DeDietrich C 610 ECO User manual

C 310 ECO - C 610 ECO
Gas fired condensing boiler
User Guide
300015183-001-A
EN

2C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.1 Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2 Safety instructions and recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2.2 Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
4 Use of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.1 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.2 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.3 Changing the settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4.4 Stopping the boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.5 Commissioning the boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Checking and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
6.1 Identification plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
6.2 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7 Technical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
8 Energy savings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

3
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
1Introduction
1.1 Symbols used
Caution danger
Risk of injury and damage to equipment. Attention must be
paid to the warnings on safety of persons and equipment.
Specific information
Information must be kept in mind to maintain comfort.
ZReference
Refer to another manual or other pages in this instruction
manual.
DHW: Domestic hot water
SMI: Integrated mixer system
1.2 Introduction
Congratulations on your choice of a high quality product. We
strongly advise you to read the following instructions in order to
guarantee the optimal operation of your appliance. We are sure
that it will be entirely to your satisfaction and will meet with all
of your expectations.
`Keep these instructions in a safe place close to the appliance.
`For a proper operating of the boiler, follow carefully the
instructions.
`The manufacturer is not liable for any improper use of the
appliance or failure to maintain or install the unit correctly (the
user shall take care to ensure that the system is installed by a
qualified fitter).
`In the interest of customers, De Dietrich Thermique SAS are
continuously endeavouring to make improvements in product
quality. All the specifications stated in this document are
therefore subject to change without notice.
`Get your fitter to explain your installation to you.

4C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
2 Safety instructions and recommendations
2.1 Safety instructions
Fire hazard
Do not stock products of an inflammable nature close to
the appliance.
If you smell gas, do not use a naked flame, do not smoke,
do not operate electrical contacts or switches (doorbell,
lights, motor, lift, etc.).
1. Cut the gas supply
2. Open the windows
3. Extinguish all flames
4. Evacuate the premises
5. Contact a qualified professional
6. Inform the gas supplier
Risk of intoxication
Do not obstruct the air inlets in the room (even partially).
In the event of flue gas emanation
1. Switch the appliance off
2. Open the windows
3. Evacuate the premises
4. Contact a qualified professional
Risk of being burnt
Avoid direct contact with the flame viewport.
Depending on the settings of the appliance:
- The temperature of the flue gas conduits may exceed 60°C
- The temperature of the radiators may reach 95°C
- The temperature of the domestic hot water may reach 65°C
Risk of damage
Do not stock chloride or fluoride compounds close to the
appliance.
Install the appliance in frost-free premises.
Do not neglect to service the appliance: Contact a qualified
professional or take out a maintenance contract for the annual
servicing of the appliance.
2.2 Recommendations
Only qualified professionals are authorised to work on the
appliance and the instalation.
Before any work, switch off the mains supply to the
appliance.
Check regularly that the installation contains water and is
pressurised.
Keep the appliance accessible at all times.
Avoid draining the installation.
The appliance should be on Summer or Antrifreeze mode rather than
switched off to guarantee the following functions:
- Antifreeze protection
- Protection against corrosion on domestic hot water tanks fitted
with a titanium anode.

5
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
3 Description
The front of the boiler (with the inspection hatch for the heat
exchanger) is the side from which it is serviced.
1. Pressure gauge
2. Sensor tube for outlet temperature sensor
3. Flow connection
4. Connection for second return (optional)
5. Return connection
6. Filling and emptying tap
7. Condensates collector
8. Combusted gas temperature sensor
9. Condensates discharge
10. Measurement point O2/CO2
11. Wheel
12. Setting bolt
13. Condensates evacuation pipe
14. Flue gas discharge duct
15. Inspection hatch
16. Reduction sleeve Ø250/Ø200 (Option)
17. Heat exchanger
18. Output sensor
19. Air intake
22. Gas connection
23. Flame inspection window
24. Ignition/ionisation electrode
25. Return sensor
26. Heating body sensor
27. Base frame
28. Pivoting castor
29. Fan
30. Venturi
31. Multivalve gas unit
32. Non-return valve
33. Differential air pressure switch
34. Gas filter
35. Air chamber
36. Control panel
37. Adjustment keys
38. Display screen
39. General ON 8/ OFF 7switch
40. Button 
41. Combusted gas flue
42. Combusted gas valve
43. Combusted gas discharge connection with an integrated
condensates collection device

6C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
4 Use of the appliance
4.1 Control panel
1. General ON 8/ OFF 7switch
The control panel should always be switched on to take
advantage of the heating pump anti-sticking function. It is
preferable to use the "summer" mode for the period during which
the heating is to be cut off.
Furthermore, if an interactive remote control (CDI 2) is connected
and the 1switch is in the off 7position, there will be no display
on the CDI 2.
2. Access hatch for the settings and programme keys
3. On light / Alarm
- The red resetting button lights up when the burner is in the
safety condition
- The flashing red light signals a sensor error
4. Reset button
5. Timed circuit breaker (4 A)
A second protective function can be found on the safety control card.
4.2 Display
1Text and numerical display
2Graphic display bar for the programme in circuit A, B or C
3Light area: Reduced temperature heating period or tank load
disabled
4Dark area: Comfort temperature heating period or tank load
enabled
5Flashing cursor showing the current time
6Number display (current time, adjusted values, parameters,
etc.)
7
Active programme display, P1, P2, P3, P4
or
E: Summer mode activated
8The arrows flash when setting values can be modified using
the +and -keys
A
bar
91011
8
1
BC
C000142_10
SUNDAY
-04
024681012141618202224
A
bar
3 4 5 6 7
91011
8
2
1
BC
SUNDAY
9Circuit operation symbols
>Opening the 3-way valve
=Closing the 3-way valve
:Displayed circuit pump on
A B C Name of the circuit displayed
10 Symbol displayed above the active operating mode
11 Symbols indicating that the following inputs/outputs are
active
DBurner on
DHW load pump on
#Summer mode
TNot available

7
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
4.3 Changing the settings
4.3.1 Keys accessible when the flap is closed
4.3.2 Keys accessible when the flap is open
0 2 4 6 8 1012141618202224
A
C000142_02
SUNDAY
-04
Temperature setting keys
2% Comfort temperature
2$ Reduced temperature
2 Domestic hot water temperature
/Is used to adjust the selected temperature
Operating mode selection keys
AUTO Heating according to the time programme
%
Forced Comfort mode:
- until midnight if flashes
- all the time if is steady
$
Forced Low mode:
- until midnight if flashes
- all the time if is steady
.Antifreeze mode
Tank load enabled mode
A
024681012141618202224
A
STANDARD
C000142_03
SUNDAY
-04
#
Manual "Summer" shutdown key
The heating is switched off and DHW production is
ensured. The symbols #and are displayed{E}.
STANDARD "Standard" programme key
Reset of all time programmes.
KFitter settings access key
Key for access to setting and measurements
JPage scrolling
ILine scrolling
HBack to the title or the previous line
Programming keys
%O Enter (per 1/2 hour) the comfort temperature period or
tank load enabled (dark area)
$P Enter (per 1/2 hour) the reduced temperature period or
tank load disabled (light area)
SReturn key
A.B.C Circuit display selection key
PROG Active heating programme selection key (P1, P2, P3 or
P4)

8C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
4.4 Stopping the boiler
1. Deactivate the electricity supply to the boiler. In this way, any
intergrated regulator is switched off.
2. Close the gas valve.
A boiler which is switched off is not protected against
frost.
4.4.1 Precautions to take if there is a danger of frost
Heating circuit:
Use a correctly dosed antifreeze to prevent the heating water
freezing. If this cannot be done, drain the system completely. In all
cases, consult the fitter.
Domestic hot water circuit:
Drain the domestic water tank and pipes.
4.4.2 Precautions to take in the event of prolonged shutdown (one year or more)
- Close the gas valve
- The boiler and the chimney must be swept carefully.
- Close the door of the boiler to prevent the internal circulation of air.
4.5 Commissioning the boiler
4.5.1 Commissioning
Before filling it with water for the first time, rinse the installation and
eliminate solder pearls, metal shavings, grease, and sludge from the
former installation.
Jobs to be done before commissioning for the first time:
1. Ensure that the boiler is switched off
2. Remove the casings on the inspection side
3. Open the main gas valve
4. Check the electrical connections, particularly the earth
5. Fill the boiler and the installation with water (minimum pressure
1.0 bar)
6. Bleed the heating installation
7. Fill the siphon with water
8. Check the connection of the combusted gas evacuation and the
air inlet
9. Empty the gas inlet
10. Open the gas valve on the gas pipe to the boiler
11. Check the admission pressure of the gas PI
12. Check whether the gas connection is leak proof
13. Activate the electricity supply to the boiler
14. Activate the boiler ON switch
15. Operate the circulation pump and check the assembly position
and the rotation direction
16. Set the boiler regulation according to the heating request
17. The boiler starts to operate
You can monitor operation in the menu #TEST INPUTS, parameter
SEQ:
a. Check the setting of the gas/air ratio and, if necessary, correct it.
The check is carried out at high and low speed, while setting
takes place only on the gas multiblock. For checking and setting,
you will need an electronic CO2meter on the basis of O2)) and a
gas manometer.Be sure correctly to close the opening around
the sensor when making the measurement. Connect the gas
manometer between the measuring point PG under the gas
multiblock and the measurement point PL on the venturi.
b. Run the boiler at high speed (forced "high speed" mode) by
pressing keys P% and P$ simultaneously for 2 seconds.
TEST EMISSION appears on the display with .
c. After reaching minimum output, measure the gas value ∆P at the
measurement point PG under the gas block and the
measurement point PL on the venturi and compare the results
with the values in the table below. Divergent values must be
corrected using the setting screw on the gas multiblock.
d. Then measure the CO2percentage and compare it with the value
in the table. If the values exceed the limits shown, correct them
according to the drawing below.
Check the flame via the flame inspection window. It must not go
out.
e. Run the boiler at low speed (forced "low speed" mode) by
pressing keys P% and P$ simultaneously for 2 seconds
then on -. TEST EMISSION appears on the display with .
f. After reaching minimum output, measure the gas value ∆P at the
measurement point PG under the gas block and the
measurement point PL on the venturi and compare the results
with the values in the table below. Divergent values must be
corrected using the setting screw on the gas multiblock.
g. Then measure the CO2percentage and compare it with the value
in the table. If the values exceed the limits shown, correct them
according to the drawing below.
Check the flame via the flame inspection window. It must not go
out.
Repeat the steps as of step e until the measurements match the
values in the table.
If you do not manage to correct the differences, contact our after
sales service.
h. Remove the measuring device and close the measurement
points.
18. Check the gas seal control and the minimum gas pressure
pressure switch (if need be)

9
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
Table of CO2- O2values
Set the parameter to a value greater than or equal to 8, depending on
the options connected.
Then set the gas seal control pressure switch to a trigger pressure
equivalent to 50% of the admission pressure. Do not forget that the
admission pressure measured does not affect the closing pressure
(higher).
19. Press the Reset key to return the boiler to "user level"
20. Heat the installation to around 80°C and then stop the boiler
21. Bleed the heating installation and Checking the hydraulic
pressure
22. The boiler is now operational
23. Set the boiler regulation to the desired values
24. Switch the boiler on and fill in the label "Set to"
Each individual boiler is delivered with the following fixed
factory settings:
Natural gas H/E
(G20)
Natural gas L/LL
(G25)
High speed (100%) Low speed (±20%) High speed (100%) Low speed (±20%)
Indicative CO2value 9,0% 9,0% 9,0% 9,0%
Adjust to ±0,5% ±0,5% ±0,5% ±0,5%
Set to 9,0 ± 0,15% 9,0 ± 0,15% 9,0 ± 0,15% 9,0 ± 0,15%
Indicative O2value 4,8% 4,8% 4,8% 4,8%
Adjust to ±0,5% ±0,5% ±0,5% ±0,5%
Set to 4,8 ± 0,25% 4,8 ± 0,25% 4,8 ± 0,25% 4,8 ± 0,25%
∆P C310-280 (Pa) 1300 ± 100 60 ± 10 1150 ± 100 45 ± 10
∆P C310-350 1020 ± 100 42 ± 10 840 ± 100 32 ± 10
∆P C310-430 900 ± 10 50 ± 10 750 ± 100 40 ± 10
∆P C310-500 1350 ± 100 65 ± 10 1200 ± 100 50 ± 10
∆P C310-570 1650 ± 100 85 ± 10 1500 ± 100 70 ± 10
Burner regulation - Modulating, depending on the
outlet temperature
Flow temperature - 90°C

10 C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
5 Checking and maintenance
The boiler is almost maintenance-free if it is set correctly.
Make the following checks at least 1 time a year:
- Checking the combustion in the boiler
- Checking the heat exchanger
- Checking condensates discharge.
- Checking the ignition electrode
- Checking for leaks (water, combusted gas, gas)
- Checking the hydraulic pressure
- Checking the air inlet circuit
Carry out the following maintenance at least *1 time a year:
- Cleaning the condensates collector
- Cleaning the siphon.

11
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
6 Troubleshooting
6.1 Identification plate
Before informing the fitter of a fault, make a note of the following
information:
Type of gas used
Boiler type
Date of manufacture
Year (01 = 2001, 02 = 2002, ...)
Week
Serial no. of the appliance
This information can be found on the rating plate stuck to the
front plate of the boiler.
D

12 C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
6.2 Error messages
6.2.1 Faults
In the event of a fault, the display may show the following messages.
Contact your fitter.
Message Probable causes Solution
24V SHORT-CIRC. Short circuit 24V Check the wiring
BURNER FAILURE
Igniter fault Check the ignition electrode (spacing of the electrodes), its
connector and its connection cable. Replace if necessary.
Ionisation error Check the earth, Check the ionisation current, If necessary
rectify the level of CO2
Faulty gas valve Replace the gas valve
No gas or presence of air in the pipe Measure the gas supply pressure. Bleed the gas circuit
I-CURRENT FAIL Ionisation fault during operation Check the earth, Check the ionisation current, If necessary
rectify the level of CO2
MCBA FAILURE 5 External influences Check the wiring
MCBA FAILURE 8 Air pressostat open
Check:
- if the flue gas / combustive air duct is not blocked (i.e.
siphon)
- if the air pressure switch and the connection are blocked
MCBA FAILURE 11 Internal fault
- Check that multi-wire connections are undamaged
- Presence of humidity in the control panel
- Eliminate electro-magnetic influences
MCBA FAILURE 12 Bridge open
- Check the bridge between terminals X4-3 and X4-12 on the
MCBA
- Fuse F2 faulty in the control p.c.b
MCBA FAILURE 30 T maxi exceeded Check the water flow
MCBA FAILURE 61 Air pressostat closed
Check:
- If Faulty air pressostat
- If the wiring to the air pressure switch is in order
- If the thermal draught is too great
MCBA FAILURE 89 Detection of gas leak V1
The gas sealing control (optional) has detected a leak.
Check whether there is a leak in the gas valve; otherwise
replace the valve.
MCBA FAILURE 90 Detection of gas leak V2
The gas sealing control (optional) has detected a leak.
Check whether there is a leak in the gas valve; otherwise
replace the valve.
MCBA FAILURE XX Internal safety control box fault Reset the boiler. Replace the command and safety box.
MCBA.COM.FAULT Communication error between DIEMATIC
and safety control box
Check the link and the connections between DIEMATIC and
safety control box
ROOM S.A FAIL.
ROOM S.B FAIL.
ROOM S.C FAIL.
EXCHAN.S.FAIL.
OUTL S.B FAIL.
OUTL S.C FAIL.
OUTSI. S.FAIL.
SWIM.P. S.FAIL
Fault in the corresponding sensor
Check the link and the connectors. Replace the sensor if
necessary.
To erase the message, briefly cut off the power to the boiler
using the On/Off switch. Advise the installer. However, you
can operate in manual mode on the part of the installation
concerned. See comments below.
FAN OFF FAIL The fan is not working
- Faulty fan
- Check the fan wiring (corrosion of the connection)
- Command and safety box faulty
FAN ON FAIL The fan is working constantly - Electrical connections broken
- Faulty fan control (replace the fan)

13
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
BOILER S.FAIL. Faulty boiler sensor
Check the link and the connectors. Replace the sensor if
necessary.
Reset the boiler.
DHW S. FAILURE Faulty domestic hot water sensor Check the link and the connectors. Replace the sensor if
necessary.
SMOKE S. FAIL. Faulty flue gas sensor
Check the link and the connectors. Replace the sensor if
necessary.
Reset the boiler
BACK S.FAILURE Faulty return sensor
Check the link and the connectors. Replace the sensor if
necessary.
Reset the boiler
VALVE FAIL Combined gas valve unit faulty
The safety control box does not signal a gas valve. Check:
- The wiring of the gas valve
- A possible fault in the gas valve (faulty coil)
- Check the wiring. Check that the fuses are in good working
condition.
PARASIT FLAME Detection of a parasite flame
Check the tightness of the gas circuit. Check the ignition
electrode spacing.
Check that the surface of the burner does not have any fibre
residues.
REARM CVI Control error Reset the boiler
STB BOILER Flow temperature > maximum
Check the wiring.
Bleed the boiler. Check the boiler pump. Check the hydraulic
circuit on the installation.
STB EXCHANGE Exchanger temperature too high
Check the wiring.
Bleed the boiler. Check the boiler pump. Check the hydraulic
circuit on the installation.
STB SMOKE Flue gas temperature too high Heat exchanger fouled
STB BALK Return temperature too high
Check the wiring.
Bleed the boiler. Check the boiler pump. Check the hydraulic
circuit on the installation.
Message Probable causes Solution

14 C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
For other codes not listed here
- Cut the power supply to the boiler.
- Reset the boiler.
- Change the safety control box if the message persists.
• ROOM S.A FAIL., ROOM S.B FAIL., ROOM S.C FAIL.
Automatic operating without room temperature influence.
• OUTL S.B FAIL., OUTL S.C FAIL.
The circuit concerned goes from automatic to manual mode. The
pump turns and the valve is no longer supplied. It may be manually
operated if necessary.
• DHW S. FAILURE
Heating of domestic hot water is no longer ensured. The load
temperature of the dhw tank is the same as the boiler.
• OUTSI. S.FAIL.
The boiler operates on BOILER MAX temperature. The regulation of
the 3-way valve on circuits B or C (if present) is no longer handled.
Nonetheless, the limitation of the maximum temperature is
guaranteed and the valve can be operated manually if necessary.
Reheating the domestic hot water remains ensured.
The 10 latest faults appearing on the display are memorised in
the paragraph #HISTORY D..

15
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
6.2.2 (Temporary) blockage
The blockage mode is a normal operating mode and therefore
does not indicate a breakdown but a normal boiler operating
status. A blockage code is likely to signal a technical problem in
the installation or an incorrect setting.
Message Probable causes Solution
BL. AIR Air supply insufficient during pre-ventilation.
A safety lockdown occurs after 5 starts.
- if the flue gas / combustive air duct is not
blocked (i.e. siphon)
- if the air pressure switch and the
connection are blocked
BL.RET.HIGH.BOI
Return temperature > Flow temperature for
10 minutes minimum, after boiler operating at
lower stage
Connection or outlet and return sensor
reversed
BL.SPEED
The maximum temperature increase speed
tolerated in the exchanger has been
exceeded. The boiler is blocked for 10
minutes.
After 5 successive attempts during a single
heating request, the repeated cut-offs will be
saved (the blockage code and the boiler
situation at the time of the blockage).
-Pump
- Water flow
- Hydraulic pressure
BLOCKING b26 Check the bridge between terminals X4-8
and X4-3 in the box
BL.DT BOI BACK
he maximum difference tolerated between
the outlet and return temperatures has been
exceeded. The boiler is blocked for 150
seconds. After 20 successive attempts
during a single heating request, the repeated
cut-offs will be saved (the blockage code and
the boiler situation at the time of the
blockage). However, the boiler does not
break down and continues to operate.
-Pump
- Water flow
- Hydraulic pressure
BL.INT.MCBA The setting of the parameters is incorrect or
the memory is faulty. - Configuration of the communication robot
BL.SMOKE Flue gas temperature > Flue gas
temperature maximum. Trigger 150 seconds.
- Boiler setting
- Fouling
BL.CS OPEN Blockage input on the CS bridge terminals, is
open, or absence of a bridge. - External safety and bridge
BL.DT BOI.EXC.
If ∆T between boiler temperature and
exchanger temperature > 5°C
Trigger 10 Min. seconds. After 5 successive
attempts during a single heating request, the
repeated cut-offs will be saved (the blockage
code and the boiler situation at the time of the
blockage). The boiler will not be locked down.
-Pump
- Water flow
BLOCKING bXX The control box is off. Check the wiring
Reset the boiler

16 C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
7 Technical characteristics
7.1 C 310 ECO
C 310-... ECO Unit 280 350 430 500 570
Introduction
Numberofsections 56789
Regulating the output Modulating
Output (80/60°C) PN minimumkW51657992106
maximum kW 261 327 395 462 531
Output (50/30°C) PN minimumkW56718498113
maximum kW 282 353 427 499 573
Power input minimumkW54688295109
maximum kW 269 336 404 471 539
Combustion gas and by-products
Gas supply pressure mbar 17 - 25
Gas flow rate Gas H/E (15°C - 1013
mbar)
minimum m3/h 5,7 7,2 8,7 10,1 11,5
maximum m3/h 28,5 35,5 42,7 49,8 57,0
Gas flow rate Gas L/LL(15°C - 1013
mbar)
minimum m3/h 6,6 8,4 10,1 11,7 13,4
maximum m3/h 33,1 41,3 49,7 57,9 66,3
Average nitrogen oxide emission (NOx) mg/kWh < 60
Maximum pressure at the flue gas
nozzle
Pa 150 150 150 150 150
Combusted gas flow minimum Kg/h 91 114 138 160 183
maximum Kg/h 453 565 680 793 907
Temperatures of the combusted gases
at 80/60°C
minimum °C 57
maximum °C 65
Boiler types: B23, C33, C53, C63, C83
Heating
Safety temperature °C 110
Water setting range °C 20 - 90
Water pressure minimum bar 0,8
Water pressure maximum bar 6
Watercontent l 4960718293
Water resistance at ∆T = 10°C mmCE 4520 4400 4800 4400 5000
Water resistance at ∆T = 20°C mmCE 1130 1100 1200 1100 1250
Electricity characteristics
Power supply voltage V/Hz 230 / 50
Power consumption minimum W 12 12 12 12 12
maximum W 303 340 470 600 858
Insulation class IP 21
Miscellaneous
Weight without water kg 360 410 460 510 560
Acoustic level at 1 meter dBA 60

17
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
7.2 C 610 ECO
C 610-... ECO Unit 700 860 1000 1140
Introduction
Number of sections 2 x 6 2 x 7 2 x 8 2 x 9
Regulating the output Modulating
Output (80/60°C) PN minimum kW 87 123 122 148
maximum kW 654 790 924 1062
Output (50/30°C) PN minimum kW 94 131 130 156
maximum kW 706 854 998 1146
Nominal output (Hi) minimum kW 91 128 127 153
maximum kW 672 808 942 1078
Combustion gas and by-products
Gas category (see table in "General Description" chapter)
Gas supply pressure mbar 17 - 25
Gas flow rate Gas H/E (15°C - 1013 mbar) minimum m3/h 9.6 13.5 13.4 16.2
maximum m3/h 70 85.4 99.6 114
Gas flow rate Gas L/LL(15°C - 1013 mbar) minimum m3/h 11.2 15.8 15.6 18.8
maximum m3/h 82.6 99.4 115.8 132.6
Average nitrogen oxide emission (NOx) mg/kWh < 60
Maximum pressure at the flue gas nozzle Pa 130
Combusted gas flow minimum kg/h 153 215 214 257
maximum kg/h 1130 1360 1586 1814
Temperatures of the combusted gases at 80/
60°C
minimum °C 57
maximum °C 65
Boiler types: B23, C33, C53, C63, C83
Heating
Safety temperature °C 110
Water setting range °C 20 - 90
Water pressure minimum bar 0,8
Water pressure maximum bar 6
Water content l 120 142 164 186
Water resistance at ∆T = 10°C mmCE 4400 4800 4400 5000
Water resistance at ∆T = 20°C mmCE 1100 1200 1100 1250
Electricity characteristics
Power supply voltage V/Hz 230 / 50
Power consumption minimum W 12
maximum W 694 980 1240 1684
Insulation class IP 21
Miscellaneous
Weight without water kg 820 920 1020 1120
Acoustic level at 1 meter dBA 63

18 C 310 ECO - C 610 ECO 02/10/07 - 300015183-001-A
8 Energy savings
Here are a few tips for saving energy:
- Install reflector panels behind the radiators.
- Do not cover the radiators. Do not hang curtains in front of the
radiators.
- Insulate pipes to prevent thermal losses and condensation.
- Do not obstruct aeration grates (even partially). They help to
reduce humidity in the home. The more humid a home, the more
heating it consumes.
- Turn heating off when airing a room (5 minutes a day is sufficient)
Avoid deregulating the thermostat. Place the start/stop switch on
Off.
- Do not shut down heating completely if you are absent. Lower the
thermostat by 3-4°C.
- Use the sun's heat as much as possible.
- Take showers rather than baths. Use a water-saving shower head.

19
02/10/07 - 300015183-001-A C 310 ECO - C 610 ECO
Warranty
You have just purchased one of our appliances and we thank you
for the trust you have placed in our products.
Please note that your appliance will provide good service for a
longer period of time if it is regularly checked and maintained.
Your fitter and our customer support network are at your disposal
at all times.
Warranty terms
Starting from the purchase date shown on the original fitter's
invoice, your appliance has a contractual guarantee against any
manufacturing defect.
The length of the guarantee is mentioned in the price catalogue.
The manufacturer is not liable for any improper use of the
appliance or failure to maintain or install the unit correctly (the
user shall take care to ensure that the system is installed by a
qualified fitter).
In particular, the manufacturer shall not be held responsible for
any damage, loss or injury caused by installations which do not
comply with the following:
- applicable local laws and regulations
- specific requirements relating to the installation, such as
national and/or local regulations
- the manufacturer's instructions, in particular those relating to
the regular maintenance of the unit
- the rules of the profession
The warranty is limited to the exchange or repair of such parts as
have been recognised to be faulty by our technical department
and does not cover labour, travel and carriage costs.
The warranty shall not apply to the replacement or repair of parts
damaged by normal wear and tear, negligence, repairs by
unqualified parties, faulty or insufficient monitoring and
maintenance, faulty power supply or the use of unsuitable fuel.
Sub-assemblies such as motors, pumps, electric valves etc. are
guaranteed only if they have never been dismantled.
France
The preceding dispositions are not exclusive of benefits for the
purchaser of the legal guarantee as stated in Civil Code articles
1641 to 1648.
Belgium
The preceding dispositions about the contractual guarantee are
not exclusive of profit if the need arises for the purchaser in
Belgium of the applicable legal dispositions on hidden defects.
Switzerland
The application of the warranty is subject to the terms and
conditions of sale, delivery and warranty of the company
marketing our products.
Other countries
The above provisions do not restrict the benefit of the legal laws
regarding hidden defects applicable in the buyer's country.

© Copyright
All technical and technological information contained in these technical instructions, as well as any
drawings and technical descriptions supplied, remain our property and shall not be multiplied
without our prior consent in writing..
Subject to alterations.
02 october 2007
DE DIETRICH THERMIQUE
57, rue de la Gare F- 67580 MERTZWILLER - BP 30
DE DIETRICH THERMIQUE S.A.S.
www.dedietrich-thermique.fr
DE DIETRICH HEIZTECHNIK
www.dedietrich-heiztechnik.de
VAN MARCKE
www.vanmarcke.be
VESCAL S.A.
www.chauffer.ch / www.heizen.ch
DE
BE
CH
NEUBERG S.A.
www.dedietrich-heating.com
LU
FR
DE DIETRICH
www.dedietrich-otoplenie.ru
DE DIETRICH
www.dedietrich-heating.com
RU
DE DIETRICH HEIZTECHNIK
www.dedietrich-heiztechnik.de
AT
CN
Direction des Ventes France
57, rue de la Gare
F- 67580 MERTZWILLER
[phone]
[phone]
Rheiner Strasse 151
D- 48282 EMSDETTEN
+49 (0)25 72 / 23-5
+49 (0)25 72 / 23-102
[email protected]
Weggevoerdenlaan 5
B- 8500 KORTRIJK
+32 (0)56/23 75 11
Z.I de la Veyre, St-Légier
1800 VEVEY 1
[phone]
[phone]
39 rue Jacques Stas
L- 2010 LUXEMBOURG
[phone]
8 Gilyarovskogo Str. 7
R- 129090 MOSCOW
+7 495.974.16.03
+7 495.974.66.08
[email protected]
Room 512, Tower A, Kelun Building
12A Guanghua Rd, Chaoyang District
C-100020 BEIJING
+86 (0)106.581.4017
+86 (0)106.581.4018
+86 (0)106.581.7056
+86 (0)106.581.4019
[email protected]
Am Concorde Park1-B4/28
A-2320 SCHWECHAT / WIEN
+43 (0)1 / 706 40 60-0
+43 (0)1 / 706 40 60-99
[email protected]
