De Agostini Model Space HUMMER H1 User manual

HUMMER H1: STEP BY STEP ™
95
RADIO CONTROL CAR
BUILDANDDRIVEYOUROWN
The ultimate 4WD
Radio Control Car
Pack 5 Stages 21-25
™

HUMMER H1: STEP BY STEP ™
96
Editorial and design by Continuo Creative, 39-41 North Road, London N7 9DP
All rights reserved © 2013 De Agostini Publishing USA, 915 Broadway, Suite 609, NEW YORK, NY 10010
NOT SUITABLE FOR CHILDREN UNDER THE AGE OF 14. THIS PRODUCT IS NOT A TOY AND IS NOT DESIGNED OR INTENDED FOR USE IN PLAY. ITEMS MAY VARY FROM THOSE SHOWN.
Photo credits All photographs copyright
© DeAgostini
Visit our website www.model-space.com
Contents
Stage 21
Beginning to assemble the chassis
Stage 22
Assembling the main chassis
Stage 23
Beginning the front dierential
Stage 24
Completing the front dierential
Stage 25
Assembling the front bulkhead
Page 95
Page 98
Page 103
Page 107
Page 111
RADIO CONTROL CAR

HUMMER H1: STEP BY STEP ™
95
Stage 21
Front chassis plate
Rear chassis plate
4 × 16mm countersunk screws × 4
Beginning to assemble the chassis
Your parts
Phillips screwdriver Rear bulkhead assembly (Stage 16)
Tools and
materials

HUMMER H1: STEP BY STEP ™
96
111
222
444
333
555
666
This is the front of the rear chassis plate. Note that none of the
holes on this side are countersunk.
Turn the parts over, holding them together carefully to prevent
the assembly slipping. Check that the holes are properly aligned.
Insert one of the 4 × 16mm countersunk screws into one of the
four holes you lined up in the previous two steps.
Make a note of which
chassis plate is which,
by laying them next
to each other on your
work surface. The front
plate is the smaller of
the two. As you will be
assembling the rear
chassis in this session,
store the front plate
away safely for now.
Take a closer look at the rear chassis plate – you will see that its
front and back surfaces are dierent. On the back, shown here,
some of the holes are countersunk (see red circle). This is to
allow the heads of the countersunk screws to sit ush with the
surface of the plate once they are screwed in.
Hold the rear chassis plate with the front facing upwards in
one hand, and with the other line up the rear bulkhead you
assembled in Stage 16. Line up the holes shown by the arrows.
Rear chassis plate – front
Rear chassis plate – back

HUMMER H1: STEP BY STEP ™
97
This stage is complete. Store the parts
away safely, resting both chassis plates at
during storage to lower the risk of their
becoming bent out of shape.
777
999
111111
888
101010
121212
Tighten with a screwdriver, but
do not screw in all the way.
Tighten with a screwdriver, again without too much force.
Check that the chassis plate is secure and does not rattle or
move, but that the screws are not too rmly tightened.
Insert another screw into the hole diagonally opposite.
Repeat with the remaining two screws.
From the front, your
assembly should look
like this. Note the
positioning of the holes
on the plate.
Tip!
You will notice that the screws
do not sit ush with the plate.
This is because other parts will
be added in later stages. Do not
overtighten the screws as this
may deform the holes and create
problems in the future.
Assembled parts

HUMMER H1: STEP BY STEP ™
98
Stage 22
Middle chassis plate
3 × 10mm countersunk screws × 11 (1 is a spare)
3mm ange nuts × 11 (1 is a spare)
Assembling the main chassis
Your parts
Tools and
materials
Phillips screwdriver
Crosswrench (Stage 8)
Thread-locking adhesive (or
rubber-based adhesive)
Masking tape
Front chassis (Stage 21)
Rear bulkhead (Stage 21)
Rear torque rod (Stage 8)
4 × 10mm binding head screws × 2 (Stage 8)
3 × 10mm countersunk screws × 2 (Stage 8)

HUMMER H1: STEP BY STEP ™
99
111
333
222
444
555
Line up the front chassis supplied with Stage 21 to the main
chassis. On both chassis plates, the side with the countersunk
holes should face upwards. Line up the holes as arrowed.
The screw will go right through both holes so that its
countersunk head sits ush with the plate’s surface. At this
stage, the screw is still moving freely within the hole.
Make a note of the shape of the 3mm ange nuts you will use
to secure the chassis plate. The back side is set with ridges that
bite into the surface of the plate for a stronger hold.
Make a note of which side of the
middle chassis is which, as they are
dierent to one another. Some of
the holes on the back of the plate
are countersunk, and the edges of
the front are angled upwards.
Insert a 3 × 10mm countersunk screw through the central hole
on the front chassis and into the hole on the middle chassis.
Both edges are angled upwards.
Holes on the front are not countersunk.
Holes on the back are countersunk.
BackFront
Front Back
Using masking tape
As at this stage the screws are not secured, it is
useful to hold them in place with masking tape
until the ange nuts are added in the next few
stages. This way, all ve screws can be positioned
at the same time without the risk of any falling
out.
With the tape holding the screws in
place, it is safe to move the assembly.
Place masking tape across the screws
once they are inserted.

HUMMER H1: STEP BY STEP ™
100
As you did in Stage 6,
tighten the ange nut
onto the protruding tip of
the screw by hand.
Next, position the middle
chassis so its back is facing
upwards, and line up the
holes arrowed with those
on the rear chassis you
attached to the bulkhead
in Stage 21.
Repeat until all ve sets of
screws and ange nuts are
tted.
Place another 3 × 10mm
countersunk screw into
the central hole of the
rear chassis. Make sure the
side with the countersunk
holes is facing you.
666
101010
888
121212
777
111111
999
131313
Turn the assembly so that
the front of the middle
chassis is facing upwards.
Holding the screw head
from behind to keep it
in place (using masking
tape will help this, see box
on page 99), t a 3mm
ange nut onto the end of
the screw and tighten by
hand.
Line up the side of the
crosswrench supplied with
Stage 8 marked '5.5' with
one of the ange nuts, as
arrowed.
Once the rst ange nut is
tightened by hand, line up
the next screw from the
back side of the chassis.
Hold the crosswrench over
the ange nut to stop it
from moving, and begin
to tighten the screws from
the other side, this time
using a screwdriver. Turn
until the hold is rm, and
repeat for all ve sets of
screws and ange nuts.
hand.
Tip!
Wet the protruding tip of the screw
with a little thread-locking adhesive
to further secure the hold.

HUMMER H1: STEP BY STEP ™
101
Once the rst ange nut
is tightened by hand,
continue to line up the
next screw from the back
side of the chassis plate.
Next, prepare the rear
torque rod that was
supplied with Stage 8, two
4 × 10mm binding-head
screws and two 3 × 10mm
countersunk screws.
Fit the next ange nut,
again only tightening it by
hand.
Position the rear torque
rod as pictured, so as to
connect the rear bulkhead
to the chassis.
141414
181818
161616
202020
151515
191919
171717
212121
The screw will go right through both holes so that its
countersunk head sits ush with the surface. At this stage, the
screw is not tightened, so hold it in place carefully.
Repeat until all ve sets of
screws and ange nuts are
in place.
Rotate the chassis and tighten a ange nut by hand onto the
tip of the screw, as you did in Stage 6.
As you did in Stage 11,
rmly tighten each set of
screws and ange nuts by
using the crosswrench and
Phillips screwdriver.
torque rod that was
supplied with Stage 8, two
4 × 10mm binding-head
screws and two 3 × 10mm
countersunk screws.
202020

HUMMER H1: STEP BY STEP ™
102
222222
242424
272727
262626
232323
252525
This stage is now complete, and
the chassis of your Hummer H1
is begining to take shape. Store
away safely until next time.
Insert one of the 4 × 10mm binding-head screws into the hole on
the torque rod (see arrow).
Repeat Steps 22 and 23 with the other
binding-head screw.
Tighten with a screwdriver. Repeat with
the second screw.
Tighten with a screwdriver.
Turn the assembly upside down, and
locate the two holes just ahead of the
joint between the rear and middle chassis
plates, circled. The countersunk holes
should be facing you.
Insert a 3 × 10mm countersunk screw into
one of the holes, making sure it is lined up
with one of the holes on the end of the
torque rod behind.
This stage is now complete, and
the chassis of your Hummer H1
is begining to take shape. Store
Assembled parts

HUMMER H1: STEP BY STEP ™
103
6mm O-ring
6 × 12mm shim
Dierential bevel (20T)
2.5 × 10.3mm metal pin
Beginning the front dierential
Your parts
Tools and
materials
Tweezers
Toothpick
Tissue paper
Dierential case
Dierential cup joint
1510 ball bearing
Bevel gears (10T) × 2
Bevel shaft
Grease (Stage 11)
Stage 23

HUMMER H1: STEP BY STEP ™
104
111
111
333
555
222
222
444
666
Place the 1510 ball bearing onto the cylindrical segment of the
dierential case, making sure it is on straight.
Apply a little of the grease you kept from Stage 11 to the tip of
a toothpick.
Now apply some grease
to the thin end of the
dierential cup joint.
Use the photo to gauge
a suitable amount.
Turn the joint from right
to left to spread the
grease. If grease builds
up between the ball
bearing and the case,
wipe it with tissue paper.
Insert the greased end
of the joint into the
case, as shown.
Turn the dierential
case around, and using
tweezers, place the 6mm
O-ring over the tip of the
joint inside.
Using both thumbs, push down on the ball bearing evenly,
being careful not to apply too much pressure, as this could
damage the ball bearing.
Using the toothpick, spread the grease around the groove on
the inside of the dierential case, as shown. Use just enough so
that the groove shines slightly.
Fitting the ball bearing to the dierential case
Assembling the inside of the dierential

HUMMER H1: STEP BY STEP ™
105
777
111111
999
131313
888
121212
101010
141414
Part the tweezers slightly, and gently push the O-ring down into
the groove at the base of the joint.
Your assembly should look like this, with equal parts of the
metal pin visible on each side of the joint.
Using tweezers, carefully line up the 2.5 × 10.3mm metal pin
with the hole drilled through the dierential joint.
Make a note of the rectangular groove in the back of the 20T
dierential bevel. The metal pin you tted in Stage 10 will sit
inside this once tted.
Next, place the 6 × 12mm shim over the shaft so that it rests
at the base, covering the O-ring. It does not matter which way
round the shim goes.
Liberally apply grease to the inside of the dierential case,
covering the shim and joint.
Carefully insert the metal pin through the hole with the
tweezers, as shown. Using the recesses cut into the inside of the
dierential case will allow you more space to position the pin.
Slide the bevel over the tip of the joint so that the groove on
the back lines up with the metal pin.

HUMMER H1: STEP BY STEP ™
106
151515
191919
171717
161616
202020
181818
Press the bevel into place with your nger.
Liberally apply grease to the inside of the dierential case, but
do not nish the bag of grease, as you will need it in future
stages.
With the 10T bevels together as shown in the photo, place the
bevel shaft into the dierential case. The ends of the bevel shaft
should t into the recesses in the side of the case.
Slide each of the 10T bevels onto the bevel shaft, so that they
are facing each other.
Holding the dierential case steady, slowly turn the joint from
the back to distribute the grease evenly among the moving
parts.
The rst half of
your Hummer H1's
front dierential
is complete. Your
assembly should
look like this.
Once in place, slide the two 10T bevels apart as far as they will
go. At this point, they should slot neatly into place with the
teeth of the 20T bevel beneath.
It is very important that you store the
parts assembled in this session away
from any dirt or dust, as this will stick
to the grease and get inside the
dierential, casuing problems
for the moving
parts within. If
possible, keep
your assembly and
grease in a sealed
plastic bag.
dierential, casuing problems
Assembled parts

HUMMER H1: STEP BY STEP ™
107
Completing the front dierential
使用する道具
107
使用する道具
使用する道具
Dierential case (Stage 23)
Grease (Stage 11)
Your parts
6 × 12mm shim
2.5 × 10.3mm metal pin
Bevel gear (20T)
2.6 × 12mm countersunk screws × 5
Dierential ring gear (43T)
Dierential cap
Dierential cup joint
1510 ball bearing
6mm O-ring
Tools and
materials
Tweezers
Toothpick
Phillips screwdriver
Stage 24

HUMMER H1: STEP BY STEP ™
108
111
111
333
555
222
222
444
666
Place the end of the
joint into the hole on the
inside of the projection
that the bearing was
placed over.
Place the 6mm O-ring
over the end of the joint.
Insert the joint into the
hole, slowly rotating it
back and forth to spread
the grease.
Push the O-ring down
onto the joint until it sits
in the recess from Step 1.
Apply some grease to the dierential cup joint.
Place the 1510 ball bearing over the projection on the
dierential case.
Press the bearing rmly into position on the projection. Make
sure the bearing is aligned with the case.
Place a small amount of grease onto the end of a toothpick, and
apply some grease to the recess in the centre of the inside of
the dierential case.
Fitting the bearing onto the dierential case
Assembling the dierential gear

HUMMER H1: STEP BY STEP ™
109
777
111111
999
131313
888
121212
101010
141414
Adjust the pin so it is positioned evenly in the joint, as shown.
Insert the 2.5 × 10.3mm pin into the hole in the joint, just above
the shim.
Hold the 20T bevel gear, as shown. Locate the groove on the
back of the gear.
Place the 6 × 12mm shim over the joint and push it down to
rest on the O-ring.
Smear some extra grease around the shim and the joint.
Align the groove on the back of the bevel gear with the position
of the pin and place the gear into the back of the case, sliding it
over the joint.
Push the bevel gear down onto the joint until the pin slots into
the groove. Retrieve the dierential gear assembly from the
previous stage.
Apply a large amount of grease into the back of the
dierential case.

HUMMER H1: STEP BY STEP ™
110
151515
171717
161616
181818
Locate the four screw
holes on both the
dierential case and cap
assemblies.
Place the 43T gear over
the end of the joint.
Align the four screw holes
of the gear with those of
the case.
Place the two assemblies
together, aligning the
screw holes of both.
191919
202020
Insert one of the 2.6 × 12mm self-tapping countersunk screws
into one of the holes and tighten until halfway in. Then, following
the order shown in the diagram on the right, tighten the next
three screws halfway into their holes, and when all four are in
place, fully tighten them in the same order.
Turn the cup joints in opposite directions to spread the grease
around the internal gears.
Assembled parts

HUMMER H1: STEP BY STEP ™
111
Stage 25
Front shock stay
Lower bulkhead
Upper bulkhead
5 × 4mm set screw
Cup joint
Driveshaft (with 13T bevel pre-tted)
1680 ball bearings × 2
4 × 25mm binding-head screws × 2
4 × 10mm binding-head screws × 2
Assembling the front bulkhead
Your parts
Phillips screwdriver
2.5mm Allen key (Stage 7)
Thread-locking adhesive (or rubber-based
adhesive)
Front dierential (Stage 24)
Grease (Stage 11)
Paper
Tools and
materials

HUMMER H1: STEP BY STEP ™
112
111
555
333
777
222
666
444
888
Make a note of the shape and orientation of the upper and
lower bulkheads. The inside of the lower bulkhead has a at
surface, marked in the photo.
Make sure the ball bearing is sitting ush with the bevel.
Your assembly should look like this, with the dierential case
sitting snugly into the lower bulkhead, and the right and left
ball bearings resting in the cylindrical recesses on either side
(circled).
Place the assembled driveshaft into the recess at the back of
the lower bulkhead (arrowed).
Place the dierential you assembled in Stage 24 carefully into
the lower bulkhead, with the ring gear on the right side of the
bulkhead.
Now slide the second 1680 ball bearing over the driveshaft until
it rests in the middle, leaving a gap between it and the rst.
Slide one of the 1680 ball bearings over the driveshaft so that it
rests against the back of the pre-tted 13T bevel gear.
The driveshaft should sit so that the ridge in the recess
separates the two ball bearings, and the teeth of the 13T bevel
engage those of the 43 ring gear.
Upper Lower
Front
Ridge
Back
