Dazon Raider Max 175S User manual

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
2
Limited Warranty
The warranty policy applies to those cases where the new seller vehicle unloaded from its shipping container,
set up and delivered by authorized dealer and under normal use and service is found to have defects in parts
or workmanship under the following terms and conditions. This warranty covers the engine and engine
related components for a period of 180 days.
This warranty does not apply to any parts that in the seller’s opinion were defective because of improper
maintenance, improper assembly, alterations, abuse, negligence or accidents.
Should warranty service be required on your vehicle during the 180-day warranty period, please contact your
nearest authorized DAZON dealer for repairs.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
3
What is not covered under this warranty?
This warranty does not cover any seller vehicles that have been subjected to:
a. Renting;
b. Disassembly, adjusting or repairing of the vehicle in any way so as to adversely affect its safety or
reliability;
c. Competition or racing.
The warranty does not cover any losses of the seller vehicle use, any losses of time, any inconveniences, or
any other consequential damages which include, but are not limited to the losses or damages to any persons,
property or expenses of returning damaged units to the vehicle distributor or any DAZON authorized
dealers.
DAZON has the right to make changes without prior notice.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
4
Contents
1. Foreword----------------------------------------------------------------------------------------------------------------5
2. A Few Words about Safety-------------------------------------------------------------------------------------------6
3. Important Safety Information----------------------------------------------------------------------------------------8
4. Safety Labels----------------------------------------------------------------------------------------------------------12
5. Are You Ready to Drive?--------------------------------------------------------------------------- ----------------13
6. Is Your Vehicle Ready to Drive?-----------------------------------------------------------------------------------17
7. Safe Driving Precautions---------------------------------------------------------------------------------------------21
8. Operation-------------------------------------------------------------------------------------------------- ------------24
9. Service Instructions---------------------------------------------------------------------------------------------------39
10. Repairs----------------------------------------------------------------------------------------------------------------47
11. Periodical Checks and Services------------------------------------------------------------------------------------48
12 Specifications---------------------------------------------------------------------------------------------------------49
13 Wiring Diagram ------------------------------------------------------------------------------------------------------54

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
5
FOREWORD
Thank you for choosing our double/single-seat Raider Max 175 which is approved by EEC for on-road
use. We hope you will have fun with it. Before starting operate this vehicle, please read through this Owner's
Manual carefully as it contains important safety and maintenance information. Failure to follow the warnings
contained in this manual can result in serious injuries.
Be sure to follow the recommended maintenance schedule and service your vehicle accordingly. Preventive
maintenance is extremely important to the longevity of your EEC-approved Raider Max 175.
Beginners should drive this vehicle in a large open area to practice handling it. Wear protective gears all the
time when driving or riding this vehicle.
We hope you will have a pleasant experience with our products and thanks again for choosing DAZON
EEC-approved Raider Max 175.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
6
A FEW WORDS ABOUT SAFETY
In order to keep everyone safe, you must take responsibility for the safe operation of your EEC-approved
Raider Max 175. To help you make informed decisions about safety, we have provided operating
procedures and other information on labels in this manual. This information alerts you to potential hazards
that could hurt you or others.
It is not practical or possible to warn you against all hazards associated with operating or maintaining your
EEC-approved Raider Max 175, so you must use your own good judgments.
You will find important safety information in a variety of forms, including:
!Safety Labels ------on the vehicle;
!Safety Messages ------ preceded by a safety alert symbol and one of the two signal
words “WARNING” or “CAUTION”;
!The meaning of these signal words:
WARNING ------Physical harm may result from the failure to follow the instructions that are described

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
7
within the labels;
CAUTION------ Damages to your vehicle and possible subsequent personal injuries or death could result
from the failure to take proper precautions described within the labels;
!Safety Headings------such as Important Safety Reminders or Important Safety Precautions;
!Safety Sections------such as EEC-approved Raider Max 175 Safety;
!Instructions------about how to use this vehicle correctly and safely.
The whole manual is filled with important safety information, so please read it carefully.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
8
IMPORTANT SAFETY INFORMATION
Your EEC-approved Raider Max 175 will provide you with many years of service and pleasure, providing
you take responsibility for your own safety and understand the challenges you will meet while driving.
There is much that you can do to protect yourself when driving your vehicle. You'll find many helpful
recommendations throughout this manual. The following are a few of the most important ones.
Follow the Age Recommendation
It is strongly recommended that no one under age of 16 be permitted to drive this EEC-approved Raider
Max 175 without adult supervision.
Always Wear a Helmet
Facts have proven that helmets can significantly reduce the quantity and severity of head injuries, so when
you drive your EEC-approved Raider Max 175, please always wear an approved motorcycle helmet. We
also recommend that you wear approved goggles, sturdy boots, durable gloves and other protective gear.
Take Time to Learn & Practice

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
9
Even if you have driven other buggies, you still should take time to become familiar with how this vehicle
works. Practice in a safe area until you have built your skills and gotten accustomed to this vehicle’s size and
weight.
Because many accidents have involved inexperienced or untrained drivers, we urge all drivers to take a
training course approved by the Buggy Safety Institute. Check with your dealer for more information on the
training course.
Be Alert to Hazards
The terrain can present a variety of challenges when you drive. Continually "read" the terrain for unexpected
turns, drop-offs, rocks, ruts and any other hazards. Always keep your speed low enough to allow time for
seeing and reacting to hazards.
Drive within Your Limits
Pushing limits is another major cause of EEC-approved Raider Max 175 accidents. Never drive beyond
your personal abilities or faster than conditions warrant. Remember that alcohol, drugs, fatigue and
inattention can significantly reduce your ability to make good judgments and to drive safely.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
10
Don't Drink and Drive
Alcohol and drive never mix. Even one drink can reduce your ability of responding to changing conditions,
and every additional drink can lengthen and worsen your reaction time. So don't drink and drive, and don't
let your friends drink and drive either.
Never Drive Indoors
The exhaust from the engine contains a tasteless, odorless but poisonous gas called carbon monoxide. For
the health of your family, please don’t drive your EEC-approved Raider Max 175 in your lovely house.
Keep away from Moving Parts
You should never place your hands or any other parts of your body near any moving parts of your vehicle.
Failure to adhere to this warning will cause physical harm to your body.
Avoid Skidding or Sliding
The terrain surface can be a major factor affecting turns. Skidding or sliding a turn is more likely to occur on
slippery surfaces such as snow, ice, mud and loose gravel. If you skid or slide on ice, you may lose all
directional controls. To avoid skidding or sliding on slippery terrain surfaces, you should keep your speed
low and drive carefully.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
11
This section presents some of the most important information and recommendations to help you drive your
EEC-approved Raider Max 175 safely. Please take a few minutes to read it.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
12
SAFETY LABELS
The labels should be considered permanent parts of
your EEC-approved Raider Max 175. If a label
comes off or becomes difficult to read, please
contact your dealer for warning label replacements.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
13
ARE YOU READY TO DRIVE?
Before each drive, you need to make sure that you and your EEC-approved Raider Max 175 are both ready
to drive. To help you be prepared, this section discusses how to evaluate your driving readiness, what items
you should check on your vehicle, and how to adjust your vehicle for your comfort, conveniences and safety.
Before driving your EEC-approved Raider Max 175 for the first time, we urge you to:
• Carefully read this owner's manual and the labels on your vehicle;
• Make sure that you understand all the safety messages;
• Learn how to operate all the controls on your vehicle;
• Ask for adult supervision if you are under 16 years old.
Before each of your drive, we urge you to be sure that:
• You feel well and you are in good physical and mental conditions;
• You are wearing an approved motorcycle helmet (with a chin strap tightened securely), approved goggles
and other protective gear;
• You don't have any alcohol or drugs in your body system.
• You have a driver’s license.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
14
Protective Apparel
For your safety, we strongly recommend that you always wear an approved motorcycle helmet, approved
goggles sturdy boots, durable gloves, long pants and long-sleeved shirt or jacket whenever you drive.
Although complete protection is not possible, wearing proper protective apparel can reduce the chances of
injuries when you drive.
The following suggestion will help you choose the proper driving gear.
1. Helmets and Eye Protection Gear
Your helmet is your most important driving gear because it offers the best protection against head injuries.
Your helmet should fit your head comfortably and securely. An open-face helmet offers some protection,
but a full-face helmet offers more. Regardless of the style, look for the helmet with an E-Mark approve
sticker.
Always wear a face shield or a pair of goggles to protect your eyes and vision.
2. Additional Driving Gear
In addition to a helmet and eye protection gear, we also recommend:

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
15
• Sturdy motorcycle boots to help protect your feet, ankles and lower legs;
• Durable motorcycle gloves to help protect your hands;
• Driving pants with knee and hip pads, a driving jersey with padded elbows, and a chest and shoulder
protector.
Driver Training
Developing your driving skills is an on-going process. Even if you have driven other Buggies, you still need
take time to become familiar with how this EEC-approved Raider Max 175 works. Practice driving this
vehicle in a safe area to build your skills. Don’t drive on rough terrain surfaces until you’ve gotten
accustomed to all the controls on this vehicle, and felt comfortable with its size and weight.
"Operating this EEC-
A
PPROVED RAIDER MAX 175 without wearing an approved motorcycle
helmet, eye protection gear, or any protective apparel could increase your chances of head
and/or eye injuries, and even possibly death in the event of severe accidents.
"Always wear an approved motorcycle helmet, an eye protection gear (goggles or a face shield),
a long-sleeved shirt or jacket, gloves, boots and long pants.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
16
Age Recommendation
It is strongly recommended that no one under age of 16 be permitted to operate this EEC-approved Raider
Max 175 without adult supervision.
No Alcohol or Drugs
Alcohol, drugs and Buggies never mix. Even a small amount of alcohol can impair your ability to operate
your EEC-approved Raider Max 175 safely. Likewise, drugs, even prescribed by your doctor, can be
dangerous when you’re operating your vehicle. Consult your doctor for the assurance that it is safe to operate
your vehicle after taking some kind of medication.
"Operating this EEC-APPROVED RAIDER MAX 175 without proper instructions could increase
your risks of accidents that could lead to serious injuries, or even death.
"A child driving a EEC-APPROVED RAIDER MAX 175 that is not recommended for his/her age
could lose the vehicle control and result in severe injury or death.
"A child under 16 should have adult supervision when operate on the vehicle.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
17
"Operating this EEC-APPROVED RAIDER MAX 175 after consuming alcohol or drugs can
seriously affect your judgments, cause you to react more slowly, affect your balance and
perception, and even could result in serious injuries or death.
"Never consume alcohol or drugs before or while operating your vehicle.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
18
IS YOUR VEHICLE READY TO DRIVE?
Before each of your drive, it is important to inspect your EEC-approved Raider Max 175 and make sure
that any problems you’ve found have been corrected. A pre-drive inspection is a must, not only for safety,
but also because a breakdown, or even a flat tire, can be a major inconvenience.
If your EEC-approved Raider Max 175 has overturned or has been involved in a collision, please don’t
drive it until your dealer has inspected it. There may be damages or other problems you can’t see.
Pre-Drive Inspection
Please check the following items before getting on your EEC-approved Raider Max 175:
"Improperly maintaining your EEC-APPROVED RAIDER MAX 175 or failing to correct a problem
before driving can cause a crash in which you can be seriously hurt or even killed.
"Always perform a pre-drive inspection before each of your drive, and correct any problems.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
19
"Engine Oil: Check the level and add oil if needed; check for leaks.
"Fuel: Check the level and add fuel if needed, and make sure the fuel filling cap is securely fastened;
check for leaks.
"Tires: Use a gauge to check the air pressure, adjust the tires if needed; look for signs of damages or
excessive abrasion.
"Nuts & Bolts: Check the wheels and all the accessible parts to see if the nuts, bolts, and fasteners are
tightened; use a wrench to tighten them if needed.
"Underbody & Exhaust System: Check for any dirt, vegetation or any other debris that could cause fire
hazards or interfere with the proper operation of your EEC-approved Raider Max 175, and remove
them.
"Air Cleaner Housing Drain Tube: Check for carbon deposits in the drain tube; if necessary, clean the
tube and check the air cleaner housing.
"Leaks & Loose Parts: Walk around your EEC-approved Raider Max 175 and look for anything that
appears unusual, such as a leak or a loose cable; repair or replace the concerned parts if needed.
"Lights: Make sure the headlights, brake lights, turning lights, rear license light and taillights etc. work
properly.

Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
20
"Throttle: Check the free play and adjust the throttle if needed; press the throttle to make sure it moves
smoothly without sticking, and release it to make sure it snaps back automatically.
"Brakes: Press the rear brake pedal several times, and check the brake pedal free play; make sure there is
no brake fluid leakage.
"Engine Stop Button: When the engine is running, press and hold the Engine Stop Button for two seconds
to see if the engine stops.
"Steering Wheel: Turn the steering wheel to see if it turns properly.
"Cable: Check the cable housing for wear and check the fittings for looseness; replace or tighten the
concerned parts if needed.
"Horn: Make sure that the horn works properly.
"Cooling System: check if the cooling system can work properly after the engine has started.
