ZC - Series
The Zone Controllers offer extended utility to the DriveRack®and ZonePRO fami-
lies. The ten Zone Controllers use analog DC voltage to provide logic control
ranging from zone source selection, volume and muting, to program or scene
selection and fire safety muting. Wired with readily available and affordable CAT5
cable with universally accepted RJ-45 connectors at distances up to 1000 ft, the ZC
Zone Controllers offer simple yet elegant solutions to the contractor.
The ZC-1 provides programmable remote volume control for the DriveRack 260,
220i and the ZonePRO products. The ZC-2 offers programmable volume and mute
control for the DriveRack 220i, 260 and the ZonePRO products. The ZC-3 can
function as a program selector for the DriveRack 260 and 220i; in addition it can
be used for as a source selector, page steering control, or a scene selector for the
ZonePRO products. The ZC-4 provides program change capability from contact
closures for the DriveRack 220i and 260; it can also provide source selection, page
steering, or scene selection for the ZonePro products. The ZC-6 is a programma-
ble volume control for the ZonePRO products. The ZC-7 is a programmable push-
to-talk page assignment controller for the ZonePRO devices. The ZC-8 provides
both programmable source selection and volume control to the ZonePro products.
The ZC-9 provides source selection for the ZonePRO 1260 and 1261. The ZC-BOB
allows “home run” or parallel wiring to the DriveRack and ZonePro products. The
ZC-FIRE is a dedicated fire safety interface for the ZonePRO products that allows
selection of either system mute or scene selection upon being triggered by either
a relay or control voltage from the fire safety system. For more information please
visit www.driverack.com or www.dbxpro.com.
• Programmable Volume
Control
• Program or Scene
Selection
• Programmable Contact
Closure Interface
• Up to 1000 ft. on CAT 5
Cable
• Programmable Push-To-
Talk Paging
• Programmable Source
Selection
ZC-1
ZC-2
ZC-3
ZC-4
ZC-BOB
ZC-6
ZC-7
ZC-8
ZC-Fire
ZC-9

Connections:
ZC-1, ZC-2, ZC-3, ZC6, ZC-7, ZC-8 and ZC-9
Connectors: (2) RJ-45
ZC-4 Connectors: (1) RJ-45, (1) 6-pin Phoenix
ZC-BOB Connectors: (7) RJ-45
ZC-FIRE: (2) RJ-45, (2) 2-pin Phoenix
Series Wiring:
Maximum Cable Length varies with number of Zone Controllers.
For Example,Three Zone Controllers: 600 ft.
Six Zone Controllers: 300 ft.
Parallel Wiring:
Using a ZC-BOB:
Up to Six Zone Controllers: 1000 ft.
Cable:
CAT5 or CAT5E with 28.6 Ohm/M (Ohm/1000 ft.) nominal DCR
and rated VW-1 or higher.
Safety Agency Certifications:
UL 60065, IEC 60065, EN 55013, E60065
ZC-Series
DriveRack and ZonePRO™ Series Wall-Mounted Zone Controllers
®
dbx engineers are constantly working to improve the quality of our products.
Specifications are, therefore subject to change without notice.
FOR MORE INFORMATION CONTACT:
dbx Professional Products
8760 S. Sandy Pkwy.
Sandy, Utah 84070
Phone [phone]
Fax [phone]
[e-mail]
http://www.dbxpro.com
A Harman International Company
The Professional’s Choice In Signal Processing™
Architects’ and Engineers’ Specifications:
ZC-1
The remote device shall provide computer programmable rotary poten-
tiometer volume control for the dbx DriveRack 260, 220i and ZonePro
devices. The remote device shall have DIP switches allowing identifica-
tion with connection to the processing device via CAT 5 cable on RJ-45
connectors. The device shall be a dbx ZC-1 remote controller.
ZC-2
The remote device shall provide computer programmable rotary poten-
tiometer and push-button volume control and muting for the dbx
DriveRack 260, 220i and ZonePro devices. The remote device shall have
DIP switches allowing identification with connection to the processing
device via CAT 5 cable on RJ-45 connectors. The device shall be a dbx
ZC-2 remote controller.
ZC-3
The remote device shall provide programmable rotary switch program
selection for the dbx DriveRack 220i and 260 devices. The remote device
shall also provide rotary switch programmable source selection, page
assignment, or scene selection for the dbx ZonePro devices. The remote
device shall have DIP switches allowing identification with connection to
the processing device via CAT 5 cable on RJ-45 connectors. The device
shall be a dbx ZC-3 remote controller.
ZC-4
The remote device shall provide programmable program selection via con-
tact closures for the dbx DriveRack 220i and 260 devices. The remote
device shall also provide contact closure programmable source selection,
page assignment, or scene selection for the dbx ZonePro devices. The
remote device shall have DIP switches allowing identification with connec-
tion to the processing device via CAT 5 cable on RJ-45 connectors. The
device shall be a dbx ZC-4 remote controller.
ZC-6
The remote device shall provide computer programmable push-button
up/down volume control for the dbx ZonePro devices. The remote device
shall have DIP switches allowing identification with connection to the pro-
cessing device via CAT 5 cable on RJ-45 connectors. The device shall be a
dbx ZC-6 remote controller.
ZC-7
The remote device shall provide programmable push-to-talk page assign-
ment for the dbx ZonePro devices. The remote device shall have DIP
switches allowing identification with connection to the processing device
via CAT 5 cable on RJ-45 connectors. The device shall be a dbx ZC-7
remote controller.
ZC-8
The remote device shall provide both programmable push-button
up/down volume control, and programmable rotary switch source selec-
tion for the dbx ZonePro devices. The remote device shall have DIP
switches allowing identification with connection to the processing device
via CAT 5 cable on RJ-45 connectors. The device shall be a dbx ZC-8
remote controller.
ZC-9
The remote device shall provide programmable source selection for the
ZonePro 1260 and 1261 devices. The remote shall have DIP switches
allowing identification with connection to the processing device via CAT 5
cable on RJ-45 connectors. The device shall be a dbx ZC-9 remote con-
troller.
ZC-BOB
The remote device shall provide up to 6 RJ-45 input jacks for “Home Run”
or parallel wiring configurations of the dbx ZC wall panel controllers, and
one output RJ-45 jack for connection to the dbx DriveRack or ZonePro
device. The device shall be a dbx ZC-BOB remote controller.
ZC-FIRE
The remote device shall provide either output muting or programmable
scene selection for the dbx ZonePro devices. Connection to the fire safety
system shall be either through a relay or directly to the control voltage
output. The remote device shall have DIP switches allowing identifica-
tion with connection to the processing device via CAT 5 cable on RJ-45
connectors. The device shall be a dbx ZC-FIRE remote controller.
