DAYCO DM0912S Instruction Manual

GENERAL DESCRIPTION
+ 19-21 cm roll towel
+ Toilet waste unit is made with 304 stainless steel 0.80 mm.
+ Operates with 4 batteries (D).
+ Electricity with 220V socket.
+ Stainless steel key.
+ Adjustable sheet lenght.
+ Easy to assemble.
+ Security lock system.
+ Counter wall option.
+ 23 lt bin capacity with lock.
COMPONENTS AND MATERIAL
+ DM0912S- Stainless Steel 304 satine finish
INSTALLATION
+ First measure out where the touchless dispenser
will be placed, mark six holes and drill into the wall.
+ Insert the provided wall plugs and screw in the top
two screws, leaving a slight gap
for the dispenser to slot onto.
+ Slot the dispenser onto the
two previously fixed screws
and then screw final screws.
+ Once the dispenser
is secure, insert the paper
back into the dispenser
by using the adjustable
handles inside.
130 cm
51,181''
37 cm
14,56''
22,5 cm
8,858 ''
32 cm
12,59 ''
61 cm
41,2 cm
16,22 ''
16 cm
6,299 ''
24,01''
DM0912S
Touchless Toilet Waste Unit
DM0912S
1/2
TECHNICAL DATA SHEET
DM0912S
25 mm 25 mm
320 mm
370 mm
1300 mm
150mm
150mm 400 mm

INSERTING THE BATERIES
1. Open the battery compartment by removing
the cover.
2. Insert 13A/1.50V alcaline batteries paying
attenton to the polarity. Alkaline batteries are highly
recommended. Put the cover back on
the battery compartment b pushing until ‘’click’’
3. Close the front cover of the dispenser.
ATTENTION
e dispenser cover must be closed to work properly.
When the supply voltage is too low, Led will blink
continously and then the dispenser will not work.
Please change the batteries immediately.
2/2
TECHNICAL DATA SHEET
MOUNTING TEMPLATE
Should be minimum 120 cm high from the floor.
DISPENSER REPLACEMENT REQUIREMENTS
AND RECOMMENDATIONS
e following recommendations are intended to
provide guidelines on the best possible placement
of the dispensers. Because every location a dispenser
is to be mounted is different, depending on customer
site, physical size limitations, and avaliable space,
these recommendations may not always be entirely
possibile to follow.However , when placing a dispenser
installation must meet ADA requirements and
should promote ease of use and be in union with its
surroundings.Upon installation, the dispenser should
be level and the job results professional,presentable
and fully functional.
AFTERCARE INSTRUCTIONS
+ Regular cleaning with a soft cloth will keep the
surface of your product looking new. Soapy water
can be used to remove stubborn mark. Dont use
abrasive or chemical cleaners as these may damage
the surface finish over time.
+ Don’t expose to sunlight.
+ Don’t respond to the product with force against
the possiblity of damnification,deformation.
+ Don’t throw any cigarettes and flammable materials
into the product.
DM0912S
Kg Kg
X
Y
Z
X
Y
Z
X
Y
Z
PRODUCT LITER PRODUCT CARTON CARTON INBOX PALLET GROSS PALLET GROSS PALLET
CODE DIMEN. DIMEN. WEIGHT QUANTITY QUANTITY DIMEN. WEIGHT
DM0912S 30 L 130x31x16 cm 137x44x30 cm 16,7 kg 1 8 80x120x160 cm 150 kg
