402
Self-contained compact work top refrigerators
Short form specications
Exterior top shall be one-piece, 22-gauge stainless steel with front edge turned down
to form nosing and rear edge turned up to form a 2" (5.1 cm) thick by 4" (10.2 cm)
high backsplash.
Exterior back and bottom shall be one-piece 24-gauge galvanized metal. Exterior
ends shall be 22-gauge stainless steel.
Base interior shall be one-piece thermoformed ABS plastic material, with integral
shelf supports. Base shall be fully insulated with high-density foamed-in-place poly-
urethane.
Doors shall have a 22-gauge stainless steel exterior, with a thermoformed ABS plas-
tic interior liner, and shall be fully insulated with foamed-in-place polyurethane. Door
handles shall be black, recessed and shall extend the full length of the top of the door.
Cabinet shall have (2) adjustable epoxy-coated wire shelves installed.
Refrigeration system shall use HFC-404A refrigerant. Compressor shall be å h.p.,
with condenser coil and hot gas condensate evaporator mounted on rear of cabinet.
Evaporator coil and temperature control shall be mounted on the interior rear wall
of the cabinet. Refrigerant ow shall be controlled by a capillary tube. Cabinet shall
maintain 36°F to 40°F (2°C to 4°C) interior cabinet temperature.
Electrical connections shall be 115 volt, 60 Hertz, single phase. Unit shall have a 7'
(2.1 m) long electrical cord and NEMA 5-15P plug. Cord and plug shall be located on
rear of cabinet, centered left to right, 16" (40.6 cm) above oor.
Equipment shall be mounted on 6" (15.2 cm) high metal legs with black enamel
nish.
Optional accessories & modications
Stainless steel back
Plastic laminate on front
Additional wire shelves
Stainless steel single-tier overshelf
3.5" (8.9 cm) diameter casters
5" (12.7 cm) diameter casters
Door lock
Full-size composite-type cutting top
220 volt, 50 Hertz electrical system
Model 402
®
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.

MODEL
NUMBER
NUMBER
OF
SHELVES
SHELF
AREA
STORAGE
CAPACITY*
SHIP
WEIGHT
HORSE-
POWER
VOLTS/
HERTZ/
PHASE AMPS
NEMA
PLUG
402 2
7.2 ft
0.67 m
5.7 ft
0.16 m
176 lbs
80 kg 115/60/1 5.0 5-15P
1/5
Self-contained compact work top refrigerators
402
AutoCAD® library reference numbers are shown below the model numbers.
DOOR CLEARANCE DETAIL
MODEL 402
24.75"
62.9 cm
STANDARD DOOR HINGING IS ON RIGHT
HINGING MAY BE REVERSED AT INSTALLATION
INSTALLATION NOTE:
Refrigeration system is designed so that
air will ow under the unit, through the
compressor area, and out the top rear
of the unit. Any restriction to this air ow
path will void the warranties.
ELEVATION VIEW RIGHT END VIEW
MODEL 402 MODEL 402
27.25"
69.2 cm
28.50"
72.4 cm
PLAN VIEW
MODEL 402
39.50"
100.3 cm
4.00"
10.2 cm
28.50"
72.4 cm
2.00"
5.1 cm
35.50"
90.2 cm
6.00"
15.2 cm
19.50"
49.5 cm
17.00"
43.2 cm
BULLET FEET CAN
ADJUST UPWARDS ONLY,
UP TO+1.00"/2.5 cm
1.00"/2.5 cm
RUBBER
BUMPER
INTERIOR CLEAR DIMENSION,
LEFT TO RIGHT: 21.25"/54.0 cm
A
B
C
D
E
SHELF SUPPORT
SPACING
A = 7.50"/19.1 cm
B = 4.00"/10.2 cm
C = 3.75"/9.5 cm
D = 2.75"/7.0 cm
E = 6.00"/15.2 cm
REF’G
27.25"
69.2 cm
39.50"
100.3 cm
