Decor Star PL-014-SS User manual

Decor Star PL-014-SS Rev. A2 1220151
Features
- Stunning stylish European inspired design
- Durable stainless steel frame construction
- Square stainless thin prole shower head
- 4 swivel massage body jets
- 3 stage shower functions (Rainfall, Massage Spray, Hand Shower)
- Contemporary brass hand shower
- Tempered glass shelf
Decor Star PL-014-SS

Decor Star PL-014-SS Rev. A2 1220152
Thank you for purchasing Decor Star products. Please read the information below and keep this
installation guide for future reference. If you require assistance, please contact our customer service
department at 1-800-879-1197, Monday - Friday 10AM - 5PM Paci c Time. Or by email at
[email protected].
Limited Two (2) Year Warranty (For USA Only)
The manufacturer warrants this product to be free of manufacture defects during daily normal
household use for as long as it is owned by the original purchaser of this product. Please keep a
copy of the original invoice as proof of purchase.
Should a malfunction occur within the warranty period, Décor Star USA will, as its option, (1)
repair or replace the defective part(s) or product(s) at no charge; (2) issue a refund of the original
purchase price of the product(s) (Valid within 30 days from the date of purchase); or (3) issue a
credit to be applied toward the purchase of a new Décor Star product. Shipping/delivery charges
may apply and are in Décor Star USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence,
improper installation, product abuse, product misuse, or use of cleaners containing abrasives, alcohol
or other organic solvents, whether performed by a contractor, service company, or yourself, are
excluded from this warranty.
Our responsibility under this limited warranty is limited to only to replacement parts and no other
costs. Décor Star USA will not be responsible for labor charges and/or damage incurred by
installation, repair or replacement, nor for any indirect incidental or consequential damages, losses,
injury or costs of any nature relating to this product. Except as provided by law, this limited warranty
is in lieu of and excludes all other warranties, conditions, and guarantees, whether expressed or
implied, statutory or otherwise, including without restriction those merchantability of  tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased
and installed in the United States. This limited warranty covers the original consumer purchase only
and does not include business, commercial or industrial use of this product. To obtain service under
the Limited Warranty, please contact Decor Star USA at [email protected]. The Decor Star
USA Customer Care Department will determine whether to repair or replace your product, issue a
refund, or issue a credit.

Decor Star PL-014-SS Rev. A2 1220153
Attention
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional if
necessary.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this product.
• Proper water pressure needs to be maintained to prevent possible scalding.
• Stainless steel shower panels are handmade and assembled. Product dimensions may vary
slightly, always measure the actual product before installation.
You may also need the following tools
1. Thread Sealant Tape, (PTFE Tape) 5. Pencil or Marker
2. Silicon Sealant 6. Level
3. Phillips Screw Driver 7. Hammer
4. Drill with ¼” Drill bit
Before You Begin
• Read and understand this instructions completely before installation.
• Unpack and inspect the shower panel from the package for shipping damage and make sure all
parts are included with the shower panel.
• Keep the product in its package until you are ready to install.
• Read and understand this installation guide completely.
• Make sure the installation site is clean and free of dust and debris.
• Please make sure the water supply is shut off to the installation area. If necessary, shut off the
water to the entire house.
• Turn on the water at a bathroom faucet in the house to relieve the pressure in the plumbing
system.
Rough-In
• Please follow all local building and plumbing codes.
• The height and placement of the shut off valves will be based on the installation height of
the shower panel, see  gure A. The installation height is approximately the total distance of
measurement A and measurement B.
• The  nished wall opening for the valves should not be larger than 4.5” wide by 6” tall. Make sure
the opening is completely waterproof to prevent any water leaking into the wall space. (NOTE:
Product warranty does not cover any damages caused by water leak due to negligent and
improper installation of the shut off valves and the shower panel.)
• A laundry outlet box such as the Sioux Chief Ox BoxTM can be used to speed up the installation
process of the shut off valves.

Decor Star PL-014-SS Rev. A2 1220154
Recommended
10” - 12”
Approximate shower inlet
valve location
laundry outlet
box
(This is the distance from
the oor to the bottom
edge of the shower panel)
Reference Model Height is 5’8”
Fig. A
(This is the distance from
the bottom edge of the
shower panel to the valve.
NOTE: This distance vary
by models, always take the
actual measurement from
the shower panel)
A
B
The installation height of the outlet box
is approximately the total distance of
measurement A and measurement B.
It is recommened to aim the top hori-
zontal body jets at the chest area of the
user for optimal showering experience.

Decor Star PL-014-SS Rev. A2 1220155
Technical / Flow Rate Data
Compliance with the following code(s) and standard(s):
Uniform Plumbing Code (UPC®)
National Plumbing Code of Canada
IGC 154-2013 and ASME A112.18.1-2012/CSA B125.1-12
Recommended Operating Pressure: 50 - 80 psi
Approx. ow rate: 2.34 gpm at 80 psi
1,300mm
51.18”
180mm
7.09” 350mm
13.78”
790mm
31.1”
225mm
8.86”
330mm
12.99”
60mm
2.36”
390mm
15.35”
*All Measurements are Approximate

Decor Star PL-014-SS Rev. A2 1220156
01. Shower Panel Body
02. Shower Arm
03. Screen Washer
04. Stainless Steel Shower Head
05. Glass Shelf
06. Metal Nut
07. Overhead water connector
08. Hand Shower water connector
09. Nut
10. Brass Hand Shower
11. Hand Shower Cradle
12. Gasket
13. Hand Shower Hose
14. Screws X 4
15. Hanging Bracket X 2
16. Wall Anchor X 4
Parts List
14 15
16
1
2
3
4
5
6 7
89
10
11
12
13

Decor Star PL-014-SS Rev. A2 1220157
1. Attach shower arm assembly to the panel body.
2. Install hand shower connector and attach PVC tub-
ing to complete the connection.
790mm
31.1”
3. Lift the panel to determine the proper height and
placement. (NOTE: It is recommened to aim the top
horizontal body jet to the chest area for optimal show-
ering experience.)
Mark the positions of the 2 brackets on the wall and set
a side the panel. (NOTE: The distance between the two
brackets should be 790mm or 31.1”)
Installation

Decor Star PL-014-SS Rev. A2 1220158
6. Apply thread sealant tape to the threading on the
shut off valves before connect both hot and cold water
supply hoses to the valves. Turn on the valves and
check all connections for possible leaks.
1”
4. Using a drill with a tile bit, drill the hole slowly into
the tile. Do not drill into any piping or wiring in the
wall. Insert the anchors into the wall. (NOTE: Before
installing the wall anchors, use a small piece of paint-
ers tape or masking tape over the drill area. This will
prevent damages to the tile)
5. Secure the mounting brackets to the wall.
Installation (cont.)

Decor Star PL-014-SS Rev. A2 1220159
8. Attache shower head. Make sure to install screen
washer (03) to protect shower head from debris in the
plumbing system.
9. Connect hand shower hose to the main panel body.
Install the rubber washer. (10)
7. Hang the unit on the wall to complete the instal-
lation. Make sure the unit is seated properly. Apply
silicon sealant on left and right sides of the shower
panel. (NOTE: do not seal the bottom of the panel,
this will allow any possible future leaks to drain out
the panel)
Installation (cont.)

Decor Star PL-014-SS Rev. A2 12201510
11. Loosen the set screws under the anchors to insert
the glass shelf. Tighten the set screws to secure the
glass shelf.
(WARNING: Do not place heavy objects on the glass
shelf. Do not excess weight limit of 2 pounds when
placing objects on the shelf)
10. Attach the hand shower to the hose.
Installation (cont.)

Decor Star PL-014-SS Rev. A2 12201511
Operation
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. In addition, pay attention to the
following points:
1. Regular cleaning can prevent mineral build up on shower head and handheld shower.
2. Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
3. Do not use abrasive / harsh chemical when cleaning the  xture as they will damage and dull the
 nish.
3. Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
4. Test the cleaner on a small area before using on the entire surface.
5. Do not leave the cleaner on the  xture longer than necessary.
6. When using spray cleaners, spray  rst onto a soft cloth or sponge. Never spray directly onto the
faucet as droplets can enter openings and gaps and cause damage.
5. After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
Overhead Rainfall Shower Horizontal Body Jets
Handheld Shower
1. To operate the unit lift up the handle to turn on water.
2. Swivel handle from side to side to set desired water temperature.
3. Turn the top knob to select desired water feature.
