setting and the difference will be seen immediately the load is released.
We recommend the optimum setting is to adjust the re-bound damping to be as slow as possible, but not so slow that the
normal ride height is not recovered. On very rough terrain, if the bike becomes progressively lower as more bumps are hit then
the re-bound damping is set too slow. On the other hand if the bike feels choppy and not plush then the re-bound damping is too
fast. A bit of trial and error is needed to get the exact setting.

4.0: SAFETY
IMPORTANT: The following are intended to be advisory notes on the safe use of your Whyte bike. You should also read thor-
oughly the General Instruction Manual also supplied with your new bike. If at any stage you are uncertain about the safety or
safe operation of the bike as a whole, or any specific component, then DO NOT RIDE YOUR WHYTE and instead please con-
sult the specific component manufacturers instruction manual or your Whyte Dealer for advice.
Maximum Weight Limit for Whyte e-Bikes: 19.5st. / 125kg (including the rider and the rider’s equipment)
WARNING: As is the case with all mechanical components, the bicycle is subjected to wear and high stresses. Different
materials and components may react to wear and stress fatigue in different ways. If the design life of a component has
been exceeded, it may fail suddenly causing possible injury to the rider. Any form of crack, scratches and decolouring in
highly stresses areas are showing that the component has exhausted its life time and has to be replaced. If you are in
any doubt about one or more components on your Whyte DO NOT RIDE YOUR BIKE. Consult the specific component
manufacturers literature, or take your bike to your local Whyte Dealer.
Designed for the following use:
e-504 and e-505:
Whyte e-504 and e-505 Hardtail bicycles have been designed, tested and comply with EN-15194:2017 Safety Standards, for
typical ‘Trail’ mountain biking use.
e-506:
Whyte e-506 Hardtail bicycles have been designed, tested and comply with EN-15194:2017 Safety Standards, for typical Urban
and Commuter Riding.
5.0: LUBRICATION
Please refer to the Whyte General Instruction Manual for guidance about lubricating many of the components on your Whyte
bicycle.
For the range of bicycles contained in this Supplementary Service Manual, there is also the following specific guidance:
5.1: GENERAL WHYTE LUBRICATION
For the correct lubrication regime and maintenance of all parts on a Whyte bicycle, please refer to the specific component man-
ufacturers detailed instructions bundled with this manual or for further information visit the specific manufacturers website.

6.0 Servicing the Whyte Modular Dropout Systems:
6.1: USING THE 12mm WHYTE QR SHAFT.
Referencing Figure 19 and 20. The rear wheel is attached to the frame by a lever-actuated mechanism that allows you to install
and remove the wheel without tools.
To undo and remove the axle from the bicycle, turn the lever anti-clockwise until the axle is disengaged from the threads in the
RH dropout, then pull the axle out of the hub and through the LH dropout to remove it from the frame. Note. If you have
placed the bike in a work-stand take care to support the rear wheel as you remove the axle, to prevent the rear wheel falling
out of the frame and potentially damaging any components in the process. If you are in the habit of turning your bicycle upside
-down to remove the wheels, please take care not to damage the saddle or any of the controls on the handlebars when doing
so.
To re-assemble the axle, ensure the wheel is placed correctly into the frame and the hub is aligned with the dropouts. Insert
the Axle into the LH dropout and push it through the dropout, hub and into the RH dropout. Turn the lever clockwise.
After inserting the axle through the dropout of the frame and wheel hub, it will be necessary to turn the lever several
times to fully engage the axle into the threads in the RH dropout before the axle tightens. The required minimum hand-
force is 15 Nm.
WARNING: If you are unsure about how tight the axle needs to be done up to, DO NOT ride your bike and instead
consult your Whyte Dealer who will be able to advise and demonstrate the correct closing force.
Ensure that the lever is back to its normal position after every adjustment is made. To do this, pull the spring-loaded ever arm
away from the bike (Fig. 19 Arrow No.1) until the lever arm dis-engages from the axle (Figure 20) Whilst the lever is dis-
engaged from the axle, rotate the lever (Fig.19 Arrow No.2) around to a ‘9’0’clock’ position as shown in Fig. 20. Next release
the spring-loaded Lever arm to re-engage the Lever Arm with the axle (Fig.19 Arrow No.3).
Under no circumstances should the 4mm Allen Screw in the centre of the Axle Lever arm be loosened. Do not loosen the screw
for opening or closing of the Axle System.
Always check for safety before riding
Before every ride check your thru axle System is in the Locked (CLOSED) position. Make sure that the wheels are cor-
rectly installed on the bicycle frame or fork, and the lever does not contact any part of the bicycle. If the lever contacts
anything, it might not be closed; replace the thru axle or consult your dealer for safety. Ensure that the tightening force
of the thru axle lever is minimum 15 Nm.
WARNING: A thru axle that is not correctly adjusted and closed to a minimum hand force of 15Nm, may allow the wheel to
work or become loose or become detached from the bike unexpectedly. This could cause the rider to lose control and fall and
may result in serious injury or death. Always make sure the thru axle is adjusted and closed correctly before every ride as part
of your Pre-ride checks.
Figure 1: 12mm QR Axle
Figure 2: 12mm QR Axle
Re-Positioning Lever Arm

7.0: Removal of the Bosch PowerTube 500 Battery:
The Whyte e-Hardtails, use a standard Bosch PowerTube assembly which is housed inside the DownTube of the Frame.
7.1: DownTube Plastic Battery Cover Removal and Installation:
The Bosch PowerTube Battery is accessed by opening and removing the Plastic DownTube battery cover from the DownTube of
the frame. The location of the Plastic Cover is shown in Fig. 3b. To remove the Plastic Cover, using a flat bladed screw driver,
insert the screw driver into the slot shown in Fig.5. Rotate the slot 90o to the position shown in Fig.4 to release the Plastic Cov-
er and then remove from the Down Tube of the frame. You can then access the standard Bosch PowerTube Locker which is
located on the side of the DownTube of the e-bike frame as shown in Fig. 3a. Peel back and remove the Whyte covering bung,
taking care not to loose it. The Bosch PowerTube Locker key is then revealed. Follow the Instruction provided by Bosch to re-
move and reinstall the Bosch PowerTube battery. To refit the Plastic Cover, is the reverse of the removal process. Make sure
the Plastic Cover is correctly located into the DT and the Slot is pre-set in the position as shown in Fig.4. With the Plastic Cover
correctly located, Rotate the slot 90o to secure the Plastic Cover to the DownTube.
WARNING: Always consult the relevant Bosch User Manual and assembly instructions that relate to the Bosch Power-
Tube 400/500/625 battery assembly and operational instructions when removing and re-installing the Bosch PowerTube
Battery in your e-bike frame.
Figure 3b: Location of
PowerTube 500 Plastic
Cover fixing point.
Figure 4: Position of the
slot indicating the Cover
can be removed.
Figure 5: Position of the
slot indicating the Cover
can not be removed.
Figure 3a: Location of
PowerTube Battery Key
Locker.

Figure 6: Bosch Battery:
Location of Bosch Power-
Tube On/Off Button with
Battery Fitted into Down
Tube and Down Tube Bat-
teryCover removed.
7.3: Location Of Bosch Battery Charge Port.
IMPORTANT: At all times follow closely all recommendations from Bosch contained in the relevant Bosch Customer User
Manual documentation material bundled with your bike (or consult the on-line Bosch resources) to fully understand how
to re-charge, handle and store your Bosch Battery. Failure to comply with all Bosch recommendations could lead to fail-
ure of the battery function, and risk of fire leading to serious injury and death.
The position of the remote charge port for the Bosch Battery has been integrated into the side of the Motor Mount as can be
seen in Fig.7 and Fig.8. To access the charge port, peel back the sealed cover of the Charge Port marked “Whyte Energy” to
reveal the charge port. Follow the instructions contained in the Bosch Battery Instruction Manual to Charge the Battery. When
Charging has finished, re-fit the Remote Charge Port Cover and press firmly to seal the Cover over the Charge port to prevent
ingress of mud and water and other contaminants. Failure to correctly secure the sealed cover can lead to corrosion and failure
of the charge port component.
Figure 7: Closed Position Figure 8: Open Position
7.2: Location of the Bosch PowerTube On/Off button.
The location of the Bosch PowerTube On/Off button is located under the DownTube Cover. Refer to Bosch PowerTube instruc-
tions for the function of this aspect of the Bosch PowerTube.

8.0: TORQUE SETTINGS
Torque explained: If no suitable Torque Wrench is available a Torque of 5 lbf.ft can be obtained by applying a force of 5lb, with a Spring Balance,
to the end of a spanner, 1 Foot in length.
IMPORTANT: For all other torque settings, refer to the specific manufacturers information bundled with this manual, or alterna-
tively, refer to the specific manufacturers website for further information.
9.0: OWNER’S NOTES
Seat Post Clamp
M6 Cap Screw 12 (Min) - 14 (Max) 8.9 (Min) - 10.3 (Max)
