New Mythos Solo:
Left/Center/Right in One Elegant Loudspeaker
The Mythos Solo is an elegantly simple Plasma Solution
®
that builds on
and extends the Mythos tradition of combining high performance sound
quality with cutting-edge styling. It is a combination Left, Center and
Right channel loudspeaker with all three driver arrays together in one
sleek and elegant enclosure that looks amazing when placed with today’s
high-tech televisions. The enclosure’s beautiful styling matches the Mythos
signature look of curved, hand-polished, aircraft grade aluminum, and it
can be either wall mounted (using the strong stainless steel wall mounting
brackets, included), placed on a shelf below or above the television, or
placed directly atop the television.
The unique curved D’Appolito driver arrays on the left and right main
speaker modules deliver wider dispersion and an expanded image size.
Use the Mythos Solo as your complete front stage speaker array. Match it
with a Definitive Technology Subwoofer and a pair of surround speakers
(such as the new compact Mythos Gem Speakers) to build a complete,
compact super clean-looking ultra high performance home theater system.
Specifications: Dimensions: 40"W x 4
1
/
8
"H x 4
1
/
4
"D. Magnetically-Shielded
Driver Complement: L & R Channel Modules: two 3
1
/
2
" bass/mid drivers,
one 1" pure aluminum dome tweeter, Center Channel Module: two 3
1
/
2
"
bass/mid drivers, two 3
1
/
2
" pressure-driven bass radiators, one 1" pure
aluminum dome tweeter. Power Handling: 10 – 175 Watts x 3. Frequency
Response: 60 Hz – 30 kHz. Finish: polished silver or polished black.
New Mythos Eight:
Larger On-Wall Loudspeakers
for Bigger On-Wall Televisions
The Mythos Eight loudspeaker is another
Plasma Solution
®
from Definitive Technology
designed to complement larger on-wall televisions
(50" and up) with gorgeous Mythos curved-
aluminum styling and award-winning sonic
performance. Mythos Eight is engineered to
be mounted vertically or horizontally (using its
stainless steel wall mounting bracket, included)
for use as sublimely beautiful Left and Right
Main Loudspeakers, or as a high performance
Center Channel Speaker (for use with Mythos
Eight or Mythos One Loudspeakers, etc., as
Mains). Specifications: Dimensions: 6
1
/
16
"W x
28
1
/
2
"H x 4
3
/
8
"D. Magnetically-Shielded Driver
Complement: two 5
1
/
4
" bass/mid drivers, two 5
1
/
4
"
pressure-driven bass radiators, one 1" pure
aluminum dome tweeter. Frequency Response:
38 Hz – 30 kHz. Recommended Amplification:
10 – 250 Watts/channel. Finish: polished silver
or polished black.
New Mythos Series Plasma Solutions®

New Mythos Solo XL:
Left/Center/Right in One Elegant Loudspeaker
The new Mythos Solo XL is the second Solo speaker. It’s basically
alarger version of the original Mythos Solo and is intended for 50" and
larger screen size video displays. Mythos Solos are the perfect Plasma
Solution
®
when a simpler installation is desirable. They are an exciting
home theater solution that continues the Mythos tradition of combining
high performance sound quality and cutting-edge styling. The Solos com-
bine three superb sounding speakers (left main, center and right main) in
one sleek and elegant polished, aircraft-grade aluminum enclosure that can
be either wall mounted (using the included stainless steel wall mounting
brackets), placed on a shelf or on top of a TV. The Solos may be used by
themselves or combined with a Definitive subwoofer and a pair of speak-
ers for surround (like the Mythos Gems) for a compact and complete ultra
high performance home theater.
The Mythos Solo XL measures 46
1
/
4
"L x 5
3
/
8
"W x 4
1
/
8
"D. Its driver
complement is two 4
1
/
2
"cast-basket drivers plus a 1" pure aluminum
dome tweeter, in a unique curved D’Appolito array that results in wider
dispersion and an expanded image size (for each left and right channel
module), and two 4
1
/
2
"drivers, two 4
1
/
2
"pressure coupled bass radiators
and a 1" pure aluminum dome tweeter for the center channel module.
There are three Linkwitz-Riley crossovers to ensure perfect driver
blending. Recommended amplification for each channel is 10 – 250
watts and the frequency response is 50 Hz – 30 kHz. Available in
polished silver or polished black.
11433 Cronridge Drive, Owings Mills, Maryland 21117, U.S.A.
[phone] • www.definitivetech.com
New UIW RLS III:
Reference Line Source Ultimate In-Wall Speaker
Definitive’s latest Ultimate In-Wall, the RLS III, is the second in-wall Reference Line Source
loudspeaker from Definitive. It is basically a smaller version of the RLS II. The RLS III is a
completely enclosed full range loudspeaker engineered for flush mount vertical or horizontal
in-wall installation. The sealed non-resonant medite enclosure houses a line source composed
of two cast basket 51/4"high-definition bass/midrange drivers that surround a one inch pure
aluminum dome tweeter perfectly blended through the use of a precision Linkwitz-Riley
crossover network. Above and below these three drivers are two 51/4"planar pressure coupled
bass radiators, which complete the line source array.The RLS III is perfect for in-wall custom
install home theater systems of the highest quality when used as either a left main, right main,
center or surround speaker. And of course they blend perfectly with any Definitive powered
subwoofer including the new IWSubs. The RLS III is capable of extraordinary sonic perform-
ance with both music and movies, which is comparable to that of the finest free standing loud-
speakers. Frequency response is 24 Hz – 30 kHz, recommended amplification is 10 – 325 watts
and cut-out size is 57/8"W x 233/4” H x 37/8”D. Overall size is 7" W x 25" H.
The Newest Mythos Plasma Solution®
An Extraordinary New Custom Installation Solution
