Defy DAF7003B User manual

Page 1
Small Appliance
Instruction manual
DAF7003B
AIR FRYER

1
2
3
4
5
6
7
8
10
11
9

Complies with the WEEE Directive. It does not contain PCB.
Please read this user manual first!
Dear Customer,
Thank you for selecting an Defy product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-
the-art technology. Therefore, please read this entire user manual and all other
accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the user
manual as well. Follow all warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
C
Important information and useful
hints about usage.
A
WARNING: Warnings for dangerous
situations concerning the safety of
life and property.
Materials are intended to be in con-
tact with food.
Do not immerse the appliance,
power cord or power plug in water
or in other liquids.
Potection class against electric
shock.
This product has been produced in environmentally-friendly, state-of-the-art facilities.

The values which are declared in the markings axed on your appliance or the other printed documents supplied with it repre-
sent the values which were obtained in the laboratories pursuant to the pertinent standards. These values may vary according to
the usage of the appliance and ambient conditions.
1. Timer button
2. Power indicator
3. Heat indicator
4. Temperature control button
5. Protection cover
6. Basket release button
7. Handle
8. Basket drawer
9. Removable basket
10. Air outlet
11. Power cord
Technical data
Power supply: 220-240 V~, 50-60 Hz
Power: 1300 W
Technical and design modifications reserved.

6 / EN
Air Fryer / User Manual
1 Important safety and environmental
instructions
This section contains safety in-
structions to prevent hazards that
can result in injury or property dam-
age.
Any warranty is void if these in-
structions are not followed.
1.1 General safety
•This appliance complies with in-
ternational safety standards.
•This appliance isintended
for home use and food
preparation only,it is not
suitable for profes-sional use.
•This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning the use
of the appliance by a person
responsible for their safety.
•Children should be supervised to
ensure that they do not play with
the appliance.
•Keep the product and the product
cable out of the reach of
children.
•Position the handles of the cook-
ing appliances (if any) so that hot
liquids do not spill and place them
securely.
•Make sure that the voltage indi-
cated on the appliance is the same
as the mains voltage in your home.
•Use the appliance in a grounding
plug.
•Do not use the appliance with an
extension cord.
•Do not place your appliance on or
near heat sources such as ovens
and stoves.
•To prevent damage to the power
cord, prevent it from being
pinched, crimped or rubbed
against sharp edges.
•Do not unplug the appliance by
pulling on the cord.
•Do not immerse the appliance or
its power cord in water.
•Do not leave the appliance unat-
tended while it is plugged in.
•Do not disassemble the appliance.
•Use only original parts or parts rec-
ommended by the manufacturer.
•Unplug the appliance before
cleaning and dry all parts com-
pletely after cleaning.

7 / EN
Air Fryer / User Manual
1 Important safety and environmental
instructions
•Clean the appliance in accordance
with the instructions in the Clean-
ing and Maintenance section.
•Do not put large pieces of food in
the appliance as it may cause a
fire.
•Do not touch the plug of the appli-
ance while your hands are damp or
wet.
•Do not use the appliance in humid
environments.
•Do not move the appliance while it
is in use and the oil inside is hot.
•Do not use the appliance in or near
explosive or flammable environ-
ments and substances.
•To avoid the risk of burns, do not
touch hot surfaces.
•Let the appliance cool down in a
safe place out of the reach of chil-
dren.
•Do not block the air inlet and air
outlet openings while the appli-
ance is operating.
•Do not lean over while the appli-
ance is in use. Hot air rises from
the appliance during use!
•The appliance becomes hot during
use. To avoid the risk of burns, do
not touch hot surfaces.
•Make sure that the room is ade-
quately ventilated during use.
•In case of fire, unplug the appli-
ance.
•Do not pour water on the ap-
pliance, as it may cause electric
shock hazard.
•Do not operate the appliance with
an external timer or a separate re-
mote control system.
•The oil level must be between the
specified maximum and minimum
levels.
•Only use metal kitchenware with
insulated handles with the appli-
ance.
•Do not put anything on the appli-
ance while it is operating or hot.
•To disconnect, turn the timer dial
and temperature dial to the off po-
sition. Then unplug the appliance.
•If you keep the packaging materi-
als, keep them out of the reach of
children.

8 / EN
Air Fryer / User Manual
1.2 Compliance with the WEEE
Directive and Disposing of the
Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other house-
hold wastes at the end of its service
life. Used device must be returned to
offical collection point for recycling of
electrical and electronic devices. To find these col-
lection systems please contact to your local au-
thorities or retailer where the product was pu-
chased. Each household performs important role
in recovering and recycling of old appliance.
Appropriate disposal of used appliance helps pre-
vent potential negative consequences for the en-
vironment and human health.
1.3 Compliance with RoHS
Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.4 Package information
Packaging materials of the product are
manufactured from recyclable materi-
als in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.
1 Important safety and environmental
instructions

9 / EN
Air Fryer / User Manual
2 Use
2. Intended use
•The appliance is intended for home use only, it is not suitable for professional use.
•The appliance may emit some smoke when you use it for the first time. This is normal.
2.1 Preparing the appliance for use
•Use the appliance in an upright position on a stable, flat, clean, dry and non-slip surface.
1
2
1
2
Before using the appliance for the first
time, remove the packaging materials
and place the appliance in a flat and
clean area.
Firmly grasp the removable basket
handle (7) to open the basket drawer;
then remove the drawer from the
machine.
To release the basket from the drawer,
place the drawer on a flat surface. Lift
the protection cover (5), press the
basket release button (6) and lift the
basket out of the drawer.
1
2
Clean the basket drawer (8), removable
basket (9) with warm soapy water and
then dry the outer surface of the appli-
ance and the parts you wash.
There are 2notches on both sides of the
handle. Lock the basket in the drawer by
sliding the tabs into the notches on the
top of the basket drawer.
Attach the drawer to the appliance
after cleaning all parts. Your appliance
is ready for use.
Never use the basket drawer without a frying basket.

10 / EN
Air Fryer / User Manual
2 Use
2.2.1 Cooking
•Blend the food you are cooking with the oil before placing it in the cooking drawer.
WARNING: It is not suitable for recipes containing large amounts of liquid. Do not overfill
the cooking pan and exceed the maximum food level.
1
2
2
1
Firmly grasp the removable basket
handle to open the basket drawer; then
remove the drawer from the appliance
and place it on a flat and clean surface.
Place the food in the frying basket.
Then attach the basket to the appliance
and make sure it fits completely.
Plug your appliance in and set the
timer and temperature control knob
according to the type of food. The
appliance starts cooking.
•If your appliance is cold, turn the timer knob (1) to +5 minutes for preheating. When the red
power indicator (2) lights, your appliance will start to warm up.
•Your appliance will not heat up unless you set the timer dial.
•When your appliance reaches the set temperature, the green heat indicator (3) light will
come on.
•To ensure that the cooking/frying process is uniform, remove and shake the basket drawer
and check it, if necessary. If necessary, adjust the temperature.
•You can turn it off at any time by turning your appliance's timer knob to 0.
WARNING: When shaking food, make sure the basket is in the locked position. Do not press
the basket release button (6) while mixing the frying basket.

11 / EN
Air Fryer / User Manual
2 Use
Bip
1
2
When the set frying time has expired, a
warning tone will sound and your appli-
ance will automatically shut down.
Remove the frying drawer and check
the colour and state of food. If addition-
al frying is required, you can increase
the frying time a little longer.
After the process is completed, pour
the ingredients in the basket into a
bowl or plate. Since hot or filtered
oil can accumulate at the bottom of
the pan, always remove the basket
with ingredients from the pan before
serving.
•Let it rest for 5 to 10 seconds before removing the food from the frying basket.
•Use tongs to remove large or soft foods from the basket.
•When a batch of food is ready, the product is instantly ready for another batch.
•If necessary, remove the inner container (9) from the appliance and use it. After removing
the inner container from the appliance, place it on a trivet.
WARNING
•The amount of food should not exceed the maximum limit.
•Note that the appliance may be very hot during the removal.
•When frying is complete, turn both the temperature control dial and the timer dial
to MIN and 0 (OFF).
The “ ” icon on your appliance refers to the continuous time function, when you want to
turn off your appliance, turn the timer switch to the off position.

12 / EN
Air Fryer / User Manual
3 Recipes
FOOD AMOUNT AND
SHAPE TEMPERATURE TIME (MIN) SHAKE
FINGER SAUSAGE 500 g. cut into three
with flower shape 180 °C 10
MEATBALL 40 g. 6 pcs, long
pressed by hand 180 °C 10
BREAD
3 slices of whole
wheat with sour-
dough and walnut
180 °C 8
FRIED EGG 3 eggs 180 °C - without basket 12
ORANGE CAKE
1 + 1/4 cup flour
with chocolate chip
and orange cake
mortar
160 ° C and then 140 ° C
- using greaseproof paper
- with basket
160 ° C for 20 minutes
and 140 ° C for 40
minutes
FILLET STEAK 150 g. chopped
cubed 200 °C - with basket 15 Once in the 8th minute
CARROT
2 pieces of medium
size, cut into thick
round slices
200 °C 35 Once in the 15th and
30th minutes
MUSHROOM 100 g. whole mush-
room 200 °C - without basket 15 1 time in 8 minutes
TART - QUICHE In muffin molds 180 °C - with basket 20 15th minute by lifting
weights on it
POTATO CHIPS Round slices from
1/4 potato, 50 g. 160 °C - with basket 15 1 time in 5 minutes
POTATO
CROQUETTES
9 ready frozen cro-
quettes 180 °C - with basket 20
CRISPY CHICKPEA
100 g. chickpeas
pre-pressed in wa-
ter and boiled for 10
minutes
180 °C - with basket 30 Once every 15 minutes
CHICKEN WITH VEG-
ETABLES
Chicken thighs
cooked with veg-
etables
180 ° C - using oven bag -
without basket 60

13 / EN
Air Fryer / User Manual
3 Cleaning and maintenance
3.1 Cleaning
Never use gasoline, solvent, abrasive cleaners, metal objects or hard brushes to clean the ap-
pliance.
Turn the appliance off and unplug it. Let the appliance cool down completely. Remove the frying basket from the
drawer.
Remove the pan and basket for your appliance to cool faster
1
1
2
Press the basket release button (6) and
remove the removable basket (9) by lift-
ing and pulling the handle (8) upwards.
Clean the removable basket (9) and
basket drawer (8) with warm soapy wa-
ter and then dry them completely.
Use a damp cloth to clean the outer
surface of the appliance. Dry the out-
side of the appliance completely.
Always keep the bottom of frying basket and drawer clean to prevent foreign material from
accumulating.

14 / EN
Air Fryer / User Manual
3 Cleaning and maintenance
3.2 Storage
•If you do not intend to use the appliance for a long time, store it carefully.
•Unplug the appliance and allow it to cool before storing it.
•Store the appliance in a cool dry place.
•Store the appliance and its cord out of the reach of children.
3.3 Transport and shipping
•During transport and shipping, carry the appliance with its original packaging. The packaging of the
appliance will protect the appliance against physical damage.
•Do not put heavy objects on the appliance or its packaging. Otherwise the appliance may be damaged.
•If the appliance is dropped, the appliance may not operate or permanent damage may occur.

Branches
If you have followed the instructions and still have a problem, contact the customer care
line on 086 100 3339. They will be able to advise you on any aspect of the appliance.
Sub-Saharan Africa Branches:
ZAMBIA: SOUTHGATE INVESTMENTS LTD
Plot 1606, Sheki Sheki Road
P.O. Box 33681
Lusaka, 10101, Zambia
Tel: [phone]
Fax: [phone]
[email protected]
NAMIBIA: ATLANTIC DISTRIBUTORS (PTY)
LTD
10 Tienie Louw Street, Northern Industrial Area
P.O. Box 21158, Windhoek, Namibia
Tel: [phone]
Fax: [phone]
[email protected]
ZIMBABWE: TRADECOMAFRICA
Trade Com Africa, 183 Loreley Crescent
Msasa, Harare, Zimbabwe
Tel: [phone]
Cell: [phone]
Cell: [phone]
BOTSWANA: RAY MORGAN AGENCIES
RMA Service Centre, Plot 48, East Gate
Gaborone International Commerce Park
Kgale View, Gaborone
Botswana
Tel: [phone]
Fax: [phone]
Cell: [phone]
[email protected]; [email protected]
SWAZILAND: LYNDS DISTRIBUTORS
P.O Box 716, Mbabane, Swaziland, H100
Tel: [phone]
Fax: [phone]
MOZAMBIQUE: COOL WORLD. LDA
Rua da Resistencia No. 97B R/C
Cell: [phone]
[email protected]
Nosso Show Room
Av: da Industrias, Parcela No.735 * 735A
Machava, Maputo
South African Branches:
BLOEMFONTEIN
Unit Number 5
Monument Business Park
50 Monument Road
Oranjesig, Bloemfontein
[email protected]
CAPE TOWN
5A Marconi Rd. Montague Gardens, 7441
[email protected]
DURBAN
135 Teakwood Road, Jacobs,
Durban, 4052
[email protected]
EAST LONDON
Robbie de Lange Road, Wilsonia,
East London, 5201
[email protected]
GAUTENG, MIDRAND
127 15th Road, Cnr Pharmaceutical &15th Rd,
Midrand, Gauteng
[email protected]
POLOKWANE
87 Nelson Mandela Drive, Superbia 0699
[email protected]
PORT ELIZABETH
112 Patterson Road, North End, Port Elizabeth
6001
[email protected]

Warranty
This certificate is issued by DEFY APPLIANCES (PTY) LIMITED manufacturers of Defy
and Ocean products, hereinafter the Company, to the original purchaser only, of the
appliance described on the certificate and shall constitute the only warranty given in
respect of this appliance.
The Company warrants to the original purchaser that for a period of ONE YEAR from date
of purchase the appliance is free from defect under normal domestic use, both in
workmanship and material, subject to the following conditions.
1. Carry-in service. Small appliances are repaired in our service centres and are not
collected from the customers home. Faulty units must be delivered to the purchasing
dealer or to the nearest Company Service Centre for warranty repairs.
2. Vitreous enamelware, fuses and lamps are specifically excluded from these warranties. It
is an express condition of these warranties that the purchaser takes due care and
attention in the use and maintenance of the appliance. Abuse, misuse in conflict with
operating instructions, connection to incorrect voltages and subjection to commercial use
shall release the Company from its obligations.
3.This warranty shall become void and cease to operate if the appliance is dismantled by,
or any repairs to the appliance are effected by any persons not duly authorised by the
Company, or if substitute parts not approved by the Company are used in the appliance,
or if the serial number of the appliance is removed.
4. The Company shall not be responsible for damages resulting from fire, flood, civil
disturbances or any Act of God. The Company shall not, in terms of these warranties be
responsible nor held liable for any consequential loss or damage of any kind caused by or
due to the failure or malfunction of the appliance. The Company shall not be responsible
for damages caused by insect and/or animal infestation.
5.The Company shall not be responsible for transportation or other costs other than those
incurred within the provisions of Point 1 of this Certificate.
6. For warranties in the Republic of South Africa and Sub-Saharan Africa, please
contact the customer care line. Please refer to the previous page for respective
South African branches and Sub-Saharan Africa branches.
7. Where service is requested under warranty and no fault or defect can be found by the
Company, all costs incurred will be for the purchaser's account.
8. This Certificate as well as your invoice will serve as proof of purchase. For the purpose
of warranty, it will be essential to produce this Certificate and invoice. Failure to do so, will
render the purchaser liable for service costs.
KEEP THIS CERTIFICATE AND SALES INVOICE AS PROOF OF
PURCHASE FOR WARRANTY PURPOSES.
