Orbital Systems Oas Standard User manual

Oas Standard : Compressed installation process

Please note: This document does not replace the
installation manuals. For installation purposes, please
use the respective Oas installation manuals.
Oas Standard

• Prepare shower space
Step. 1

• Mount Drain Unit and sewage piping
Step. 2

• Mount piping to Shower Heads, Diverter
and Control Dial
Step. 3

• Install incoming water (hot & cold)
• Install power supply
Step. 4

• Cover wall
• Raise floor
Step. 5

• Apply waterproofing membrane
Step. 6

• Tile walls & floor
• Mount Core brackets and fixtures
Step. 7

Step. 8
• Mount Oas Core to brackets
• Install Smart Sensor in Drain Unit

• Install Shower Heads, Diverter and
Control Dial
• Connect cables and pipes to Oas Core
Step. 9

For comprehensive installation material please visit
www.orbital-systems.com
Installation completed

CERTIFIED SPACE TECHNOLOGY
www.orbital-systems.com
