STAGE PAGE
68 Heating parts 285
69 Central frame and heating duct 289
70 Front suspension 293
71 Left front wheel suspension 297
72 Front suspension 301
73 The electrical system 305
74 Left side door 309
75 Left side door window 313
76 Left side door inner panel 317
77 Left side door trim 321
78 Right side door 325

Step by Step
285
Diagram
Stage 68:
heating parts
Your parts
68-1 Front heating jacket upper
68-2 Front heating jacket lower
68-3 Pedal cables
68-4 Brake fluid line
68-5 Tube
68-6 Clutch cable
68-7 Screws 2.3 x 4mm (BD04)
68-8 Screws 1.8 x 3mm (BP09)
68-4 68-5 68-6 68-7 68-8
68-368-268-1
68-1
68-8
68-2
68-5
68-6
68-4
68-8
68-7
68-3

286
VW Samb
STEP 68-A
Combine the two parts of the
front heating jacket (68-1 and
68-2), as shown. Secure them
with two BP09 screws (68-8).
STEP 68-D
Turn the chassis upside down
again and fit the brake fluid
line (68-4) alongside the front
heating jacket. Secure the line
from above with two BP09
screws (68-8).
STEP 68-B
Turn the chassis over and insert the posts on the
heating jacket into the two indicated holes.
STEP 68-C
Turn the chassis back over and secure the front
heating jacket with two BD04 screws (68-7).

Step by Step
287
STEP 68-E
Next, fit the clutch cable
(68-6) to the indicated
points in the chassis.
STEP 68-G
Then install the three
pedal cables (68-3) at
the positions shown.
STEP 68-F
Press the ends of the
cable into the holes.

288
VW Samb
STAGE COMPLETE
Completed model
STEP 68-H
Finally, fit the tube
(68-5) into the
indicated hole in
the chassis.

Step by Step
289
Diagram
Your parts
69-1 Central frame
69-2 Heating duct
69-3 Screws 1.8 x 3mm (BP03)
69-4 Screws 2.3 x 4mm (BD04) 69-1 69-2
69-3 69-4
69-1
69-2
69-3
69-4
Stage 69:
Central frame and
heating duct

290
VW Samb
STEP 69-A
The end of the
heating duct (69-2)
is semicircular.
STEP 69-D
Mount the frame over the heating duct, onto the chassis,
with the angled section identified in the previous step
towards the rear.
STEP 69-C
Now identify the end of the central frame
(69-1) that angles out slightly.
STEP 69-B
Turn the chassis upside
down and place the
heating duct (69-2)
along the centre of
the chassis, in the two
recesses in the frame.

Step by Step
291
STEP 69-F
Secure the rear of the
frame with two BP03
screws (69-3).
STEP 69-E
Press the frame into
place, as shown.
STEP 69-G
Then secure the front
of the frame with two
BD04 screws (69-4).

292
VW Samb
Completed model
STAGE COMPLETE

Step by Step
293
Diagram
Stage 70:
Front suspension
Your parts
70-1 Front suspension lower
70-2 Front suspension upper
70-3 Right suspension stop
70-4 Left suspension stop
70-5 Steering damper body
70-6 Screws 2.3 x 4mm (BD04)
70-1 70-2
70-3 70-4 70-5 70-6
70-2
70-1
70-6
70-5
70-3
70-4
70-6

294
VW Samb
STEP 70-A
Place the steering damper
body (70-5) over the
indicated hole in the front
suspension lower (70-1).
Secure with a BD04
screw (70-6).
STEP 70-C
The suspension stops each have
a letter indicating the side of the
suspension where they fit: R for
the right stop (70-3) and L for
the left (70-4).
STEP 70-D
Fit the left suspension
stop (70-4) into the
slot in the left side of
the front suspension
upper (70-2).
STEP 70-B
Identify the sides of the
front suspension upper
(70-2). Each side is
identified by a letter: L
for the left side, R for
the right side.
R
RL
L

Step by Step
295
STEP 70-E
Fit the right suspension
stop (70-3) at the other
end of the part.
STEP 70-G
Secure the parts with
two BD04 screws (70-6).
STEP 70-F
Insert the two posts
of the suspension
lower into the
corresponding holes in
the suspension upper.

296
VW Samb
Where the parts fit
STAGE COMPLETE
STEP 70-H
Tighten two additional
BD04 screws (70-6)
into the holes in the
rear of the suspension.

Step by Step
297
Diagram
Your parts
71-1 Left upper suspension arm
71-2 Left lower suspension arm
71-3 Shock absorber body
71-4 Shock absorber shaft
71-5 Shock absorber spring
71-6 Washers
71-7 Steering rack
71-8 Plate
71-9 Screw 2.3 x 3 (BP10)
71-10 Screw 2.3 x 5 (BD06)
71-6 71-7 71-8 71-9 71-10
71-1 71-2 71-3 71-4 71-5
71-3
71-6
71-10
71-9
71-10
71-5
71-4
71-1
71-9
71-2
71-9
71-10
Stage 71:
left front
wheel suspension
71-6

298
VW Samb
STEP 71-A
Fit the shock absorber
shaft (71-4) onto the left
lower suspension arm
(71-2). Secure the strut
to the arm with a BD06
screw (71-10).
STEP 71-C
Place the shock spring (71-5) onto the
shock shaft.
STEP 71-D
Hold the shock absorber body (71-3) as shown, and fit it
over the spring.
STEP 71-B
Retrieve the front
suspension assembly
from Stage 70 and fit the
lower suspension arm
onto the left side of the
assembly. Secure the
lower arm with a BP10
screw (71-9).

Step by Step
299
STEP 71-E
Secure the shock body
to the suspension with a
BP10 screw (71-9).
STEP 71-G
Retrieve the left front
wheel and place the
wheel hub between
the suspension arms,
as indicated.
STEP 71-H
Then insert one of the
washers (71-6) into
the upper arm and
secure with a BD06
screw (71-10).
STEP 71-F
Fit the upper left
suspension arm (71-1)
onto the indicated part of
the suspension assembly
and secure with a BP10
screw (71-9).

300
VW Samb
Where the parts fit
STAGE COMPLETE
STEP 71-I
Place the other washer
(71-6) into the lower arm
and secure the with another
BD06 screw (71-10).

Step by Step
301
Diagram
Your parts
72-1 Right upper suspension arm
72-2 Right lower suspension arm
72-3 Shock absorber body
72-4 Shock absorber shaft
72-5 Shock absorber spring
72-6 Washers
72-7 Steering damper shaft
72-8 Right steering arm (short)
72-9 Left steering arm (long)
72-10 Screws 1.8 x 3.5mm (BD03)
72-11 Washer screws 2.3 x 5 x 6mm
(BD06)
72-12 Washer screws 2.3 x 3 x 6mm
(BD07)
72-13 Screws 2.3 x 5mm (BP05)
72-14 Washer screws 2.3 x 3 x 6mm
(BP10)
72-1
72-14
72-7 72-8 72-9 72-10 72-11 72-12
72-13
72-2 72-3 72-4 72-5 72-6
72-11
72-14
72-5
72-4
72-14
72-1
72-3
72-14
72-2
72-11
72-6
72-6
Stage 72:
Front suspension

302
VW Samb
STEP 72-C
Place the shock spring
(72-5) onto the shock shaft.
STEP 72-A
Fit the shock absorber shaft (72-4) onto the
right lower suspension arm (72-2). Secure the
strut to the arm with a BD06 screw (72-11).
STEP 72-B
Retrieve the front suspension assembly from Stage 71 and
fit the lower suspension arm onto the right side of the
assembly. Secure the lower arm with a BP10 screw (72-14).
STEP 72-D
Fit the shock absorber
body (72-3) over the
spring. Secure the
shock body to the
suspension with a
BP10 screw (72-14).
