Blanke DIBA-LINE 2.0 Configuration guide

General information
Limescale from water, hair, skin particles, soap, shower gel and sham-
poo contribute that soiling in the channel and drain area arises with
daily use of the shower. This soiling can be removed as necessary.
For convenience, household, non-aggressive or non-abrasive clean-
ing products can be used. These must not contain any solvents or
acids. Furthermore, the grate covers must not be cleaned with steel
wool or wire brushes.
Page 1 of 2
CLEANING INSTRUCTIONS
Cleaning instructions for BLANKE LINEAR DRAINAGE UNITS:
BLANKE DIBA-LINE 2.0 and BLANKE DISK-LINE
BLANKE DIBA-LINE EC and BLANKE DISK-LINE EC
BLANKE DIBA-LINE SL and BLANKE DISK-LINE SL

Stenglingser Weg 68-76
58642 Iserlohn/Germany
[e-mail]
Iwww.blanke-systems.de
Author: AWT 18.01.2018
Page 2 of 2
T+49 2374 507-0
F+49 2374 507-4230
Blanke GmbH & Co. KG
CLEANING INSTRUCTIONS
Cleaning instructions for BLANKE LINEAR DRAINAGE UNITS
1 The grate cover is raised and lifted out using the grate lifter (white plastic lever) included in
the scope of delivery.
2 Remove the hair sieve by hand. 3 Remove coarse soiling in the channel body with owing warm water and household
cleaning products. A sponge or a brush is helpful
here. The same procedure has to be applied on the
hair sieve. Rinse the drain with plenty of water pri-
or to reinstillation.
1 The grate cover is raised and lifted out using the grate lifter (white plastic lever) included in
the scope of delivery.
2 Push the grate lifter up into the groove of the drain connection nozzle and press it out; this is
towards the wall or away from the wall depending
on the installation situation.
3 Remove coarse soiling in the channel body with owing warm water and household
cleaning products. A sponge or a brush is helpful
here. The same procedure has to be applied on the
drain connection nozzle. Grease the sealing ring of
the drain connection nozzle prior to reinstillation
(e.g. with tting grease or Vaseline).
1 The grate cover is raised and lifted out using
the grate lifter (white plastic lever) included
in the scope of delivery.
2 Grip the siphon on both sides and press it out
of the drain connection; this is towards the
wall or away from the wall depending on the in-
stallation situation.
3 Remove coarse soiling in the channel body
with owing warm water and household
cleaning products. A sponge or a brush is help-
ful here. The same procedure has to be applied
on the siphon. Grease the insertion connector of
the siphon prior to reinstillation (e.g. with tting
grease or Vaseline).
BLANKE DIBA-LINE 2.0 and BLANKE DISK-LINE
BLANKE DIBA-LINE EC and BLANKE DISK-LINE EC
BLANKE DIBA-LINE SL and BLANKE DISK-LINE SL
Attention: During installation please refer to the notes in our latest technical data sheets. All work must also be carried out in compliance with current industrial standards.
