SPECIFICATION LINE: SELF-CONTAINED HINGED GLASS DOOR PASS-THRU REFRIGERATOR
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
Specification Line
Self-Contained Hinged Glass Door Pass-Thru Refrigerator
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date____________________
SARPT1-G
SPECIFICATIONS
Exterior: Cabinet exterior sides, front and shroud
shall be 22-gauge, corrosion resistant stainless steel.
Upper shroud shall be hinged, with stay-open feature
to provide easy access to refrigeration system.
Interior: Cabinet interior shall be 22-gauge, corrosion
resistant stainless steel (SS models) or heavy gauge
aluminum (SA models). Bottom and top surfaces are
die stamped to provide radius corners and recessed
floor. Three chrome plated wire shelves are provided
per section. Shelves rest on clips which are adjustable
in 1” increments on stainless steel pilasters affixed to
the cabinet interior. Pilasters are removable without
tools for cleaning. Interior light mounted to the
interior ceiling is controlled automatically through
a switch mounted in the hinge assembly to protect
against breakage. Door openings are protected with
heavy gauge stainless steel breaker strips. An air duct
is mounted to the ceiling assuring low velocity, even air
movement throughout the cabinet interior.
Doors: Double paned tempered thermopane glass.
Constructed with a combination of extruded aluminum
and PVC. Each door has two edgemount, self-closing, cam
lift style hinges. Doors can be removed from the cabinet
without the use of tools. Door handle is continuous along
vertical dimension of the door. Door gaskets are magnetic
and mount to the door, snapping in place and removable
with out tools. Keyed door lock is mounted to the door.
Lock is mounted to the door. Lock engages into a heavy
duty strike mounted to the cabinet face.
Refrigeration system: All components are mounted
to the exterior cabinet ceiling, outside the food zone and
are assembled as one piece and can be removed as one
piece. Environmentally friendly R404A refrigerant is used.
System has the capability of maintaining between 27˚F and
40˚F in heavy use food service operations. Refrigerant
is metered using a highly responsive thermostatic
expansion valve. System is controlled using Delfield’s
ACT-Advanced Control Technology electronic temperature
control, which provides improved pull down times,
reducing compressor cycling and longer compressor life
with lower energy consumption.
Control system uses adaptive defrost to assure
evaporator coil is free of ice and operating at optimum
efficiency. Evaporator condensate is eliminated using an
energy efficient hot gas system.
Electrical: Standard electrical connections shall be 115V,
60Hz, single phase. A 10’ cord and plug is supplied
attached to a junction box mounted on the exterior top
of the cabinet.
MODELS
 SSRPT1-G 1 section stainless interior
full glass door
 SSRPT1-GH 1 section stainless interior
half glass door
 SARPT1-G 1 section aluminum interior
full glass door
 SARPT1-GH 1 section aluminum interior
half glass door
 SSRPT2-G 2 section stainless interior
full glass door
 SSRPT2-GH 2 section stainless interior
half glass door
 SARPT2-G 2 section aluminum interior
full glass door
 SARPT2-GH 2 section aluminum interior
half glass door
 SSRPT3R-G 3 section stainless interior
full glass door
 SSRPT3R-GH 3 section stainless interior
half glass door
 SARPT3R-G 3 section aluminum interior
full glass door
 SARPT3R-GH 3 section aluminum interior
half glass door
STANDARD FEATURES
• Stainless steel interior and exterior (SS)
• Stainless steel exterior, aluminum interior (SA)
• Built in door locks with heavy duty strikes
• Exterior digital thermometer with high/low
temperature alarm
• Easy to use electronic control
• Three chrome plated wire shelves per section
• 10’ attached cord and plug standard on 115V units
• 6” adjustable stainless steel legs
• Stainless steel breaker strips
• Energy savings door heater switch
• Two year parts & labor warranty
OPTIONS AND ACCESSORIES
 Security package
 Flourescent light
 Additional shelves
 Tray slides
 Stainless steel back
 Laminate on front, sides and back
 Bottom mount electrical
 Stainless steel banking strip
 Heat shield end
 Stainless steel kick plate
 Laminate kick plate
 High humidity evaporator coil
 4” stainless steel utility base
 Alarm control display
 220-50-1 electrical
 220-60-1 electrical

Specification Line: Self-contained hinged glass door pass-thru refrigerator
Model #__________
CSI Section 11400
Printed in the USA.
03/07
DSSSRPTG
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice.
Mechanical Data
MODEL
NUMBER VOLTAGE AMPS STORAGE SHELVES SQ.FT.
NO. OF
SHELVES
UNIT
H.P.
BTU/HR
SYSTEM CAP SHIP WEIGHT NEMA PLUG
SSRPT1-G, SARPT1-G
SSRPT1-GH, SARPT1-GH 115 7.0 26.64 12.81 3 1/4 2488 455 5/20P
SSRPT2-G, SARPT2-G
SSRPT2-GH, SARPT2-GH 115 11.2 55.42 27.54 6 1/2 4046 700 5-15P
SSRPT3R-G, SARPT3R-G
SSRPT3R-GH, SARPT3R-GH 115/208-230 12.4 84.19 42.27 9 3/4 7569 972 N/A
END SECTION VIEW
ALL MODELS
ELEVATION VIEW
SSRPT1-G, SARPT1-G
ELEVATION VIEW
SSRPT1-GH, SARPT1-GH
ELEVATION VIEW
SSRPT2-G, SARPT2-G
ELEVATION VIEW
SSRPT2-GH, SARPT2-GH
PLAN VIEW
SSRPT1-G, SARPT1-G
PLAN VIEW
SSRPT1-GH, SARPT1-GH PLAN VIEW
SSRPT2-G, SARPT2-G
PLAN VIEW
SSRPT2-GH, SARPT2-GH
PLAN VIEW
SSRPT3R-G, SARPT3R-G PLAN VIEW
SSRPT3R-GH, SARPT3R-GH
ELEVATION VIEW
SSRPT3R-G, SARPT3R-G
ELEVATION VIEW
SSRPT3R-GH, SARPT3R-GH










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%










30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).% 30%#)&)#!4)/.,).%
* R= REMOTE UNIT
